Renac N1-HV Series User manual

N1-HV-3.0
N1-HV-3.68
N1-HV-5.0
N1-HV-6.0
User Manual
Series
N1-HV
Series

1. About This Manual 3
1.1 Applicability 3
1.2 Target group 3
1.3 Symbols used 3
2. Safety 3
2.1 General Safety 3
2.2 Important safety instructions 3
2.3 Explanation of symbols 5
3. Introduction 5
3.1 Basic features 5
3.2 Work modes 6
3.3 Terminals 8
3.4 Dimension 9
4. Technical data 9
5. Installation 11
5.1 Unpacking 11
5.2 Check for transport damage 13
5.3 Installation precaution 13
5.4 Available space 13
5.5 Preparation 13
5.6 Installation steps 15
5.7 Electrical Wiring Connection 16
5.7.1 PV Wiring Connection 17
5.7.2 Battery Connection 18
5.7.3 AC Output Connection 20
5.7.4 Earth Connection 21
5.7.5 Communication connection 22
5.8 Inverter manipulation 24
6. Operation method 24
6.1 Control panel 24
6.2 LCD function 25
6.3 LCD operation 26
7. Troubleshooting 32
8. Decommissioning 36
8.1 Dementling the inverter 36
8.2 Packaging 36
8.3 Storage 36
8.4 Disposal 36
Content

N1-HV Series User Manual
23
N1-HV Series User Manual
Notice
This manual contains important safety instructions that must be followed during installation and maintenance of the equipment.
：
Save the manual!
This manual must be stored carefully and be available at all times.
Save the manual!
corporation or individual should not plagiarize, partially copy or fully copy it, and no reproduction or distribution of it in any form or by
any means without prior written permission from RENAC Power.
latest
version.
1. About This Manual
1.1 Applicability
Please read the product manual carefully before installation,operation or maintenance.This manual contains important safety instruc-
tions and installation instructionsthat must be followed during installation and maintenance of the equipment.
2.2Importantsafety instructions
1.2 Targetgroup
installation and
commissioning in the energy storage system.
1.3 Symbols used
DANGER!
will result in death or serious injury.
WARNING!
-
ed, will result in death or serious injury.
CAUTION!
could result in minor or moderate injury.
NOTICE!
-
ment or property damage.
NOTE!
product.
N1-HV-3.0 N1-HV-3.68 N1-HV-5.0 N1-HV-6.0
2. Safety
2.1 General Safety
◆injury or death to the operator or a third party;
◆damage to the inverter or other properties.
NOTICE

N1-HV Series User Manual
45
N1-HV Series User Manual
2.3 Explanation of symbols
3. Introduction
3.1 Basic features
The N1-HV series hybrid inverters apply to PV energy storage system with PV module, battery, loads and grid.
The energy produced by PV systemshall be used to optimize self-consumption, excess power charge battery and the rest power could
This section gives an explanation of all the symbols shown on the type label.
Symbols on the Type Label
guidelines.
Danger of high voltages.
Danger to life due to high voltages in the inverter!
Danger.
The inverter cannot be disposed of together with the household waste.
Disposal information can be found in the enclosed documentation.
PV generation suppliers.
Danger to life due to high voltage.
There is residual voltage in the inverter which needs 5 min to discharge.
Wait 5 min before you open the upper lid or the DC lid.
Beware of hot surface.
The inverter can become hot during operation. Avoid contact during opera-
tion.
Figure 3-1 PV Energy Storage System
Symbol Explanation
PV Panels
Battery Normal Load
Grid
Meter
Hybrid Inverter
Monitor
DANGER!
◆PV strings will produce electrical power when exposed to sunlight and
◆
◆Do not open the enclosure when the inverter is running. Unauthorized
opening will void warranty and warranty claims and in most cases termi-
nate the operating license.
◆When the enclosure lid is removed, live components can be touched
◆Operating a damaged inverter can lead to hazardous situations that can
◆
they are short circuited, or wrongly installed.
◆Lethal voltages are present at the battery terminals and cables
connecting to the inverter. Severe injuries or death may occur if the
cables and terminals in the inverter are touched.
◆
grounded as default design. Connecting PV- or BAT- to EARTH are strictly
forbidden.
WARNING!
◆Do not disconnect PV connectors, AC connector or battery connectors
while the inverter is running. De-energize from all multiple power sourc-
es. Wait 5 minutes for the internal capacitors to discharge. Verify that
there is no voltage or current before disconnecting any connectors.
Use personal protective equipment, including rubber gloves and prote-
tive bootsduringthe installation or maintenance.
CAUTION!
temperature of inverter surface might exceed 60℃
CAUTION!
◆Electrical installation and maintenance must be carried out by compe-
tent electricians according to localregulations.
◆Do not open inverter cover or change any components without RENAC
inverter will be invalid.
◆Usage and operation of the inverter must follow instructions in this user
manual, otherwise the protection design might be useless and warranty
for the inverter will be invalid.
NOTE!
◆Electrical installation and maintenance must be carried out by compe-
tent electricians according to localregulations.
The inverter built-in RCMU will exclude possibility of DC residual current
NOTICE

