Rich electric INVERTEK L series User manual

INVERTEK®
SWITCH-MODE BATTERY CHARGER
(MICROPROCESSOR SYSTEM)
USER MANUAL
FOR ALL PATTERNS 1 AND 3 OUTPUTS
利佳興業股份有限公司
RICH ELECTRIC CO.,LTD.

1
CONTENTS
Introduction............................................................................................................2
Technical Features.................................................................................................2
Advanced Charging Technique ............................................................................3
Safety Devices.........................................................................................................3
Options....................................................................................................................4
Safety Instruction...................................................................................................4
Installation..............................................................................................................5
Front Panel.............................................................................................................7
LED Indicators.......................................................................................................7
Instruction of Charging Curve Selection ...........................................................7
DC Power Supply...................................................................................................9
BTS/Remote Control ...........................................................................................10
Trouble Shooting Guide......................................................................................10
Specification .........................................................................................................11

2
Introduction
Invertek Battery Charger is small and lightweight charger that offers charging patterns
which are perfectly adapted to each battery technology (liquid electrolyte, gel electrolyte,
lead calcium, etc... ). A charging pattern may be factory set to suit your specific
application. To prolong the life of your batteries and conserve their initial capacity, the
charger is programmed with 5 three-state charging patterns:
zBOOST Charge/FAST Charge :Restores battery capacity until 80 % in a short
space of time.
zABSORPTION Charge/BALANCE Charge : Complements of charge until 100 %
of battery capacity
zFLOATING Charge/TOP-UP Charge : Compensates for constant battery drain,
while keeping the battery fully charged.
Invertek Battery Charger is the only charger on the market to allow the battery to be
connected and used constantly, while still offering a real BOOST (high voltage) charge
over short period. The charger switches back to top-up mode automatically.
In accordance with EC standards, the Invertek Battery charger is fitted with a PFC
(Power Factor Corrector) which limit peak current draw from the input power required
from the generator or Mains supply to be reduced.
Technical Features
-Management and control by microprocessor
-Charging curve of 3 states IUU type
- UNIVERSAL input voltage 90V to 250VAC (item 12V/40A, 12V/60A, 24V/30A,
24V/50A)
- Input voltage 230V ~ +10%/-15% (item 12V/20A, 24V/15A )
- Frequency 50/60Hz
- Output voltage Ubat ±1% ; output current Ibat ±5%
- Operating temperature -10 to + 45°C; storage temperature -20 to +70°C
- Charging curve selection by rotate switch for 5 different batteries types
- Sensor used to balance charging voltage according to temperature gaps (-27mV/°C)
- Automatic air vented cooling
- Protection Index IP 235

3
Advanced Charging Technique
Charging curves of the 3-state IUU type, with a boost phase and a floating phase.
The 3-state charging characteristic, used on boats everywhere, saves on charging time. In
addition, the charger can be adapted to all types of battery thanks to its 5 integral
charging curves supervised by a micro controller. Charge cycle starts on with the mains
power-up of product.
BOOST/Fast Charge
Charging continues at constant current (charger Inom) until the battery reaches the
maximum boost voltage. This voltage is maintained until the charging current falls to
Inom/8 ~Inom/10 boost charge over short period (12 hours) from the mains power-up of
product. This phase makes it possible to supply the maximum amount of energy in the
least possible time.
FLOATING/Top-Up Charge
The charger supplies just the current necessary to keep the battery at a constant and stable
voltage (floating voltage). This charging mode allows 12-volt equipment to be used
continuously (water pump, refrigeration, auto pilot, radio, lights, etc.) without the
batteries discharging.
It means that the on-board circuit can be used while keeping the battery charge level
constant. WITHOUT BATTERY AND IN SPECIAL CIRCUMSTANCES, THE
INVERTEK CHARGER SUPPLIES STABLE VOLTAGE.
General form of the charging curve (five possible levels according to battery type)
Top-up ChargeBalance ChargeFast Charge
CURRENT
VOLTAGE
CAPACITY Ah
ABSORPTION FLOATINGBOOST
Charging Current
The nominal current shown in case of nominal voltage is the mean current supplied by
the charger.
Safety Devices
Electronic protection against:
- Output short-circuits
- Battery discharge in the event of mains failure

