ResMed S7 Lightweight User manual

trim length to suit manual spine width
USER’SMANUAL
RESMED
Reorder number: 308167/1 04 05
308167r1Manual Cover.p65 6/05/2004, 2:03 PM1

Manufactured by:
ResMed Ltd 97 Waterloo Road North Ryde NSW 2113 Australia
Tel: [phone] or 1 800 658 189 (toll free) Fax: [phone] Email: [email protected]
Distributed by:
ResMed Corp 14040 Danielson Street Poway CA 92064-6857 USA
Tel: [phone] or 1-800-424-0737 (toll free) Fax: [phone] Email: [email protected]
US DESIGNATED AGENT: ResMed Corp
EU AUTHORIZED REPRESENTATIVE: ResMed (UK) Ltd
Internet: www.resmed.com
Protected by patents: US 4944310, US 5199424, US 5522382, US 6705315. Other patents pending.
Protected by design registrations: AU 147283, AU 147335, AU 147336, AU 154957, CH 128.709, CH 128.710, CH
128.711, DE 40202007, DE 40202008, DE 40201723, DE 40202020, ES 153514, ES 153515, ES 153516, ES 153518,
ES 156136, FR 02 1407, GB 3001791, GB 3001819, GB 3001820, GB 3001821, JP 1164087, JP 1164265, JP 1164266,
JP 1164267, SE 75598, SE 75599, SE 75600, SE 75715, US D467335, US D468011, US D476077, US D477868, US
D487311. Other designs pending
S7, HumidAire 2i, Mirage, Protégé, and
Ultra Mirage are trademarks of ResMed Ltd.
© 2004 ResMed Ltd.
308167r1.book Page 3 Friday, May 7, 2004 1:40 PM

iii
CONTENTS
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DEFINITIONS 1
USER/OWNER RESPONSIBILITY 1
MEDICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
WHAT ARESMED S7™ LIGHTWEIGHT UNIT ISFOR 1
TELL YOUR DOCTOR IF... 1
WARNINGS 2
CAUTIONS 3
THE RESMED S7 LIGHTWEIGHT SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . 5
RESMED S7 LIGHTWEIGHT COMPONENTS 5
MASKS 6
HUMIDIFIER 6
PREPARING FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SETTING UPTHE RESMED S7 LIGHTWEIGHT 9
FEATURES OF THE RESMED S7 LIGHTWEIGHT 14
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
STARTING TREATMENT 17
STOPPING TREATMENT 17
HELPFUL HINTS 18
CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
DAILY 19
WEEKLY 19
PERIODICALLY 19
REPLACING THE AIR FILTER 20
SERVICING 20
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
SYSTEM SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
308167r1.book Page iii Friday, May 7, 2004 1:40 PM

iv
308167r1.book Page iv Friday, May 7, 2004 1:40 PM

1
ENGLISH
INTRODUCTION
INTRODUCTION
DEFINITIONS
This manual contains special terms that appear in the text to draw your attention to
specific and important information.
!
WARNING
Alerts you to possible injury.
!
CAUTION
Explains special measures for the safe and effective use of the device.
Note: Is an informative or helpful note.
USER/OWNER RESPONSIBILITY
The user or owner of this system shall have sole responsibility and liability for any injury
to persons or damage to property resulting from:
•operation which is not in accordance with the operating instructions supplied
•maintenance or modifications carried out unless in accordance with authorized
instructions and by authorized persons.
Please read this manual carefully before use.
MEDICAL INFORMATION
WHAT ARESMED S7™ LIGHTWEIGHT UNIT ISFOR
The RESMED S7™ LIGHTWEIGHT system is intended for the treatment of adult patients
with obstructive sleep apnea (OSA).
!
CAUTION
In the USA, federal law restricts this device to sale by or on the order of a physician.
TELL YOUR DOCTOR IF...
You must tell your doctor, and CPAP (continuous positive airway pressure) therapy
must not be used, if you have any of the following conditions:
•pneumothorax or pneumomediastinum (air in the pleural cavity or mediastinum)
•severe heart failure, low blood pressure, or dehydration
•surgery to the brain, middle or inner ear, pituitary gland, or sinuses
•respiratory distress syndrome
•middle ear infection or perforated ear drum
•severe nosebleed.
308167r1.book Page 1 Friday, May 7, 2004 1:40 PM

