REITEL POLIRET TWIN User manual

Operating Instructions
LABORATORY EQUIPMENT IN
STAINLESS STEEL
POLIRET TWIN
Fig.: with optional speed control
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone.: [phone] | Fax: [phone]
www.reitel.com | [email protected]

II
Dear Customer!
The POLIRET TWIN is a powerful stainless steel polishing unit with two spindles and two
maintenance-free motors. Separate stainless steel spindle speed control. The comfortable
housing width enables working on both sides. Variable speed control 270 - 4.500 rpm –thus
speed is perfectly adapted to your requirements. The powerful brushless motors are
maintenance free and extremely durable. The POLIRET TWIN offers economic and precise
grinding, polishing, cleaning and brushing of metal and plastic material The integrated and
silent suction absorbs dust directly at the spindle. The textile filter bags are washable and
reusable. Closing one ventilation flap maximum suction power is achieved on the other side.
Since the exhaust air outlet is located on top of the housing the device can be placed directly
at a wall without losing suction power. Connection to an external central suction is not
provided, however it’s available on request.
Any other use or use beyond this is deemed improper. For resulting damage the
user/operator of this device is solely responsible.
Prior to installation of the device operating instructions and especially the safety instructions
must be read and followed by all personnel who use this device.
After having unpacked the device, please check carefully whether transportation damages of
any kind have occurred. If that is the case, the carrier or manufacturer must be notified within
3 days. The company will not be responsible for any damages found after that.
These operating instructions must be read and followed by all personnel who use this device.
To ensure quick access we recommend to keep it at a safe place near the device. In case of
loss it can be ordered from the manufacturer.
This document is protected by the copyright law. Passing on or duplication of this document
or extracts thereof, evaluation and communication of its contents are not authorised.

III
INDEX
TECHNICAL DESCRIPTION......................................................................................... 4
BASIC EQUIPMENT....................................................................................................... 4
SPECIAL ACCESSORIES................................................................................................ 4
DEVICE COMPONENTS ................................................................................................. 5
TECHNICAL DATA......................................................................................................... 7
SAFETY NOTES........................................................................................................... 8
GENERAL SAFETY NOTES ............................................................................................ 8
SPECIFIC SAFETY INSTRUCTIONS ................................................................................. 9
INSTALLATION ...........................................................................................................10
INSTALLATION.............................................................................................................10
TOOL ASSEMBLY ........................................................................................................10
OPERATION................................................................................................................10
CHRONOLOGICAL RUN OF OPERATION..........................................................................10
EMERGENCY STOP BUTTON........................................................................................10
FILTER REPLACEMENT................................................................................................11
LAMP REPLACEMENT ..................................................................................................11
TROUBLESHOOTING .................................................................................................12
MAINTENANCE...........................................................................................................13
WARRANTY.................................................................................................................14
DISPOSAL REGULATIONS ........................................................................................17
SPARE PARTS LIST ...................................................................................................18
EC CONFORMITY DECLARATION.............................................................................19

4
Technical Description
Basic Equipment
•POLIRET TWIN polishing unit
•Right and left polishing spindle
•2 filter bags
Special Accessories
•Order-No. 24800000 Vario–lifting table
•Order-No. 22603000 Workholding fixture for polishing and grinding tools
´ incl. drill chuck
•Order-No. 22702000 Filter bag
•Order-No.: 22604000 Speed-Display

5
Device Components
1 Left locking screw
2 Left ventilation flap open/shut
3 Speed control left polishing motor
4 Speed control right polishing motor
5 Left safety panel
6 Left polishing spindle
7 Switch left polishing motor
8 Switch right polishing motor
9 Right locking screw
10 Right ventilation flap open/shut
11 Emergency stop button
12 Suction switch
13 Power switch
14 Right safety panel
15 Right polishing spindle
16 Cover
17 Device’s fuse
18 Main plug
19 Lamp
20 Motor shaft sealings
21 Polishing trough
22 Filter bags
23 Holding rings
24 Filter neck
25 Air sheet

6
1
2
3
5
14
21
9
19
20
16
17
18
7
6
10
13
12
11
15
22
4
8
Device view
Lateral view
Interior of the unit
23
24
Air sheet
25

7
Technical Data
Line voltage
230 V/50–60 Hz
Power consumption motor
2x370 W
Power consumption suction
400 W
Height/width/depth
500+100/730/560 mm
Weight
60 kg
Variable speed
270 –4.500 rpm
Suction
800 m³/h
Sound level
≤70 dB(A)
Housing
stainless steel
Order-No.:
12703000
Made in Germany (Subject to modifications)

