Ricoh WG-20 User manual

•Specifications and external dimensions are subject to change without notice.
OPWG2020 -EN Copyright © RICOH IMAGING COMPANY, LTD. 20 4
FOM 0 .02.20 4 Printed in Europe
RICOH IMAGING
COMPANY, LTD.
2-35-7, Maeno-cho, Itabashi-ku,
Tokyo 174-8639, JAPAN
(http://www.ricoh-imaging.co.jp)
RICOH IMAGING
EUROPE S.A.S
112 Quai de Bezons, B.P. 204,
95106 Argenteuil Cedex, FRANCE
(http://www.ricoh-imaging.fr)
RICOH IMAGING
DEUTSCHLAND GmbH
Am Kaiserkai 1, 20457 Hamburg, GERMANY
(http://www.ricoh-imaging.de)
RICOH IMAGING
UK LTD.
PENTAX House, Heron Drive, Langley, Slough,
Berks SL3 8PN, U.K.
(http://www.ricoh-imaging.co.uk)
RICOH IMAGING
AMERICAS CORPORATION
633 17th Street, Suite 2600,
Denver, Colorado 80202, U.S.A.
(http://www.us.ricoh-imaging.com)
RICOH IMAGING
CANADA INC.
1770 Argentia Road Mississauga,
Ontario L5N 3S7, CANADA
(http://www.ricoh-imaging.ca)
RICOH IMAGING
CHINA CO., LTD.
23D, Jun Yao International Plaza, 789 Zhaojiabang
Road, Xu Hui District, Shanghai, 200032, CHINA
(http://www.ricoh-imaging.com.cn)
To ensure the best performance from your camera, please read
the Operating Manual before using the camera.
Digital camera
Operating Manual
Cover_WG20_ENG.fm Page i Thursday, February 6, 2014 11:39 AM

Thank you for purchasing this RICOH WG-20.
Please read this manual before using the camera in order to get the most
out of all the features and functions. Keep this manual safe, as it can be
a valuable tool in helping you to understand all the camera’s capabilities.
Regarding copyrights
Images taken using the RICOH WG-20 that are for anything other than personal
enjoyment cannot be used without permission according to the rights as specified
in the Copyright Act. Please take care, as there are cases where limitations are
placed on taking pictures even for personal enjoyment during demonstrations,
performances or of items on display. Images taken with the purpose of obtaining
copyrights also cannot be used outside the scope of use of the copyright as laid
out in the Copyright Act, and care should be taken here also.
Regarding trademarks
• SDXC Logo is a trademark of SD-3C, LLC.
• Microsoft, Windows and Windows Vista are registered trademarks of Microsoft
Corporation in the United States of America and other countries.
• Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S.
and other countries.
•ArcSoft
®, and its logo are either the registered trademark or trademark
of ArcSoft Inc. in the United States and/or other countries.
• HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing, LLC in the United States and/or
other countries.
• Eye-Fi, the Eye-Fi logo, and Eye-Fi
connected are trademarks of Eye-Fi, Inc.
• Intel, Intel Core and Pentium are trademarks of Intel Corporation in the U.S.
and/or other countries.
• AMD, AMD Athlon and ATI Radeon are trademarks or registered trademarks
of Advanced Micro Devices, Inc.
• NVIDIA and GeForce are trademarks and/or registered trademarks of NVIDIA
Corporation in the U.S. and/or other countries.
• This product supports PRINT Image Matching III. PRINT Image Matching
enabled digital still cameras, printers and software help photographers to
produce images more faithful to their intentions. Some functions are not
available on printers that are not PRINT Image Matching III compliant.
Copyright 2001 Seiko Epson Corporation. All Rights Reserved.
PRINT Image Matching is a trademark of Seiko Epson Corporation.
The PRINT Image Matching logo is a trademark of Seiko Epson Corporation.
• All other trademarks are the property of their respective owners.
Regarding Product Registration
In order to better serve you, we request that you complete the product
registration, which can be found on the CD-ROM supplied with the camera
or on our website. Thank you for your cooperation.
Refer to “Product Registration on the Internet” (p.246) for more information.
WG20_OPM_ENG.book Page 0 Wednesday, February 5, 2014 2:20 PM