2
WARNINGS
CPAP therapy should be used with caution if you have any of the following conditions:
•respiratory failure
•cavities or cysts in the lung (called bullae, and usually due to emphysema), or
previous history of pneumothorax
•previous history of severe nosebleed
•sinus infection.
Tell your doctor if you have any of these conditions. Your doctor will advise you
whether the likely benefits of CPAP therapy outweigh the expected risks.
Special care should be exercised if you are dehydrated, or may become dehydrated,
for example as a result of fluid restriction or diuretic therapy (including changes in
therapy).
Discontinue therapy and seek medical advice if, during therapy or when you start
therapy each night, you feel faint or light-headed.
The following are general warnings that pertain to your use of a RESMED S7
LIGHTWEIGHT unit. Specific warnings appear next to the relevant instructions in the
manual.
•This is NOT a life support device. It may stop operating with power failure
or if a fault occurs in the unit.
•The air flow for breathing produced by this device can be as much as 11oF (6oC)
higher than the temperature of the room. Caution should be exercised if the room
temperature is warmer than 90oF (32oC).
•The RESMED S7 LIGHTWEIGHT unit should only be used with masks (and
connectors)*recommended by ResMed, or by your physician or respiratory
therapist. A mask should not be used unless the RESMED S7 LIGHTWEIGHT unit is
turned on and operating properly. The vent hole or holes associated with the
mask should never be blocked.
Explanation: The RESMED S7 LIGHTWEIGHT unit is intended to be used with
special masks (or connectors)*which have vent holes to allow continuous flow of
air out of the mask. When the device is turned on and functioning properly, new
air from the device flushes the exhaled air out through the mask vent holes.
However, when the device is not operating, insufficient fresh air will be provided
through the mask, and the exhaled air may be rebreathed. Rebreathing of exhaled
air for longer than several minutes can, in some circumstances, lead to suffocation.
This applies to most models of CPAP devices.
•The RESMED S7 LIGHTWEIGHT unit should only be connected to the components,
humidifiers, or accessories specified in this manual. Connection of other items may
result in injury, or damage to the RESMED S7 LIGHTWEIGHT unit.
•At low pressures, the flow through the exhalation ports of your mask may not
clear all exhaled gas from the tubing. Some rebreathing may occur.
•This device is not intended for use with supplemental oxygen.
* Ports may be incorporated in the mask or in connectors that are near the mask.
308167r1.book Page 2 Friday, May 7, 2004 1:40 PM

3
ENGLISH
MEDICAL INFORMATION
•Explosion hazard—do not use in the vicinity of flammable anesthetics.
•Blocking the hose while in operation could lead to overheating of the device.
WARNINGS RELATED TO OXYGEN USE
!
WARNING
If oxygen is used with this device, the oxygen flow must be turned off when the device
is not operating.
Explanation: when the device is not in operation and the oxygen flow is left on,
oxygen delivered into the air delivery tubing may accumulate within the device
enclosure and create a risk of fire. This applies to most types of CPAP machines.
•Oxygen supports combustion. Oxygen should not be used while smoking or in the
presence of an open flame.
•Always ensure airflow is being generated by the device before the oxygen supply is
turned on.
•Always turn the oxygen supply off before stopping the airflow from the device.
Note: At a fixed rate of supplemental oxygen flow, the inhaled oxygen concentration will
vary, depending on where the oxygen is introduced, the pressure settings, patient breathing
pattern, mask selection, and leak rate.
WARNINGS RELATED TO TREATMENT
!
WARNING
•If you stop your CPAP treatment, your sleep apnea will return.
•Always consult your clinician if you expect to be in a situation where you cannot
use your RESMED S7 LIGHTWEIGHT unit.
•If you are admitted to a hospital or prescribed any other form of medical
treatment, always inform the medical staff that you are being treated with CPAP. It
is also important to contact the clinician who is treating you for sleep apnea.
•If you experience an infection of the upper respiratory tract, middle ear, or sinuses,
contact your clinician before continuing your CPAP treatment. You may be
advised to stop treatment until the infection has cleared. If you continue with
treatment during an infection, be sure to clean your mask and tubing after every
use.
CAUTIONS
The following are general cautions. Specific cautions appear next to the relevant
instructions in the manual.
•Do not open the RESMED S7 LIGHTWEIGHT case. There are no user serviceable
parts inside. Repairs and internal servicing should only be performed by an
authorized service agent.
308167r1.book Page 3 Friday, May 7, 2004 1:40 PM

