Rice Lake Survivor SR2411-SC-60 User manual

S E R I E S
TRUCK SCALES
SR & EZ
Vehicle Scale
Handbook
Toughest
Truck Scales
On Earth.
45700

Preface
How to use this Vehicle Scale Handbook
This handbook is an aid to help you in making a truck scale presentation on the SURVIVOR series vehicle
scales.
This booklet is divided into sections devoted to specific truck scale concerns and needs.
Introduction: Planning a truck scale installation
US State and Canadian Province truck size and weight regulations
Scale information: Weighbridge structure
Wiring, Electronics, and Lightning Protection
Site information: Foundation requirements
State Weights and Measures agencies
Installation information: Recommended equipment (SR series)
Recommended equipment (EZ series)\
Engineering details: Specifications sheets (SR and EZ series)
Engineering reference quote sheet (SR and EZ series)
Quotation Form
Warranty: Vehicle scale warranty
Shipping and Scheduling: Shipping Guidelines for SR series
Shipping Guidelines for EZ series
Simplified Buyers Guide: Questionnaire pullout section for the truck scale buyer
Drawing Package 70’x14’ 100-ton SR Concrete Deck Scale and foundation options
By reviewing this booklet, you will be better equipped to make an informed decision on what is a very
expensive and long-term investment.
Should you have any questions concerning this booklet or other scale-related issues, please call Rice Lake
Weighing Systems at [phone].
© 1998 Rice Lake Weighing Systems, Inc. Rice Lake, WI USA. All Rights Reserved.
RICE LAKE WEIGHING SYSTEMS • 230 WEST COLEMAN STREET • RICE LAKE, WISCONSIN 54868 • USA

Contents
Planning a Truck Scale Installation .................................................................................................. 1
US State and Canadian Province Truck Size and Weight Regulations .......................................... 3
Scale Information ............................................................................................................................... 7
Weighbridge Structure .................................................................................................................... 7
Concentrated Load Capacity (CLC) ......................................................................................... 7
Federal Bridge Standards “r” factor ......................................................................................... 7
Span Deflection Ratio............................................................................................................... 8
Truck Scale Grounding and Lightning Protection.......................................................................... 9
Lightning and Transient Protection Options........................................................................... 10
Lightning Protection Extended Warranty Coverage............................................................... 11
Lightning Protection Extended Warranty Inspection Document............................................ 12
Electrical Conduit Requirements for Scale Wiring ...................................................................... 13
Site Information and Foundation Specifications ........................................................................... 14
Overview ...................................................................................................................................... 14
Soil Bearing Capacity............................................................................................................. 14
Deviation from Published Specifications ............................................................................... 14
Concrete Sampling ................................................................................................................. 14
Concrete, Rebar, and Mesh Requirements ................................................................................... 15
Foundation and Deck Material for 11' SR-Series Scales........................................................ 15
Foundation and Deck Material for 12' SR-Series Scales........................................................ 16
Foundation and Deck Material for 14' SR-Series Scales........................................................ 17
Checklist of Foundation Questions .............................................................................................. 18
State Weights and Measures Directors ......................................................................................... 19
Installation Information................................................................................................................... 25
SR Series Assembly Overview .....................................................................................................25
Scheduling and Labor Guidelines for SR-Series Installation................................................. 25
Recommended Equipment and Tools ..................................................................................... 25
EZ Series Assembly Overview .....................................................................................................26
Scheduling and Labor Guidelines for EZ-Series Installation................................................. 26
Recommended Equipment and Tools ..................................................................................... 26
Engineering Details .......................................................................................................................... 27
SR-Series Engineering Specifications Sheet ................................................................................ 27
SR-Series Specifications .............................................................................................................. 29
Standard Equipment Supplied by RLWS ............................................................................... 29
Distributor-Supplied Equipment............................................................................................. 29
EZ-Series Engineering Specifications Sheet ................................................................................ 31
EZ-Series Specifications............................................................................................................... 33
Standard Equipment Supplied by RLWS ............................................................................... 33
Distributor-Supplied Equipment............................................................................................. 33
Truck Scale Pricing with Options................................................................................................. 35
Continued