8
Safety Notes
General Safety Notes
•All equipment undergoes final inspection and testing before leaving our factory. However,
if equipment is damaged during shipping or through any other circumstances, it must not
be used in service. Please check the device regularly for damages. Damaged parts
should be replaced immediately.
•All power/air/water/gas sources should be rated for the demands of the device as listed in
the technical data sheets. Maximum ratings must not be exceeded. All VDE (Verein
Deutscher Elektro-Ingenieure) standards should be followed. Equipment should be
grounded according to standards.
•Adherence to valid regulations regarding necessary checks (e.g. according to Accident
Prevention & Insurance or electrical equipment) is exclusively taken over by the
buyer/user of this product.
•This device has been designated to be used only for its intended purpose. All other
applications must be prohibited for safety reasons as otherwise the manufacturer’s
warranty expires.
•The device should be set-up in a clean, well-ventilated room, if necessary under a hood.
•Supporting surfaces should be straight, flat and adequately stable.
•Don’t place anything on top of the machine.
•To avoid injury, appropriate protection should be worn (e.g. gloves, safety glasses, safety
shoes, hearing protection etc.)
•If the machine is defective or working improperly it must be taken out of service. In case
of further use of the machine the owner will be held responsible for any consequential
damage.
•To prevent accidents from water, fire or explosion, all power/air/water/gas sources should
be turned off after working hours and during breaks, and secured against unauthorized
access.
•When carrying out maintenance works or repairs or when opening the device always turn
off the main power switch and unplug the whole unit.
•Repairs should be carried out only by the manufacturer or by qualified and certified
personnel appointed according to chapter 7 –warranty.
•In case of leaking water out of housing or tank shut down device and call service.
•Check all hose joints for tightness, if necessary fasten clamps.

9
Specific Safety Instructions
Attention:
•Wait for at least 2 min. before unplugging the mains plug for cutting off the device from
the domestic supply line in order to unload the condensers.
•The tool must be securely fastened to the spindle.
Danger of injury!
•Operation at too high motor speed may lead to burns!
•Keep the housing dry and clean.
•Tools and lamps may only be changed when the spindle stands still and the whole unit is
unplugged.
•Fold the protective panel down and wear protective glasses.
•Only use appropriate and no unbalanced tools. Make sure all tools are fastened securely.
•Switch suction on.
•Never touch the running machine.
•Always follow the instructions of the tool’s manufacturer (e.g. max. speed, recommended
material).
•Only use appropriate material for polishing. Follow the instructions provided by polishing
and grinding tool’s manufacturer, especially regarding health protection.
•Always wear clothing which is tight at the forearms and hands. Avoid loose hair and
jewels which could get into the spindle or tools.
•Only use clean and disinfected material with the machine.
•In case of danger press emergency stop button (11). Prior to releasing the emergency
stop button, switch off power switch (13) and both motor switches (7) and (8). To release
the emergency stop button, turn it to the right (see chapter 4.2).
•Hold the object to be polished tight. Danger of injury from flying particles and danger of
damage to the workpiece.

10
Installation
The equipment is delivered ready for immediate use. The sealed plug can be connected
directly to the mains supply 230 V/16 A. For installation please refer to chapter 2.
Installation
For extract air and filter change save a minimum space of 20 cm above the device. Connect
to the power supply.
Tool Assembly
1. Slide the polishing spindles (6) and (15) over the axle shaft, fixing them tightly with the
Allen head screw and check correct fit.
2. Fix the required polishing tool on the polishing spindles (6) and (15) and check correct fit.
Right side: right-hand thread.
Left side: left-hand thread.
3. Removing the Allen head screw the polishing spindles (6) and (15) can be removed from
the axle shaft. If necessary use a removal tool.
Operation
Chronological run of operation
1. Turn off the motor switch
2. Turn the main power switch (13) on. The light goes on.
3. Fix the polishing tool. If required fill polishing troughs with polishing paste/pumice or apply
paste/pumice to polishing tools.
4. Switching on one or two polishing motors (7) and/or (8), speed is adjustable with speed
control (3) and (4).
5. Turn the suction on with the suction switch (12). Closing one ventilation flap (2) or (10)
suction power on the other side is increased.
6. Hold the object to be polished tight, slightly pressing it against the rotating polishing tools.
7. When work is completed switch off the polishing motors with switches (7) and (8) and the
power switch (13).
Emergency Stop Button
1. Activating the emergency stop button the device goes into stop mode.
2. Turn off power switch (13) and the two polishing motors (7) and (8).
3. To release emergency stop button, turn to the right.

