ResMed Mirage Activa LT User manual

Mirage Activa™ LT
nasal mask
User Guide
English

i
Mirage Activa LT
A
1
2
3
4
5
6
7
9
10
11
12
8
B C
DE
13
6

ii
Mask components/ Composants du masque/
Piezas de la mascarilla/ Componentes da máscara
Item/ Article/
Artículo/ Item Description/ Description/ Descripción/ Descrição Part number/ Code produit/ Número
de parte/ Código
do produto
1 Mask frame/ Entourage rigide/ Armazón
de la mascarilla/ Armação da máscara
60180 (St)
60193 (S)
2 Dial/ Molette de réglage/ Disco/
Botão giratório
61289
3 Forehead support/ Support frontal/
Apoyo para la frente/ Suporte para a testa
16393
4 Forehead support pad/ Tampon frontal/
Almohadilla del apoyo para la frente/
Almofada do suporte para a testa
60123 (1)
60124 (10)
5 Activa LT Cushion & clip/ Bulle et clip/
Almohadilla y broche/ Almofada e
presilha
60198 (S)
60177 (M)
60178 (L)
60179 (LW)
6 Cushion clip/ Clip de la bulle/ Broche de
la almohadilla/ Presilha da almofada
60176 (St)
60197 (S)
7 Headgear clip/ Clip d’attache du harnais/
Broche del arnés/ Presilha do arnês
16569 (2)
16734 (10)
8Headgear/ Harnais/ Arnés/ Arnês 16118 (S)
16117 (M)
16119 (L)
9 Ports cap/ Bouchon d’entrées/ Tapón de
los puertos/ Tampa das portas
16570 (2)
16571 (10)
10 Swivel/ Pièce pivotante/ Pieza giratoria/
Peça giratória
16565
11 Elbow/ Coude/ Codo/ Cotovelo 16387
12 Vent/ Orifice de ventilation/ Ventilación/
Respiradouro
—
13 SoftGel Cushion & clip/ Bulle et clip/
Almohadilla y broche/ Almofada e
presilha
61631 (S)
61632 (M)
61633 (L)
61634 (LW)

iii
Item/
Article/
Artículo/
Item
Description/ Description/
Descripción/ Descrição Part number/ Code produit/ Número
de parte/ Código
do produto
A Complete system/ Système complet/
Sistema completo/ Sistema completo
60182 (S)
60148 (M)
60149 (L)
60150 (LW)
B Frame system/ Entourage complet/
Sistema de armazón/ Sistema da armação
60195 (S)
60172 (M)
60173 (L)
60174 (LW)
C Frame assembly/ Ensemble entourage/
Conjunto del armazón/ Conjunto da
armação
60175 (St)
60196 (S)
D Elbow assembly/ Ensemble coude/
Conjunto del codo/ Conjunto do cotovelo
16399
E SoftGel Cushion & clip/ Bulle et clip/
Almohadilla y broche/ Almofada e presilha
61631 (S)
61632 (M)
61633 (L)
61634 (LW)
Also available/ Également disponible/También está disponible/
Também disponível
A + E ConvertAble Pack 61604 (S)
61609 (M)
61615 (L)
61620 (LW)
S Small/ Petit/ Pequeña/ Pequeno(a)
M Medium/ Moyen/ Mediana/ Médio(a)
St Standard/ Standard/ Estándar/ Standard
L Large / Grand / Grande / Grande
LW Large Wide / Grand et large / Grande-Largo (GL) / Grande-Ancho (GA)

iv
Fitting/ Mise en place/ Colocación/ Colocação
12 3
45 6
78

v
Disassembly/ Démontage/ Desmontaje/ Desmontagem
Removal / Enlèvement du masque / Para quitarse la
mascarilla / Remoção
1 2 3
4 5 6
7 8 9
1 2

vi
Reassembly/ Remontage/ Montaje/ Remontagem
123
4 5 6
7
10
89
12
11

1
English
Mirage Activa™ LT
nasal mask
Thank you for choosing the Mirage Activa™ LT. The Mirage Activa LT is the first
in ResMed’s ConvertAble™ Series—offering a choice of two high performance
cushions (Mirage Activa LT and Mirage SoftGel) on the one durable frame. For
further information, refer to the ConvertAble Series section in this User Guide.
Intended Use
The Mirage Activa LT channels airflow noninvasively to a patient from a positive
airway pressure device such as a continuous positive airway pressure (CPAP)
or bilevel system.
The Mirage Activa LT is:
•to be used by adult patients (>66 lb/30 kg) for whom positive airway
pressure has been prescribed
•intended for single-patient re-use in the home and multipatient re-use in
the hospital/institutional environment.
Using your mask
When using your mask with ResMed CPAP or bilevel devices that have mask
setting options, refer to the Technical specifications section in this user guide
for mask selection options.
For a full list of compatible devices for this mask, see the Mask/Device
Compatibility List on www.resmed.com on the Products page under Service
& Support. If you do not have internet access, please contact your ResMed
representative.
WARNING
•The vent holes must be kept clear.
•Follow all precautions when using supplemental oxygen.
•Oxygen flow must be turned off when the flow generator is not
operating, so that unused oxygen does not accumulate within the flow
generator enclosure and create a risk of fire.
•At a fixed flow rate of supplemental oxygen flow, the inhaled oxygen
concentration varies, depending on the pressure settings, patient
breathing pattern, mask, point of application and leak rate.
Rx Only