4
Disjonction protection against:
- Battery overvoltage or undervoltage
- Battery or charger overtemperature
Protection by fuses against :
- Mains input overload
- Battery polarity inversion
Anti-corrosion
Casing in aluminum with anti-corrosion paint.
Anti-impact
Resistance to impacts in normal use thanks to the 1.8 mm-thick casing (1,5mm for the
cover).
Ventilation
If the internal charger sensor exceeds 45°C, the fan starts. If the internal charger sensor
decreases to 40°C, the fan stops.
Options
1. Battery Temperature Sensor (BTS):
Sensor is used to balance charging voltage according to temperature gaps, compared
with reference temperature 25°C. If temperature exceeds 45°C, pre-alarm starts and
LED of BTS OH flashes. If temperature exceeds 50°C, charging stops and BTS OH is
lit on. Charging restarts when temperature is less than 50°C.
Procedure of connecting BTS is:
1. Disconnect the charger from the mains (MANDATORY). To avoid short-circuit,
disconnect the batteries.
2. Extract fixing screw from wires cover and remove it
3. Connect the sensor connector to the green terminal on the PCB. (See figure A)
4. Connect charger to the mains
5. Fix the temperature sensor(s) on corresponding battery(ies) with double-sided
adhesive tape supplied with sensor.
To disconnect sensor from the charger, charger must be disconnected from the mains
before (even if the charger indicates a default).
CAUTION: In case of fault, charger switches off automatically. Disconnect charger from
mains then wait for approximately 10 minutes before starting it again.
2. Remote Control: It can be connected to the Invertek charger. All operating controls
and displays are available on the remote control unit.
Safety Instruction
A battery can generate gas in the case of high overcharge, that can be explosive.
Attention must be paid to produce no spark or flame near a battery on charge, arrange for
a well-ventilated room.
Invertek charger limits overcharges and reduces this risk.
zExcessive discharges are among the principal causes of premature wear.
Invertek charger prevents such excessive discharge. After every discharge, (especially

5
higher than 50%), recharging should not be deferred for a long time.
zLow and permanent overcharge is another cause of premature wear. The Invertek
Charger delivers the current necessary for battery charge and adapts itself to supply
the optimum end of charge.
zThe accidental and violent overcharge or higher end of charge current produces early
destruction by excessive rise of temperature. The temperature should not exceed 50°C.
By the regulation of the current, the Invertek protects the battery from the temperature
rise at the end of charge.
It is advisable to
zPut batteries in a well ventilated area
zNot to smoke near batteries
zTake the battery manufacturer prescriptions into consideration
Accidental Leakage Current between Line And Earth
zConnections will be realized by an electrician or a professional installer.
zThe charger must be connected to a system having a two-pole differential circuit
breaker with 30 mA sensitivity.
Accidental Leakage Current between Charge Circuit and Earth
zTo detect accidental leakage currents to earth, you must use a safety device outside
the charger.
zThe rating and nature of the protection must be ensured by the installer.
zSpecial precautions are recommended on any installation where there is a danger of
electrolytic effects.
zRegulations require the presence of a battery cut-out on the output + pole and on
the output – pole.
Precautions Regarding Lightning Strike
In geographic zones exposed to a high risk of lightning strikes, it may be recommended
fitting a lightning conductor on the inlet side of the charger. Rich Electric will not take
charge of damaged caused by lightning strike.
Precautions Regarding Electromagnetic Interference
zMake sure the length of the cables and screening connections are kept as short as
possible.
zSeparate the power supply cables from output cables.
zCables must only carry the charger power supply. Branch or bridging connections in
order to supply another equipment are too be banned.
Installation
The location of the Invertek charger must be chosen by the following criteria:
Protection from unauthorized handling.
Dry dust free room, no condensation, no rodents.
Keep ventilation holes free. The ventilation of the Invertek is designed in such a way that
it will work most efficiently when mounted horizontally.
Before any connection, put the switch on the right charging curve.

