Resol DeltaTherm HC MAX User manual

*11201037* 11201037
Thank you for buying this RESOL product.
Please read this manual carefully to get the best performance from this unit.
Please keep this manual carefully.
DeltaTherm®HC
www.resol.com
Manual
en
Mounting
Connection
Operation
Troubleshooting
Application examples
Heating controller
Manual for the
specialised craftsman
version 1.04
Adjust your heating via app

2
en
© 20150804_11201037_DeltaTherm_HC.monen.indd
Safety advice
Please pay attention to the following safety advice in order to avoid danger and
damage to people and property.
Instructions
Attention must be paid to the valid local standards, regulations and directives!
Information about the product
Proper usage
The controller is designed for use in heating systems in compliance with the
technical data specified in this manual.
Improper use excludes all liability claims.
CE-Declaration of conformity
The product complies with the relevant directives and is therefore la-
belled with the CE mark.The Declaration of Conformity is available upon
request, please contact RESOL.
Note
Strong electromagnetic fields can impair the function of the controller.
ÎMake sure the controller as well as the system are not exposed to
strong electromagnetic fields.
Subject to technical change. Errors excepted.
Target group
These instructions are exclusively addressed to authorised skilled personnel.
Only qualified electricians should carry out electrical works.
Initial installation must be effected by the system owner or qualified personnel
named by the system owner.
Description of symbols
WARNING! Warnings are indicated with a warning triangle!
ÎThey contain information on how to avoid the dan-
ger described.
Signal words describe the danger that may occur, when it is not avoided.
• WARNING means that injury, possibly life-threatening injury, can occur.
• ATTENTION means that damage to the appliance can occur.
Note
Notes are indicated with an information symbol.
ÎArrows indicate instruction steps that should be carried out.
Disposal
• Dispose of the packaging in an environmentally sound manner.
• Dispose of old appliances in an environmentally sound manner. Upon request
we will take back your old appliances bought from us and guarantee an environ-
mentally sound disposal of the devices.

3
en
DeltaTherm®HC Heating controller
1 Overview ........................................................................................... 4
2 Installation ........................................................................................ 5
2.1 Mounting .....................................................................................................................5
2.2 Electrical connection ................................................................................................5
2.4 SD card slot................................................................................................................6
2.3 Data communication/Bus .......................................................................................6
3 Operation and function ................................................................... 7
3.1 Buttons ........................................................................................................................7
3.2 Selecting menu points and adjusting values.........................................................7
4 Commissioning............................................................................... 11
4.1 Initial commissioning.............................................................................................. 11
4.2 Schemes with basic settings................................................................................. 12
4.3 Step-by-step parameterisation ............................................................................ 22
5 Functions and options.................................................................... 23
5.1 Menu structure ....................................................................................................... 23
5.2 Status menu ............................................................................................................. 24
5.3 Heating...................................................................................................................... 24
5.4 Arrangement ........................................................................................................... 24
5.5 HQM ......................................................................................................................... 24
5.6 Meas./ Balance values............................................................................................. 24
5.7 Messages................................................................................................................... 25
6 Heating............................................................................................ 25
6.1 Shared relays............................................................................................................ 25
6.2 Heating circuits....................................................................................................... 27
6.3 Optional functions ................................................................................................. 35
7 Arrangement .................................................................................. 40
7.1 Optional functions ................................................................................................. 40
8 HQM ................................................................................................ 48
9 Basic settings .................................................................................. 50
10 SD card ........................................................................................... 50
11 Manual mode ................................................................................. 51
12 User code ....................................................................................... 52
13 In- / Outputs..................................................................................... 52
13.1 Modules .................................................................................................................... 52
13.2 Inputs......................................................................................................................... 53
13.3 Outputs .................................................................................................................... 54
13.4 PWM profiles .......................................................................................................... 55
14 Troubleshooting.............................................................................. 56
15 Accessories ..................................................................................... 58
15.1 Sensors and measuring instruments .................................................................. 59
15.2 VBus®accessories .................................................................................................. 59
15.3 Interface adapters................................................................................................... 60
16 Index ................................................................................................ 61
Navigator
Installation page 5
For mounting and connecting the controller, see page 5.
Commissioning page 7
For commissioning the controller, see page 7.
Adjustments page 22
For making adjustments in the main and additional functions (including
chimney sweeper and screed drying), see page 22.
Data communication page 50
For establishing communication to the controller, see page 50.
Troubleshooting page 56
For diagnostics and troubleshooting in the case of an error, see page 56.
Contents

