Renogy REGO User manual

VERSION A0
Inverter Charger
REGO
12V 3000W
USER MANUAL
AC / INV CHC
OFF
ON
FAULT
ARNING
please read the instructions carefully
Before working on this product.
High voltage,in order to avoid risks,
Pure Sine Wave Inverter Charger

02
Applicability
The user manual applies to the following product:
zREGO 12V 3000W Inverter Charger (RIV1230RCL-1SS-G1)
Disclaimer
zRenogy makes no warranty as to the accuracy, sufficiency, or suitability of information in the
user manual because continuous product improvements are going to be made.
zRenogy assumes no responsibility or liability for losses or damages, whether direct, indirect,
consequential, or incidental, which might arise out of the use of information in the user
manual.
zRenogy is not responsible or liable for the failures, damages, or injuries resulting from repair
attempted by unqualified personnel or improper installation and operation.
zThe illustrations in the user manual are for demonstration purposes only. Details may appear
slightly different depending on product revision and market region.
zRenogy reserves the right to change the information in the user manual without notice.
Copyright
REGO 12V 3000W Inverter Charger User Manual © 2022 Renogy. All rights reserved. All
information in the user manual is subject to copyright and other intellectual property rights of
Renogy and its licensors. The user manual may not be modified, reproduced, or copied, in
whole or in part, without the prior written permissions of Renogy and its licensors.
Trademarks
The following are trademarks or registered trademarks of Renogy in the United States and other
countries and regions:
RENOGY
All other trademarks in the user manual are the property of their respective owners and their
use herein does not imply sponsorship or endorsement of their products or services. The
unauthorized use of any trademark displayed in the user manual or on the product is strictly
prohibited.
Date and Revision
January 2022, Revision A0

03
Table of Contents
Important Safety Information .......................................................................................................06
Symbols Used .........................................................................................................................06
General Safety Information .....................................................................................................06
Introduction ..................................................................................................................................08
General Information ................................................................................................................08
Key Features ...........................................................................................................................08
Package Contents .......................................................................................................................10
Optional Accessories ...................................................................................................................11
Product Overview ........................................................................................................................12
External View ..........................................................................................................................12
Internal View ............................................................................................................................13
Wiring Diagram ............................................................................................................................14
Recommended Cable Sizing .......................................................................................................15
Components & Tools ...................................................................................................................16
Inspection ....................................................................................................................................19
Inspecting Inverter Charger .....................................................................................................19
Environment ............................................................................................................................19
Placement ...............................................................................................................................20
Checking Battery .....................................................................................................................21
Preparation ..................................................................................................................................23
Mounting .................................................................................................................................23
Removing the Plate .................................................................................................................23
Cautions ..................................................................................................................................24
Ground Cable Wiring ...................................................................................................................25
Remote Control Wiring ................................................................................................................27

04
Temperature Sensor Wiring .........................................................................................................28
Battery Wiring ..............................................................................................................................30
Device-side Wiring ..................................................................................................................30
Battery-side Wiring ..................................................................................................................32
AC Output Wiring.........................................................................................................................38
Device-side Wiring ..................................................................................................................38
Load Wiring .............................................................................................................................39
AC Input Wiring ...........................................................................................................................41
Automatic Generator Start ...........................................................................................................43
Communication............................................................................................................................47
Inter-Device Communication ...................................................................................................47
Monitoring Device Communication .........................................................................................52
Putting Plates Back .....................................................................................................................57
Power on .....................................................................................................................................58
Main Switch .............................................................................................................................58
Wired Remote Control .............................................................................................................59
Operation .....................................................................................................................................60
LCD .........................................................................................................................................60
Button ......................................................................................................................................63
Setting Battery Type ................................................................................................................64
User Mode ...............................................................................................................................67
Working .......................................................................................................................................73
Working Logic ..............................................................................................................................75
Power Supply Logic ................................................................................................................75
Charging Logic ........................................................................................................................75
Heat Dissipation Logic ............................................................................................................77
Power off .....................................................................................................................................78
Main Switch .............................................................................................................................78

05
Wired Remote Control .............................................................................................................78
Overcurrent Protection ................................................................................................................80
LED Indicators .............................................................................................................................81
Indicator of the Inverter Charger ............................................................................................81
Indicator of the Wired Remote Control ....................................................................................81
Program Codes ...........................................................................................................................82
Warning/Fault Codes ...................................................................................................................91
Technical Specifications ..............................................................................................................93
Dimensions ..................................................................................................................................95
Maintenance ................................................................................................................................96
Inspection ................................................................................................................................96
Cleaning ..................................................................................................................................96
Storage ....................................................................................................................................96
Emergency Responses ...............................................................................................................97
Fire ..........................................................................................................................................97
Flooding ..................................................................................................................................97
Smell .......................................................................................................................................97
Noise .......................................................................................................................................97
Technical Support ........................................................................................................................98