1
To users of this camera
• Do not use or store this device in the vicinity of equipment that generates strong
electromagnetic radiation or magnetic fields.
Strong static charges or the magnetic fields produced by equipment such
as radio transmitters could interfere with the monitor, damage the stored data,
or affect the product’s internal circuitry and cause camera misoperation.
• The liquid crystal panel used in the display is manufactured using extremely
high precision technology. Although the level of functioning pixels is 99.99%
or better, you should be aware that 0.01% or fewer of the pixels may not
illuminate or may illuminate when they should not. However, this has
no effect on the recorded image.
• A band of light may appear on the display if the camera is aimed at a bright
subject. This is known as a smear, but it is not a malfunction.
• There is a possibility that the illustrations and the display screen in this manual
are different from the actual product.
• In this manual, SD Memory Cards, SDHC Memory Cards and SDXC Memory
Cards are referred to as SD Memory Cards.
• In this manual, the generic term “computer(s)” refers to either a Windows PC
or a Macintosh hereafter.
• In this manual, the term “battery(ies)” refers to any type of batteries used for this
camera and accessories.
We have paid close attention to the safety of this product. When
using this product, we request your special attention regarding
items marked with the following symbols.
Using Your Camera Safely
Warning This symbol indicates that violating this item
could cause serious personal injuries.
Caution This symbol indicates that violating this item
could cause minor or medium personal injuries,
or loss of property.
WG20_OPM_ENG.book Page 1 Wednesday, February 5, 2014 2:20 PM

2
Warning
• Do not attempt to take the camera apart or modify the camera.
High voltages are present within the camera, and there is a danger
of electric shock if the camera is taken apart.
• If the inside of the camera should become exposed as a result of,
for example, the camera being dropped, please do not under any
circumstances touch such exposed portions, as there is a danger
of receiving an electric shock.
• Wrapping the strap of the camera around your neck is also dangerous.
Please take care that small children do not hang the strap around their
necks.
• If any irregularities occur during use, such as smoke or a strange odor, stop
use immediately, remove the battery or the AC adapter, and contact your
nearest service center. Continuing to use the product can cause a fire or
electric shock.
Caution
• Do not place your finger on the flash when it is discharging as there is a risk
of burns.
• Do not discharge the flash while it is touching your clothing as there
is a risk of discoloring.
• Some portions of the camera heat up during use, so please take care,
as there is a risk of low temperature burns if such portions are held for long
periods of time.
• Should the LCD be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin, in your eyes,
or in your mouth.
• Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any abnormality,
stop using the camera and get medical attention immediately.
About the Camera
WG20_OPM_ENG.book Page 2 Wednesday, February 5, 2014 2:20 PM

3
Warning
• Always use the battery charger and AC adapter exclusively developed for
this product, with the specified power and voltage. Using a battery charger
or AC adapter not exclusive to this product, or using the exclusive battery
charger or AC adapter with an unspecified power or voltage can cause
a fire, electric shock, or camera breakdown. The specified voltage
is 100-240V AC.
• Do not disassemble or modify the product. This can cause a fire or electric
shock.
• If the generation of smoke or strange odor from the product or other
abnormality occurs, immediately discontinue its use and consult your
nearest service center. Continuing to use the product can cause a fire
or electric shock.
• If water should happen to get inside the product, consult your nearest
service center. Continuing to use the product can cause a fire or electric
shock.
• If a thunder storm should occur while using the battery charger or AC
adapter, unplug the AC plug cord and discontinue use. Continuing to use
the product can cause damage to the equipment, fire, or electric shock.
• Wipe off the plug of the AC plug cord if it becomes covered with dust.
Dust on the plug may cause a fire.
Caution
• Do not place heavy objects on the AC plug cord, allow heavy objects
to drop onto it or allow the AC plug cord to become damaged due
to excessive bending. If the AC plug cord becomes damaged, consult
your nearest service center.
• Do not short or touch the output terminals of the product while it is still
plugged in.
• Do not plug in the AC plug cord with wet hands. This can cause an electric
shock.
• Do not subject the product to strong impacts or allow it to drop onto a hard
surface. This can cause a malfunction.
• Do not use the battery charger to charge a battery other than
a rechargeable lithium-ion battery D-LI92. This can cause overheating,
explosion, or battery charger failure.
About the Battery Charger and the AC Adapter
WG20_OPM_ENG.book Page 3 Wednesday, February 5, 2014 2:20 PM