4
POSSIBLE SIDE EFFECTS
The RESMED S7 LIGHTWEIGHT flow generator helps you have a good night’s sleep.
However, you need to be aware of possible problems that may arise during CPAP
treatment.
!
WARNING
Consult your clinician immediately if you experience any of the following symptoms
during your CPAP treatment:
•headache
•middle ear or sinus discomfort
•chest pain
•dryness of the nose, mouth, or throat
•feeling bloated due to air swallowing
•air continually leaking out of the mouth while sleeping
•recurrence of any sleep apnea symptoms while on CPAP.
Skin irritation may occur from sensitivity to the mask materials or from excessively tight
headgear straps. A correctly fitted mask and appropriately adjusted straps will often
prevent skin irritation. If problems persist, contact your clinician for advice.
308167r1.book Page 4 Friday, May 7, 2004 1:40 PM

5
ENGLISH
THE RESMED S7 LIGHTWEIGHT SYSTEM
THE RESMED S7 LIGHTWEIGHT SYSTEM
RESMED S7 LIGHTWEIGHT COMPONENTS
Please identify and familiarize yourself with the following components of the RESMED
S7 LIGHTWEIGHT unit:
ACCESSORIES
The following accessories may be purchased separately.
RESMED S7 LIGHTWEIGHT ACCESSORIES
HUMIDIFIER ACCESSORIES
(HUMIDAIRE and ResMed PASSOVER only)
ResMed S7 Lightweight unit
Handle
LCD
Control panel
Removable front cap
Front view
Air tubing, 6’6" (2 m) Power cordCarry bag
Air outlet
screen
Air tubing,
9’10" (3 m)
Medium air tubing
21" (52 cm) for
humidifier connection
308167r1.book Page 5 Friday, May 7, 2004 1:40 PM

6
MASKS
You will also need a ResMed mask system (supplied separately).
The following ResMed mask systems are recommended for use with the RESMED S7
LIGHTWEIGHT:
HUMIDIFIER
A humidifier may be required if you are experiencing dryness of the nose, throat, or
mouth. The RESMED S7 LIGHTWEIGHT is compatible for use with the following
humidifiers:
!
WARNING
Only the HumidAire 2i, HumidAire 2iC, HumidAire heated humidifier, and the
ResMed Passover are compatible for use with the ResMed S7 Lightweight. Please
MIRAGE®MASK
MIRAGE®FULL FACE MASK
ULTRA MIRAGE™
MIRAGE®FULL FACE MODULAR MASK
PROTÉGÉ™ MASK
MASK SERIES 2
MASK
MIRAGE VISTA™
MASK
HUMIDAIRE 2i heated humidifier HUMIDAIRE 2iC passover humidifier
HUMIDAIRE heated humidifier ResMed PASSOVER humidifier
308167r1.book Page 6 Friday, May 7, 2004 1:40 PM

7
ENGLISH
THE RESMED S7 LIGHTWEIGHT SYSTEM
refer to “Warnings” on page 2.
308167r1.book Page 7 Friday, May 7, 2004 1:40 PM

8
308167r1.book Page 8 Friday, May 7, 2004 1:40 PM

9
ENGLISH
PREPARING FOR USE
PREPARING FOR USE
SETTING UPTHE RESMED S7 LIGHTWEIGHT
1Place the RESMED S7 LIGHTWEIGHT unit on a table near the head of your bed.
!
CAUTION
Be careful not to place the device where it can be bumped or where someone is
likely to trip over the power cord.
Note: The ResMed S7 Lightweight unit may be placed on the floor beside or underneath
your bed. Ensure that the area is free from dust and clear of bedding, clothes, or any other
objects that could block the air inlet.
2Connect the power cord to the socket at the rear of the flow generator. Plug the other
end of the power cord into a power outlet.
!
WARNING
•Make sure the power cord and plug are in good condition and the equipment is
not damaged.
•The air filter cover protects the device in the event of accidental liquid spillage
onto the device. Ensure that the air filter and air filter cover are fitted at all
times.
3Connect one end of the air tubing firmly onto the air outlet of the unit.
!
WARNING
Only ResMed air tubing should be used with your flow generator. A different type
of air tubing may alter the pressure you actually receive reducing the effectiveness
of your treatment.
4Assemble your mask system according to the mask user instructions.
308167r1.book Page 9 Friday, May 7, 2004 1:40 PM