N1-HV Series User Manual
67
N1-HV Series User Manual
3.2 Workmodes
Work mode: Self-use
into the grid.
This mode applies the area that has high feed-in tariff and export control.
Work mode: Feed in Pirority
34
4
1
2
3
2
1
Work mode:Force time use
24
1
3
34
1
2

8N1-HV Series User Manual 9
N1-HV Series User Manual
Work mode: Back up mode
This mode applies the area that has frequent power outages. And this mode ensures the battery will has enough energy to supply
24
1
3
WARNING!
the range of the EPS output, and turn the inverter on.
is within the range of the EPS output.
3.3 Terminals
TheN1-HV series hybrid inverters apply to PV energy storage system with PV module, battery, loads and grid.
The energy produced by PV system shall be used to optimize self-consumption, excesspowercharge battery and the rest power could
A B C
D
E F G H
4 Technical data
Object
DC switch
Battery connector
A
B
C
D
E
H
Communication port
SD port
EPS port
AC port
Description Object Description
3.4 Dimension
5500 9000
4500 7500
600
120~550
360
150
2
1
Model
PV Input Data
N1-HV-5.0N1-HV-3.68 N1-HV-6.0N1-HV-3.0
Start-up Voltage
Integrated
DC Switch

N1-HV Series User Manual
10 N1-HV Series User Manual 11
3680
16
0.8leading ~0.8lagging
<2
Lithium
80-450
25
CAN
6000
26.1
3000
13
5000*1
21.7*1
3680 6000
3000 5000
97.45
97.17
99.90
97.17
97.50
97.20
99.90
97.20
97.42
97.15
99.90
97.15
97.50
97.20
99.90
97.20
16 26.1
13 21.7
<2
<0.5
120% Overload.600
Intergrated
Intergrated
Intergrated
Model
AC Output Data(on-grid)
Output DC( Battery)
EPS Output(With Battery)
φ]
Battery Type
Communication Interface
DC Insulation Monitoring
Input Reverse Polarity Protection
Anti-island Protection
21.7A.
Intergrated
Intergrated
520*412*172
20
LED+OLED
-30 ~ 60
0-95
<15 for hot standby, <3 for cold standby
Natural Convection
IP65
EN50549,IEC61727,IEC62116
IEC 62109-1, IEC 62109-2, IEC62040
Model
General Data
AC Short-circuit Protection
AC Overvoltage Protection
DC Surge Protection
AC Surge Protection
User Interface
Communication
Operating Temperature Range (℃
Topology
Cooling
Enclosure
Warranty
Safety Regulation
EMC EN 61000-6-2, EN 61000-6-3,
EN 61000-4-16, EN 61000-4-18, EN 61000-4-29
5 Installation
5.1 Unpacking
4500 3000 5500 3680 6000 5000 6000 6000
Protective Class
Intergrated
Intergrated
Over-heat Protection
AC Overcurrent Protection
3680 6000
3000 5000*1
(
16 26.1
13 21.7*1
35
Intergrated
Residual Current Monitoring
Overvoltage Category

