Renogy ONE Core User manual

USER MANUAL
VERSION A0
Core
RENOGY ONE
RSHGWSN-W02W-G1

Before Getting Started
The user manual provides important operation and maintenance instructions for Renogy ONE Core
(hereinafter referred to as Core).
Read the user manual carefully before operation and save it for future reference. Failure to observe the
instructions or precautions in the user manual can result in electrical shock, serious injury, or death, or
can damage the Renogy ONE Core, potentially rendering it inoperable.
zRenogy ensures the accuracy, sufficiency, and the applicability of information in the quick guide at
the time of printing due to continual product improvements that may occur.
zRenogy assumes no responsibility or liability for personal and property losses, whether directly and
indirectly, caused by the user’s failure to install and use the product in compliance with the user
manual.
zRenogy is not responsible or liable for failures, damages, or injuries resulting from repair attempted
by unqualified personnel, improper installation and operation.
zThe illustrations in the user manual are for demonstration purposes only. Details may appear
slightly different depending on product revision and market region.
zRenogy reserves the right to change the information in the quick guide without notice. For the
latest user manual, visit renogy.com.
Disclaimer
Renogy ONE Core User Manual © 2023 Renogy. All rights reserved.
RENOGY and are registered trademarks of Renogy.
zAll information in the user manual is subject to copyright and other intellectual property rights of
Renogy and its licensors. The user manual may not be modified, reproduced, or copied, in whole or
in part, without the prior written permissions of Renogy and its licensors.
zThe registered trademarks in the user manual are the property of Renogy. The unauthorized use of
the trademarks is strictly prohibited.
Online Manual
User ManualQuick Guide
DC Home App
DC Home App
Download on the

1. General Information ........................................................................................................................... 1
1.1. Symbols Used .............................................................................................................................................. 1
1.2. Introduction ................................................................................................................................................. 1
1.3. Key Features ................................................................................................................................................ 1
1.4. SKU................................................................................................................................................................. 1
2. Get to Know RENOGY ONE Core .........................................................................................................2
2.1. What’s In the Box? ..................................................................................................................................... 2
2.2. Required Tools ............................................................................................................................................ 2
2.3. Product Overview....................................................................................................................................... 3
2.4. System Setup ............................................................................................................................................. 4
3. Preparation .........................................................................................................................................5
3.1. Installation Site and Environment.......................................................................................................... 5
3.2. Checking Renogy ONE Core..................................................................................................................... 5
3.3. Checking DC Power ................................................................................................................................... 6
3.4. Extend the Power Cable ........................................................................................................................... 6
3.5. How to connect RS-485 Communication Devices (Optional) ...........................................................7
4. Installation ..........................................................................................................................................9
4.1. Place Renogy ONE Core on a Table......................................................................................................... 9
4.2. Mount Renogy ONE Core on a Wall ........................................................................................................10
5. Configure RENOGY ONE Core........................................................................................................... 13
5.1. Power On/Off .............................................................................................................................................13
5.2. Pairing with DC Home ..............................................................................................................................13
5.3. Add Devices ...............................................................................................................................................13
5.4. RV Leveling.................................................................................................................................................14
6. Troubleshooting................................................................................................................................ 15
7. Interoperability Matrix..................................................................................................................... 17
8. FAQ...................................................................................................................................................... 19
9. Dimensions and Specifications....................................................................................................... 21
9.1. Dimensions.................................................................................................................................................21
9.2. Technical Specifications..........................................................................................................................21
Maintenance..............................................................................................................................................23
Inspection .............................................................................................................................................................23
Cleaning ................................................................................................................................................................23
Storage.................................................................................................................................................................. 23
Table of Contents

Emergency Responses.............................................................................................................................24
Fire..........................................................................................................................................................................24
Flooding................................................................................................................................................................. 24
Smell ......................................................................................................................................................................24
Noise ......................................................................................................................................................................24
Renogy Support ........................................................................................................................................25
FCC & RSS ..................................................................................................................................................26
FCC Statement ....................................................................................................................................................26
FCC Radiation Exposure Statement................................................................................................................ 26
RSS Standard....................................................................................................................................................... 26
Privacy Policy ............................................................................................................................................27
Definitions............................................................................................................................................................. 27
Types of Data Collected ..................................................................................................................................... 27
Disclosure of Data............................................................................................................................................... 29
Service Providers ................................................................................................................................................30
Analytics ...............................................................................................................................................................30
Changes to This Privacy Policy.........................................................................................................................30
Contact Us............................................................................................................................................................30