10
5Connect your mask system to the free end of the air tubing.
The RESMED S7 LIGHTWEIGHT is now ready for use. To start treatment, see
“Operating Instructions” on page 17.
HUMIDIFIER USE
Notes
•The ResMed S7 Lightweight has no humidifier setting options.
•The ResMed S7 Lightweight does not have the Warm-Up and cooling down features
mentioned in the HumidAire 2i User’s Manual. When the HumidAire 2i is attached to
the ResMed S7 Lightweight, you may begin therapy immediately.
HUMIDAIRE 2i
The HUMIDAIRE 2i attaches to the front of the RESMED S7 LIGHTWEIGHT to provide
heated humidification. No other accessories are required for its use.Please refer to
the HumidAire 2i User’s Manual for details.
308167r1.book Page 10 Friday, May 7, 2004 1:40 PM

11
ENGLISH
PREPARING FOR USE
HUMIDAIRE 2iC
The HUMIDAIRE 2iC attaches to the front of a RESMED S7 LIGHTWEIGHT unit to
provide passover humidification. No other accessories are required for its use. Please
refer to the HumidAire 2iC User’s Manual for details.
HUMIDAIRE AND RESMED PASSOVER HUMIDIFIERS
Medium size 21" (52 cm) air tubing is a necessary accessory for connecting the RESMED
S7 LIGHTWEIGHT unit to the HUMIDAIRE and ResMed PASSOVER humidifiers.
1Fill the HUMIDAIRE or PASSOVER with water as described in the humidifier manual.
2HumidAire Users Place the filled water chamber inside the HUMIDAIRE. Connect
the medium 21" (52 cm) air tubing to the left connector port, and the long air tubing
6’6" or 9’10" (2 m to 3 m) to the right connector port on the humidifier. Close the
HUMIDAIRE lid.
ResMed Passover Users Connect the medium 21in (52 cm) air tubing to the left
connector port, and the long air tubing 6’6" or 9’10" (2 m to 3 m) to the right
connector port on the humidifier.
HumidAire ResMed Passover
Medium (21in)
air tubing
Long
air tubing
Medium (21in)
air tubing
Long
air tubing
308167r1.book Page 11 Friday, May 7, 2004 1:40 PM

12
3Place the RESMED S7 LIGHTWEIGHT on top of the HUMIDAIRE or PASSOVER. Do not
place the RESMED S7 LIGHTWEIGHT unit underneath the humidifier. (This is to avoid
water spilling into the unit.)
4HumidAire Users Connect the free end of the medium air tubing to the air outlet
of the RESMED S7 LIGHTWEIGHT.
ResMed Passover Users Connect the free end of the medium air tubing to the air
outlet of the RESMED S7 LIGHTWEIGHT.
5Connect the mask system to the free end of the long air tubing. The final assembly
should look like this:
6HumidAire Users Plug the HUMIDAIRE power cord into a power outlet and turn
the power on.
HumidAire ResMed Passover
HumidAire ResMed Passover
HumidAire ResMed Passover
308167r1.book Page 12 Friday, May 7, 2004 1:40 PM