2
•The technical specifications of the mask are provided for your clinician
to check that they are compatible with the flow generator. If used
outside specification or if used with incompatible devices, the seal
and comfort of the mask may not be effective, optimum therapy may
not be achieved, and leak, or variation in the rate of leak, may affect
the flow generator function.
•Discontinue using the mask if you have ANY adverse reaction to the
use of the mask, and consult your physician or sleep therapist.
•Using a mask may cause tooth, gum or jaw soreness or aggravate an
existing dental condition. If symptoms occur, consult your physician
or dentist.
•As with all masks, some rebreathing may occur at low CPAP
pressures.
•Refer to your CPAP or bilevel device manual for details on settings and
operational information.
•Remove all packaging before using the mask.
Cleaning your mask in the home
Your mask and headgear should only be handwashed by gently rubbing in
warm (approximately 86°F/30°C) water using mild soap. All components
should be rinsed well with drinking quality water and allowed to air dry out of
direct sunlight.
Daily/After each use:
•To optimize the mask seal, facial oils should be removed from the cushion
after use.
•Handwash the separated mask components (excluding headgear).
•If the vent requires cleaning use a soft bristle brush.
Weekly:
•Handwash the headgear. It may be washed without being disassembled.
WARNING
•Do not use aromatic-based solutions or scented oils (eg, eucalyptus
or essential oils), bleach, alcohol or products that smell strongly (eg,
citrus) to clean any of the mask components. Residual vapors from
these solutions can be inhaled if not rinsed thoroughly.They may also
damage the mask, causing cracks.

3
English
CAUTION
•If any visible deterioration of a mask component is apparent (cracking,
crazing, tears etc.), the mask component should be discarded and
replaced.
•Avoid connecting flexible PVC products (eg, PVC tubing) directly
to any part of this mask. Flexible PVC contains elements that can
be detrimental to the materials of the mask, and may cause the
components to crack or break.
Reprocessing the Mask between Patients
This mask should be reprocessed when used between patients.
Cleaning, disinfection and sterilization instructions are available from the
ResMed website, www.resmed.com/masks/sterilization/americas.
If you do not have internet access, please contact your ResMed
representative.
Troubleshooting
Possible reason Solution
Mask is uncomfortable
Headgear straps are too tight. Adjust the straps evenly. The forehead support
“anchors” your mask and should sit firmly on
your forehead.
Cushion incorrectly inflated. With the air turned off, adjust the straps so that
you can insert two fingers between your cheek
and the lower headgear strap.
Mask is too noisy
Cushion clip is not inserted
correctly.
Check that the cushion clip is correctly inserted
into the cushion, and that the cushion is
correctly clipped to the frame.
Ports cap or elbow incorrectly
inserted.
Check the the ports cap and elbow are correctly
inserted.
Vents are blocked or partially
blocked.
Clean vents according to instructions in
“Cleaning the Mask at Home”.
Air leaking around the face
Mask not positioned correctly. Reposition the mask upon the face.
Air leaking around the bridge of the
nose.
Wind the dial in.
Air leaking around the top of the lip. Wind the dial out.

4
The mask does not fit properly
Cushion could be the wrong size. Talk to your clinician.
Mask is incorrectly assembled. Reassemble the mask according to the
instructions in “Reassembly”.
Cushion may be dirty. Clean cushion according to instructions in
“Cleaning the Mask at Home”.
Cannot insert forehead support into mask frame
When assembling the mask, you
have inserted the dial into the frame
before the forehead support.
Push dial base onto a hard surface until the dial
comes out of the frame.
Technical Specifications
The mask system does not contain latex, PVC or DEHP materials.
Pressure–Flow
Curve
The mask contains passive venting to protect against rebreathing.
As a result of manufacturing variations, the vent flow rate may
vary.
0
5
0
5
20
25
30
35
40
45
50
4680246
82
0
Pressure
(cm H2O) Flow
(L/min)
419
8 28
12 34
16 40
20 45
Vent Flow Rate (L/min)
Mask Pressure (cm H2O)
Dead Space
Information
The dead space of the mask varies according to cushion size. It is
185 mL for the Medium size.
Therapy Pressure 4 to 20 cm H2O
Environmental
Conditions
Operating temperature: +41°F to 104°F (+5°C to +40°C)
Operating humidity: up to 95% non-condensing
Storage and transport temperature: -4°F to 140°F (-20°C to +60°C)
Storage and transport humidity: up to 95% non-condensing
Resistance Drop in pressure measured (nominal)
at 50 L/min: 0.1 cm H2O
at 100 L/min: 0.7 cm H2O
Gross
dimensions
S: 5.55”/141mm (H) x 3.58”/91mm (W) x 4.21”/107mm (D)
M, L, LW: 6.06”/154 mm (H) x 3.74”/95mm (W) x 4.6”/117 mm (D)
Mask fully assembled – no headgear.
Mask setting
options
Select ‘Activa’ (if available) otherwise select ‘Standard’ as the
mask option.
The manufacturer reserves the right to change these specifications without
notice.