4
en
1 Overview
• Extra large graphic display
• 5 relay outputs
• 8 (9) inputs for Pt1000, Pt500 or KTY temperature sensors (system
dependent)
• 2 inputs for digital Grundfos Direct Sensors™
• 2 PWM outputs for speed control of high-efficiency pumps
• Datalogging/ firmware updates via SD memory card
• 9 pre-programmed basic systems
• 1 mixed heating circuit, 1 unmixed heating circuit
• DHW heating
• Circulation (with EM extension module)
• Thermal disinfection (with EM extension module)
• Pre-programmed optional functions (with EM extension module)
• RESOL VBus®
• Energy-efficient switching-mode power supply
170
198
43
upper fastening point
lower fastening point
Technical data
Inputs: 8 (9) inputs for Pt1000, Pt500, or KTY temperature sensors (can option-
ally be used for RTA11-M remote controls), 1 impulse inputV40, inputs for 2 digi-
tal Grundfos Direct Sensors™, 1 input for a CS10 irradiation sensor
Outputs: 4 semiconductor relays, 1 potential-free relay, 2 PWM outputs
PWM frequency: 1000 Hz
PWM voltage: 10,5V
Switching capacity per relay:
1 (1) A 240 V~ (semiconductor relay)
4 (2) A 240 V~ (potential-free relay)
Total switching capacity: 4 A
Power supply: 100 … 240 V~, 50… 60 Hz
Supply connection: typeY attachment
Standby power consumption: < 1W
Mode of operation: type 1.B.C.Y
Rated impulse voltage: 2,5 kV
Interfaces: RESOLVBus®, SD card slot
Functions:weather-compensated heating circuit control,afterheating,DHW heat-
ing with priority logic,circulation,thermal disinfection,heat quantity measurement,
optional functions such as solid fuel boiler, return preheating, etc.
Housing: plastic, PC-ABS and PMMA
Mounting: wall mounting, also suitable for mounting into patch panels
Display: full graphic display, control lamp (directional pad) and background il-
lumination
Operation: 7 push buttons at the front of the housing
Protection type: IP 20 / EN 60529
Protection class: I
Ambient temp.: 0…40°C
Degree of pollution: 2
Dimensions: 198 × 170 × 43 mm

5
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
2 Installation
WARNING! Electric shock!
Upon opening the housing, live parts are exposed!
ÎAlways disconnect the controller from power supply
before opening the housing!
2.1 Mounting
The unit must only be located in dry interior rooms.
The controller must additionally be supplied from a double pole switch with
contact gap of at least 3mm.
Please pay attention to separate routing of sensor cables and mains cables.
In order to mount the device to the wall, carry out the following steps:
ÎUnscrew the cross-head screw from the cover and remove it along with the
cover from the housing
ÎMark the upper fastening point on the wall. Drill and fasten the enclosed wall
plug and screw leaving the head protruding
ÎHang the housing from the upper fastening point and mark the lower fasten-
ing points (centres 150mm)
ÎInsert lower wall plugs
ÎFasten the housing to the wall with the lower fastening screws and tighten
ÎCarry out the electrical wiring in accordance with the terminal allocation,
see page 6
ÎPut the cover on the housing
ÎAttach with the fastening screw
Note
Strong electromagnetic fields can impair the function of the controller.
Make sure the controller as well as the system are not exposed to
strong electromagnetic fields.
cover
screw
2.2 Electrical connection
WARNING! Electric shock!
Upon opening the housing, live parts are exposed!
ÎAlways disconnect the controller from power supply
before opening the housing!
WARNING! ESD damage!
Electrostatic discharge can lead to damage to electronic
components!
ÎTake care to discharge properly before touching
the inside of the device!To do so, touch a grounded
surface such as a radiator or tap!
Note
Connecting the device to the power supply must always be the last step
of the installation!
Depending on the product version, cables are already connected to the device. If
that is not the case, please proceed as follows:
The controller is equipped with 5 relays in total to which loads such as pumps,
valves, etc. can be connected:
Relays 1 ... 4 are semiconductor relays, designed for pump speed control:
Conductor R1… R4
Neutral conductor N (common terminal block)
Protective earth conductor PE ⏚(common terminal block)
Relay 5 is a potential-free relay (normally open contact): Connections to the R5
terminals can be made with either polarity.