06
Important Safety Information
The user manual provides important installation, operation, and maintenance instructions for
REGO 12V 3000W Inverter Charger (hereinafter referred to as inverter charger). Read the user
manual carefully before installation and operation and save it for future reference. Failure to
observe the instructions or precautions in the user manual can result in electrical shock, serious
injury, or death, or can damage the inverter charger, potentially rendering it inoperable. The
installation and service of the inverter charger might require knowledge of high voltage electricity
and is recommended to be carried out by qualified personnel.
Symbols Used
The following symbols are used throughout the user manual to highlight important information:
WARNIN
G
Indicates a potentially dangerous condition which could result in
injury or death.
CAUTIO
N
Indicates a critical procedure for safe and proper installation and
operation.
NOT
E
Indicates an important step or tip for optimal performance.
INFO
Indicates that more information is available in other documents
relating to the subject.
General Safety Information
WARNIN
G
zThe voltage of the inverter charger exceeds the human body safety voltage. Read all
instructions and precautions in the manual before installation.
zInspect the inverter charger for any visible damage including cracks, dents, deformation, and
other visible abnormalities before installation.
zDo not puncture, drop, crush, penetrate, shake, strike, or step on the inverter charger.
zDo not open, dismantle, repair, tamper with, or modify the components of the inverter
charger.
zInstall the inverter charger on a vertical surface indoors protected from direct sunlight, high
temperature, and water. Make sure there is good ventilation.
zKeep the inverter charger away from heating equipment.
zDo not insert foreign objects into the inverter charger.
zDo not install the inverter charger near flammable fumes or gases.
zKeep the inverter charger out of the reach of children.
zWear proper protective equipment and use insulated tools during installation and operation.
Do not wear metal jewelry, such as necklaces and watches.
zDo not touch the connector contacts while the inverter charger is in operation.
Important Safety Information
Symbols Used General Safety Information

07
Important Safety Information
zDisconnect all connectors from the inverter charger before maintenance or cleaning.
zRisk of electric shock! Be careful when touching bare terminals of the inverter charger as
they may retain high lethal voltages even after power is removed.
zDo not dispose of the inverter charger as household waste. Comply with local, state, and
federal laws and regulations and use recycling channels as required.
zIn the event of fire, use fire extinguishers suitable for electrical equipment.
zIf the inverter charger is installed improperly on a boat, it may cause damage to the corrosive
agents of the boat. Please have the inverter charger installed by a qualified electrician.
CAUTIO
N
zDo not expose the inverter charger to flammable or harsh chemicals or vapors.
zEnsure that there is no water source including downspouts, sprinklers, or faucets above or
near the inverter charger.
zEnsure that the battery bank is properly connected before installation.
zCheck the installation environment of the inverter charger regularly and keep it clean to
prevent the ventilation holes from being blocked by debris or dust.
Symbols Used General Safety Information

08
Introduction
Introduction
General Information
REGO 12V 3000W Inverter Charger is your off-grid smart living center that revolutionizes
comfort when you live in your off-grid home or RV. The inverter charger can invert DC to AC
and directly supply power to the load, and charge the battery when it is connected to the utility
power.
In addtion, it supports different types of batteries such as AGM, Gel, Sealed Lead Acid (SLA),
and Li. The inverter charger can switch power supply from the utility power to batteries within
10 milliseconds, ensuring a smooth mode switch without powering off the load. The lever style
connectors make AC IN/OUT connections simply and easy. They simplify installation and
shorten the installation time.
The inverter charger can be connected to Renogy devices and smart accessories via Bluetooth
or RV-C. When the inverter charger works in association with the DC Home app, you will
have the same system monitoring wherever you go on your smartphone. With advanced pure
sine wave technology, the inverter charger can protect and extend the life of your electronic
equipment and loads.
Key Features
zRobust and sleek design
The housing of the inverter charger is made of steel plates to ensure its firmness and a more
fashionable appearance.
zIntuitive LCD and LED
You can view and check the status displayed on the LCD and LEDs, and modify parameters of
the inverter charger according to the actual use.
zHigh quality waveform with little harmonic distortion
Advanced Pure Sine Wave technology provides high-quality AC power equivalent to the grid
power. The voltage increases and decreases in a smooth way with little harmonic distortion.
zMulti-stage Battery charging
Up to three stage battery charging including bulk, boost, and float as well as equalization for
select battery types
zConfigurable charging current
The maximum charging current of the inverter charger is 75A, adjustable at 5A each time. The
charging current can be ajusted to satisfy your daily use.
zNine preset battery voltages and custom options
The inverter charger is compatible with nine types of batteries to meet your needs in daily use.
You can also customize the battery parameters of the inverter charger.
zAutomatic generator start
The inverter charger is equipped with a set of NO and NC dry contacts, which are used to
connect the generator with automatic start and stop function and automatically charge the
battery, facilitating your daily use.
General Information Key Features