13
ENGLISH
PREPARING FOR USE
7Connect the power cord to the socket at the rear of the RESMED S7 LIGHTWEIGHT.
Plug the other end of the power cord into a power outlet and turn the power on.
!
WARNING
Make sure that the power cord and plug are in good condition and the equipment
is not damaged.
8The RESMED S7 LIGHTWEIGHT is now ready for use with the HUMIDAIRE or ResMed
PASSOVER.
ALTITUDE COMPENSATION
Changes in altitude will affect the pressure delivered by the RESMED S7 LIGHTWEIGHT.
The device has a feature which compensates for these changes in altitude.
As you move or travel with the RESMED S7 LIGHTWEIGHT to areas of different
altitudes, you will need to adjust the altitude compensation setting in the device. To
change the altitude compensation setting, see “Using the Menus” on page 14.
There are three altitude settings to choose from:
For example, if you are at an altitude of 3107 ft (947 m), your altitude compensation
setting would be 2001–4000 ft (611–1219 m), as 3107 ft falls within that range.
Note: If you are above 7000 ft (2134 m), consider consulting your clinician.
Altitude Settings
0–2000 ft (0–610 m)
2001–4000 ft (611–1219 m)
4001–7000 ft (1220–2134 m)
308167r1.book Page 13 Friday, May 7, 2004 1:40 PM

14
FEATURES OF THE RESMED S7 LIGHTWEIGHT
LCD SCREEN AND KEYPAD
The control panel of the RESMED S7 LIGHTWEIGHT includes an LCD screen and
keypad.
The RESMED S7 LIGHTWEIGHT keypad has the following keys:
To assist you in adjusting the RESMED S7 LIGHTWEIGHT the keypad is equipped with
a backlight. The keypad is backlit with power-up of the unit. Under normal operation,
the keypad remains illuminated to indicate that the device is ON.
USING THE MENUS
The ResMed S7 LIGHTWEIGHT unit provides a set of functions which are arranged in
menus. Via the LCD screen, the menus allow you to view and change the settings for
a particular function. You can access the menus when the Ramp screen is displayed.
After the Welcome Screen appears and device self-checks are complete, the Ramp
screen appears. In the Ramp screen, you can immediately set a ramp time. Ramp time
is the period during which the pressure increases from a low comfortable pressure to
Key Function
Front • Starts or stops treatment
Up/Down • Allows you to scroll through the ResMed S7 LIGHTWEIGHT menus
and setting options.
Left • Performs the function indicated by the guiding text displayed
above it on the LCD screen. Guiding text includes menu,
change,and apply.
Right • Performs the function indicated by the guiding text displayed
above it on the LCD screen. Guiding text includes exit and
cancel.
Start/Stop
LCD screen
Front Key
Up/down key
Right key
Left key
Start/Stop
308167r1.book Page 14 Friday, May 7, 2004 1:40 PM

15
ENGLISH
PREPARING FOR USE
the prescribed treatment pressure. Ramp time can be altered in 5 minute increments
(from 0min to a maximum ramp time set by your clinician) by using the Up/Down
key.
See Figure 1 for a summary of the RESMED S7 LIGHTWEIGHT menus.
•To access the RESMED S7 LIGHTWEIGHT menus:
Press the Left key (menu) while the Ramp screen is displayed.
•To scroll through items within a menu:
Press the Up/Down key
•To change a setting option for a function:
1. Press the Left key (change)
2. Press the Up/Down key until the desired setting option appears.
3. Press the Left key (apply) to select the setting option.
•To exit without changing options:
Press the Right key (cancel)
•To exit out of a menu or submenu:
Press the Right key (exit)
Figure 1: ResMed S7 Lightweight Menu Series
MENU FUNCTIONS
The RESMED S7 LIGHTWEIGHT menu functions are summarized in Table 1 with a brief
description of what each function does and the available setting options. To access
these functions see “Using the Menus” on page 14.
SETTINGS MENU
The Settings Menu allows you to view and change certain operating features of the
RESMED S7 LIGHTWEIGHT unit.
RAMP: 10min
menu
ALT: 0-2000ft
change exit
exit
USED HRS: 8888
ResMed S7 Lightweight
Ramp screen
308167r1.book Page 15 Friday, May 7, 2004 1:40 PM

16
Table 1: Settings Menu Functions
Function Function Description Setting Options
Altitude
(Compensation)
Sets the altitude compensation
range.
0–2000 ft (0–610 m),
2001–4000 ft (611–1219 m),
4001–7000 ft (1220–2134 m)
Used hours Displays the total number of
treatment hours.
(View only)
308167r1.book Page 16 Friday, May 7, 2004 1:40 PM