— 1 —
1. General Information
1.1. Symbols Used
The following symbols are used throughout the user manual to highlight important information.
WARNING: Indicates a potentially dangerous condition which could result in injury or death.
CAUTION: Indicates a critical procedure for safe and proper installation and operation.
NOTE: Indicates an important step or tip for optimal performance.
1.2. Introduction
Renogy ONE Core provides a comprehensive solution for energy monitoring and analysis, enabling users
to monitor and analyze energy data at any time.
Thanks to the ONE Connect 2.0 technology, Renogy ONE Core allows energy monitoring both locally
through the in-built screen and remotely via Renogy ONE Portal and DC Home app.
Additionally, the ONE Core features an RV leveling system for optimal stability and can function as a
smart home hub, seamlessly connecting with other smart home appliances.
1.3. Key Features
z24/7 Energy Analysis
Monitor and analyze energy data anytime.
zWorldwide Monitoring
Remote energy monitoring anywhere through ONE Connect 2.0
zBuilt-in RV Leveling
Effortlessly adjust your RV’s position to achieve optimal stability and comfort.
zSmart Home Integration
Function as a central hub for your smart home, seamlessly connecting and controlling all your smart
home appliances.
zEasy Installation
Simple setup process that ensures the device is perfectly level, eliminating the need for repeated
adjustments.
zOver-the-Air (OTA) Updates
Stay up to date with the latest features and improvements through continuous over-the-air updates.
1.4. SKU
RENOGY ONE Core RSHGWSN-W02W-G1

— 2 —
2. Get to Know RENOGY ONE Core
2.1. What’s In the Box?
RENOGY ONE Core × 1 Mounting Screws × 4
(1 extra)
Power Cable (5 m) × 1
M3.5*14 mm
VERSION A0
Core
RSHGWSN-W02W-G1
RENOGY ONE
QUICK GUIDE
Quick Guide × 1
Make sure that all accessories are complete and free of any signs of damage.
2.2. Required Tools
Phillips Screwdriver (#1)
Insulation Tape
Skill Saw Impact Drill with Hole Saw, 2.17 in/55 mm
Tools are required only when the Core is flush mounted on a wall.
You can use either a skill saw or an electric drill with a hole saw.

— 3 —
2.3. Product Overview
█Front
LCD
On/O Button
█Rear
Mounting Holes
Mounting Holes
Power Port
Mounting Holes
Type-C Port
Bubble Level
Communication Port
Mounting Base

— 4 —
2.4. System Setup
Negative
Positive
DC
Communication
+
-
DC Power (8V to 60V) Devices (RS-485)5V, DC
+ -
HUB
You can choose either the Power Port or the Type-C port to supply Renogy ONE Core.

— 5 —
3. Preparation
3.1. Installation Site and Environment
To ensure proper running of the RV leveling function on Renogy ONE Core, ensure it is installed in a
spot with the screen pointing to the front, rear, left, or right side of the RV, vertically to the RV floor. It is
recommended that RV leveling blocks should be used during the leveling process.
90°
90°
90°
90°
-4°F to 158°F
-20°C to 70°C
0% to 95% RH
≤5000m
Altitude
KEEP DRY FRAGILE INDOOR
Install the Renogy ONE Core indoors and prevent its components from being exposed to direct
sunlight.
Do not expose Renogy ONE Core to flammable or harsh chemicals or vapors.
Keep Renogy ONE Core out of the reach of children.
Make sure that the Renogy ONE Core is installed with ambient temperature range from -4°F to
158°F or -20°C to 70°C.
Make sure that the Renogy ONE Core is installed in an environment with relative humidity
between 0% and 95% and no condensation.
To ensure quality wireless communication for Renogy ONE, keep it away from metal objects at a
minimum distance of 200 mm or 7.9 inches.
3.2. Checking Renogy ONE Core
Inspect the Renogy ONE Core for any visible damage including
cracks, dents, deformation, and other visible abnormalities. All
connector contacts shall be clean, dry, and free of dirt and corrosion.
Do not use Renogy ONE Core if it appears to be damaged.
There are no serviceable parts in Renogy ONE Core. Do not open, dismantle, repair, tamper with,
or modify it.
Wear proper protective equipment and use insulated tools during installation.
Do not dispose of Renogy ONE Core as household waste. Comply with local, state, and federal
laws and regulations and use recycling channels as required.

