RFI CSA40-67-DIN User manual

COMPONENTS
BEFORE ASSEMBLING YOUR ANTENNA PLEASE ENSURE THAT ALL THE COMPONENTS BELOW ARE
INCLUDED IN THE KIT.
406-512 MHz
CSA40-67-DIN
M-8565
SCREEN CENTRE
QTY: 1
M-8565
SCREEN SIDES
QTY: 2
0A-40-67-DIN
DIPOLE ASSEMBLY
QTY: 1
CORNER BRACKET
QTY: 12
LARGE CLAMP PLATE
QTY: 4
M6 FLAT WASHER
M6x65 HEX HEAD BOLT
M6 FLAT WASHER
M6 SPRING WASHER
M6 HEX NUT
M6x65 BOLT ASSEMBLY
QTY: 24
M12 HEX NUT
M12 SPRING WASHER
M12 FLAT WASHER
M12x250 THREADED ROD
M12 STUD ASSEMBLY
QTY: 4
INS-40101-5 ©RF Industries Pty Ltd 2009
www.bird-technologies.com
PAGE 1 OF 4

406-512 MHz
SIDE SCREEN
CENTRE SCREEN
SIDE SCREEN
CORNER BRACKET
M6x65 BOLT ASSEMBLY
0A-40-67-DIN
DIPOLE ASSEMBLY
CENTRE SCREEN
M12 STUD
ASSEMBLY
90°
2.5
110
135
2MM (5.3")
TOP OF BOOM
TO TOP OF SCREEN
CSA40-67-DIN
ANTENNA ASSEMBLY
STEP 1:
ASSEMBLE THE 2 SIDE SCREENS TO THE CENTRE SCREEN AS DEPICTED BELOW USING THE 8 CORNER
BRACKETS AND THE 16 M6x65 BOLT ASSEMBLIES INCLUDED IN THE KIT.
TIGHTEN THE M6 BOLTS TO 15Nm (11 lbf.ft).
STEP 2:
ASSEMBLE THE DIPOLE TO THE CENTRE SCREEN AS DEPICTED BELOW USING THE 2 LARGE CLAMP PLATES
AND THE 4 M12 STUD ASSEMBLIES INCLUDED IN THE KIT. TIGHTEN THE M12 NUTS TO 55Nm (40 lbf.ft).
LEAVE APPROXIMATELY 110mm PROTRUDING OUT THE BACK SIDE.
INS-40101-5 ©RF Industries Pty Ltd 2009
www.bird-technologies.com
PAGE 2 OF 4

406-512 MHz
CSA40-67-DIN
MOUNTING TUBE
(NOT INCLUDED)
ANTENNA MOUNTING HARDWARE HAS BEEN
DESIGNED TO ACCEPT MOUNTING TUBE
DIAMETERS IN THE RANGE OF 50-75mm (2-3")
MOUNTING TUBE LENGTH TO BE SIZED BY
INSTALLER TO SUIT INSTALLATION METHOD.
PLEASE NOTE MOUNTING POLE NOT SUPPLIED.
LARGE CLAMP PLATE
INS-40101-5 ©RF Industries Pty Ltd 2009
www.bird-technologies.com
PAGE 3 OF 4
ASSEMBLY INSTRUCTIONS continued
STEP 3:
WITH THE ANTENNA ASSEMBLY LOCATED ON THE MOUNTING TUBE ATTACH THE REMAINING 2 LARGE
CLAMP PLATES AND TIGHTEN THE M12 NUTS CLAMPING THE ANTENNA ASSEMBLY TO THE MOUNTING
TUBE. TIGHTEN TO 55Nm (40 lbf.ft)

406-512 MHz
CSA40-67-DIN
TOWER
OUTRIGGER
TOWER CLAMPS
MOUNT POLE
SCREENED ARRAY ASSEMBLY
CSA-40-67-DIN
SCREENED ARRAY IS DESIGNED TO BE
FIXED TO A TOWER MOUNTED POLE OR
TOWER LEG.
ENSURE THAT MOUNTING POLE,
CLAMPS AND MOUNTING STRUCTURE IS
APPROPRIATELY SIZED TO SUIT LOCAL
WIND AND ICE INSTALLATION
CONDITIONS.
NOTE : MOUNTING POLE NOT SUPPLIED
STRAIN RELIEVE FEED CABLE BACK
TO SUPPORT STRUCTURE. SEAL
CONNECTOR WITH A SUITABLE SELF
AMALGAMATING TAPE.
TYPICAL
INSTALLATION
SIDE VIEW
THESE ITEMS
NOT
INCLUDED
IN ANTENNA KIT:
ASSEMBLY INSTRUCTIONS continued
TYPICAL INSTALLATION
INS-40101-5 ©RF Industries Pty Ltd 2009
www.bird-technologies.com
PAGE 4 OF 4