4
• To reduce the risk of hazards, use only a CSA/UL certified power supply
cord set, cord is Type SPT-2 or heavier, minimum NO.18 AWG copper,
one end with a molded-on male attachment plug cap (with a specified
NEMA configuration), and the other is provided with a molded-on female
connector body (with a specified IEC nonindustrial type configuration)
or the equivalent.
Warning
• Be sure to store the battery out of the reach of small children. Placing it in
their mouths may cause an electric shock.
• If any leakage from the battery should come in contact with your eyes,
it may cause a loss of sight. Flush your eyes with clean water and get
medical attention immediately. Do not rub them.
Caution
• Only use the specified battery with this camera. Use of other batteries may
cause an explosion or fire.
• Do not disassemble the battery. Disassembling the battery may cause
an explosion or leakage.
• Remove the battery from the camera immediately if it becomes hot
or begins to smoke. Be careful not to burn yourself during removal.
• Keep wires, hairpins, and other metal objects away from the + and -
contacts of the battery.
• Do not short the battery or dispose of the battery in fire. This can cause
an explosion or fire.
• If any leakage from the battery should come in contact with skin or clothes,
it may cause irritation to the skin. Wash the affected areas thoroughly with
water.
• Precautions for D-LI92 Battery Usage:
BATTERY MAY EXPLODE OR FIRE IF MISTREATED.
- DO NOT DISASSEMBLE OR DISPOSE OF IN FIRE.
- DO NOT CHARGE EXCEPT SPECIFIED CHARGING CONDITION.
- DO NOT HEAT ABOVE 140°F / 60°C, OR SHORT CIRCUIT.
- DO NOT CRUSH OR MODIFY.
About the Battery
WG20_OPM_ENG.book Page 4 Wednesday, February 5, 2014 2:20 PM

5
Warning
• Be sure to keep the camera and its accessories out of the reach of small
children.
1. Injuries may result from the product falling or from unexpected
movement.
2. Suffocation may result from wrapping the strap around the neck.
3. Small accessories such as battery or an SD Memory Card may
be swallowed. Seek medical attention immediately if an accessory
is accidentally swallowed.
• When traveling, take the Worldwide Service Network listing that is included
in the package. This will be useful if you experience problems abroad.
• When the camera has not been used for a long time, confirm that it is still
working properly, particularly prior to taking important pictures (such as
at a wedding or when traveling). Contents of the recording cannot be
guaranteed if recording, playback or transferring your data to a computer,
etc. is not possible due to a malfunction of your camera or recording media
(SD Memory Card), etc.
• The lens on this camera is not interchangeable. The lens is not removable.
• Storing the battery fully charged may decrease the battery performance.
Avoid storing it especially in high temperatures.
• If the battery is left inserted and the camera is not used for a long time,
the battery will over-discharge and shorten the battery’s service life.
• Charging the battery a day before use or on the day of use is recommended.
• The AC plug cord supplied with the camera is for exclusive use with
the battery charger D-BC92. Do not use it with any other equipment.
Keep the Camera and Accessories Out of the Reach of Small Children
Care to be Taken During Handling
Before Starting Use
About the Battery and Battery Charger
WG20_OPM_ENG.book Page 5 Wednesday, February 5, 2014 2:20 PM