— 6 —
3.3. Checking DC Power
8V to 60V
Ensure that the connected DC power supply rates at 8V to 60V.
Connecting the Core to a power source beyond the range results in
a power-on failure or permanent damage to the Core.
Confirm the polarities of the devices before connecting Renogy ONE Core to a power supply. A
reverse polarity contact can result in damage to the Core, thus voiding the warranty.
Risk of electrical shock! Ensure the connected DC power is turned off before connecting it to the
Renogy ONE Core.
3.4.Extend the Power Cable
If the included power cable is not long enough for connecting Renogy ONE Core to your DC power

Recommended Tools & Accessories
Bare Wires (≥ 22 AWG) × 2Wire stripper
Confirm the polarities of the included cable and the extension one before connecting them. A
reverse polarity contact will result in abnormal operations. The extension cable should not exceed
10 meters (32.8 feet).
1. Cut the included power cable.

— 7 —
2. Strip off some of the insulation.
3. Strip some insulation off the extension cable, and connect the
cable to the included power supply cable.
4. Tape over the cutoff areas.
3.5. How to connect RS-485 Communication Devices (Optional)
Renogy ONE Core can communicate with Renogy energy devices in several ways:
1. Bluetooth wireless communication;
2. Wired communication based on RS-485 protocol;
You can choose an appropriate communication method according to the actual situation.
zFor Bluetooth wireless communication, communication wiring is not required.
zFor RS-485 communication, you need to wire Renogy ONE Core with energy devices.
Recommended Components & Accessories
RJ45 Ethernet Cable(s)
(CAT5 or above)
Renogy Communication Hub
(For Multiple Devices)
HUB
Renogy BT-1/BT-2 Bluetooth Module
(For Multiple Devices)
Bluetooth Module
LINK
POWER
2

— 8 —
Select the appropriate communication cable (sold separately) according to the distance between
devices. The communication cable should be less than 6 meters (19.6 feet).
█Only One Device
+
-
RS-485 port
RJ45 Ethernet Cable
█Multiple Devices (Wired Connection)
HUB
+ -
RJ45 Ethernet Cable
█Multiple Devices (Wireless Connection)
Renogy BT-1/BT-2
Bluetooth Module
HUB
+ -
RJ45 Ethernet Cable
POWER
LINK
BT-2
Bluetooth Module
When adding multiple devices to Renogy ONE Core through the Communication Hub, connect
every single device to Renogy ONE Core individually through the hub first, and then reconnect all
devices to the hub. Turn to the hub’s manual for more details.

— 9 —
4. Installation
You can place Renogy ONE Core on a table or mount it on a wall.
4.1. Place Renogy ONE Core on a Table
The package box is environmentally friendly. You can use it as a bracket to hold the Core when installing
it on the wall is not required.
The RV leveling function is unavailable on Core when it is placed on a table.
31 2
Battery Combiner Box
Power Cable
(included)
5V, DC
Type-C Cable (optional)
4A 4B
When installing the power cable, always connect the negative first, and then the positive.
You can connect Renogy ONE Core to a power supply through the included power cable or a
Type-C cable (not included).
Devices (RS-485)
+ -
HUB
RJ45 Ethernet Cable
(Max length: 6 m)
5
For details, see “3.5. How to connect RS-485 Communication Devices (Optional)”.

— 10 —
4.2.Mount Renogy ONE Core on a Wall
Please tear off quick guide mounting template or print this piece of paper, and paste it to the
mounting location for drilling holes. You can also draw your own Mounting Template based on the
dimensions indicated in the following image.
█Mounting Template #1 (Use an Impact Drill with a Hole Saw, 2.17 in/55 mm)
2.17 in (55 mm)
2.17 in
(55 mm)
█Mounting Template #2 (Use a Skill Saw)
2.17 in (55 mm)
0.9 in
(23 mm)
0.635 in
(16 mm)
0.635 in
(16 mm)
0.9 in
(23 mm)
0.635 in
(16 mm)
0.635 in
(16 mm)
2.17 in
(55 mm)

— 11 —
Mounting Screws
7 8
64 5
Tools are required only when the Core is flush mounted on a wall.
NOTE
The RV leveling function is unavailable on Core when it is placed on a table.
NOTE
Step 1 (A). Place Renogy ONE Core on a Table
123
The package box is environmentally friendly. You can use it as a bracket to hold the Core when installing it on the wall is
not required.
Required Tools
Phillips Screwdriver (#1) Insulation Tape Skill Saw or Electric Drill and Hole Saw (55mm)
Please tear o this piece of paper and paste it to the mounting location for drilling holes.
Mounting Template
2.17in (55mm)
2.17in
(55mm)
Please tear o this piece of paper and paste it to the mounting location for drilling holes.
Mounting Template
2.17in (55mm)
2.17in
(55mm)
Yellow Area
Please tear o this piece of paper and paste it to the mounting location for drilling holes.
Mounting Template
2.17in (55mm)
2.17in
(55mm)
Blue Area
Please tear o this piece of paper and paste it to the mounting location for drilling holes.
Mounting Template
2.17in (55mm)
2.17in
(55mm)
3A 3B
1 2
Battery Combiner Box
Power Cable
(included)
5V, DC
Type-C Cable
(optional)
9A 9B
When installing the power cable, always connect the negative first, and then the positive.
You can connect Renogy ONE Core to a power supply through the included power cable or a
Type-C cable (not included).

