REITEL SUPERSTEAM User manual

Operating Instructions
LABORATORY EQUIPMENT IN
STAINLESS STEEL
SUPERSTEAM with Luer-Lock Adaptor
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: [phone] | Fax: [phone]
www.reitel.com | [email protected]

II
Dear Customer!
The SUPERSTEAM is a steam cleaner with 6 bar steam pressure, including dry and wet
steam or hot water jet cleaning and wax extraction function. With this SUPERSTEAM you’re
able to clean and degrease objects without chemical additives.
Prior to installation of the device operating instructions and especially the safety instructions
must be read and followed by all personnel who use this device.
After having unpacked the device, please check carefully whether transportation damages of
any kind have occurred. If that is the case, the carrier or manufacturer must be notified within
3 days. The company will not be responsible for any damages found after that.
These operating instructions must be read and followed by all personnel who use this device.
To ensure quick access we recommend to keep it at a safe place near the device. In case of
loss it can be ordered at a nominal fee from the manufacturer.

III
INDEX
TECHNICAL DESCRIPTION......................................................................................... 4
BASIC EQUIPMENT....................................................................................................... 4
SPECIAL ACCESSORIES................................................................................................ 4
OPERATING ELEMENTS................................................................................................ 5
TECHNICAL DATA......................................................................................................... 7
SAFETY NOTES........................................................................................................... 7
GENERAL SAFETY NOTES ............................................................................................ 7
SPECIFIC SAFETY INSTRUCTIONS ................................................................................. 8
INSTALLATION ............................................................................................................ 9
OPERATION................................................................................................................10
CHRONOLOGICAL RUN OF OPERATION..........................................................................10
DECALCIFYING THE DEVICE WHEN NOT USING DISTILLED WATER ....................................11
TROUBLESHOOTING .................................................................................................12
MAINTENANCE...........................................................................................................13
WARRANTY.................................................................................................................14
DISPOSAL REGULATIONS ........................................................................................17
SPARE PARTS LIST ...................................................................................................18
EC CONFORMITY DECLARATION.............................................................................19

4
Technical Description
Basic Equipment
•Steam Cleaner SUPERSTEAM
•Luer-Lock set
- Steam nozzle 2,5 mm
- Tool for nozzle change
Special Accessories
•Order-No.: 20116000 Steam nozzle 1,5 mm
•Order-No.: 20119000 Tool for nozzle change
•Order-No.: 20112000 Steam brush for external cleaning
•Order-No.: 20113000 Steam brush for internal cleaning, 25 cm, Ø 4 mm
•Order-No.: 20114000 Steam brush for internal cleaning, 50 cm, Ø 4 mm
•Order-No.: 20107000 Wall shelf
•Order-No.: 20121000 Decalcifying pump (manual operation)
•Order-No.: 90410000 REITEL descaler
•Order-No.: 10106000 BIOSTEAM CENTER with extraction
•Order-No.: 10205000 Water softening device DELIMER COMFORT

5
Operating Elements
1 Flow rate control unit of media taken out
2 Main switch
3 Steam gun holder
4 Humidity control
5 Heating control
6 Tank cap
7 Lamp „water deficiency“
8 Gauge
9 Steam gun’s hose
10 Safety valve (if necessary with baffle)
11 Temperature limiter
12 Device’s fuse
13 Compressed air connection „air“
14 Steam gun incl. hose
15 Contact screw
16 Steam gun switch „compressed air“
17 Steam gun switch „dry damp“
18 Steam gun switch „hot water“
19 Luer-Lock adaptor
20 Steam brush
21 Tool for quick nozzle change
22 Steam nozzle 2,5 mm
23 Steam nozzle 1,5 mm (option)

6
Fig.: Device view
18 17 16
Fig.: Steam gun
1
4
5
6
14
3
15
2
7
8
9
10
11
12
13
Fig.: Rear view
Fig.: Safety valve
19
Fig.: Luer-Lock Set
20
21
22
23

