MARLOW MIRROR 30" (77CM) X 40" (102CM)
ASSEMBLY & INSTALLATION INSTRUCTIONS
ENGLISH

MARLOW MIRROR 30" (77 CM) X 40" (102 CM) ENGLISH
RH.COM
REVISION 06-01-22
MARLOW MIRROR 30" (77 CM) X 40" (102 CM)
PARTS INCLUDED
(A) Mirror With Bracket x 1
(B) Wall Bracket (400 x 43 x 10 x 3 mm) x 1
(C) Flatten-head Screw (M8 x 40 mm) x 4
(D) Plastic Anchors (ø14 x 47 mm) x 4
(E) Hollow Wall Anchors (M3 x 60 mm) x 4
TOOLS NEEDED
(A) Carpenter’s level
(B) Phillips head screwdriver
BEFORE YOU BEGIN
Professional installation recommended.
E
D
C
B
A

MARLOW MIRROR 30" (77 CM) X 40" (102 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARNING
DO NOT STACK ANYTHING ON TOP OF THE MIRROR. KEEP
THE MIRROR PACKAGED UNTIL INSTALLATION. STORE MIRROR
UPRIGHT ON THE LONG EDGE.
SAFETY INSTRUCTIONS
MIRROR HANDLING INSTRUCTIONS
1. Remove vertically from package.
2. Always carry mirror vertically as illustrated. Carrying flat will cause
breakage.

MARLOW MIRROR 30" (77 CM) X 40" (102 CM) ENGLISH
RH.COM
REVISION 06-01-22
INSTALLATION OF MIRROR
1. Determine desired location for the mirror (A).
2. Preset the mirror on wall and mark the location with a light pencil
mark. Use tape or pencil to transcribe the location of the back
of the mirror’s pre-drilled bracket to the wall. See FIGURE 1.
3. Hold the wall bracket (B) against the wall, ensuring the bracket
screw holes must be corresponding to each stud on the wall. Attach
the wall bracket to the wall with stud by using screws (C) provided.
Tighten until snug against wall. See FIGURE 2.
4. Note: If your wall type is not wall is not wall with stud, please use
steps with wall type option as below:
- CONCRETE: Drill pilot hole on each marking, and then insert
plastic anchor (D). Use a screwdriver to attach the wall bracket
to the wall with screws (C).
- DRYWALL WITHOUT STUDS: Use hollow wall anchors and screws
(E) to affix to drywall.
5. Carefully hang mirror (A) on wall bracket (B) as illustrated FIGURE3.
Mirror may be hung vertically or horizontally. Refer to FIGURE 4.
B
C
Wall
Stud
FIGURE 1
FIGURE 2
FIGURE 3 FIGURE 4
Line of pencil
Horizontal
Vertical
FIGURE 4

MARLOW MIRROR 30" (77 CM) X 40" (102 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARRANTY
If you are not completely satisfied with your purchase, please contact
us to return or exchange your item(s) within 30 days of the delivery
date, with proof of purchase. Note that returns or exchanges are not
accepted for special orders, items that have been installed, mattresses
and/or foundations no longer in their original packaging, and other
items listed below. Other exclusions may apply. Contact us for details.
Unfortunately, galleries cannot accept returns of furniture or other large
items.
CARE INSTRUCTIONS
To maintain and protect the luster of all product clean with a soft damp
cloth only.

MARLOW MIRROR 26" (67CM) X 48" (122CM)
ASSEMBLY & INSTALLATION INSTRUCTIONS
ENGLISH

MARLOW MIRROR 26" (67 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
MARLOW MIRROR 26" (67 CM) X 48" (122 CM)
PARTS INCLUDED
(A) Mirror With Bracket x 1
(B) Wall Bracket (400 x 43 x 10 x 3 mm) x 1
(C) Flatten-head Screw (M8 x 40 mm) x 4
(D) Plastic Anchors (ø14 x 47 mm) x 4
(E) Hollow Wall Anchors (M3 x 60 mm) x 4
TOOLS NEEDED
(A) Carpenter’s level
(B) Phillips head screwdriver
BEFORE YOU BEGIN
Professional installation recommended.
E
D
C
B
A

MARLOW MIRROR 26" (67 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARNING
DO NOT STACK ANYTHING ON TOP OF THE MIRROR. KEEP THE
MIRROR PACKAGED UNTIL INSTALLATION. STORE MIRROR
UPRIGHT ON THE LONG EDGE.
SAFETY INSTRUCTIONS
MIRROR HANDLING INSTRUCTIONS
1. Remove vertically from package.
2. Always carry mirror vertically as illustrated. Carrying flat will cause
breakage.