N1-HV Series User Manual 13 N1-HV Series User Manual
12
Quantity
A
B
C
D
E
H
I
J
K
L
M
N
O
P
1
1
2
4
4
1
1
6
1
3
1
1
4
1
1
1
AC Terminal
EPS Terminal
Ethernet RJ45 Connector
M5 Screw
Earth Terminal
Tubular terminal
Meter
8P Pluggable Terminal Block
5.2 Check for transport damage
5.3 Installation precaution
·
·
·Do not install the inverter in potentially explosive areas.
·
cause corrosion and damage to the electric components.
·Provide adequate ventilation when using batteries, and also read the warning label on the bottom of the inverter.
·Install the inverter in a location that maintains an ambient air temperature that is less than 40°C;That is to maintain a safe
internal component temperature; the inverter would reduce power if the ambient air temperature exceeds 40°C. • The inverter
should be installed in a location that is not accessible for children.
·The inverter emits a slight vibrating noise when operating, which is normal and no effect on performance.
·
·The inverter is heavy, ensure the mounting place is strong enough to hold the weight of the inverter.
·
to dissipate the heat generated by the unit.
5.4 Available space
500mm
500mm
300mm 300mm 300mm
A B C D
E F G H
I J K L
M N O P

N1-HV Series User Manual
14 N1-HV Series User Manual 15
Lifting and Handling
The unit is heavy. Do not lift it alone.
·
·
·Ensure that the method of lifting will not allow the unit to slip from chains and slings or turn-over or slide from lifting devices.
5.5 Preparation
No. Tool ModelFunction
1
2
3
4
5
6
7
8
9
Level
BOSCH HD18-2 Two-
Speed Hammer Dril
properly installed
Drill holes on the wall
Strippling plier for PV cable
Crimping plier for PV cable
Crimping tool for RJ45 terminal
Electrical Connectors
Wiring
Brushless Impact
Wrench Set
Screwdriver
RJ45 Crimping Tool
Crimping plier
Hammer
5.6 Installation steps
Step 1:
·
Step2:
·Transportation of the inverter needs at least 2 people, each one needs to use the handles at the sides of the inverter.
·
·Drill holes with ф
tubes.
·
·
·
·Avoid sudden movements and jolts when unloading and positioning the unit. Internal handling procedures must be conducted
with care. Do not exert leverage on the components of the machine.
·If the unit is not balanced apply ballast. Any protruding parts should not be supported by hand.
·The inverter should be installed so that the operating panel shall be easily accessible- easy access to the electrical power
connection point.
·
·
·
weight of the devices according to IEC62109-1. And supporting characteristics will be impaired by wear, corrosion, material
fatigue or ageing, This should be calculated by inspection of the design data of supporting material and consulting construction
engineer.

N1-HV Series User Manual
16 N1-HV Series User Manual 17
5.7 Electrical Wiring Connection
System Connection Diagrams
，
5.7.1 PV Wiring Connection
·
·
·
·
1.Turn off the DC switch.
2.Prepare 2.5-4mm2 PV cable and PV plugs as below.
4.Insert striped cable into pin contact and ensure all conductor strands are captured in the pin contact.
crimping pliers and crimp the contact.
pin contact assembly is seated correctly.
·PV string connection
·AC output connection
·Battery connection
·Battery power connection
·Battery communication connection
·EPS connection
·Earth connection
·Communication connection
PV Panels
Grid
Meter
PV Panels
Grid
Meter

18 N1-HV Series User Manual 19
N1-HV Series User Manual
5.7.2 BatteryConnection
provides the necessary part of the interfaces to connect the battery.
WARNING!
7.Tight the DC connector.
b.Rotate the cable nut to secure the cable.
9.Separate the DC connector
b.When separate the DC+ connector, push the tool down from upside.
c.When separate the DC- connector, push tool down from the bottom side.
d.Separate the connectors by hands.
□.
□
□
1
2
2
2.Battery Communication Connection
6.Push the insert into the sleeve (□
7.Tighten the cable gland to 2 Nm (□
to hold the connector in place.
10.Separating connectors
□,
□
Pin 1
NC NC NC NC NC NCCANH CANL
2 3 4 5 6 7 8
Function
3
3
4
4