09
Introduction
zPeak conversion efficiency >90%
The peak conversion efficiency is more than 90% during operation, which reduces the energy
loss.
zMultiple electronic protections
The inverter charger is equiped with undervoltage protection, overvoltage protection, overload
protection, overtemperature protection, and short circuit protection.
General Information Key Features

10
Package Contents
Package Contents
REGO 12V 3000W Inverter Charger ×1 Quick Guide ×1
AC/ INV CHC
OFF
ON
FAULT
ARNING
pleaseread the instructions carefully
Beforeworking on this product.
Highvoltage,in order to avoid risks,
Pure Sine Wave Inverter Charger
AC/INV CHC
OFF
ON
FAULT
ARNING
pleasereadthe instructions carefully
Beforeworkingon this product.
Highvoltage,inorder to avoid risks,
PureSine Wave Inverter Charger
VERSION A0
Inverter Charger
REGO
12V 3000W
QUICK GUIDE
Battery Temperature Sensor x 1 Wired Remote Control x 1
ON ERR
RMS-P2
RJ11 Network Cable (5 m) x 1

11
Optional Accessories
Optional Accessories
zYou can buy optional accessories from renogy.com.
DC Fuse (400A)
The DC fuse protects the inverter charger, wires and batteries
from overcurrent.
Fuse Cable 4/0 AWG
The cable is integrated with copper rings at both ends, enabling
the inverter charger to be connected with an external fuse.
NOT
E

12
Product Overview
Product Overview
External View
AC / INV CHC
OFF
ON
FAULT
ARNING
please read the instructions carefully
Before working on this product.
High voltage,in order to avoid risks,
Pure Sine Wave Inverter Charger
7 8 9
2 3 4 5 61 6
1110
No. Part No. Part
1Remote & Accessory Cable Entry 7DC Negative Battery Cable Entry
2AC Output Cable Grommet 8DC Cable Plate
3AC Input Cable Grommet 9DC Positive Battery Cable Entry
4 Main Power Switch 10 Chassis Ground Lug
5LCD & Button Panel 11 Top Plate
6 Mounting Holes
External View Internal View

13
Product Overview
Internal View
WARNING
please read the instructions carefully
Before working on this product.
CHARGER INPUT
PROTECT
INVERTER OUTPUT
PROTECT
BTS
NO
NC
DRY
OUTPUT INPUT
N
NL
L
CONTACT
REMOTE
C
CAN
High voltage,in order to avoid risks,
AC/INV
OFF
ON
CHC FAULT
Pure Sine Wave Inverter Charger
GITIVE
ATIVE
14 15 1613
18 19 20 21 22
12
17
No. Part No. Part
12 Wired Remote Port (REMOTE) 18 Battery Temperature Sensor (BTS) Port
13 Dry Contact Relay Terminal Block 19 DC Negative Battery Terminal
14 AC Output Lever Terminal Block 20 Fan
15 AC Input Lever Terminal Block 21 DC Positive Battery Terminal
16 Input Circuit Breaker 22 Output Circuit Breaker
17 Communication Port (CAN Bus)
External View Internal View

14
Wiring Diagram
Wiring Diagram
WARNING
please read the instructions carefully
Before working on this product.
CHARGER INPUT
PROTECT
INVERTER OUTPUT
PROTECT
BTS
NO
NC
DRY
OUTPUT INPUT
N
NL
L
CONTACT
REMOTE
C
CAN
High voltage,in order to avoid risks,
AC/INV
OFF
ON
CHC FAULT
Pure Sine Wave Inverter Charger
GITIVE
ATIVE
Remote control
Temperature sensor
Ground
Negative (DC)
Positive (DC)
Shore Power or Generator
(120V Single Phase, 40A Max.)
AC Load Center
AC Loads
(120V Single Phase, 30A Max.)
Battery System (12V)
DC Fuse
(400A)
Chassis Ground Lug
+
Wired Remote Control
ON ERR
RMS-P2
Neutral wire (AC)
Live wire (AC)
NOT
E
zDo not use the temperature sensor on a LiFePO4 (LFP) battery which comes with a Battery
Management System (BMS).

