ResMed Swift FX User manual

Swift™FX
NASAL PILLOWS SYSTEM
Dual-wall nasal pillows
seal on contact for a gentle,
comfortable seal, offer a wide
fit range and disperse air
gently to the nose
Soft, narrow cushion with
integrated flexible chamber
makes side sleeping
comfortable and helps
maintain seal during
movement
Ultra-smooth 360° rotating elbow
rotates with easy, fluid movement
for flexibility in tube positions
Quiet vents
diffuse and direct airflow
quietly away from the user
and bed partner
Spring-flex lightweight tube
stretches and bends uniquely
for increased stability without
the use of a tube retainer
Less mask. More you.
• Minimaldesignreinforcessenseof
freedom
•Unprecedentedsoftness,simplicity
andstability
• Flexible,fluidformfollowsfacial
contoursandusermovements
• Promotesearlytherapyacceptance
• Intuitive,virtuallyinstantfitting
• Stableperformance,evenat
highpressures
Size and name indicators
make it easy to identify the size as
well as the correct orientation of the mask
“Lock and key”
for easy attachment and
detachment of side straps
Flexible pillows with trampoline action
accommodate movement in multiple
directions while maintaining seal
Soft wraps
enhance comfort at the cheeks
Low-profile backstrap
with Velcro fasteners
offers easy,
fine adjustments
Simple top buckle
has clearly marked notches
for easy adjustment
Soft silicone headgear
embraces the face
gently and needs minimal
adjustment—default
setting fits most users

USER BENEFITS
Soft comfort, stable performance
• Thesoftdesignoftheentiresystem
enhances comfort.
• Dual-wallpillowsandflexiblecushionbase
maintain seal while adapting to movement.
• Theflexible,lightweighttubingreducespull
onthemaskandenhancesstability.
Patients may even forget it’s there
• Minimaldesignreinforcesthesenseof
freedom—it’s as much to do with how
the user feels as with how the mask looks
on their face.
Choice of sleeping positions
•Swift FX users can sleep on their side
ortheirback,positioningthetube
as desired.
Quiet performance for quiet sleep
• Innovativeventdesigndelivers
super-quietmaskperformance—
and gently disperses air away from patient
andbedpartner.
PROFESSIONAL BENEFITS
Intuitive, almost instant fit
• Savesvaluabletimeforcliniciansandsleep
professionals. Once the right pillow size is
selected, adjustment is minimal.
Stable seal at high pressures
• Uniquelydesigned,thesystemstaysinplace
and maintains seal effectively, even at high
treatment pressures.*
Easier therapy acceptance by patients
• Designedforinstantappeal,theSwiftFXis
anon-intimidatingmask,facilitatingearly
acceptance of therapy.
Reduced inventory, wide (>95%) fit range**
• Packedwiththreepillowsizestosuitmost
users, reducing inventory.
• AnExtraSmallsizeisalsoavailable.
Easy product handling
• Withveryfewparts,theSwiftFXiseasy
tocleanandassemble.
Convenient to recommend or prescribe
• Userguideandonlinesupportfacilitate
training for users and staff.
PRODUCT CODES
Swift FX Nasal Pillows System
Americas 61500
* Tested up to 20 cm H2O in clinical trials
** Based on ResMed’s market research
MASK HIGHLIGHT
Comfort all around
• Withminimalfacialcontactandunobtrusivedesign,the
SwiftFXmakestherapylessintimidatingandeasierto
acceptatanearlystage.
• Fromthetipofthenasalpillowstothesoftandsecure
sides,fromthecomfortingsoftwrapsto
thesmoothbackstrap…theSwiftFXissolightand
gentle,patientswillforgetit’sthere.
• Thesnugheadgearstrapsdotheworkofmaintaining
seal,sothefitfeelslooseandthere’snoneedtoover-
tightentheheadgear.

Swift™FX
NASAL PILLOWS SYSTEM
Shorttubeassembly
(shorttube,elbowandswivel)
61528 (1)
61527 (10)
Headgearassembly
(headgear,backstrap)
61529
Components Card
Complete system Frame system
61500(includesSmall(S),Medium(M) (noheadgear)
andLarge(L)pillows*) XS* 61510
S 61511
M61512
L 61513
Pillows
XS* 61520
S 61521
M 61522
L 61523
Softwraps
61530 (2)
*ExtraSmall(XS)pillowsareavailableseparately

T
I
P
Fitting Guide
• Holdingthepillowsatyournose,
pulltheheadgearoveryourhead.
• Headgearshouldsitmidway
betweentheearsandeyes.
• Adjustthetopstrapfirst.
• Pullthestrapthroughthebuckle
onenotchatatime.
• Donotover-tighten.
• SwiftFXpillowsaredesignedto
provideanaturalfit.
• Minoradjustmentcanhelpposition
thepillowsatthemostcomfortable
angleinthenose.
• ConnecttheSwiftFXshorttube
tothedeviceairtubing.
• SwiftFXisnowfittedandready
foruse.
Note: For additional information, refer to the Swift FX Nasal Pillows System User Guide.
54
• Adjustthebackstraptofine-tune
thefittingifnecessary.
• Donotover-tighten.
• Thebackstrapcanbepositioned
overorunderthehair.
123
OPTIONAL SOFT WRAPS
• Wrapeachofthe
softwrapsaround
eithersideofthe
headgear,folding
thetopfastener
overthelowerone.
• Thesoftwraps
shouldbepositioned
onthecheeks,with
thefastenersonthe
outside.
• Withthedeviceturnedon,check
thatthenasalpillowsareproperly
inflated.Todothis,pullthenasal
pillowsawayfromthefaceand
cheek,makesuretheyareinflated
andrepositiontheminthenose.
Swift™FX
NASAL PILLOWS SYSTEM