Vehicle Scale Limited Warranty...................................................................................................... 36
Vehicle Scales Labor and Travel Reimbursement Program ......................................................... 37
Labor and Mileage Claims under Vehicle Scale Limited Warranty ....................................... 37
Parts Replacement under Vehicle Scale Limited Warranty .................................................... 37
Shipping and Scheduling Guidelines ..............................................................................................38
SURVIVOR SR Shipping............................................................................................................. 38
SURVIVOR EZ Shipping............................................................................................................. 38
Truck Scale Buyer’s Questionnaire ................................................................................................ 39
Application Specifics.................................................................................................................... 39
Site Selection Specifics ................................................................................................................ 39
Foundation Specifics .................................................................................................................... 40

1
Planning a Truck Scale Installation
A vehicle scale is a major investment and probably represents one of the most expensive weighing
systems you will ever buy. With that expense in mind, the decision must be founded in long-range plan-
ning that takes into account all present and likely future uses of the scale system. Ideally, a qualified
project engineer familiar with your industry should analyze your company's needs and write specifica-
tions for a comprehensive solution to meet those needs. Alternately, you can do your own analysis, then
write your own specifications before purchasing a vehicle scale. Whichever method you choose to
transfer your needs to a written specification, the variety of information needed may surprise you.
The comprehensive information you need to compile a “system” specification must normally be sought
from several sources. The purpose of this handbook is to provide you with some of the hard-to-find
information required, and to help you discover the right questions to ask. Only by asking the hard ques-
tions will you eventually find the best solutions for all aspects of your total vehicle weighing system.
The following questions will help you discover and organize the information needed to make informed,
long-range decisions and find the best solutions for the complete vehicle-weighing system.
Capacities
1. What type of trucks will be weighed? Single-axle? Dual-axle? Tri-axle?
What are the maximum axle loads of each type expected?
2. How long should the weighing platform be for current and future needs?
What is the maximum legal truck/trailer combination length in your state?
3. How many weighments are expected per day?
4. Are axle weights necessary, or only gross vehicle weights?
5. What is the maximum total weight expected to be weighed on the scale?
What is the minimum total weight expected to be weighed on the scale?
Site Location
6. What approach length is required by NTEP? Is there sufficient room?
7. Will existing traffic patterns at the site interfere with the vehicle scale?
8. Will high groundwater or even occasional flooding create a possible problem?
9. Is there abnormal RFI/EMI noise at the site?
10. Is the site located within a hazardous environment?
11. Will you possibly want to relocate the scale in future years?
12. Are soil-bearing characteristics acceptable without major excavation and fill?
13. Will underground utilities need to be rerouted from the site?
14. Is there construction and maintenance access to both or only one side of the scale?

2
Life Cycle and Warranty Considerations
15. The heart of a vehicle scale is the weighbridge. How long is the weighbridge warranty?
16. How much does the deck bend under a maximum legal highway load on tandem-axle spacing?
17. What is the “r” factor of the weighbridge compared to Federal Bridge Standards?
Load Cells and Suspension
18. Are load cells NTEP-approved for legal-for-trade applications?
19. Are load cells sized at 75,000 lbs to protect against accidental overload?
20. Are stainless steel, hermetically-sealed load cells needed for chemical or water contact?
21. Are load cell mount suspension systems self-checking and self-centering?
22. How long is the standard load cell warranty?
23. Is extended warranty lightning insurance available and needed for load cells?
The following map of thunderstorm frequency may be helpful in answering this question.
Average Days of Thunderstorm Activity in US
Zone 2
15 – 34
Zone 1
Less than 14 Zone 4
55 – 74
Zone 3
35 – 54 Zone 5
More than 74
WI
MN
ND
SD
NE IA
CA
KS
OK
TX
MO
AR
LA
IL IN OH
MI
KY
TN
MS AL GA
FL
SC
VA
PA
ME
VT
NH
MA
RI
CT
NJ
DE
MD
AK
HI
WV
NC
NV
OR
WA
ID WY
UT
NM
CO
AZ
MT
NY