7
Technical Data
Line voltage
230 V/50–60 Hz
Current consumption
2.200 W
Height / width / depth
420 / 300 / 350 mm
Weight
14 kg
Pressure
6 bar variabel
Compressed air connection
max. 6 bar
Temperature
160 °C
Volume
5 l
Control
Druck über Temperatur
Moisture & quantity
stufenlos regelbar
Filling
manuell
Sound level
≤70 dB(A)
Housing
Edelstahl
Order-No.:
14201000
Made in Germany (Subject to modifications)
Safety Notes
General Safety Notes
•All equipment undergoes final inspection and testing before leaving our factory. However,
if equipment is damaged during shipping or through any other circumstances, it must not
be used in service. Please check the device regularly for damages. Damaged parts
should be replaced immediately.
•All power/air/water/gas sources should be rated for the demands of the device as listed in
the technical data sheets. Maximum ratings must not be exceeded. All VDE (Verein
Deutscher Elektro-Ingenieure) standards should be followed. Equipment should be
grounded according to standards.
•Adherence to valid regulations regarding necessary checks (e.g. according to Accident
Prevention & Insurance or electrical equipment ) is exclusively taken over by the
buyer/user of this product.
•This device has been designated to be used only for its intended purpose. All other
applications must be prohibited for safety reasons as otherwise the manufacturer’s
warranty expires.
•The device should be set-up in a clean, well-ventilated room, if necessary under a hood.
•Supporting surfaces should be straight, flat and adequately stable.
•Don’t place anything on top of the machine.
•To avoid injury, appropriate protection should be worn (e.g. gloves, safety glasses, safety
shoes, hearing protection etc.)

8
•If the machine is defective or working improperly it must be taken out of service. In case
of further use of the machine the owner will be held responsible for any consequential
damage.
•To prevent accidents from water, fire or explosion, all power/air/water/gas sources should
be turned off after working hours and during breaks, and secured against unauthorized
access.
•When carrying out maintenance works or repairs or when opening the device always turn
off the main power switch and unplug the whole unit.
•Repairs should be carried out only by the manufacturer or by qualified and certified
personnel appointed according to chapter 7 –warranty.
•In case of leaking water out of housing or tank shut down device and call service.
•Keep the device clean and dry.
•Check all hose joints for tightness, if necessary tighten hose clamps.
Specific Safety Instructions
Attention:
•Keep a minimum safe distance of 100 cm from the safety valve (back) to traffic areas
or workplaces –Danger of scalding.
•Grounding yourself, touch the steam gun handle (14) and the contact screw (15).
Alternatively lay your hand flat on the steam cleaner’s housing. (Gases or fluids flowing
through pipes generate static electricity. For safety reasons static electricity is
discharged during evaporation by the contact screw at the steam gun’s handle. If the
user gets an electric shock when touching the device or the steam gun the person was
exposed to static electricity before. The combination of floor covering and shoe soles is
often the reason, falling outside the sphere of influence of the steam cleaner’s
manufacturer)
•We recommend to fill this device only with decalcified or distilled water (damage due to
limescale deposits is not covered by warranty). Decalcification is depending on water
hardness: every one or two weeks. It’s not necessary when always using distilled water
(we recommend to use our water softening device DELIMER –see „Special
accessories“).
•The steam jet is only to be aimed at objects to be cleaned, never at living beings.
•Only clean appropriate objects, if necessary first samples or test on an inconspicuous
area.
•The tank cap (6) may only be opened when the device isn’t under pressure.

9
•The device must not be filled if the heater is hot and the tank is empty (danger of
scalding).
•The device should be filled up every morning when it’s in a cold state, protecting the heat
aggregates as well as the gaskets. An unwanted interruption of operation is also avoided.
•In case of leaking hot water out of the housing or tank further use of the device is
prohibited (see chapter 5: Troubleshooting).
•Gases or fluids flowing thorugh closed tubes or hoses generate static electricity. It should
be continuously discharged. If static electricity is noticeable before using the steam gun,
the user was exposed to static electricity before (carpets, shoes).
•Keep a safe distance.
Installation
The equipment delivered is ready for immediate use. The sealed plug can be connected
directly to the mains supply 230 V/16 A. For installation please refer to chapter 2.