6
1. Connect the positive battery on terminal marker +BAT 1 and open the entry of the
upper case to tighten it with screws.
2. Connect the negative battery cable to terminal marker –BAT and open the entry of the
upper case to tighten it with screws.
3. Do the same for batteries number 2 and 3 for +BTA 2 and +BTA 3. For a 3 outputs
charger, refer to the table below to choose conductor section.
-BAT+BAT1+BAT2+BAT3
BTS3BTS2BTS1
+BAT3 +BAT2 +BAT1 -BAT
BTS1 BTS2 BTS3
FigureA: Batteries terminals and BTS terminals
Battery fuse board:
Model No. 12V/20A 12V/40A 12V/60A
FUSE Atofuse (car) 1 x 25A 2 x 25A 2 x 30A
Model No. 24V/15A 24V/30A 24V/50A
FUSE Atofuse (car) 1 x 15A 2 x 15A 2 x 30A
WARNING: Check carefully the tightness of the battery connections to the charger (risk
if not properly tightened). Rich Electric will not take charge of damage caused by a
bad tightness of connections.
Don’t connect a charge distributor on an Invertek charger, 1 or 3 outputs.
4. Put the AC power cord in the rear panel. The charger operates on sector 90V to 250
VAC - 50/60 Hz.
5. Conductor section according to charge current cables length is as follows.
Sector flex section (5m)
Length
Current 5m 10m 15m
220V 110V
Puissance
(W)
30A 6 mm210 mm216 mm21.5 mm22.5 mm2750
40A 10 mm216 mm225 mm21.5 mm21.5 mm2500
50A 16 mm225 mm235 mm21.5 mm22.5 mm21200
60A 25 mm225 mm235 mm21.5 mm22.5 mm2750
Main fuse board:
Model No. 12V/20A, 12V/40A, 12V/40A,
24V/15A, 24V/30A, 24V/50A
Temporized glass fuse 6.3x32mm 16A

7
Front Panel
Remote
Control
BTS
FLOAT VOLTAGE
BOOST VOLTAGE
BATTERY TYPE
FUSE OPEN
BTS OH
OH
UV/OV
FLOATING
ABSORPTION
BOOST
POWER
MICROPROCESSOR SYSTEM
SWITCH-MODE BATTERY CHARGER
R
Invertek
POWER
Top-up ChargeBalance ChargeFast Charge
CURRENT
VOLTAGE
CAPACITY Ah
BOOTS ABSORPTION FLOATING
0
1
LED Indicators
POWER: It is lit when the AC power has been input through the AC plug.
BOOST: It is lit as long as the battery is not fully charged at set charge current.
ABSORPTION: It is lit as long as the battery is not fully charged at set voltage.
FLOATING: It is lit when the battery is fully charged.
UV/OV:
Under Voltage---Deep battery discharge Ubat < 10V for 12V system and < 20V for 24V
system. If Ubat stays < 10V for 12V system and < 20V for 24 system
during more than 5 minutes, charger shuts down. To restart the charger:
disconnect the mains, wait few minutes and reconnect the charger on
mains.
Over Voltage--- Battery overcharge Ubat >16V for 12V system and > 32V for 24V
system. If Ubat >16V for 12V system and > 32V for 24V system
during more than 5 minutes, charger shuts down. To restart the charger:
disconnect the mains, wait few minutes and reconnect the charger on
mains.
OH: Over Heat---It is flashing when the heatsink of the charger reaches > 70℃. The
charger shuts down when the charger is > 80℃.
BTS OH: Battery Temperature Sensor Over Heat--- It is flashing when the BTS reaches
> 45℃. The charger shuts down when the battery temperature is > 50℃.
FUSE OPEN: Fuse is broken.
Instruction of Charging Curve Selection (4 Battery Types and 1 User
Define)
Every battery is designed according to particular technology and therefore calls for a
particular charging curve.
With Invertek battery charger, you can achieve this perfect match between battery and
charger using a switch, which is simply positioned according to the required, charging
curve.