5
English
Storage
Ensure that the mask is thoroughly clean and dry before storing it for any
length of time. Store the mask in a cool dry place out of direct sunlight.
Disposal
The mask does not contain any hazardous substances and may be disposed of
with your normal household refuse.
Symbols
Caution, consult accompanying documents;
LOT
Batch Code;
REF
Catalogue Number; European Authorised Representative;
Temperature limitation; Humidity limitation; Does not contain
natural rubber latex; Manufacturer; Indicates a Warning or Caution and
alerts you to a possible injury or explains special measures for the safe and
effective use of the device. Keep away from rain; This way up;
Fragile, handle with care.
Limited warranty
ResMed Ltd (hereafter ’ResMed’) warrants that your ResMed mask system
(including mask frame, cushion, headgear and tubing) shall be free from
defects in material and workmanship from the date of purchase for the period
of 90 days or in the case of disposable masks the maximum use period.
This warranty is only available to the initial consumer. It is not transferable.
If the product fails under conditions of normal use, ResMed will repair or
replace, at its option, the defective product or any of its components.
This limited warranty does not cover: a) any damage caused as a result of
improper use, abuse, modification or alteration of the product; b) repairs
carried out by any service organization that has not been expressly authorized
by ResMed to perform such repairs; and c) any damage or contamination due
to cigarette, pipe, cigar or other smoke.
Warranty is void on product sold, or resold, outside the region of original
purchase.
Warranty claims on defective product must be made by the initial consumer at
the point of purchase.
This warranty replaces all other expressed or implied warranties, including any
implied warranty of merchantability or fitness for a particular purpose. Some
regions or states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.

6
ResMed shall not be responsible for any incidental or consequential damages
claimed to have resulted from the sale, installation or use of any ResMed
product. Some regions or states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation may not apply to
you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from region to region. For further information on your
warranty rights, contact your local ResMed dealer or ResMed office.

1
Rx Only
Cushion & clip / Bulle et
clip/ Almohadilla y broche/
Almofada e presilha
61631 (S)
61632 (M)
61633 (L)
61634 (LW)
Cushion clip/ Clip
de la bulle/ Broche
de la almohadilla/
Presilha da
almofada
60176 (St)
60197 (S)
Mirage™ SoftGel
nasal mask / masQUE nasal / masCaRIlla nasal /
mÁsCaRa nasal
User information
English

2
English
Please read this information in conjunction with your Mirage ActivaTM LT User
Guide when changing your Mirage Activa LT cushion to the Mirage SoftGel
cushion.
Intended use
The Mirage SoftGel channels airflow noninvasively to a patient from a positive
airway pressure device such as a continuous positive airway pressure (CPAP)
or bilevel system.
The Mirage SoftGel is:
•to be used by adult patients (> 66 lb/30 kg) for whom positive airway
pressure has been prescribed
•intended for single-patient re-use in the home environment and
multipatient re-use in the hospital/institutional environment.
Troubleshooting
Problem/possible
cause Solution
Mask is uncomfortable
Headgear straps are too
tight.
Adjust straps evenly. The forehead support ‘anchors’ your
mask and should sit firmly on your forehead.
Fit is too tight. Wind out dial.
Technical specifications
Dead space information Physical dead space is the empty volume of the mask to
the end of the swivel. Using the large cushions it is 145
mL.
Resistance Drop in pressure measured (nominal)
at 50 L/min: 0.3 cm H2O
at 100 L/min: 0.9 cm H2O
Gross dimensions Large: Mask fully assembled - no headgear
6.10“ (H) x 3.58“ (W) x 4.65“ (D)
(155 mm (H) x 91 mm (W) x 118 mm (D))
Mask setting options Select ‘ACTIVA ’ (if available), otherwise select
‘STANDARD’ as the mask option.

6
Fitting and assembly / Ajustement et montage /
Colocación y montaje / Encaixe e montagem
1
4
6 7
109
3 5
8
2

Manufacturer:
ResMed Ltd 1 Elizabeth Macarthur Drive Bella Vista NSW 2153 Australia
Distributed by:
ResMed Corp 9001 Spectrum Center Boulevard San Diego CA 92123 USA
ResMed (UK) Ltd 96 Milton Park Abingdon Oxfordshire OX14 4RY UK
See www.resmed.com for other ResMed locations worldwide.
For patent information, see www.resmed.com/ip.
Mirage and Activa are trademarks of ResMed Ltd and are registered in U.S. Patent
and Trademark Office.
© 2012 ResMed Ltd.

Global leaders in sleep and respiratory medicine www.resmed.com
608307/2 2012-04
MIRAGE ACTIVA LT
USER
AMER - ENG
12
34
56
7
608307