6
en Installation Adjustments Data communication TroubleshootingCommissioning
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R1-R4
100 ... 240 V~
50-60 Hz
T4A
1 (1) A 240 V~
4 (1) A 240 V~
4 (1) A 24V
R5
R3 R2 R1
L' L
GND
Temp. Sensor
PWM/0-10V
RPD
N
Isolate mains before removing cover!
Vor Öffnen Gerät spannungslos schalten!
Use ground common terminal block
Masse-Sammelklemme benutzen
Use neutral conductor common terminal block
Neutralleiter-Sammelklemme benutzen!
Use PE Common terminal block
Schutzleiter-Sammelklemme benutzen
VFD
CS10 V40/S9 VBus
VBus GND
DeltaTherm® HC
Made in Germany
input for Grundfos
Direct Sensors™
potential-free
relay
sensor ground com-
mon terminal block
sensor terminals
protective conductor
common terminal block (PE)
neutral conductor
common terminal
block
PWM (0-10V) terminals
VBus®
2.4 SD card slot
The controller is equipped with an SD card slot.
With an SD card, the following functions can be carried out:
• Store measurement and balance values onto the SD
card.After the transfer to a computer, the values can be
opened and visualised, e. g. in a spreadsheet.
• Prepare adjustments and parameterisations on a com-
puter and transfer them via the SD card.
• Store adjustments and parameterisations on the SD card
and, if necessary, retrieve them from there.
• Download firmware updates from the Internet and install them on the con-
troller.
For more information about using an SD card, see page 50.
With an SD card, the following functions can be carried out:
Temperature sensors (S1 to S9) have to be connected to the terminals
S1… S9 and GND (either polarity).
The terminal S9 can be used as an impulse input for a V40 flowmeter or a FS08
flow switch.
A V40 flowmeter can be connected to the terminals S9/ V40 and GND (either
polarity).
Connect the irradiation sensor CS10 to the terminals CS10 and GND with
correct polarity.To do so, connect the cable marked GND to the GND common
terminal block, the cable marked CS to the terminal marked CS10.
The terminals marked PWM are control outputs for high-efficiency pumps.
In the In-/Outputs menu, relays can be allocated to the PWM outputs.
Connect the digital Grundfos Direct Sensors™ to the RPD andVFD inputs.
The controller is supplied with power via a mains cable.The power supply of the
device must be 100…240V~ (50… 60 Hz).
The mains connection is at the terminals:
Neutral conductor N
Conductor L
Conductor L' (L' is not connected with the mains cable. L' is a fused contact
permanently carrying voltage)
Protective earth conductor PE ⏚(common terminal block)
WARNING! Electric shock!
L' is a fused contact permanently carrying voltage.
ÎAlways disconnect the controller from power supply
before opening the housing!
Note
For more details about the initial commissioning procedure, see page 11.
2.3 Data communication / Bus
The controller is equipped with the RESOL VBus®for data transfer with and
energy supply to external modules. The connection is carried out at the two
terminals marked VBus and GND (either polarity). One or more RESOL VBus®
modules can be connected via this data bus, such as:
• RESOL AM1 Alarm module
• RESOL DL2 Datalogger
• RESOL EM Extension module
Furthermore, the controller can be connected to a PC via the RESOLVBus®/USB
orVBus®/LAN interface adapter (not included).With the RESOL ServiceCenter
Software (RSC), measured values can be read, processed and visualised.The soft-
ware allows an easy function control of the system.
Note:
For more information about accessories, see page 58.