11
4. After approx. 8 sec. the power switch can be turned on and the two polishing motors can
be activated.
Filter Replacement
1. Unscrew the fixing screws (1) and (9) on top of the device and remove the cover (16).
2. Remove the old filter bags (22) by detaching the holding rings (23) from the filter support
(24).
3. Empty the filter bags, if necessary wash them (machine washable 60⁰C).
4. Put the new filter bag on the filter neck, fasten it with the locking ring and reinsert the
cover.
Lamp Replacement
1. Turn off the main power switch (13) and pull the plug.
2. Remove plexiglas cover.
3. Pull out the lamp.
4. Insert new lamp and check proper fit.
5. Refasten the plexiglas cover.

12
Troubleshooting
Unit does not start.
a. Emergency stop activated. Release it
by turning it to the right (see chapter
4.2).
b. Motor switch was turned on when
starting main switch →turn off motor-
switch and start again
c. wait approx. 2 sec. between main
switch and motor switch to turn on.
d. Power failure →Check the building’s
main fuse. Switch on and off polishing
motors (7) and (8).
e. Check the device’s fuse (17).
Overload protection was released.
Motor becomes overloaded, caused by
continuous use and/or too high contact
pressure →
Turn off the power switch, check the run of
the spindle and turn power switch on again
after a short cooling-down period.
Insufficient suction power
a. Clean filter bag (22), or replace it. The
filter is machine washable at 60⁰C.
Please respect the polishing paste
manufacturer’s instructions.
b. Cover (16) is untight and has to be
fixed.
Insufficient motor power:
a. Polishing brush is too big (max.
diameter: approx. 150 mm).
b. Contact pressure is too high.
Uneasy running / machine is vibrating.
a. Unbalanced polishing disc or polishing
spindle.
b. Detach spindle with Allen head key and
replace it.
c. Replace tool (pay attention to type of
thread).

13
Maintenance
•Regularly check the state of the device. Pay attention to visible damage of the housing or
power cords.
•Regularly clean dirty tools or polishing troughs (21).
•Regularly replace blunt or defective tools.
•Regularly replace or wash the filter bag (22) (see chapter 4.2 filter replacement).

14
Warranty
We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven
date of purchase. This warranty covers all defects traceable to materials, design or
workmanship. The following warranty regulations are applicable:
Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees
at its sole option, to perform repair or replace this product at no charge covering all defects
traceable to materials, design or workmanship. Warranty only applies to appropriate use and
regular maintenance of this product according to the operating instructions. Claims under
warranty are restricted to complementary performance. Additional claims, especially claims
for indemnifications, are not covered by this warranty.
1.
Warranty claims have to be addressed to the distributor the product was purchased from or
directly to our service department.
Contact:
REITEL Feinwerktechnik GmbH
Senfdamm 20
49152 Bad Essen
Germany
Phone: [phone] (Service Department)
Phone: [phone] (Reception)
Fax-No: [phone]
2.
In case of warranty claim application the sales receipt or your purchase invoice showing the
date of purchase of the product and the serial number must be furnished. Securely pack and
ship the device, freight charges prepaid, at your own risk to us, along with a report describing
the defect. We reserve the right to decline warranty if this information has been removed or
modified after purchase of the product or if they are not included in case of warranty claims.
3.
Warranty repairs have to performed by REITEL Feinwerktechnik GmbH or by authorised
distributors. Repairs performed by non-authorised companies will void the claim for refund
since damages to the product resulting hereof are not covered by warranty.
4.