10
Operation
Chronological run of operation
1. Use the device only when it’s filled with water. (Pay attention to safety notes in chapter
2!) In order to avoid an unintended dry run, a daily filling in the morning is recommended.
To do this, turn the heating control (5) completely to the left (if necessary ventilate tank by
activating steam gun). Fill the device only in a cold state. Open the tank cap (6) and fill in
distilled or decalcified water up to the edge (a filling funnel is recommended). Close the
tank cap (6) and hand tighten it.
2. Attach the required steam nozzle or brush (20 / 22 / 23) and be sure it is securely
attached during steam cleaning.
3. Turn the device on with the main switch (2). Set heating control (5) to max. Heating will
turn on automatically. After approx. 18 min. full pressure is reached and the lamp goes
out.
4. The maximum steam pressure is adjustable with the regulator (5). (Pressure is only built
up in the upper quadrant of the controller range. Delayed pressure build-up.)
5. For taking out dry steam please activate the hot water key (18).
6. Device needs refilling: Control lamp (7) shines. Refilling (see chapter 4: Notes for the
user, item 1). Control lamp is automatically switched off after refilling.
7. Keep the compressed air connector (13) screwed in while not being used. Do not exceed
max. pressure of 4 bar at the device’s back. For connection remove the plug and screw in
sleeve (included in delivery).
8. For nozzle change use the special tool (21) when the nozzle (22 / 23) is too hot or the
steam brush has been attached too tight. Slide the tool (21) with its round opening over
the steam nozzle or brush (22 / 23), gently press together and detach the nozzle or
brush. When attaching another nozzle or brush be sure it is securely attached during
steam cleaning.
Caution:
The metal nozzles (18 / 19) can become very hot during operation. Therefore please
use the special tool (17) for nozzle change.

11
Decalcifying the device when not using distilled water
1. Turn power switch off (2).
2. Let the device cool itself down and empty it.
3. Fill decalcifier in according to manufacturer’s instructions.
4. Close tank cap (6).
5. Turn power switch on (2). As soon as the pressure starts building up (control by
activating the steam gun switch), turn the control unit (5) down. For decalcifying the
steam valve place the device several times on its left side for a short period and activate
the steam gun switch (18). Then put it in an upright position and leave the decalcifying
product to take effect for some time.
6. Let the device cool down. Let the steam out until pressure is „0“, and empty the tank. For
easy emptying, use the optional decalcifying pump (manual operation).

12
Troubleshooting
Device cannot be switched on.
a. Check fuse of the building.
b. Check device’s fuse
Safety valve (10) opens or water leaks out.
a. Turn the control unit (5) down and call
customer service. ATTENTION: If
used, do not remove cover and do
not close opening.
b. Tank is overfilled →drain off some
water.
Control lamp (7) shines although there’s
enough water in the tank.
Temperature limiter (11) or control unit (5)
might be released →Set control unit to
max and push temperature limiter back in
again after cooling down - for this purpose
remove black protective cap
Tank cap (6) can hardly be opened.
Ventilate tank by activating steam gun
switch „hot water“ (18)
Tank cap (6) untight.
→Replace cap or seal.
No steam.
a. Cold water was refilled and device is
heating up.
b. Device is calcified, blocked valve,
switches or valves defective →Call
customer services.
No steam pressure.
1. Regulator (5) was not set to max.
Pistol drips.
Device might be calcified or the valve
blocked →
Decalcify or use distilled water.
Electric shocks when using the steam gun
Touch the contact screw (15) on steam
gun while jetting (see chapter 2.2
Specific Safety Notes).
High wear of seals.
→Prior to heating up ventilate tank by
activating steam gun switch „hot water“
(18).
Device doesn’t work after turning it on,
main switch (2) doesn’t shine.
No power at the socket →check fuse for
the building.
Device’s fuse has blown.
→Press overcurrent protection
knob/device’s fuse knob (12) in.
Short circuit
Water in housing: shut down the device and
call customer service.
Attention: Water temperature might be up
to 160°C –Danger of scalding!

