ResMed Swift FX Nano Assembly instructions

Small in size
BIG ON
COMFORT
Introducing Swift FX Nano, the new compact
nasal mask your patients have been waiting for.
Swift FX Nano
TM
NASAL MASK
Swift FX Nano for Her
TM
NASAL MASK
Global leaders in sleep and respiratory medicine www.resmed.com
Distributed by: ResMed Corp 9001 Spectrum Center Boulevard San Diego CA 92123 USA. ResMed (UK) Ltd 96 Jubilee Ave, Milton Park Abingdon Oxfordshire
OX14 4RW UK. See www.resmed.com for other ResMed locations worldwide. Swift, SoftEdge and Spring Air Technology are trademarks of ResMed Ltd and are
registered in the U.S. Patent and Trademark Office. © 2013 ResMed Ltd. Specifications may change without notice. 1016418/1 2013-06
ResMed Ltd
1 Elizabeth Macarthur Drive
Bella Vista NSW 2153 Australia
Fitting Guide
• Adjustthetopstrapfirstbypulling
thestrapthroughthebuckle,one
notchatatime,untilthemaskis
comfortablyoveryournose.
• Donotovertighten.
• Ensurebottomofcushionopening
alignswiththebottomofyournose
thenplacethemaskoveryournose.
• Thenpullheadgearoveryourheadso
itsitsmidwaybetweenearsandeyes.
1 2
• Thebackstrapshouldsitjustabove
theearsatthebackofthehead.
• Adjustbothfastenersonthefabric
backstrapatthesametime.
• Ensurebackstrapsitsoveryourhair.
3
• Checkforleakandadjustifneeded.
Ifanyairisleakingoutthenreadjust
thebackstrapbeforereadjusting
thetopstrap.
• Yourmaskisnowreadytouse.
6
• Adjustthenasalcushionuntilitsits
comfortablyonyournose.
• Connectthefreeendoftheshort
tubeassemblytotheairtubingof
yourdevice,thenturniton.
5
•Wrapeachofthesoftwraps
aroundeithersideofthe
headgear,foldingthetop
fasteneroverthelowerone.
•Thesoftwrapsshouldbe
positionedonyourcheeks,
withthefastenerson
theoutside.
OptionalSoftWraps
4
• Ensuremaskiscomfortablysealed.
For more details, refer to the Swift FX Nano
or Swift FX Nano for Her User Guide.

Small, light and appealing
Withitscompact,open-faceddesign,minimaltwo-pointheadgear
(noneedforrigidframesorforeheadsupport)lightweight,and
optionalsoftwraps,SwiftFXNanoprovidespatientswithcomfort
andarealsenseoffacialfreedom.
Sleepapneapatientsoftenlookforthesmallest,leastintrusiveand
mostcomfortablemasktheycanfind.Newpatientscannowenjoy
thecomfortoftheSwiftFXNanoinanappealingnewcompactsize.
SoftEdgeTM fabric back strap
is soft and comfortable, with
quick setting fasteners
Quick fitting headgear
with easy adjusting notches on the
top strap. Set once and forget!
All soft nasal cushion
with a dual-wall design and Spring-Air
TechnologyTM that is soft for the patient
while providing a comfortable seal
Ultra smooth ball-joint
with 360° unimpeded movement
for adaptive flexibility
‘Lock and key’
for easy attaching and
detaching of headgear
Size and name indicators
clearly identify the size and the
correct orientation of the mask
Two-point headgear
has only minimal contact
on the face and provides
excellent all round vision
Whisper-quiet diffuse venting
gently distribute air away from
the user and their bed partner
Spring-flex tubing
minimises any pull on the mask,
enhancing comfort on the face
Innovative cuff
decouples the turning force from elbow
to the short tube, allowing the tube to
move independently of the elbow Cushion tab hinges
adapt to improve flexibility
between headgear and cushion
Benefitsforyou
Builds on the strength of Swift FX
Swift FX Nano delivers the compact size, facial freedom, reliability and comfort
that the Swift name is famous for with the breathing ease of a nasal cushion.
Set up once and they’re set
It fits quickly and requires minimal or often no adjustment once fitted, saving time,
money and additional patient visits.
Simple to use and reassemble after cleaning
Swift FX Nano has fewer main parts than most other nasal masks (just three:
headgear, cushion and tube) and it is simple to use.
Maintains a comfortable seal
Its smooth 360° rotating ball-joint helps maintain seal effectively and provides
comfort with adaptive flexibility.
Designed for easy user acceptance
Swift FX Nano is light and compact with minimal headgear helping encourage
patients to accept and continue therapy.
Swift FX Nano /Swift FX Nano for Her 
Components
Benefitsforyourpatients
Light and natural
It provides the lightness of a Swift FX pillows mask with the natural breathing
comfort of a nasal mask.
Can easily wear glasses on therapy
Swift FX Nano provides uninterrupted vision, so patients can wear glasses
to comfortably watch TV, or read, while on therapy.
Choice of sleeping positions
Swift FX Nano is flexible during movement as the user sleeps, so patients
can sleep in a variety of different positions.
Surprisingly quiet performance
Advanced venting design diffuses airflow so the mask is quiet to
use—just 25 dBA.*
* Declared dual numbered noise emission values (with uncertainty 3 dBA) in accordance with ISO 4871.e1.
* Includes Standard or Wide cushion, Swift FX Nano headgear assembly, plus grey backstrap, soft wraps and frame assembly.
** Includes Small cushion, Swift FX Nano For Her headgear assembly, plus pink backstrap, soft wraps and frame assembly.
Swift FX Nano / Swift FX Nano for Her 
Masksystem
Soft wraps
(Grey)
61530 (2)
Soft wraps
(Pink)
61544 (2)
Headgear assembly
(includes silicon
headgear, backstrap
and soft wraps)
Grey: 62238 (1)
Pink: 62248 (1)
Cushions
62230 (Standard)
62281 (Wide)
62231 (Small)
Frame assembly (Grey)
(includes short tube,
elbow and swivel)
62236 (1)
62237 (10)
Frame assembly
(Pink)
62244 (1)
62245 (10)
Backstrap only
(Grey)
62290
Product Codes
APAC
Swift FX Nano mask system* (Standard) 62216
Swift FX Nano mask system* (Wide) 62218
Swift FX Nano for Her mask system** (Small) 62217