MARLOW MIRROR 26" (67 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
INSTALLATION OF MIRROR
1. Determine desired location for the mirror (A).
2. Preset the mirror on wall and mark the location with a light pencil
mark. Use tape or pencil to transcribe the location of the back of the
mirror’s pre-drilled bracket to the wall. See FIGURE 1.
3. Hold the wall bracket (B) against the wall, ensuring the bracket
screw holes must be corresponding to each stud on the wall. Attach
the wall bracket to the wall with stud by using screws (C) provided.
Tighten until snug against wall. See FIGURE 2.
4. Note: If your wall type is not wall is not wall with stud, please
use steps with wall type option as below:
- CONCRETE: Drill pilot hole on each marking, and then insert
plastic anchor (D). Use a screwdriver to attach the wall bracket
to the wall with screws (C).
- DRYWALL WITHOUT STUDS: Use hollow wall anchors and screws
(E) to affix to drywall.
5. Carefully hang mirror (A) on wall bracket (B) as illustrated FIGURE 3.
Mirror may be hung vertically or horizontally. Refer to FIGURE 4.
B
C
Wall
Stud
FIGURE 1
FIGURE 2
FIGURE 3 FIGURE 4
Horizontal
Vertical
Line of pencil

MARLOW MIRROR 26" (67 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARRANTY
If you are not completely satisfied with your purchase, please contact
us to return or exchange your item(s) within 30 days of the delivery
date, with proof of purchase. Note that returns or exchanges are not
accepted for special orders, items that have been installed, mattresses
and/or foundations no longer in their original packaging, and other
items listed below. Other exclusions may apply. Contact us for details.
Unfortunately, galleries cannot accept returns of furniture or other large
items.
CARE INSTRUCTIONS
To maintain and protect the luster of all product clean with a soft damp
cloth only.

MARLOW MIRROR 36" (92CM) X 48" (122CM)
ASSEMBLY & INSTALLATION INSTRUCTIONS
ENGLISH

MARLOW MIRROR 36" (92 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
MARLOW MIRROR 36" (92 CM) X 48" (122 CM)
PARTS INCLUDED
(A) Mirror With Bracket x 1
(B) Wall Bracket (550 x 43 x 10 x 3 mm) x 1
(C) Flatten-head Screw (M8 x 40 mm) x 6
(D) Plastic Anchors (ø14 x 47 mm) x 6
(E) Hollow Wall Anchors (M3 x 60 mm) x 6
TOOLS NEEDED
(A) Carpenter’s level
(B) Phillips head screwdriver
BEFORE YOU BEGIN
Professional installation recommended.
E
D
C
B
A

MARLOW MIRROR 36" (92 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARNING
DO NOT STACK ANYTHING ON TOP OF THE MIRROR. KEEP
THE MIRROR PACKAGED UNTIL INSTALLATION. STORE MIRROR
UPRIGHT ON THE LONG EDGE.
SAFETY INSTRUCTIONS
MIRROR HANDLING INSTRUCTIONS
1. Remove vertically from package.
2. Always carry mirror vertically as illustrated. Carrying flat will cause
breakage.

MARLOW MIRROR 36" (92 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
INSTALLATION OF MIRROR
1. Determine desired location for the mirror (A).
2. Preset the mirror on wall and mark the location with a light pencil
mark. Use tape or pencil to transcribe the location of the back
of the mirror’s pre-drilled bracket to the wall. See FIGURE 1.
3. Hold the wall bracket (B) against the wall, ensuring the bracket
screw holes must be corresponding to each stud on the wall. Attach
the wall bracket to the wall with stud by using screws (C) provided.
Tighten until snug against wall. See FIGURE 2.
4. Note: If your wall type is not wall is not wall with stud, please
use steps with wall type option as below:
- CONCRETE: Drill pilot hole on each marking, and then insert
plastic anchor (D). Use a screwdriver to attach the wall bracket
to the wall with screws (C).
- DRYWALL WITHOUT STUDS: Use hollow wall anchors
and screws (E) to affix to drywall.
5. Carefully hang mirror (A) on wall bracket (B) as illustrated FIGURE3.
Mirror may be hung vertically or horizontally. Refer to FIGURE 4.
B
C
Wall
Stud
FIGURE 1
FIGURE 2
FIGURE 3 FIGURE 4
Horizontal
Vertical
Line of pencil

