Richell 3-Step Pet Stool V1 User manual

Top Step
Step (2)
Left Side Leg Cross Bar Step Bar (2)
Right Side Leg
Left Bottom Leg Right Bottom Leg
Bolts (18)
Dowels (4)
Spring Washers (18)
Flat Washers (18)
Screws (4)
Part Set
Appropriate Pet Weight for Proper Usage
lThis product is designed for small to medium size dogs, 6.6 - 33lbs.
Do not use this product for dogs outside of this weight range to avoid unexpected
accidents/injury.
lWood frame coordinates well with home interiors.
lRubber skids keep step stool in place and prevents shifting.
lThis product is designed for use with pets only. Do not place the steps in a location where its use could lead to
possible danger. Choose the location carefully.
lThis product is designed for small to medium dogs and indoor use only. Do not use this product for anything
other than its intended purpose.
lDo not place the step at the top of a staircase or near a glass door where doing so could lead to possible danger.
lPlace the steps on a flat and solid surface.
lDo not use this product while your pet is leashed to avoid unexpected accidents/injuries, such as dog entanglement.
lMake sure each part is properly fixed in place to avoid unexpected serious injury to pets and/or product damage.
lPay special attention while installing this product for your personal safety and to avoid injury. Follow instructions
carefully.
lPlease use this product for dogs that weigh 6.6 - 33lbs. Do not use this product for dogs outside of this weight range
to avoid unexpected accidents/injury.
lDo not lean or hang on to this product to avoid unexpected accidents and/or product damage.
lKeep this product away from all heat sources at all times to avoid unexpected product damage or burn-related
injuries to self/pets.
lOnly use genuine Richell parts and do not alter the design of this product to avoid accidents and/or injury.
Richell USA contact information is listed at the bottom of this manual.
lIf you notice anything wrong with the product, discontinue its use at once.
lThis product is made of natural material. Be careful not to injure self from natural splinters and/or cracks.
Before assembling this product, make sure the following parts are included:
lBe sure the product is securely fixed. If not, tighten the bolts as necessary.
lThis product is designed for indoor use only. Do not use it outdoors.
lThere may be some joint warpage and each product may experience different coloration in the wood grain of
the acacia as frames are made of natural material.
Instruction Manual 3-Step Pet Stool V1
94807
Thank you for choosing Richell's 3-Step Pet Stool V1. Please read this instruction manual carefully before using this product,
and keep for future reference. If you give this product to someone else, please also give this instruction manual to the new owner.
Please note that some parts of the figures shown below may be slightly different from the actual product, for your better
understanding of the structure and proper use of the product.
Features
Important!
Cautions!
Warnings!
Warnings!
The following signs are special remarks for safety use of the product.
Keep these remarks in mind before using this product.
: Remarks on inappropriate use which might cause death, serious injury and/or physical damage.
: Remarks on inappropriate use which might cause slight injury and/or physical damage.
: Remarks on inappropriate use which might cause trouble, damage and/or shorter life to product.
What are the following signs?
Instructions of Proper Use
Cautions!
Important!
Parts
All manuals and user guides at all-guides.com
all-guides.com

Hole for
the Dowel
Hole for
the Bolt
Hole for the Dowel
Outer Side of
Bottom Leg
Flat Washer
Flat Washer
Bolt
Bolt
Spring Washer
Spring Washer
*Before assembling, please make sure which side of the Left/Right Side Leg is the outer side. There are only 8 holes
on the outer side of the Left/Right Side Leg.
*There are 3 holes for the Bolts and 2 holes for the Dowels, which should face the outer side of the Left/Right Bottom Leg.
8.1lbs
Step: Acacia(Lacquer finish) Rubber skid: Elastomer Anti-Slip Carpet: Polyester
Back side of Anti-Slip Carpet:Acrylic resin
Product Name 3-Step Pet Stool V1
15"W x 26"D x 18.5"H
Product Size
Product Weight
Material
lUse a mild detergent and water and clean with a soft cloth/sponge. Cleaning with a scrub brush and/or using a
polishing powder may cause scratches, rust and/or discolor this product.
lWhen using creosol or other disinfectants, make sure to dilute them, otherwise damage to the wood finish or
discoloration may occur.
lDo not use harsh chemicals such as thinner, benzene or alcohol as these may cause damage/discoloration to
the wood finish.
lAfter cleaning, wipe dry with soft cloth or place in a shaded area to air dry; do not place product in direct sunlight.
1. Insert Dowels into the dowel holes of the Left/Right Bottom
Legs. Then attach the Left and Right Side Legs using bolts
as shown below (only one side of the Side Leg needs to be
attached).
2. Insert the Dowels on the Cross Bar into the dowel
holes on the Bottom Leg, followed by attaching the
Top Step/Steps to the Side Leg using Bolts. Then
attach the Step Bars to the bottom Steps using
Screws as shown below.
3. Repeat Steps 1 and 2 to attach the other Bottom Leg/Side Leg.
Side Leg
Bottom Leg
Dowel
Top Step
Step Cross Bar
Bottom Leg
Side Leg
How to Clean
Specifications
lPlease note that product specifications and design may change without prior notice for the purpose of the quality improvement.
*One side needs to be on the bottom when
assembled by one person.
*Please make sure there are no loose Bolts.
How to Assemble Use a Phillips-head screwdriver for assembly.
Step
Screw
Step Bar
Shop for other Pet Supplies on our website.