20 N1-HV Series User Manual 21
N1-HV Series User Manual
5.7.4 Earth Connection
Connection step:
You can additionally earth the inverter enclosure of a second earthling or equipotential bonding is required locally. This
prevents touch current if the original protective conductor fails.
connector.
5.7.3AC Output Connection
required, a type A RCD with rated residual current of 30mA or higher is recommended.
Connection Step:
1.Remove the cable jacket by 40 mm, and strip the wire insulation by 8 mm-15 mm.
2. Lead the AC cable through the cable gland and the housing.
WARNING!
Overview for all battery connections
BMS
BAT+
BAT-
Model
4mm2
25A 25A 32A 32A
4mm26mm26mm2
N1-HV-5.0
Cable(Cu)
Micro-Breaker
PE
L
N
40 mm
10 mm

22 N1-HV Series User Manual 23
N1-HV Series User Manual
5.7.5 Communication connection
Communication interface
（optional）, Dry contact and extend port and for
human and machine communication, etc., can be delivered to PC or other monitoring equipment via these interfaces.
1. WIFI or GPRS
4.METER port
3.
ADD Interface
Pin 1
METER-485A METER-485B +5V SHUTOWN Temp
2 3 4 5 6 7 8
Function
Pin 1
METER-485A METER-485B NC NC NC NC NC NC
2 3 4 5 6 7 8
Function
Meter wiring diagram
4. DRED
PV Panels
Battery Normal Load
Grid
AC Switch
Hybrid Inverter
12
3 4
56
Meter
7
RS485A
RS485B
Pin 1
+3.3V HND
2 3 4 5 6 7 8
Function
RS485
2. RS485 Interface
RS485 interface PINS definition:
Pin 1
+5V GND 485A 485B
23 4
Function

24 N1-HV Series User Manual 25
N1-HV Series User Manual
5.8 Inverter manipulation
Start inverter:
·
·
·
·
·Turn on the external AC, DC switch.
·
·
·Inverter will start automatically when the PV panel generate enough energy or the battery is charged.
·
·
-All the connections are right.
-All the external disconnect switches are closed.
-The DC switch of the inverter is in the ‘ ON ‘ positon.
·Enter the setting interface.
·
NOTE!
you need to start up the inverter.
6 Operation method
6.1 Control panel
ABCD
J
E F G H
6.2 LCD function
Menu structure :
Object Name
Indicator
LED
Button
LCD Screen Display the information of the inverter.
A
B
C
D
E
F
G
H
J
===Comm Addr===
Local Addr
>Meter Addr
===Comm Addr===
>Local Addr
Meter Addr
===Local Addr===
>001
OK
===Meter Addr===
>001
OK
=====Settings=====
Work Mode
PV Config
>Comm Addr
=PV Connection=
>Comm
OK
=PV Connection=
>Multi
OK
=====Settings=====
Data&Time
Work Mode
>PV Config
======Menu======
Status
History
>Setting
=====Settings=====
Language
Data&Time
>Work Mode
===Work Mode===
>Self Use
OK
===Work Mode===
>Force Time Use
OK
===Work Mode===
>Backup Use
OK
===Work Mode===
>Feedin Use
OK
=====About=====
Model:
N1-HV-6.0
=====About=====
InverSN:
123456789abcdefg
=====About=====
M Ver: Vx.xx
S Ver: Vx.xx
H Ver: Vx.xx
=====Menu=====
Setting
SysSwitch
>About
====SysSwitch====
>Turn On
OK
=====Menu=====
History
Setting
>SysSwitch
To ‘Advanced
=====Solar=====
Vpv1: V
Vpv2: V
=====Solar=====
Ipv1: A
Ipv2: A
=====Grid=====
Vac: V
Iac: A
Pac: W
=====Grid=====
Fac: Hz
=====BMS=====
Vbat: V
Ibat: A
Vchr: V
=====BMS=====
Vdis: V
Ichr: A
Idis: A
=====EPS=====
Veps: V
Ieps: A
Peps: W
======Menu======
>Status
History
Setting
=====Charger=====
Vbat: V
Ibat: A
Pbat: W
=====Menu=====
Status
>History
Setting
====History====
>Yield Logs
Error Logs
====Language====
>English
OK
=====Settings=====
>Language
Data&Time
Work Mode
===Data&Time===
Data:xx-xx-xx
Time:xx:xx:xx
OK
=====Settings=====
Language
>Data&Time
Work Mode
=====Solar=====
Ppv1: W
Ppv2: W
PV Conf: Multi
=====EPS=====
Feps: Hz
=====TEMP=====
Inner: ℃
Charger: ℃
Inverter: ℃
=====TEMP=====
Boost: ℃
===Yield Logs===
>Output Total
kWh
===Yield Logs===
>Eps Total
kWh
===Yield Logs===
>Solar Total
kWh
===Yield Logs===
>Batdischr Total
kWh
===Yield Logs===
>Batchr Total
kWh
===Yield Logs===
>Input Total
kWh
===Error Logs===
01: xx-xx-xx
xx:xx:xx
XXX Fault
=====About=====
BMS M Ver: Vx.xx
BMS S Ver: Vx.xx
Normal
Power: W
Battery: %
XX-XX XX:XX:XX
Normal
Ppv: W
Pbat: W
Normal
Pac: W
Pfeed: W
Pload: W
Normal
Battery Status:
XXX
Normal
WorkMode:
Self Use