15
If the unit sent in for repair or replacement is still under the original warranty then warranty is
to the end of the original 1 year warranty.
5.
If the unit is destined to be operated in another country than originally intended and
manfactured for, modifications to the product might be necessary to comply to special
technical and /or safety standards of that specific country. Such modifications are no defects
traceable to materials, design or workmanship. and are therefore expressly excluded from
warranty claims.
Modification costs or damages arising from operation of the product under deviating
conditions are not covered by warranty.
6.
Exclusions from warranty:
−Service and maintenance work as well as repair and replacement of consumables
according to our consumables‘ list
−Transportation cost of the machine or installation and dismounting expenses incurred
−Damages due to use of the product other than for its intended purpose
−Damages due to faulty installation or insufficient maintenance of the product (e.g.
decalcification)
−Damages due to natural disaster e.g. lightning, water, fire, act of nature beyond
control, war, inadequate line voltage, insufficient ventilation, no decalcification,
insufficient care and cleaning or non-adherence to operation and maintenance
instructions according to the accompanying operation guide.
−Damage due to use of the product other than in accordance with the instructions
provided by REITEL Feinwerktechnik GmH;
−The warranty does not cover the cost of removal and replacement of parts and
accessories, unless supplied as original equipment by REITEL Feinwerktechnik
GmbH
−All kind of damages occurred not directly at the device as well as consequential
damages (e.g. damages to furniture due to a lack of water, downtime of the machine,
material, lost working hours, wages and other consequential damages).
This warranty shall be rendered null and void if:
−the product has been subject to any modification, repair or replacement other than as
authorised by REITEL Feinwerktechnik GmbH
−the product is continued to be operated despite a functional defect

16
7.
The warranty is device specific and may be claimed, within the warranty period, by any
person who has legally acquired the device.
8.
Consumables are excluded from warranty. Spare parts are subject to a warranty coverage of
6 months against all defects traceable to materials, design or workmanship according to
these warranty regulations.
9.
Legal default claims on the part of the purchaser remain unaffected by this warranty.
10.
We reserve the right to charge a fee if repair of the device is rejected and the device is
destined to be sent back unrepaired.
11.
Please note:
Upon repair or replacement of this unit, personal data and settings might get lost or
damaged. We don’t accept liability for all kind of data loss. The customer is advised to
backup essential programs and data before sending for service.
12.
This warranty shall be interpreted in accordance with German law to the exclusion of UN
sales law. Place of jurisdiction is our business location.
13.
If any provisions of this warranty are judged to be illegal or unenforceable, the continuation in
full force and effect of the remaining provisions will not be prejudiced. The provisions of this
warranty judged to be illegal or unenforceable shall be construed so as to give effect to the
intent manifested by the provision held invalid, illegal or unenforceable and to give effect to
section 13 hereof.
14.
Should you need to borrow a device while your device is being repaired, please contact
Messrs. REITEL or your distributor. These loans are a service for which availability cannot
necessarily be guaranteed. After the warranty period, a free may be charged for loan
equipment as well as for shipping and packaging.

17
Disposal Regulations
According to valid laws our devices are properly disposed of according to B2B –
regulations for proper disposal. Pls. contact your local dealer for additional
information.

18
Spare Parts List
Best.-Nr.
Ref.
Poliret + Poliret Twin 27
Ersatzteilliste / Spare parts list - 03/2019
Stck/ME
Qty.
ME
Unit
E6158800
Beleuchtung Scheibe, Acryl 185*50*4dick
Acrylic screen for lamp
1
Stck
piece
E6134910
Dichtung f.Polierspindel, Leder
1
Stck
piece
22702000
Filterbeutel mit Reissverschluß (1 Pack= 2 Stück )
Filter bag with zipper (2 pcs.)
1
Pack
pack
E6152200
Gummieinlage für Trog (1Satz=2 Stück)
Rubber pad for trough (1 set)
1
Satz
set
E6152100
Kantenschutzprofil
Edge protection profile
1
m
22603000
Polier- und Schleifaufnahme m.Bohrfutter
1
Stck
piece
E61453-E
Polierspindel POLIRET / E aktuell, zylindrisch, bitte Gerätenummer
angeben), li oder re
1
Stck
piece
E6145300
Polierspindel POLIRET TWIN, zylindrisch
Polishing spindle POLIRET TWIN, cylindric, li oder re
1
Stck
piece
E6152700
Prallschutz ( 2 Stück/Satz )
Baffle absorber 2 pcs./pack
1
Satz
set
E6064800
Schalter mit Lampe grün
Switch with green lamp
1
Stck
piece
E6156000
Schutzglas mit Haltebügelsatz
Support for protecting glass, incl. glass
1
Stck
piece
E6153020
Sieb Kunststoff, für Absaugkanal
Plastic sieve for suction channel
1
Stck
piece
E6150500
Trog für POLIRET
Trough for POLIRET
1
Stck
piece

19
EC Conformity Declaration

We manufacture in compliance with Quality Management ISO 9001:2015 incorporating
established standards.
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: [phone] | Fax: [phone]
www.reitel.com | [email protected]
062019