— 12 —
Devices (RS-485)
+ -
HUB
RJ45 Ethernet Cable
(Max length: 6 m)
10
For details, see “3.5. How to connect RS-485 Communication Devices (Optional)”.
Click
45°
11 12 13

— 13 —
5. Configure RENOGY ONE Core
5.1. Power On/Off
5s
Long press the On/Off Button for 5s to power the Core on or off.
5.2. Pairing with DC Home
For initial startup, follow the startup wizard on the Core to pair it with the DC Home app. Alternatively, go
to > System > Pair with App.
1 2
5.3. Add Devices
Renogy ONE Core can connect to Bluetooth, Bluetooth mesh, and Zigbee Renogy devices concurrently.
Internet
1 2 3

— 14 —
5.4. RV Leveling
> RV Leveling
1 2
RV leveling calibration on Renogy ONE Core is required each time the installation site for the Core
is changed.

— 15 —
6. Troubleshooting
Issue Possible Cause Solution
Power on failure
Reverse polarity contact
Check whether the positive and
negative polarities of the power
terminals are normally connected.
Renogy ONE Core damaged Contact our customer service
through renogy.com/contact-us/.
Failure to add devices
or smart accessories
The device is too far away from
Renogy ONE Core.
Move the device closer to Renogy
ONE Core.
zBluetooth: within 10 m in an open
environment.
zZigbee: within 50 m in an open
environment.
The smart accessories have been
connected to other devices.
Reset the smart accessories, and
redo adding. For details, see the user
manuals of specific accessories at
renogy.com/support/downloads.
The device or smart accessory is
incompatible with Renogy ONE
Core.
Use Renogy devices and smart
accessories.
Wi-Fi connection
failure
Unsupported Wi-Fi frequency band Ensure the Wi-Fi router is working on
the 2.4 GHz band.
WPA3 encryption Disable WPA3 encryption on the Wi-Fi
router.
Wrong password Enter the correct Wi-Fi SSID and
password.
Signal shielding
Ensure that there is no metal object
around Renogy ONE Core and the Wi-
Fi router because it may undermine
the wireless communication.
BT-1 or BT-2
communication failure Unstable communication quality
Unplug the BT-1 or BT-2 Bluetooth
module from the devices, and then
plug it to the devices again. Redo
device scanning on Renogy ONE Core
if necessary.
Laggy and
unresponsive
operations on the LCD
Improper power supply
Check the voltage of the power
supply. Make sure the voltage is 8V to
60V DC for the Power Port or 5V DC
for the Type-C port, and the voltage
should be stable.
Failure to find
Bluetooth devices
1. The Bluetooth device is powered
off.
2. The Bluetooth device has been
paired with DC Home app.
3. Bluetooth on the device is
turned off.
1. Power on the Bluetooth device.
2. Unpair the device from the app
first and then redo on Renogy ONE
Core.
3. Turn on Bluetooth on the device.

— 16 —
Issue Possible Cause Solution
Inaccurate or delayed
RV level data on both
the Core and DC Home
The RV is not parked on a level
surface during initial installation of
Renogy ONE Core.
Park the RV on a level surface, and
redo RV leveling on Renogy ONE Core.
The bubble is not centered in the
bubble level when you install the
base.
Park the vehicle on a level surface,
rotate and remove the Core from its
base. Readjust the base to ensure the
bubble is centered before redoing RV
leveling on the Core.
The performance of the built-
in 6-axis sensor is affected by
environmental factors such as
temperature.
Install the Renogy ONE Core in a well-
ventilated location to prevent RV
leveling data discrepancies due to
extreme temperatures.
Inaccurate or delayed
RV level data on DC
Home
Renogy ONE Core is placed too
far away from your phone or there
are obstacles around Renogy ONE
Core to affect normal Bluetooth
communication between the Core
and your DC Home app.
zEnsure there is no metal object
around Renogy ONE Core.
zReinstall Renogy ONE Core at a
site which is within a range of 10
meters of the driver’s cabin.