26 N1-HV Series User Manual 27
N1-HV Series User Manual
The main screen as below. Press up or down for more information.
6.3 LCD operation
1. Main screen
2. Status
This status shows the real time PV parameters of the system. The input voltage, current and power of each PV input. Press up
A) Solar
This status shows the real time grid parameters such as voltage, current, output power and frequency. Pac measures the
output of the inverter.
B) Grid
This status shows the charger situation of the system. Include the battery voltage, charge or discharge current. Charge or
C) Charger
=====Charger=====
Vbat: V
Ibat: A
Pbat: W
This status shows the battery situation of the system. Include the battery voltage and current, charge and discharge voltage,
D) BMS
E）EPS
=====BMS=====
Vbat: V
Ibat: A
Vchr: V
=====BMS=====
Vdis: V
Ichr: A
Idis: A
=====Solar=====
Vpv1: V
Vpv2: V
=====Solar=====
Ipv1: A
Ipv2: A
=====Solar=====
Ppv1: W
Ppv2: W
PV Conf: Multi
==User Verify==
0000
OK
=====Settings=====
PV Config
Comm Addr
>Advanced*
====Safety====
>AS4777
OK
====On-Grid====
Safety
>Grid
Export Control
====On-Grid====
>Safety
Grid
Export Control
===Advanced*===
>On-Grid
Battery
Feature
==Freq Protect==
>Fac Upper Fast
52.00Hz
OK
==Freq Protect==
>Fac Upper Slow
52.00Hz
OK
==Freq Protect==
>Fac Lower Slow
47.00Hz
OK
==Freq Protect==
>Fac Lower Fast
47.00Hz
OK
=====Grid=====
Volt Protect
>Freq Protect
==Volt Protect==
>Vac Lower Fast
000.0V
OK
==Volt Protect==
>Vac Lower Slow
180.0V
OK
==Volt Protect==
>Vac Upper Slow
260.0V
OK
==Volt Protect==
>VacUpperFast
265.0V
OK
==Volt Protect==
>Vac 10M Avg
255.0V
OK
=====Grid=====
>Volt Protect
Freq Protect
====On-Grid====
Safety
Grid
>ExportControl
=ExportControl=
>User Value
10000W
OK
====Battery====
>Battery Awaken
No
OK
====Battery====
>Dischr Max Curr
25.0A
OK
====Battery====
>Chr Max Curr
25.0A
OK
====Battery====
>Min On-Grid SOC
000%
OK
====Battery====
>Min Capacity
010%
OK
====Battery====
>EpsOLRecSOC
100%
OK
====Battery====
>Eps BT Low Rec
Disable
OK
===Advanced*===
On-Grid
>Battery
Feature
===Advanced*===
New Password
>Reset
>USB
=====USB=====
>Upgrade
====Upgrade====
>DSPM Upgrade
DSPS Upgrade
ARMC Upgrade
==DSPM Upgrade==
>No< Yes
====Upgrade====
DSPM Upgrade
>DSPS Upgrade
ARMC Upgrade
==DSPS Upgrade==
>No< Yes
====Upgrade====
DSPS Upgrade
ARMC Upgrade
>BATM Upgrade
====Upgrade====
ARMC Upgrade
BATM Upgrade
>BATS Upgrade
==BATS Upgrade==
>No< Yes
====Upgrade====
DSPM Upgrade
DSPS Upgrade
>ARMC Upgrade
==ARMC Upgrade==
>No< Yes
==BATM Upgrade==
>No< Yes
=====Reset=====
>ResetEnergy
Reset Errlogs
Factory Reset
===Advanced*===
Feature
New Password
>Reset
=====Reset=====
Reset Energy
>Reset Errlogs
Factory Reset
=Reset Errlogs=
>ESC<ENT
=====Reset=====
Reset Energy
Reset Errlogs
>FactoryReset
=Factory Reset=
>ESC< ENT
==Reset Energy==
>ESC< ENT
===Advanced*===
Battery
Feature
>NewPassword
==New Password==
Enter Password
0000
OK
====Feature====
>RemoteControl
DRM0
Meter Setting
=Remote Control=
>Disable
OK
====Feature====
Remote Control
>DRM0
Meter Setting
=====DRM0 =====
>Disable
OK
====Feature====
Remote Control
DRM0
>MeterSetting
===Advanced*===
On-Grid
Battery
>Feature
=Meter Setting=
>Disable
OK
Normal
Power: W
Battery: %
XX-XX XX:XX:XX
Normal
Ppv: W
Pbat: W
Normal
Pac: W
Pfeed: W
Pload: W
Normal
WorkMode:
Self Use
Normal
Battery Status:
XXX
=====Solar=====
Vpv1: V
Vpv2: V
=====Solar=====
Ipv1: A
Ipv2: A
=====Grid=====
Vac: V
Iac: A
Pac: W
=====Grid=====
Fac: Hz =====BMS=====
Vbat: V
Ibat: A
Vchr: V
=====BMS=====
Vdis: V
Ichr: A
Idis: A
=====EPS=====
Veps: V
Ieps: A
Peps: W
======Menu======
>Status
History
Setting =====Charger=====
Vbat: V
Ibat: A
Pbat: W
=====Solar=====
Ppv1: W
Ppv2: W
PV Conf: Multi
=====EPS=====
Feps: Hz
=====TEMP=====
Inner: ℃
Charger: ℃
Inverter: ℃
=====TEMP=====
Boost: ℃
=====Grid=====
Vac: V
Iac: A
Pac: W
=====Grid=====
Fac: Hz
=====EPS=====
Veps: V
Ieps: A
Peps: W
=====EPS=====
Feps: Hz

