RF-Star RF-BM-ND01 User manual

RF-BM-ND01
Bluetooth 4.2 Low Energy Module
Version 1.3
Shenzhen RF-star Technology Co., Ltd.
May 26th, 2023
All rights reserved. Those responsible for unauthorized reproduction will be prosecuted.

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 1 of 18
1 Device Overview
1.1 Description
RF-BM-ND01 is an RF module based on Nordic BLE SoC nRF51822 with ARM® Cortex®-M0 32-bit processor. It
integrates a 16.0 MHz crystal, an optional 32.768 kHz, an LC filter, an antenna matching and a meander line inverted-F
PCB antenna. It features low power consumption, compact size, robust connection distance, and rigid reliability. It
supports Bluetooth® v4.2 Low Energy and 2.4 GHz proprietary wireless applications and can be pre-programmed with
SPI master/slave, I2C master and UART for simple programming. 1.27-mm pitch stamp stick package for easy
assembling and cost-effective PCB design. RF-BM-ND01 is pin-2-pin compatible with RF-BM-ND04/ND04I/ND05/ND05I.
1.2 Key Features
•Bluetooth® low energy mode
•TX power: -20 to +4 dBm
•16 MHz ARM® Cortex®-M0 32-bit processor
•Supply voltage range 1.8 V ~ 3.6 V
•Memory
- 256 KB flash
- 16 KB RAM
•Peripherals
- 10 bit ADC
- 29 GPIOs
- SPI Master / Slave
- I2C Master
- UART (CTS / RTS)
•Quadrature Decoder (QDEC)
•AES HW encryption
•Real Timer Counter (RTC)
•Dimension: 24.8 mm x 15.0 mm x 2.3 mm
•Certificates: SRRC
1.3 Applications
•Mouse and keyboard
•Mobile HID
•Multi-touch trackpad
•Remote control
•Gaming controller
•Wearables
•Virtual reality headsets
•Health/fitness sensor and monitor device
•Industrial lighting
•Smart toys
•Medical devices
•Beacons

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 2 of 18
1.4 Functional Block Diagram
Figure 1. Functional Block Diagram of RF-BM-ND01
1.5 Part Number Conventions
The part numbers are of the form of RF-BM-ND01 where the fields are defined as follows:
Figure 2. Part Number Conventions of RF-BM-ND01
RF
BM
ND
Company Name
RF-star
Wireless Type
Bluetooth Module
Chipset Manufacturer
Nordic Semiconductor
-
-
01
Module Version
nRF51822 Version
nRF51822
GPIOs
Debug
Reset
PCB
Antenna
LC Filter
Power Supply
1.8 V ~ 3.6 V
Antenna
Matching
16.0 MHz
32.768 kHz
32.768 kHz crystal is an optional component.
No 32.768 kHz crystal version is by default.

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 3 of 18
Table of Contents
1 Device Overview............................................................................................................................................................. 1
1.1 Description............................................................................................................................................................ 1
1.2 Key Features ....................................................................................................................................................... 1
1.3 Applications.......................................................................................................................................................... 1
1.4 Functional Block Diagram .............................................................................................................................. 2
1.5 Part Number Conventions.............................................................................................................................. 2
Table of Contents................................................................................................................................................................ 3
2 Module Configuration and Functions ...................................................................................................................... 4
2.1 Module Parameters........................................................................................................................................... 4
2.2 Module Pin Diagram ......................................................................................................................................... 5
2.3 Pin Functions....................................................................................................................................................... 5
3 Specifications ................................................................................................................................................................... 7
3.1 Recommended Operating Conditions ....................................................................................................... 7
3.2 Handling Ratings................................................................................................................................................ 7
4 Application, Implementation, and Layout............................................................................................................... 8
4.1 Module Photos.................................................................................................................................................... 8
4.2 Recommended PCB Footprint...................................................................................................................... 8
4.3 Schematic Diagram........................................................................................................................................... 9
4.4 Antenna.................................................................................................................................................................. 9
4.4.1 Antenna Design Recommendation ................................................................................................ 9
4.5 Basic Operation of Hardware Design ......................................................................................................10
4.6 Trouble Shooting..............................................................................................................................................11
4.6.1 Unsatisfactory Transmission Distance........................................................................................11
4.6.2 Vulnerable Module..............................................................................................................................11
4.6.3 High Bit Error Rate .............................................................................................................................11
4.7 Electrostatics Discharge Warnings ...........................................................................................................11
4.8 Soldering and Reflow Condition.................................................................................................................12
5 Optional Package Specification ..............................................................................................................................14
6 Certification .....................................................................................................................................................................16
6.1 SRRC ...................................................................................................................................................................16
7 Revision History ............................................................................................................................................................17
8 Contact Us.......................................................................................................................................................................18