7
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
3 Operation and function
3.1 Buttons
The controller is operated via the 7 buttons next to the display.They have the
following functions:
Button ❶- scrolling upwards
Button ❸- scrolling downwards
Button ❷- increasing adjustment values
Button ❹- reducing adjustment values
Button ➄- confirming
Button ➅- entering the status menu / chimney sweeper or screed drying
mode (system-dependent)
Button ➆- escape button for changing into the previous menu
1
2
4
63
5
7
3.2 Selecting menu points and adjusting values
During normal operation of the controller, the display is in the status menu. If no
button is pressed for a few seconds, the display illumination goes out.
Press any button to reactivate the display illumination.
ÎIn order to scroll though a menu or to adjust a value, press either buttons ❶
and ❸or buttons ❷and ❹
ÎTo open a sub-menu or to confirm a value, press button ➄
ÎTo get back to the status menu, press button ➅– unconfirmed adjustments
will not be saved
ÎTo enter the previous menu, press button ➆– unconfirmed adjustments
will not be saved
If no button has been pressed within a couple of minutes, the adjustment is can-
celled and the previous value is retained.
Chimney sweeper / screed
The chimney sweeper function or the screed drying function can be triggered
with button ➅. The chimney sweeper function is activated by default. In order
to activate the screed drying function, the chimney sweeper function must be
deactivated in all heating circuits (see page 33).
ÎIn order to trigger the chimney sweeper or screed drying function, press and
hold down button ➅for 5 s.
If the symbol ⏩is shown behind a menu item, pressing button ➄will open a
new sub-menu.
If a sensor has several functions, the symbol ▶will appear next to the allocated
sensor function. Use buttons ❷and ❹to scroll to the allocated functions.
If the symbol ➕is shown in front of a menu item, pressing button ➄will open a
new sub-menu. If it is already opened, a ➖is shown instead of the ➕.

8
en Installation Adjustments Data communication TroubleshootingCommissioning
current value savedminimum value maximum value
adjusted value
(not yet confirmed)
adjustment channel
Values and adjustments can be changed in different ways:
Numeric values can be adjusted by means of a slide bar.The minimum value is
indicated to the left, the maximum value to the right.The large number above
the slide bar indicates the current adjustment. By pressing buttons ❷or ❹the
upper slide bar can be moved to the left or to the right.
Only after the adjustment has been confirmed by pressing button ➄will the
number below the slide bar indicate the new value.The new value will be saved if
it is confirmed by pressing button ➄again.
active area inactive area
When 2 values are locked against each other, they will display a reduced adjust-
ment range depending on the adjustment of the respective other value.
In this case, the active area of the slide bar is shortened, the inactive area is indi-
cated as a dotted line.The indication of the minimum and maximum values will
adapt to the reduction.
If only one item of several can be selected, they will be indicated with “radio but-
tons”. When one item has been selected, the radio button in front of it is filled.
If more than one item of several can be selected, they will be indicated with
checkboxes.When an item has been selected, an xappears inside the checkbox.

9
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
Adjusting the timer
When the Timer option is activated, a timer is indicated in which time frames
for the function can be adjusted.
First of all, an overview of the current adjustments is displayed. For each day of
the week there is an overview display.The display can be switched back and forth
between the different days by pressing buttons ❷or ❹.
In order to adjust the timer, press button ➄.
First the individual days of the week or all days of the week can be selected.
The last menu item after the list of days is Continue. If Continue is selected, the
Edit timer menu opens, in which the time frames can be adjusted.
Adding a time frame:
The time frames can be adjusted in steps of
15 minutes.
In order to add an active time frame, proceed
as follows:
ÎMove the cursor to the desired starting
point of the time frame by pressing but-
tons ❷and ❹. Confirm the starting
point of the time frame by pressing but-
ton ❶.
ÎMove the cursor to the desired ending
point of the time frame by pressing but-
tons ❷and ❹.
ÎThe end of a time frame can be deter-
mined by pressing button ➄.
ÎIn order to add another time frame, re-
peat the last 3 steps.
ÎPress button ➄again to get back to the
overview of current adjustments.