28 N1-HV Series User Manual 29
N1-HV Series User Manual
3. History
advanced and so on.
4. Settings
A) Language
====Language====
>English
OK
=====Settings=====
>Language
Data&Time
Work Mode
B) Date Time
===Data&Time===
Data:xx-xx-xx
Time:xx:xx:xx
OK
=====Settings=====
Language
>Data&Time
Work Mode
C) Work Mode
=====Settings=====
Language
Data&Time
>Work Mode
===Work Mode===
>Self Use
OK
===Work Mode===
>Force Time Use
OK
===Work Mode===
>Backup Use
OK
===Work Mode===
>Feedin Use
OK
=====Menu=====
Status
>History
Setting
====History====
>Yield Logs
Error Logs
===Yield Logs===
>Output Total
kWh
===Yield Logs===
>Eps Total
kWh
===Yield Logs===
>Solar Total
kWh
===Yield Logs===
>Batdischr Total
kWh
===Yield Logs===
>Batchr Total
kWh
===Yield Logs===
>Input Total
kWh
===Error Logs===
01: xx-xx-xx
xx:xx:xx
XXX Fault
D) PV Connection
=PV Connection=
>Comm
OK
=PV Connection=
>Multi
OK
=====Settings=====
Data&Time
Work Mode
>PV Config
E) Communication Address
F) Safety
==User Verify==
0 0 0 0
OK
=====Settings=====
PV Config
Comm Addr
>Advanced*
====Safety====
>AS4777
OK
====On-Grid====
>Safety
Grid
Export Control
G) Grid
===Comm Addr===
Local Addr
>Meter Addr
===Comm Addr===
>Local Addr
Meter Addr
===Local Addr===
>001
OK
===Meter Addr===
>001
OK
=====Settings=====
Work Mode
PV Config
>Comm Addr