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 4 of 18
2 Module Configuration and Functions
2.1 Module Parameters
Table 1. Parameters of RF-BM-ND01
Chipset
nRF51822
Supply Power Voltage
1.8 V ~ 3.6 V, recommended to 3.3 V
Frequency
2402 MHz ~ 2480 MHz
Transmit Power
-20.0 dBm ~ +4.0 dBm (typical: 0 dBm)
Receiving Sensitivity
-93 dBm
Power Consumption
13 mA peak RX, 10.5 mA peak TX (@ 0 dBm)
9.7 mA peak RX, 8.0 mA peak TX (@ 0 dBm with DC/DC)
GPIO
29
Crystal
16 MHz, optional 32.768 kHz
RAM
16 KB
Flash
256 KB
Package
SMT Packaging (1.27-mm half-hole pitch stamp stick)
Frequency Error
±20 kHz
Dimension
24.8 mm x 15.0 mm x 2.3 mm
Type of Antenna
PCB antenna
Operating Temperature
-40 ℃ ～ +85 ℃
Storage Temperature
-40 ℃ ～ +125 ℃

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 5 of 18
2.2 Module Pin Diagram
Figure 3. Pin Diagram of RF-BM-ND01
2.3 Pin Functions
Table 2. Pin Functions of RF-BM-ND01
Pin
Name
Chip Pin
Pin Type
Description
1
GND
GND
GND
GND
2
VCC
VCC
Power
Power supply 1.8 V ~ 3.6 V, Recommend 3.3 V
3
P21
P0.21
Digital I/O
4
P22
P0.22
Digital I/O
5
P23
P0.23
Digital I/O
6
P24
P0.24
Digital I/O
7
P25
P0.25
Digital I/O
8
P28
P0.28/AIN4
Digital I/O & Analog

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 6 of 18
9
P29
P0.29/AIN5
Digital I/O & Analog
10
P30
P0.30/AIN6
Digital I/O & Analog
11
P00
P0.00
Digital I/O
12
P01
P0.01
Digital I/O
13
P02
P0.02/AIN0
Digital I/O & Analog
14
P03
P0.03/AIN1
Digital I/O & Analog
15
P04
P0.04/AIN2
Digital I/O & Analog
16
P05
P0.05/AIN3
Digital I/O & Analog
17
P06
P0.06
Digital I/O
18
P07
P0.07
Digital I/O
19
P08
P0.08
Digital I/O
20
P09
P0.09
Digital I/O
21
P10
P0.10
Digital I/O
22
P11
P0_11
Digital I/O
23
P12
P0.12
Digital I/O
24
P13
P0.13
Digital I/O
25
P14
P0.14
Digital I/O
26
P15
P0.15
Digital I/O
27
P16
P0.16
Digital I/O
28
SWDIO
nRESET
SWDIO
nRESET
Digital I/O & Analog
Hardware debug and falsh programming I/O.
Reset pin. Active low.
29
SWCLK
SWDCLK
Digital Input
Hardware debug and falsh programming I/O.
30
P17
P0_17
Digital I/O
31
P18
P0_18
Digital I/O
32
P19
P0_19
Digital I/O
33
P20
P0_20
Digital I/O

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 7 of 18
3 Specifications
3.1 Recommended Operating Conditions
The functional operation does not guarantee performance beyond the limits of the conditional parameter values in the
table below. Long-term work beyond this limit will affect the reliability of the module more or less.
Table 3. Recommended Operating Conditions of RF-BM-ND01
Items
Condition
Min.
Typ.
Max.
Unit
Operating Supply Voltage
Battery Mode
1.8
3.3
3.6
V
Operating Temperature
/
-40
+25
+85
℃
Environmental Hot Pendulum
/
-20
+20
℃/min
3.2 Handling Ratings
Table 4. Handling Ratings of RF-BM-ND01
Items
Condition
Min.
Typ.
Max.
Unit
Storage Temperature
Tstg
-40
+25
+125
℃
Human Body Model
HBM
±4000
V
Moisture Sensitivity Level
3
Charged Device Model
±500
V

