Retevis RB35 User manual

USER’S MANUAL
UHF(462.5500-462.7250MHz)
Super Receiving
Scanning
VOX
Torch
Alarm Function
Channel Lockout
Monitor
High-Low Power Selection
Busy Channel Lockout
Low Battery Warning
Special Signaling
50 CTCSS/208 DCS
RB35
TWO WAY RADIO

Charging the Battery
1.The battery is not charged in the factory, please charge the battery
under the environmental temperature 5—40℃before using.
2.After purchasing or long-term storage(more than two months),charging
the battery for the first time can not reach its saturation capacity,repeat
charge/discharge for twice or three times to make battery capacity
achieve the best state.
3.Before charging,please power off the transceiver,using the transceiver
during charging may affect correct charging.
4.If the battery has been charged fully,please do not charge it
again,otherwise the service life of the battery may be shorten or may be
damaged.
5.If the service time is significantly reduced even after completely correct
charging,the battery can not be used any more,please replace a new
battery.
BASIC OPERATION:
·Power/Volume Button
Rotate the power button, you can turn on/off the radio.
When radio is turn on, Rotate it again, you can adjust the radio’s Volume
·Channel Selection
Short press【UP/DOWN】keys to adjust the channels.
·PTT
Press this button you can talk to others.
·Monitoring
When“Side Key 2” in the software is programmed to the monitoring
function,long press 【DOWN】key for two seconds to enter into the
monitor mode, release it to exit.
1

·Torch
Press 【UP】key for two seconds to turn on the flashlight, press 【
DOWN】key to turn it off.
·Channel Lockout
Press both【UP】【DOWN】keys to lock; Operate them again to unlock.
·Scanning
It is convenient for the user to search for calls from other channels.
When defined the side key down button on the software with the scan
function, long press down button for 2 seconds, radio will active the scan
function.
Radio will start scanning from current channel. When radio scan the
signals from other channels, it will stay, if you don’t press PTT within 4
seconds, it will continue scanning.
Note: At least to add 2 channels with scan function, or you can not use
the scan function.
Carrier Scan: When the radio detects a signal it will stop scanning and
will stay on the same frequency and will resume scanning after 4 seconds
when the signal ends.
·Emergency Alarm
When“Side Key 2” in the software is programmed to the alarm
function,long press 【DOWN】key for two seconds to alarm; Press PTT
key to exit.
·High/Low Power
You can choose the High/Low power on the programming software.
·Chinese/English Voice Prompt
You can choose the Chinese/English voice by hand.
Switch to Channel 16, turn off the radio, then press 【UP】key and
meanwhile turn on the radio to switch between the Chinese and English.
2

· VOX
This function can be voice activated so the user doesn’t have to press the
PTT key. Switch to Channel 7, turn off the transceiver, then press the 【
UP】key and turn on the transceiver at the same time to switch between
the ON and OFF of the VOX function.
You can set the VOX level by its software, level from 1-9
· Busy Channel Lockout
The function can prevent interference from other transceivers using the
same channel.
· Battery Power Saving
If there is no signal or operation,the radio will reduce its power
consumption.The battery power-saving function activates when the
channel is unoccupied or has not been in operation.
· Low Battery Warning
If the battery power falls to the predetermined value during transmis-
sion,the transceiver will give out a voice prompt: please charge in time.
· Time Out Timer(TOT)
The purpose of the TOT is to prevent any single person from using a
channel for an extended period of time.An alarm will sound if the
transmission continues beyond the set time.The transceiver will stop
transmission if this occurs.To stop the alarm,release the PTT key and the
transceiver will return to standby.
·CTCSS/DCS
The transceiver has 50 CTCSS and 208 DCS, also non-standard
subaudio can be programmed!
·Special Signaling
Special Signaling refers to the CDCSS on the channels is special
processed codes.Only when the transceivers in the same company are
programmed the same frequency point with the same CDCSS and
meanwhile special signaling is programmed,then they can talk to each
other.
3

Technical Parameters
SPECIFICATIONS
TRANSMITTER
RECEIVER
Frequency Range
Supply Power
Memory Channel
Antenna Configuration
Work Mode
Ground Method
Dimension
Output Power
Modulation Mode
Max.Frequency Deviation
Sparious Radiation
Preemphasis Character
Emission Current
Sensitivity
Audio Power
Audio Distortion
Intermodulation
InterferenceResistance Receiving Current
Standby Current
462.5500-462.7250MHz
DC3.7V
16
Integrated antenna
Co/Differ-frequency
Simplex Communication
Cathode
109.8*57.5*32mm
≤2W
FM(F3E)
≤5KHz
≤7.5μW
Per Octave 6dB
≤1000mA
＜0.16μV（12dB SINAD）
≥300mW
＜5%
≥60dB
≤300mA
≤20mA
▲We May Change The Specifications For Technical Improvement
Without Prior Notice.
4