MARLOW MIRROR 36" (92 CM) X 48" (122 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARRANTY
If you are not completely satisfied with your purchase, please contact
us to return or exchange your item(s) within 30 days of the delivery
date, with proof of purchase. Note that returns or exchanges are not
accepted for special orders, items that have been installed, mattresses
and/or foundations no longer in their original packaging, and other
items listed below. Other exclusions may apply. Contact us for details.
Unfortunately, galleries cannot accept returns of furniture or other large
items.
CARE INSTRUCTIONS
To maintain and protect the luster of all product clean with a soft damp
cloth only.

MARLOW MIRROR 42" (107CM) X 78" (199CM)
ASSEMBLY & INSTALLATION INSTRUCTIONS
ENGLISH

MARLOW MIRROR 42" (107 CM) X 78" (199 CM) ENGLISH
RH.COM
REVISION 06-01-22
MARLOW MIRROR 42" (107 CM) X 78" (199 CM)
PARTS INCLUDED
(A) Mirror With Bracket x 1
(B) Wall Bracket (550 x 43 x 10 x 3 mm) x 2
(C) Flatten-head Screw (M8 x 40 mm) x 12
(D) Plastic Anchors (ø14 x 47 mm) x 12
(E) Hollow Wall Anchors (M3 x 60 mm) x 12
TOOLS NEEDED
(A) Carpenter’s level
(B) Phillips head screwdriver
BEFORE YOU BEGIN
Professional installation recommended.
E
D
C
B
A

MARLOW MIRROR 42" (107 CM) X 78" (199 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARNING
DO NOT STACK ANYTHING ON TOP OF THE MIRROR. KEEP THE
MIRROR PACKAGED UNTIL INSTALLATION. STORE MIRROR
UPRIGHT ON THE LONG EDGE.
SAFETY INSTRUCTIONS
MIRROR HANDLING INSTRUCTIONS
1. Remove vertically from package.
2. Always carry mirror vertically as illustrated. Carrying flat will cause
breakage.

MARLOW MIRROR 42" (107 CM) X 78" (199 CM) ENGLISH
RH.COM
REVISION 06-01-22
INSTALLATION OF MIRROR
1. Determine desired location for the mirror (A).
2. Preset the mirror on wall and mark the location with a light pencil
mark. Use tape or pencil to transcribe the location of the back of the
mirror’s pre-drilled bracket to the wall. See FIGURE 1.
3. Hold the wall bracket (B) against the wall, ensuring the bracket
screw holes must be corresponding to each stud on the wall. Attach
the wall bracket to the wall with stud by using screws (C) provided.
Tighten until snug against wall. See FIGURE 2.
4. Note: If your wall type is not wall is not wall with stud, please use
steps with wall type option as below:
- CONCRETE: Drill pilot hole on each marking, and then insert
plastic anchor (D). Use a screwdriver to attach the wall bracket to
the wall with screws (C).
- DRYWALL WITHOUT STUDS: Use hollow wall anchors and screws
(E) to affix to drywall.
5. Carefully hang mirror (A) on wall bracket (B) as illustrated FIGURE3.
Mirror may be hung vertically or horizontally. Refer to FIGURE 4. At
the same time, refer to distance of the wall brackets for the 2 opiton
vertical or horizontal.
B
C
Wall
Stud
FIGURE 1
FIGURE 2
FIGURE 3 FIGURE 4
Horizontal
Vertical
Line of pencil
1145 mm
480 mm
Variable
(Min = 380 mm) Variable
(Min = 255 mm)
Floor Floor
Vertical Hozirontal

MARLOW MIRROR 42" (107 CM) X 78" (199 CM) ENGLISH
RH.COM
REVISION 06-01-22
WARRANTY
If you are not completely satisfied with your purchase, please contact
us to return or exchange your item(s) within 30 days of the delivery
date, with proof of purchase. Note that returns or exchanges are not
accepted for special orders, items that have been installed, mattresses
and/or foundations no longer in their original packaging, and other
items listed below. Other exclusions may apply. Contact us for details.
Unfortunately, galleries cannot accept returns of furniture or other large
items.
CARE INSTRUCTIONS
To maintain and protect the luster of all product clean with a soft damp
cloth only.