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 8 of 18
4 Application, Implementation, and Layout
4.1 Module Photos
Figure 4. Photos of RF-BM-ND01
4.2 Recommended PCB Footprint
Figure 5. Recommended PCB Footprint of RF-BM-ND01 (mm)

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 9 of 18
4.3 Schematic Diagram
Figure 6. Schematic Diagram of RF-BM-ND01
4.4 Antenna
4.4.1 Antenna Design Recommendation
1. The antenna installation structure has a great influence on the module performance. It is necessary to ensure the
antenna is exposed and preferably vertically upward. When the module is installed inside of the case, a high-quality
antenna extension wire can be used to extend the antenna to the outside of the case.
2. The antenna must not be installed inside the metal case, which will cause the transmission distance to be greatly
weakened.
3. The recommendation of antenna layout.
The inverted-F antenna position on PCB is free-space electromagnetic radiation. The location and layout of the
antenna is a key factor to increase the data rate and transmission range.
Therefore, the layout of the module antenna location and routing is recommended as follows:
（1）Place the antenna on the edge (corner) of the PCB.
（2）Make sure that there is no signal line or copper foil in each layer below the antenna.
（3）It is best to hollow out the antenna position in the following figure to ensure that the S11 of the module is
minimally affected.

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 10 of 18
Figure 7. Recommendation of Antenna Layout
Note: The hollow-out position is based on the antenna used.
4.5 Basic Operation of Hardware Design
1. It is recommended to offer the module with a DC stabilized power supply, a tiny power supply ripple coefficient, and
reliable ground. Please pay attention to the correct connection between the positive and negative poles of the power
supply. Otherwise, the reverse connection may cause permanent damage to the module;
2. Please ensure the supply voltage is between the recommended values. The module will be permanently damaged
if the voltage exceeds the maximum value. Please ensure a stable power supply and no frequently fluctuated voltage.
3. When designing the power supply circuit for the module, it is recommended to reserve more than 30% of the margin,
which is beneficial to the long-term stable operation of the whole machine. The module should be far away from the
power electromagnetic, transformer, high-frequency wiring, and other parts with large electromagnetic interference.
4. The bottom of the module should avoid high-frequency digital routing, high-frequency analog routing, and power
routing. If it has to route the wire on the bottom of the module, for example, it is assumed that the module is soldered
to the Top Layer, the copper must be spread on the connection part of the top layer and the module, and be close
to the digital part of the module and routed in the Bottom Layer (all copper is well-grounded).
5. Assuming that the module is soldered or placed in the Top Layer, it is also wrong to randomly route the Bottom Layer
or other layers, which will affect the spurs and receiving sensitivity of the module to some degrees;
6. Assuming that there are devices with large electromagnetic interference around the module, which will greatly affect
the module performance. It is recommended to stay away from the module according to the strength of the
interference. If circumstances permit, appropriate isolation and shielding can be done.
7. Assuming that there are routings of large electromagnetic interference around the module (high-frequency digital,
high-frequency analog, power routings), which will also greatly affect the module performance. It is recommended
to stay away from the module according to the strength of the interference. If circumstances permit, appropriate
isolation and shielding can be done.
8. It is recommended to stay away from the devices whose TTL protocol is the same 2.4 GHz physical layer, for

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 11 of 18
example, USB 3.0.
4.6 Trouble Shooting
4.6.1 Unsatisfactory Transmission Distance
1. When there is a linear communication obstacle, the communication distance will be correspondingly weakened.
Temperature, humidity, and co-channel interference will lead to an increase in communication packet loss rate. The
performances of ground absorption and reflection of radio waves will be poor when the module is tested close to the
ground.
2. Seawater has a strong ability to absorb radio waves, so the test results by the seaside are poor.
3. The signal attenuation will be very obvious if there is a metal near the antenna or the module is placed inside the
metal shell.
4. The incorrect power register set or the high data rate in an open-air may shorten the communication distance. The
higher the data rate, the closer the distance.
5. The low voltage of the power supply is lower than the recommended value at ambient temperature, and the lower
the voltage, the smaller the power is.
6. The unmatchable antennas and modules or the poor quality of the antenna will affect the communication distance.
4.6.2 Vulnerable Module
1. Please ensure the supply voltage is between the recommended values. The module will be permanently damaged
if the voltage exceeds the maximum value. Please ensure a stable power supply and no frequently fluctuated voltage.
2. Please ensure the anti-static installation and the electrostatic sensitivity of high-frequency devices.
3. Due to some humidity-sensitive components, please ensure suitable humidity during installation and application. If
there is no special demand, it is not recommended to use at too high or too low temperature.
4.6.3 High Bit Error Rate
1. There are co-channel signal interferences nearby. It is recommended to be away from the interference sources or
modify the frequency and channel to avoid interferences.
2. The unsatisfactory power supply may also cause garbled. It is necessary to ensure the power supply's reliability.
3. If the extension wire or feeder wire is of poor quality or too long, the bit error rate will be high.
4.7 Electrostatics Discharge Warnings
The module will be damaged for the discharge of static. RF-star suggests that all modules should follow the 3 precautions
below:
1. According to the anti-static measures, bare hands are not allowed to touch modules.