13
Maintenance
•Regularly check the device’s state. Pay attention to visible damage to housing or power
cord.
•Using hard water we recommend regular decalcification of the device (chapter 4
operating instructions, 4.2 Decalcify device when using non-distilled water).
Note
Clean and protect your device at regular intervals with the REITEL stainless steel care
spray (order -no.: 90405000) to remove lime, plaster and dust as well as other
contaminants from the surface of the equipment and to prevent corrosion. The spray
creates a lasting, water repellent protective film which helps keep the equipment
clean.

14
Warranty
We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven
date of purchase. This warranty covers all defects traceable to materials, design or
workmanship. The following warranty regulations are applicable:
Within the warranty period Reitel Feinwerktechnik GmbH or an authorised distributor agrees
at its sole option, to perform repair or replace this product at no charge covering all defects
traceable to materials, design or workmanship. Warranty only applies to appropriate use and
regular maintenance of this product according to the operating instructions. Claims under
warranty are restricted to complementary performance. Additional claims, especially claims
for indemnifications, are not covered by this warranty.
1.
Warranty claims have to be addressed to the distributor the product was purchased from or
directly to our service department.
Contact:
REITEL Feinwerktechnik GmbH
Senfdamm 20
49152 Bad Essen
Germany
Phone: [phone] (Service Department)
Phone: [phone] (Reception)
Fax-No: [phone]
2.
In case of warranty claim application the sales receipt or your purchase invoice showing the
date of purchase of the product and the serial number must be furnished. Securely pack and
ship the device, freight charges prepaid, at your own risk to us, along with a report describing
the defect. We reserve the right to decline warranty if this information has been removed or
modified after purchase of the product or if they are not included in case of warranty claims.
3.
Warranty repairs have to performed by REITEL Feinwerktechnik GmbH or by authorized
distributors. Repairs performed by non-authorized companies will void the claim for refund
since damages to the product resulting hereof are not covered by warranty.
4.

15
If the unit sent in for repair or replacement is still under the original warranty then warranty is
to the end of the original 1 year warranty.
5.
If the unit is destined to be operated in another country than originally intended and
manufactured for, modifications to the product might be necessary to comply to special
technical and /or safety standards of that specific country. Such modifications are no defects
traceable to materials, design or workmanship. and are therefore expressly excluded from
warranty claims.
Modification costs or damages arising from operation of the product under deviating
conditions are not covered by warranty.
6.
Exclusions from warranty:
−Service and maintenance work as well as repair and replacement of consumables
according to our consumables‘ list
−Transportation cost of the machine or installation and dismounting expenses incurred
−Damages due to use of the product other than for its intended purpose
−Damages due to faulty installation or insufficient maintenance of the product (e.g.
decalcification)
−Damages due to natural disaster e.g. lightning, water, fire, act of nature beyond
control, war, inadequate line voltage, insufficient ventilation, no decalcification,
insufficient care and cleaning or non-adherence to operation and maintenance
instructions according to the accompanying operation guide.
−Damage due to use of the product other than in accordance with the instructions
provided by REITEL Feinwerktechnik GmH;
−The warranty does not cover the cost of removal and replacement of parts and
accessories, unless supplied as original equipment by REITEL Feinwerktechnik GmH
−All kind of damages occurred not directly at the device as well as consequential
damages (e.g. damages to furniture due to a lack of water, downtime of the machine,
material, lost working hours, wages and other consequential damages).
This warranty shall be rendered null and void if:
−the product has been subject to any modification, repair or replacement other than as
authorized by REITEL Feinwerktechnik GmbH
−the product is continued to be operated despite a functional defect
7.