15
Recommended Cable Sizing
Recommended Cable Sizing
Cable Cable Length (ft) / (m) Recommended Cable Size
AC Output
0 ft to 10 ft (0 m to 3 m) 8 AWG
11 ft to 20 ft (3 m to 6 m) 6 AWG
21 ft to 30 ft (6 m to 9 m) 6 AWG
AC Intput
0 ft to 10 ft (0 m to 3 m) 8 AWG
11 ft to 20 ft (3 m to 6 m) 6 AWG to 8 AWG
21 ft to 30 ft (6 m to 9 m) 6 AWG
NOT
E
zThe cable specifications listed above account for critical, less than 3% voltage drop and may
not account for all configurations.

16
Components & Tools
Components & Tools
CAUTIO
N
zThe adapter cable used in this manual can be made by yourself or purchased from renogy.
com by searching names in Recommended Components.
Recommended Components
Battery Scenario A: REGO Battery Kit
REGO 12V 400Ah Lithium Iron Phosphate Battery
System Combiner Box Accessory Set Positive / Negative Busbars Accessory Set
REGO 4 Ports 400A System Combiner Box Positive / Negative Busbars
DC-DC Charger
Inverter
Battery Adapter Cable 4/0 AWG
(Anderson 350 Connector to
Ring Terminal Adapter Cable or
Ring Terminal Adapter Cable)
Battery Inverter Cable 4/0 AWG
(Ring Terminal Adapter Cable)

17
Components & Tools
Battery Scenario B: Normal Battery Kit
Normal Battery with +/- Bolts Battery Inverter Cable 4/0 AWG
(Ring Terminal Adapter Cable)
+
-
Required Tools
Wrench (10 mm) Wrench (14 mm) Measuring Tape Insulation Tape
10mm
10mm
10mm
14mm
14mm
14mm
3
4
5
6
Phillips Screwdriver
(6 mm)
Slotted Screwdriver
(6 mm)
Socket Wrench
(12 mm) Wire stripper
Bare Wire
Grounding (6 AWG to 8 AWG) AC Output x 3

18
Components & Tools
NOT
E
zThe AC Output Cable Grommet has an inner diameter of 13 mm. Properly select the AC
cable size and ensure it can run through the grommet.
zThe DC Positibe/Negative Terminals use M8 Studs. Select the appropriate ring terminal.
zRead Recommended Cable Sizing in this manual, and select the appropriate cables
according to actual use.

19
Inspection
Inspection
Inspecting Inverter Charger
AC/ INV CHC
OFF
ON
FAULT
ARNING
pleaseread the instructions carefully
Beforeworking on this product.
Highvoltage,in order to avoid risks,
Pure Sine Wave Inverter Charger
1. Inspect the inverter charger for any visible damage including
cracks, dents, deformation, and other visible abnormalities.
All connector contacts shall be clean, dry, and free of dirt
and corrosion.
WARNIN
G
zDo not use the inverter charger if it has any visible damage.
Environment
Install the inverter charger on a flat surface indoors protected from direct sunlight, high
temperature, and water. Make sure there is good ventilation.
Make sure that the inverter charger is installed in a place at ambient temperature from -4°F to
104°F or -20°C to 40°C and relative humidity between 0% and 95% no condensation.
NOT
E
zInstall the inverter charger as close to the battery as possible to avoid voltage drops due to
long cables.
WARNIN
G
zRisk of explosion! Never install the inverter charger in a sealed enclosure with flooded
batteries! Do not install it in a confined area where battery gases can accumulate.
Inspecting Inverter Charger Environment Placement Checking Battery

20
Inspection
Placement
The inverter charger can be fixed vertically (terminals facing down) to a wall or horizontally to
the floor.
AC/INV CHC
OFF
ON
FAULT
ARNING
pleasereadthe instructions carefully
Beforeworkingon this product.
Highvoltage,inorder to avoid risks,
PureSine Wave Inverter Charger
PureSine Wave Inverter Charger
AC/ INV
ON
OFF CHC FAULT
3000W
PureSine Wave Inverter Charger
AC/ INV
ON
OFF
CHC FAULT
3000W
PureSine Wave Inverter Charger
3000W
AC/ INV
ON
OFF
CHC FAULT
PureSine Wave Inverter Charger
3000W
AC/ INV
ON
OFF
CHC FAULT
PureSine Wave Inverter Charger
AC/ INV
ON
OFF
CHC FAULT
3000W
AC/INV CHC
OFF
ON
FAULT
ARNING
pleasereadthe instructions carefully
Beforeworkingon this product.
Highvoltage,inorder to avoid risks,
PureSine Wave Inverter Charger
≥178mm
(7in)
≥178mm
(7in)
≥254mm
(10in)
≥254mm
(10in)
1. Ensure enough space to avoid tangles and kinks of cables.
Allow at least 10 inches of clearance at the fan and at least
7 inches around each side. It is better to have a larger
ventilation gap. Do not obstruct the fan openings.
Inspecting Inverter Charger Environment Placement Checking Battery