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 12 of 18
2. Modules must be placed in anti-static areas.
3. Take the anti-static circuitry (when inputting HV or VHF) into consideration in product design.
Static may result in the degradation in performance of the module, even causing the failure.
4.8 Soldering and Reflow Condition
1. Heating method: Conventional Convection or IR/convection.
2. Solder paste composition: Sn96.5 / Ag3.0 / Cu0.5
3. Allowable reflow soldering times: 2 times based on the following reflow soldering profile.
4. Temperature profile: Reflow soldering shall be done according to the following temperature profile.
5. Peak temperature: 245 ℃.
Table 5. Temperature Table of Soldering and Reflow
Profile Feature
Sn-Pb Assembly
Pb-Free Assembly
Solder Paste
Sn63 / Pb37
Sn96.5 / Ag3.0 / Cu0.5
Min. Preheating Temperature (Tmin)
100 ℃
150 ℃
Max. Preheating Temperature (Tmax)
150 ℃
200 ℃
Preheating Time (Tmin to Tmax) (t1)
60 s ~ 120 s
60 s ~ 120 s
Average Ascend Rate (Tmax to Tp)
Max. 3 ℃/s
Max. 3 ℃/s
Liquid Temperature (TL)
183 ℃
217 ℃
Time above Liquidus (tL)
60 s ~ 90 s
30 s ~ 90 s
Peak Temperature (Tp)
220 ℃ ~ 235 ℃
230 ℃ ~ 250 ℃
Average Descend Rate (Tpto Tmax)
Max. 6 ℃/s
Max. 6 ℃/s
Time from 25 ℃ to Peak Temperature (t2)
Max. 6 minutes
Max. 8 minutes
Time of Soldering Zone (tP)
20±10 s
20±10 s

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 13 of 18
Figure 8. Recommended Reflow for Lead-Free Solder

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 14 of 18
5 Optional Package Specification
The default package method is by tray. If you need the modules to be shipped by tape & reel, pls contact us in advance.
Figure 9. Default Package by Tray

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 15 of 18
Figure 10. Package by Tape & Reel

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 16 of 18
6 Certification
6.1 SRRC
SRRC ID: 2019DP6207
Figure 11. SRRC Certificate

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 17 of 18
7 Revision History
Date
Version No.
Description
2016.05.31
V1.0
The initial version is released.
2017.07.26
V1.0
Update module picture.
2017.07.27
V1.1
Add part number conventions.
2018.01.24
V1.2
Update module picture.
2018.03.02
V1.3
Update module parameters.
2018.08.02
V1.3
Update company address.
2023.05.26
V1.3
Update MSL level.
Update the Shenzhen office address.
Note:
1. The document will be optimized and updated from time to time. Before using this document, please make sure it is
the latest version.
2. To obtain the latest document, please download it from the official website: www.rfstariot.com and www.szrfstar.com.

RF-BM-ND01
www.szrfstar.com V1.3 - May, 2023
Shenzhen RF-star Technology Co., Ltd. Page 18 of 18
8 Contact Us
SHENZHEN RF-STAR TECHNOLOGY CO., LTD.
Shenzhen HQ:
Add.: Room 502, Podium Building No. 12, Shenzhen Bay Science and Technology Ecological Park, Nanshan District,
Shenzhen, Guangdong, China, 518063
Tel.: [phone]
Chengdu Branch:
Add.: N2-1604, Global Center, North No. 1700, Tianfu Avenue, Hi-Tech District, Chengdu, Sichuan, China, 610095
Tel.: [phone]
Email: [e-mail], [e-mail]
Web.: www.rfstariot.com, www.szrfstar.com
