Rex-royal S 500 MCT-HS User manual

User Manual
Rex-Royal S 500 MCT-HS
UM S500 MCT-HS(2020)

Deutsch 12 - 21
Français 22 - 31
English 2 - 11
Customer informaon
Introducon
Water quality
The quality of the water is an important factor in the
producon of a good and tasty coee. Too much lime or
various avourings can signicantly reduce the quality
of your coee. In this case, too, we will be happy to
make our experse available to you. Get in touch with
us. Refer to the corresponding «Installaon Diagram»
for further informaon.
Food suitability
The coee machine is approved for use with the
following foods:
• Drinking water via xed water connecon
• Pure coee beans without roasng addives in the
bean container (no added sugar, etc.)
• Decaeinated, machine-suitable coee powder for
the decaeinated chute (no soluble coee)
For machines with milk module:
• Milk (2 - 5 °C)
Maintenance and support
With the purchase of a Rex-Royal coee machine you
have opted for the highest quality. Here are some ps
on how to keep your machine in perfect condion for a
long me and how to keep the quality of the coee at an
opmum level all the me.
HACCP – hygiene concept and cleaning instrucons
For a hygienically clean coee machine, the instrucons
in the cleaning instrucons must always be followed.
The cleaning instrucons are a separate document
supplied with the coee machine (see cleaning box). If
required, you can also obtain these instrucons from
your supplier or from our website www.rex-royal.ch.
Thanks to the innovave design, cleaning is quick.
The opmal beverage quality
Observe the general and country-specic hygiene
regulaons for coee and milk products.
• Use only chilled milk at a maximum temperature of
5 °C.
• Only use high quality coee. Try to adapt the type
of coee to your requirements in terms of strength,
variety, roasng, etc.
• Store the coee in a cool, dry place and never leave
the beans open.
• Close the container immediately aer lling the
beans. Never ll the bean container before a long
break (e.g. overnight or over the weekend).
• Rinse the machine aer a long break.
Service
A professional machine needs professional service. We
recommend that you have the machine serviced once
a year by our well-trained service technicians. Regular
maintenance extends the life of the coee machine.
In addion, our service professional will check your
machine for opmum quality and funconality every
me. The best care for your Rex-Royal coee machine
can be guaranteed by a service contract.
Safety
When moving the trolley, please make sure that no
obstacles are blocking its way (risk of pping).
The coee machine is only allowed to be operated
by persons who have read and understood these
instrucons. All instrucons must be followed exactly.
These operang instrucons must always be available
at the place where the machine is used.
The operang instrucons
These operang instrucons make it easier for you
to get to know your coee machine and to use all
possible applicaons. This manual contains important
informaon for proper and safe operaon. Following
them helps to avoid dangers and unnecessary repair
costs. This increases the reliability and service life of the
coee machine.
Who is allowed to operate the coee machine?
This device is allowed to be used by children over 8 years
of age and by persons with reduced physical, sensory or
mental abilies or lack of experience and knowledge if
they are supervised or have been instructed in the safe
use of the device and understand the resulng hazards.
Children are not allowed to play with the device.
Cleaning and maintenance work must not be carried out
by children.
Faults
Error messages indicate an unusual condion (error) or
a malfuncon of the coee machine. The display shows
which part of the machine is causing the fault.
Switch o the machine at the main switch and switch it
on again aer a short wait of about one minute. Try to
dispense a product again. If the aempt is not successful,
switch o the machine and contact customer service.
In the event of discrepancies or dierences between the
languages, the German version shall prevail.
More informaon: www.rex-royal.ch
Index
Languages
EN
32

Coee machine
Overview
Hot water outlet
Bean container
2 grinders:
2x 1.5 kg
Insert for cleaning tablets
see cleaning manual
Main switch
USB port
*oponal
Operang unit
Video-capable
10" touchscreen
Locking device for bean container
Lock for front door
Release buon
Front door
Double outlet
Hot milk
Automac reorder mode
for coee / milk (key switch)
Double outlet
Coee
Detecon sensors for pots
Automac reorder mode
Grounds drawer XL*
max. 4 kg
Residual water tank
max. 12 l
Fresh water connecon
G 3/8" internal thread
Water lter
Drip tray
Cup posioner*
adjustable
Grounds drawer
max. 1.25 kg
Power supply
Milk sucon tube
Dispersal area
Milk container
EN
54

TX0106XX
2
21
1
Filling bean container
Connecng milk container
Operaon
Li the container lid, ll in
beans.
Tip: max. 1 day’s supply
If necessary, conrm the
system message on the
touchscreen with .
Set a container with cooled
milk in posion.
Hang in the milk sucon.
Emptying the grounds drawer
Open the front door and
remove the grounds drawer.
Empty and clean the grounds
drawer.
Conrm system message
with if the grounds drawer
has been emped. Otherwise,
press .
Reinsert the grounds drawer
and close the front door.
Switching on/o
Open front door and set main
switch to posion I. Then close
front door again.
Conrm system message with
to rinse the coee machine.
Aer a short me the machine
will have nished rinsing, will
be warmed up and is ready
for use.
Note: Before switching o, the
coee machine must be cleaned.
Please follow the instrucons in
the cleaning manual.
Cleaning the residual water tray
Fill residual water tank
Remove the drip grid. Clean the grid and tray. Place the drip grid back.
Remove residual tank. Empty residual water tank. Insert residual tank again.
Note: Follow the informaon in
the cleaning manual.
Remove/insert bean container
1 Pull the locking devices
2 Remove the container
1 Set up the container
2 Push the locking devices
Emptying the grounds drawer XL
Remove the grounds drawer. Empty and clean the grounds
drawer.
Reinsert the grounds drawer.
EN
76

Product dispensing
Dispensing coee
Dispensing hot water
Select the desired product on
the touchscreen.
Dispensing hot milk
Beverage dispensing starts.
Aenon: Danger of burns!
Don’t touch the area under the
outlet.
Move two pots into posion
under the coee outlets.
Select the desired product on
the touchscreen.
Beverage dispensing starts.
Aenon: Danger of burns!
Don’t touch the area under the
outlet.
Move two pots into posion
under the milk outlets.
Select the desired product on
the touchscreen.
Beverage dispensing starts.
Aenon: Danger of burns!
Don’t touch the area under the
outlet.
Move hot water outlet into
posion over a cup or glass.
Note: Beverages are dispensed
in several cycles. Please do not
remove the pot unl the prod-
uct has been nished.
Product selecon
Stop/Cancel
Status display
Press and hold for 5 seconds:
directly to “Service Menu”
Code: 348108
Cleaning menu
Service menu
Code: 348108
Machine info
Touchscreen
Opons
Press and hold for 5 seconds
Stascs
If the key switch is acvated,
the beverage dispensing starts
automacally, as soon as a pot
is detected.
Automac reorder mode (Coee & Milk)
EN