30 N1-HV Series User Manual 31
N1-HV Series User Manual
With this function the inverter can control the energy export to the grid. Press up or down button to change the export power.
H) Export control
====On-Grid====
Safety
Grid
>Export Control
=Export Control=
>User Value
10000W
OK
I) Battery
====Battery====
>Battery Awaken
No
OK
====Battery====
>Dischr Max Curr
25.0A
OK
====Battery====
>Chr Max Curr
25.0A
OK
====Battery====
>Min On-Grid SOC
000%
OK
====Battery====
>Min Capacity
010%
OK
====Battery====
>Eps OL Rec SOC
100%
OK
====Battery====
>Eps BT Low Rec
Disable
OK
===Advanced*===
On-Grid
>Battery
Feature
J) Feature
K) NewPassword
===Advanced*===
Battery
Feature
>New Password
==New Password==
Enter Password
0 0 0 0
OK
L) Reset
=====Reset=====
>Reset Energy
Reset Errlogs
Factory Reset
===Advanced*===
Feature
New Password
>Reset
=====Reset=====
Reset Energy
>Reset Errlogs
Factory Reset
=Reset Errlogs=
>ESC< ENT
=====Reset=====
Reset Energy
Reset Errlogs
>Factory Reset
=Factory Reset=
>ESC< ENT
==Reset Energy==
>ESC< ENT
====Feature====
>Remote Control
DRM0
Meter Setting
=Remote Control=
>Disable
OK
====Feature====
Remote Control
>DRM0
Meter Setting
=====DRM0 =====
>Disable
OK
====Feature====
Remote Control
DRM0
>Meter Setting
===Advanced*===
On-Grid
Battery
>Feature
=Meter Setting=
>Disable
OK
====On-Grid====
Safety
>Grid
Export Control
==Freq Protect==
>Fac Upper Fast
52.00Hz
OK
==Freq Protect==
>Fac Upper Slow
52.00Hz
OK
==Freq Protect==
>Fac Lower Slow
47.00Hz
OK
==Freq Protect==
>Fac Lower Fast
47.00Hz
OK
=====Grid=====
Volt Protect
>Freq Protect
==Volt Protect==
>Vac Lower Fast
000.0V
OK
==Volt Protect==
>Vac Lower Slow
180.0V
OK
==Volt Protect==
>Vac Upper Slow
260.0V
OK
==Volt Protect==
>Vac Upper Fast
265.0V
OK
==Volt Protect==
>Vac 10M Avg
255.0V
OK
=====Grid=====
>Volt Protect
Freq Protect

