REINER 940
The LED indicator marks the selected setting and flashes in case of warnings.
On the setting functions (see “Online Help of the PCset graphic software”).
Note: Close the shutter lever before making any settings through the selector wheel!
fTo avoid malfunctions align the settings precisely with the LED indicator!
fTo activate Bluetooth, turn the setting wheel
1
to position Online/Bluetooth
(see “Online Help of the PCset graphic software”).
Set Wheel
Clean
Online/Bluetooth
Functions
Print image 3
Print image 4
Print image 2
Print image 1
LED indicator
O
1
Set wheel
2
LED indicator
3
Mounting Flange
4
Micro-USB socket
5
Battery compartment
6
Shutter Lever Lock
7
Closure lever
8
Print Trigger
9
Sensor Roller
Operating Elements
10
Positioning Guide
11
Nozzle cover
12
Cartridge Cover
13
Print cartridge
14
Cartridge Cover Relase Key
15
Contact print cartridge
16
Protective Nozzle Seal
17
Sealing tip
18
Nozzles

8
REINER 940
Important Notes
Before commissioning of the REINER 940, always read the operating instructions and in
particular the safety notes with care. This prevents mistakes in handling of the marking device
and connected safety risks to keep you safe and avoid damage to the device.
For detailed operating instructions and further information, see the online help of the
PCset graphic software, or the enclosed USB memory stick.
Safety Notes
WARNING Possible blinding in case of contact between ink and eyes.
fNever hold the REINER 940 with its nozzles pointing at the face of persons!
CAUTION Possible tripping and damage to the device from device lines placed freely in
the room.
fPlace the device lines so that they do not pose any danger source!
Health risks if ink is swallowed.
fDon’t swallow!
fKeep cartridge out of the reach of children!
NOTICE Damage to the device due to improper transport.
fOnly use packaging that provides protection from impact and shock to the device!
Damage to the device by moisture.
fBefore commissioning, wait until device has reached room temperature and is
completely dry!
Safety Notes on Rechargeable Batteries
Rechargeable batteries are subject to wear. A longer service life than six months cannot be
warranted.
WARNING Possible explosion at contact with fire.
fNever throw rechargeable batteries into fire.
CAUTION Injuries from destruction of rechargeable battery jacket when using unsuit-
able rechargeable batteries or non-rechargeable batteries.
fUse only rechargeable batteries intended for the device!

9
REINER 940
Disposal
Defective or flat batteries
Flat batteries of rechargeable batteries must not be disposed of in the household
waste.
Electrical and electronic waste devices
Waste devices must not be disposed of in the conventional household waste. They
must be returned to a special collection point for recycling of electrical and electro-
nic devices.
1. Preparation and Taking into Operation
1.1. Commissioning
The rechargeable batteries must be charged completely before the first use.
The charging time is approx. 3 hours. The rechargeable batteries are charged when the
green charge display
2
goes out.
Inserting rechargeable batteries Fig. B
Always replace all rechargeable batteries at once. Date, time and counter reading of the
numbering machine are retained when the rechargeable batteries are removed.
fOpen the rechargeable battery compartment
5
in the direction of the arrow.
Be careful to insert the rechargeable batteries the correct way round (+/- polarity).
fClose the rechargeable battery compartment
5
.
Charge batteries Fig. A
Only connect the device to the PC when the PCset graphic-Software was installed.
Installation of the PCset graphic software installs the required USB drivers. The USB
drivers are automatically recognised and loaded when the device is connected to the
computer. The device driver installation fails if the device is connected without the
PCset graphic software being installed.
Charging at a USB hub without dedicated power supply is not possible.
fConnect Micro-USB of the device
4
to the mains unit with the USB cable and connect the.
Green charging indicator
2
lights up.

10
REINER 940
1.2. Inserting Printing Cartridge
Inserting printing cartridge Fig. A+ C+ E
Depending on ink type used, dierent Protective Nozzle Seals are required.
Use sealing of the enclosed printing cartridge.
fTurn the setting wheel
1
to position O.
fPush the cartridge cover release key
14
downwards, to open cartridge cover
12
.
fTake the cartridge
13
out of its packaging and remove protective film from the jet
18
.
fInsert the cartridge
13
.
fClose the cartridge cover
12
.
1.3. Install PCset graphic Software
Installation is only possible with administrator rights on the computer.
fInsert PCset graphic USB memory stick into the drive.
fIf the installation programme does not start up automatically, start the file “setup.exe”.
fObserve the installation programme instructions.
1.4. Firmware update
The most up to date firmware for the REINER 940 can be downloaded from the website www.
reiner.de.
1.5. Recognising and Removing Interferences
For more information, see the online help of the PCset graphic software, or the enclosed
memory USB.
All rights reserved. Translation, reprint and other reproduction of these operating instruc-
tions, even in parts and no matter the form, shall require our express written consent. We
reserve the right to make content changes to these operating instructions without notice.

Technical modifications reserved | PC-940088-000-F | 07.2019