10
en Installation Adjustments Data communication TroubleshootingCommissioning
Removing a time frame:
In order to remove an active time frame, pro-
ceed as follows:
ÎDetermine the point from which on the
time frame is to be removed by pressing
button ❸.
ÎMove the cursor to the desired ending
point of the time frame by pressing but-
tons ❷and ❹.
ÎIn order to conclude removing the time
frame, press button ➄upon reaching the
desired ending point.
ÎPress button ➄again to get back to the
overview of current adjustments.

11
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
4 Commissioning
4.1 Initial commissioning
When the hydraulic system is filled and ready for operation, connect the control-
ler to the mains.
The controller runs an initialisation phase in which the directional pad flashes red.
When the controller is commissioned for the first time or when it is reset, it
will run a commissioning menu after the initialisation phase.The commissioning
menu leads the user through the most important adjustment channels needed
for operating the system.
Commissioning menu
The commissioning menu consists of the channels described in the following. In
order to make an adjustment, push button ➄.Adjust the value by pressing but-
tons ❷and ❹, then push button ➄to confirm. The next channel will appear
in the display.
5
5
Adjustment mode
Button navigation
Changing a value
Confirming a value
Next parameter appears
automatically
2
4
1. Language:
ÎAdjust the desired menu language.
2. Units:
ÎAdjust the desired temperature unit.
ÎAdjust the desired volume unit.
ÎAdjust the desired pressure unit.
ÎAdjust the desired energy unit.
3. Daylight savings time adjustment:
ÎActivate or deactivate the automatic day-
light savings time adjustment.

12
en Installation Adjustments Data communication TroubleshootingCommissioning
4. Time:
ÎAdjust the clock time. First of all adjust the
hours, then the minutes.
5. Date:
ÎAdjust the date. First of all adjust the year,
then the month and then the day.
7. Completing the commissioning menu:
After the scheme has been selected, a security
enquiry appears. If the safety enquiry is con-
firmed, the adjustments are saved.
ÎIn order to confirm the security enquiry,
press button ➄.
ÎInordertoreenterthe commissioning menu
channels, press button ➆.
If the security enquiry has been confirmed,
the controller is ready for operation and
should enable an optimum system opera-
tion.
All adjustments made during commissioning
can, if necessary, be changed later on in the ba-
sic settings menu.
6. Basic system:
ÎAdjust the desired scheme (heating circuit,
demand, DHW heating).
4.2 Schemes with basic settings
The controller is pre-programmed for 9 basic systems.The basic pre-adjustments
have already been made. For afterheating it is necessary to allocate the demand
and the boiler loading pump by means of shared relays. Afterwards the system
can easily be extended.
Relay and sensor allocation correspond to the figure.
Scheme 0 has no pre-adjustments.

13
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
Scheme 1: one mixed heating circuit
S2
S1
R1
R2/3
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 Free 3/GND
S4 Free 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Temperature sensors
Relay outputs
Mains
19 / N / PE
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 Free 14/N/PE
R5 Free 13/12
By means of the flow sensor S1 and the outdoor temperature sensor S2, a mixed
weather-compensated heating circuit can be controlled.

14
en Installation Adjustments Data communication TroubleshootingCommissioning
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 Free 3/GND
S4 Afterheating/boiler 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 Free 14/N/PE
R5 Demand 13/12
Scheme 2: one mixed heating circuit with afterheating (demand)
S2
S1
R1
R2/3
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
S4
R5
Temperature sensors
Relay outputs
Mains
19 / N / PE
By means of the flow sensor S1 and the outdoor temperature sensor S2, a mixed
weather-compensated heating circuit can be controlled. Boiler demand via the
potential-free relay is triggered depending on the temperature difference between
the set flow temperature and the value measured at the afterheating sensor S4.