16
The warranty is device specific and may be claimed, within the warranty period, by any
person who has legally acquired the device.
8.
Consumables are excluded from warranty. Spare parts are subject to a warranty coverage of
6 months against all effects traceable to materials, design or workmanship according to
these warranty regulations.
9.
Legal default claims on the part of the purchaser remain unaffected by this warranty.
10.
We reserve the right to charge a fee if repair of the device is rejected and the device is
destined to be sent back unrepaired.
11.
Please note:
Upon repair or replacement of this unit, personal data and settings might get lost or
damaged. We don’t accept liability for all kind of data loss. The customer is advised to
backup essential programs and data before sending for service.
12.
This warranty shall be interpreted in accordance with German law to the exclusion of UN
sales law. Place of jurisdiction is our business location.
13.
If any provisions of this warranty are judged to be illegal or unenforceable, the continuation in
full force and effect of the remaining provisions will not be prejudiced. The provisions of this
warranty judged to be illegal or unenforceable shall be construed so as to give effect to the
intent manifested by the provision by the provision held invalid, illegal or unenforceable and
to give effect to section 13 hereof.
14.
Should you need to borrow a device while your device is being repaired, please contact
Messrs. REITEL or your distributor. These loans are a service for which availability cannot
necessarily be guaranteed. After the warranty period, a free may be charged for loan
equipment as well as for shipping and packaging.

17
Disposal Regulations
According to valid laws our devices are properly disposed of according to B2B-
regulations for proper disposal. Pls. contact your local dealer for additional
information.

18
Spare Parts List
Best.Nr.
neu 2018
SUPERSTEAM
Ersatzteilliste / Spare parts list
Stck
Qty.
ME
Unit
E6065870
Dampfpistole (schwarz) bestehend aus Griffstück, Luerlock + 2,5mm
Düse, Werkzeug, Taster, Federn, Tülle
Steam gun (black), completed
1
Stck
piece
E6065880
Dampfpistole (Luerlock) kpl. mit Schlauchpaket, ohne Klammer.
Steam gun (luerlock) cpl. with hose package
1
Stck
piece
20110000
Dampfpistole: Mehrpreis für Schlauchlänge 2,30 m
Extra hose extension - 2,30m
1
Stck
piece
20118000
Luerlock Dampfdüsenbaugruppe Tronada/Supersteam, inkl.
1,5/2,5/Werkzeug
1
Bgr
assy
E7000800
Dichtung für Tankverschluß 5/PACK
Tank cap seal 5 pcs./pack
5
Pack
E6226100
Einfüllschale inclusive Dichtring
Funnel incl. sealing ring
1
Stck
piece
E6227700
Heizkörper inclusive Druckplatte und Dichtung
Heating element incl. flange and seal
1
Stck
piece
E6060400
Klammer für Pistole inclusive Halter
Clip for steam gun incl. Holder
1
Stck
piece
E7209700
Pistolentaster für schwarze Pistole
Steam gun switch for black steam gun
1
Stck
piece
20121000
Pumpe für Entkalkung, Handbetrieb
Pump for decalcification, manual operation
1
Stck
piece
E6064800
Schalter beleuchtet grün
Green illuminated switch
1
Stck
piece
E7413400
Signallampe rot, rund
Round red signal lamp
1
Stck
piece
E6063000
Tankverschluß ohne Sicherheitsventil
Tank cap without safety valve
1
Stck
piece
E7209800
Taster für Luftentnahme (schwarze Pistole)
Push button for taking out air (black steam gun)
1
Stck
piece

19
EC Conformity Declaration

Approved manufacturing according to Quality Management ISO 9001:2015 incorporating
established process standards.
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: [phone] | Fax: [phone]
www.reitel.com | [email protected]
062019