8
Note: Do indicate the type of your battery when buying the charger, and position the
switch correctly before use.
The user can very easily adapt the Invertek charger to the type of battery by rotate switch
used.
To modify configuration, carryout the following steps:
STEP 1: Disconnect charger from the mains. To avoid short-circuit, disconnect the
batteries.
STEP 2: According to 4 different battery types and desired charge current (30%, 70% and
100%), choose the rotate switch from 1 to C. If the used battery is not in 4 listed
battery types, User Define is available.
BATTERY TYPE U Boost U Float Charge
Current Rotate Switch
14.4V 13.5V 100% 1
14.4V 13.5V 70% 2
Standard lead acid unsealed
14.4V 13.5V 30% 3
14.2V 13.8V 100% 4
14.2V 13.8V 70% 5
Sealed lead acid (Gel Cell)
14.2V 13.8V 30% 6
14.6V 14.0V 100% 7
14.6V 14.0V 70% 8
Lead calcium
(Standard charge) 14.6V 14.0V 30% 9
16.0V 13.8V 100% A
16.0V 13.8V 70% B
Lead calcium
(Deep charge) *1 16.0V 13.8V 30% C
──100% D
──70% E
User Define *2
──30% F
*1 This curve is used to regenerate the battery electrolyte in case of deep discharge (U
Boost 16V), it is indispensable to disconnect the battery from other consumers.
*2 User Define: Use the switches of the BOOST VOLTAGE and FLOAT VOLTAGE to
choose desired voltages from the following tables.
BOOST VOLTAGE Selection
Rotate
Switch Boost Volt. Rotate Switch Boost Volt. Rotate Switch Boost Volt. Rotate Switch Boost Volt.
0 14.4V 5 14.9V A 15.4V F 14.3V
1 14.5V 6 15.0V B 15.6V
2 14.6V 7 15.1V C 15.8V
3 14.7V 8 15.2V D 16.0V
4 14.8V 9 15.3V E 14.2V

9
FLOAT VOLTAGE Selection
Rotate Switch Floating Volt. Rotate Switch Floating Volt.
0 13.5V 5 14.0V
1 13.6V 6 13.1V
2 13.7V 7 13.2V
3 13.8V 8 13.3V
4 13.9V 9 13.4V
STEP 3: Connect charger to the mains.
Example:
To use the Invertek charger of 12V/60A to charge a battery of Sealed lead acid at desired
charging current 42A, users should choose rotate switch of battery type to be “5”.
DC Power Supply
Invertek charger can not only charge the battery but also supply DC power directly. The
desired voltage can be set by the following steps.
STEP 1: Choose the rotate switch of BATTERY TYPE to be“0”.
STEP 2: Use the rotate switch (0~F) of BOOST VOLTAGE to set the first two digits of
desired voltage. Refer to the below table for what 0~F represents.
Rotate
Switch Boost Volt. Rotate Switch Boost Volt. Rotate Switch Boost Volt. Rotate Switch Boost Volt.
0 13.0V 5 16.0V A 16.0V F 16.0V
1 14.0V 6 16.0V B 16.0V
2 15.0V 7 16.0V C 16.0V
3 16.0V 8 16.0V D 16.0V
4 16.0V 9 16.0V E 16.0V
STEP 3: Use the rotate switch (0~9) of FLOAT VOLTAGE to set the decimal of desired
voltage. Refer to the below table for what 0~9 represents.
Rotate Switch Floating Volt. Rotate Switch Floating Volt.
0 0.0V 5 0.5V
1 0.1V 6 0.6V
2 0.2V 7 0.7V
3 0.3V 8 0.8V
4 0.4V 9 0.9V
Example:
To set the desired DC power supply of 14.3V, firstly, choose the rotate switch of
BATTERY TYPE to be“0”and then choose the rotate switch of BOOST VOLTAGE to
be“1”; finally, choose the rotate switch of FLOAT VOLTAGE to be“3”.