15
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 Free 3/GND
S4 Afterheating/boiler 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 Boiler loading pump 14/N/PE
R5 Demand 13/12
Scheme 3: one mixed heating circuit with afterheating (demand and boilder loading pump)
S4
R5
S2
S1
R1
R2/3
R4
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
Temperature sensors
Relay outputs
Mains
19 / N / PE
By means of the flow sensor S1 and the outdoor temperature sensor S2, a mixed
weather-compensated heating circuit can be controlled. Boiler demand via the
potential-free relay and control of the boiler loading pump are triggered depending
on the temperature difference between the set flow temperature and the value
measured at the afterheating sensor S4.

16
en Installation Adjustments Data communication TroubleshootingCommissioning
Scheme 4: one mixed heating circuit with DHW heating
S3
S2
S1
R1
R2/3
R4
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
Temperature sensors
Relay outputs
Mains
19 / N / PE
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 DHW 3/GND
S4 Free 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 DHW loading pump 14/N/PE
R5 Free 13/12
By means of the flow sensor S1 and the outdoor temperature sensor S2, a mixed
weather-compensated heating circuit can be controlled. DHW heating is triggered
depending on the value measured at the DHW sensor S3.

17
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
Scheme 5: one mixed heating circuit with DHW heating and afterheating (demand for heating circuit and DHW)
S3
S2
S1
R1
R2/3
R4
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
S4
R5
Temperature sensors
Relay outputs
Mains
19 / N / PE
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 DHW 3/GND
S4 Afterheating/boiler 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 DHW loading pump 14/N/PE
R5 Demand 13/12
By means of the flow sensor S1 and the outdoor temperature sensor S2, a mixed
weather-compensated heating circuit can be controlled. DHW heating is triggered
depending on the value measured at the DHW sensor S3. Boiler demand via the
potential-free relay is triggered depending on the temperature difference between
the set flow temperature and the value measured at the afterheating sensor S4.
DHW heating is triggered depending on the value measured at the DHW sensor S3.

18
en Installation Adjustments Data communication TroubleshootingCommissioning
Scheme 6: one mixed and one unmixed heating circuit
S2
S1
S3
R1
R2/3
R4
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
Temperature sensors
Relay outputs
Mains
19 / N / PE
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 Flow HC2 3/GND
S4 Free 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 Pump HC2 14/N/PE
R5 Free 13/12
By means of the flow sensors S1 and S3 respectively and the outdoor sensor S2,
a mixed and an unmixed weather-compensated heating circuit can be controlled.

19
en
Installation
AdjustmentsTroubleshooting Data communication Commissioning
Scheme 7: one mixed and one unmixed heating circuit with afterheating (demand)
S2
S1
S3
R1
R2/3
R4
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
S4
R5
Temperature sensors
Relay outputs
Mains
19 / N / PE
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 Flow HC2 3/GND
S4 Afterheating/boiler 4/GND
S5 Free 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 Pump HC2 14/N/PE
R5 Demand 13/12
By means of the flow sensors S1 and S3 respectively and the outdoor tem-
perature sensor S2, one mixed and one unmixed weather-compensated
heating circuit can be controlled. Boiler demand via the potential-free relay
is triggered depending on the temperature difference between the set flow
temperatures and the value measured at the afterheating sensor S4.

20
en Installation Adjustments Data communication TroubleshootingCommissioning
Scheme 8: one mixed heating circuit with solid fuel boiler
S5
S2
S1
R1
R2/3
S3
R4
S1 S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R3 R2 R1
L' L
GND
PWM/0-10V
RPD
VFD
CS10 V40/S9 VBus
VBus GND
Temperature sensors
Relay outputs
Mains
19 / N / PE
Sensors
S1 Flow HC1 1/GND
S2 Outdoor 2/GND
S3 Solid fuel boiler 3/GND
S4 Free 4/GND
S5 Store 5/GND
S6 Free 6/GND
S7 Free 7/GND
S8 Free 8/GND
Relays
R1 Pump HC1 17/N/PE
R2 Mixer open 16/N/PE
R3 Mixer closed 15/N/PE
R4 Pump SFB 14/ N / PE
R5 Free 13/12
By means of the flow sensor S1 and the outdoor temperature sensor S2, a mixed
weather-compensated heating circuit can be controlled.The solid fuel boiler is con-
trolled depending on the temperature difference between the sensors S3 (solid
fuel boiler) and S5 (store).