32 N1-HV Series User Manual 33
N1-HV Series User Manual
7 Troubleshooting
M) USB
5.System Switch
====SysSwitch====
>Turn On
OK
=====Menu=====
History
Setting
>SysSwitch
This interface shows the information of the inverter, such as series number and software version.
This section contains information and procedures for solving possible problems with the N1 HV series inverters, and provides
you with trouble shooting tips to identify and solve most problems that could occur with the N1 HV series inverters.
This section will help you narrow down the source of any problems you may encounter. Please read the following trouble-
shooting steps.
·
message is displayed, record it before doing anything further.
·Attempt the solution indicated in below table.
6. About
=====About=====
Model:
N1-HV-6.0
=====About=====
InverSN:
123456789abcdefg
=====About=====
M Ver: Vx.xx
S Ver: Vx.xx
H Ver: Vx.xx
=====Menu=====
Setting
SysSwitch
>About
=====About=====
BMS M Ver: Vx.xx
BMS S Ver: Vx.xx
===Advanced*===
New Password
>Reset
>USB
=====USB=====
>Upgrade
====Upgrade====
>DSPM Upgrade
DSPS Upgrade
ARMC Upgrade
==DSPM Upgrade==
>No< Yes
====Upgrade====
DSPM Upgrade
>DSPS Upgrade
ARMC Upgrade
==DSPS Upgrade==
>No< Yes
====Upgrade====
DSPS Upgrade
ARMC Upgrade
>BATM Upgrade
====Upgrade====
ARMC Upgrade
BATM Upgrade
>BATS Upgrade
==BATS Upgrade==
>No< Yes
====Upgrade====
DSPM Upgrade
DSPS Upgrade
>ARMC Upgrade
==ARMC Upgrade==
>No< Yes
==BATM Upgrade==
>No< Yes
Inverter over current or battery over current or PV over current detected by hardware.
• Disconnect PV, grid and battery, then reconnect.
PV voltage out of range.
Bus voltage out of range detected by hardware.
• Disconnect PV, grid and battery, then reconnect.
Battery voltage fault.
The grid voltage is out of range for the last 10 Minutes.
DC component is out of limit in output current.
• Disconnect PV, grid and battery, then reconnect.
DC component is out of limit in output voltage.
• Disconnect PV, grid and battery, then reconnect.
Output current high detected by software.
• Disconnect PV, grid and battery, then reconnect.
The isolation is failed.
The inverter temperature is high.
The battery connection is reversed.
The residual current is high.

34 N1-HV Series User Manual
EPS Over Load
The sample value between master and slave is not consistent.
• Disconnect PV, grid and battery, then reconnect.
Over load in off grid mode.
Over load in on grid mode.
• Resetting the PV connection.
The battery power is low.
• Wait the battery to be recharged.
By pass relay fault
• Disconnect PV, grid and battery, then reconnect.
The communication between master and slave fault
•Disconnect solar power PV+ , PV- and battery, reconnect them.
The communication between BMS and Inverter is interrupted.
connected.
• Disconnect solar power PV+ , PV- and battery, reconnect them.
• Disconnect solar power PV+ , PV- and battery, reconnect them.
The master eeprom is fault.
• Disconnect PV, grid and battery, then reconnect.
• Disconnect PV, grid and battery, then reconnect.
• Disconnect PV, grid and battery, then reconnect.
Other device fault.
• Turn off the PV, battery and grid , reconnect them.
The residual current circuit is fault.
BMS Protect OV
BMS Protect LV
BMS Protect ChrOC
The manager eeprom is fault.
• Disconnect PV, grid and battery, then reconnect.
The communication between meter and Inverter is interrupted.
connected.
SCI communication fault
•Disconnect solar power PV+ , PV- and battery, reconnect them.
Battery cell error
Battery other error
Battery over voltage protect
Battery under voltage protect
Battery over current charging protect
Battery voltage sensor error
Battery temperature sensor error
BMS internal communication fault.
，battery internal wiring
then reconnect.
Battery input over voltage error
Battery input transposition error
The battery relay is fault.
• Disconnect battery, then reconnect.
35
N1-HV Series User Manual

36 N1-HV Series User Manual
Tel：[phone]
[e-mail]
.renacpo er.com
SMART ENERGY FOR BETTER LIFE
422-00113-05
8 Decommissioning
8.1 Dementling the inverter
8.2 Packaging
If it is nolonger available, you can also use an equivalent carton that meets the following requirements.
8.3 Storage
Store the inverter in dry place where ambient temperatures are alwaysbetween -20 °C - +60 °C.
8.4 Disposal
When the inverter or other related components need to be disposed. Have it carried out according to local waste handling regulations.
recycle.
Remark
installation allows proper operation of the unit.
·Is theinverter located in a clean,dry, and adequately ventilated place?
·
·Arethe cables adequately sized and short enough?
·Arethe input and output connections and wiring in good condition?
·
·Arethe display panel and the communications cable properly connected and undamaged?
Contact Renac Power Customer Service for further assistance. Please be prepared to describe details of your system installationand
provide themodel and serial number of the unit.
BMS Protect DishargeOC
BMS Protect TemHigh
BMS Protect TemLow
Battery over current discharging protect
Battery temperature is high
Battery temperature is low