10
BTS/Remote Control
It is a port for phone jack of the battery temperature sensor and upcoming remote control
to be connected.
Troubleshooting Guide
Problem and Symptoms Possible Cause Solution
No alternative current or main
fuse is melted down Check the fuse and replace it
No output voltage and/or
intensity Main or generating unit too
weak Check the input voltage
Battery is almost totally
charged Check that the charger is on a floating mode
Intensity of charge is too
weak and less than 10% Alimentation is too weak Check the input voltage
Battery consumption > power
of the charger Reduce the consumption on the battery
Charger delivers a weak
output voltage but a max.
intensity One or several elements of the
battery present a short-circuit Check that there 's no increase of battery temperature
Loss (emission of gas) Change the battery or check the
level of water
Battery is quickly empty
Sulfate on / stagnation
Charge / discharge several time
the battery or check the
charging curve or replace the
battery
Consumption on the battery
during the charge is too
important
Decrease the consumption
Time of charge is too short Choose a more powerful
charger
Battery temperature too weak Use a temperature sensor
Battery is never totally
charged
Defective battery Change the battery
Defective battery Replace the battery
Battery is hot/emission of
gas Temperature of the battery is
too high
Use a temperature sensor and/or
check the charging
curve
UV/OV LED ON
Stop because of battery
voltage < 10 V for 12V or
battery voltage > 16V
(< 20V/> 32V for a 24V
battery )
Disconnect the charger, wait 20
minutes and connect to the main
OH LED flashes or ON The charger is near to the
"switch off" temperature Ventilate the charger
BTS OH LED flashes or
ON
Battery temperature is too high
(with a temperature sensor)
Check the charging curve and
placed the battery in a
ventilated area

11
Problem and Symptoms Possible Cause Solution
Fuse open LED ON
Default of the battery which is
in deep discharged or polarity
inversion of the battery
Check the connection of the
battery, the polarity and
the output fuse
No LED is lighting when
the charger is connected to
the mains
DEFAULT
Check the main input, the
connection of display and
the fuses.
Specifications
Output: 12V
Model No. ADC-20U-122A ADC-40U-123A ADC-60U-123A
Input Voltage Input voltage
230V ~
+10%/-15%
Universal input:
90V to 250V
Output Voltage 12V
Charging Capacity 20A 40A 60A
Frequency 50Hz/60Hz
Output Patterns 1 or 3
Input Voltage U bat +/-2%
Output Current I bat +/-10%
Charging Curve Type 3 states IUU type
(Boost Charge, Absorption Charge, Floating Charge)
Charging Curve Selection By SWITCH for 5 different battery types:
Standard lead acid unsealed, Sealed lead acid (Gel Cell),
Lead calcium (standard charge/deep discharge), User define
Working Temperature -10℃~ +45℃
Storage Temperature -20℃~ +70℃
Protection Feature Against output short-circuit, battery discharge in the event of
mains failure, mains input overload, battery polarity inversion
Protection Options Battery or charger overtemperature
(Temperature sensor)
Dimensions 310x200x70 mm 400x250x80mm 400x250x80 mm
Weight 3 kgs 6 kgs 6 kgs

12
Output: 24V
Model No. ADC-15U-242A ADC-30U-243A ADC-50U-243A
Input Voltage Input voltage
230V ~
+10%/-15%
Universal input:
90V to 250V
Output Voltage 24V
Charging Capacity 15A 30A 50A
Frequency 50Hz/60Hz
Output Patterns 1 or 3
Input Voltage U bat +/-2%
Output Current I bat +/-10%
Charging Curve Type 3 states IUU type
(Boost Charge, Absorption Charge, Floating Charge)
Charging Curve Selection By SWITCH for 5 different battery types:
Standard lead acid unsealed, Sealed lead acid (Gel Cell), Lead
calcium (standard charge/deep discharge), User define
Working Temperature -10℃~ +45℃
Storage Temperature -20℃~ +70℃
Protection Feature Against output short-circuit, battery discharge in the event of
mains failure, mains input overload, battery polarity inversion
Protection Options Battery or charger overtemperature
(Battery Temperature Sensor)
Dimensions 310x200x70 mm 400x250x80mm 400x250x80 mm
Weight 3 kgs 6 kgs 6 kgs
OUTPUT
VOLTAGE
12VDC
24VDC
INPUT VOLTAGE
1- 90~120VAC
2- 180~240VAC
3- 90~240VAC
CHARGE
CURRENT
15A
20A
30A
40A
50A
60A
U: HIGH-FREQ.
DESIGN
L: LOW-FREQ.
DESIGN
POWER CORD
A- American
B- UK
C- Australia
D- Europe
ADC – 20 U – 1 2 2 A
AC TO DC CHARGER