6
• Hot and humid places should be avoided. Particular care should be taken
regarding vehicles, which can become very hot inside.
• Ensure that the camera is not subjected to substantial vibrations, shocks,
or pressure as this may cause damage, malfunction, or a loss in waterproof
performance. Place the camera on a cushion for protection when the
camera is subjected to the vibrations of a motorbike, car, ship, etc. If the
camera is subjected to substantial vibrations, shocks, or pressure, take
your camera to your nearest service center and have it checked.
• The temperature range in which the camera can be used is -10°C to 40°C
(14°F to 104°F).
• The liquid crystal display will become black at high temperatures but will
return to normal at normal temperatures.
• The response speed of the liquid crystal display becomes slow at low
temperatures. This is due to the properties of the liquid crystal and is not
a malfunction.
• If the camera is subjected to rapid temperature changes, condensation
may form on the inside and outside of the camera. Therefore put
the camera in a bag or plastic bag and take the camera out when
the difference in temperature has subsided.
• Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salts.
These could cause the camera to breakdown. Wipe the camera to dry
off any rain or water drops.
• Please do not press forcefully on the display. This could cause it to break
or malfunction.
• Be careful not to sit down with the camera in your back pocket as this may
damage the exterior of the camera or the display.
• When using a tripod with the camera, be careful not to overtighten
the screw in the tripod socket on the camera.
• Do not clean the product with organic solvents such as thinner, alcohol
or benzene.
• Use a lens brush to remove dust accumulated on the lens. Never use
a spray blower for cleaning as it may damage the lens.
Cautions when Carrying and Using the Camera
About Repairs
WG20_OPM_ENG.book Page 6 Wednesday, February 5, 2014 2:20 PM

7
• Avoid storing the camera where pesticides and chemicals are handled.
Remove the camera from its case and store it in a well-ventilated place
to prevent the camera from becoming moldy during storage.
• Avoid using or storing the camera where it may be exposed to static
electricity or electrical interference.
• Avoid using or storing the camera in direct sunlight or in locations where
it may be exposed to rapid changes in temperature or to condensation.
• Periodic checks are recommended every 1 to 2 years in order to maintain
high performance.
• The SD Memory Card is equipped with
a write-protect switch. Setting the switch
to LOCK prevents new data from being
recorded on the card, the stored data from
being deleted, and the card from being
formatted by the camera or computer.
r appears on the display when the card is write-protected.
• Care should be taken when removing the SD Memory Card immediately
after using the camera, as the card may be hot.
• Keep the battery/card cover closed and do not remove the SD Memory
Card or turn the camera off while the data is being played back or saved
to the card, or the camera is connected to a computer with the USB cable,
as this may cause the data to be lost or the card to be damaged.
• Do not bend the SD Memory Card or subject it to violent impact.
Keep it away from water and store away from high temperature.
• Do not remove the SD Memory Card during formatting as this may damage
the card and render it unusable.
• The data on the SD Memory Card may be lost in the following
circumstances. We do not accept any liability for data that is deleted
(1) when the SD Memory Card is mishandled by the user.
(2) when the SD Memory Card is exposed to static electricity or electrical
interference.
(3) when the SD Memory Card has not been used for a long time.
(4) when the SD Memory Card is ejected or the batteries are removed
while the card is being accessed.
About Storage
Others
Write-protect
switch
WG20_OPM_ENG.book Page 7 Wednesday, February 5, 2014 2:20 PM

8
• If it is not used for a long time, the data on the card may become
unreadable. Be sure to regularly make a backup of important data
on a computer.
• Be sure to format SD Memory Cards that are unused or have been used
on another camera. Refer to “Formatting the Memory” (p.214).
• Please note that deleting data, or formatting the SD Memory Cards or the
built-in memory does not completely erase the original data. Deleted files
can sometimes be recovered using commercially available software.
It is user’s responsibility to ensure the privacy of such data.
WG20_OPM_ENG.book Page 8 Wednesday, February 5, 2014 2:20 PM

9
Regarding Waterproof, Dustproof, and
Shockproof Design
• This camera is provided with a waterproof/dustproof design complying with
JIS waterproof grade 8 and JIS dustproof grade 6 (equivalent to IP68).
• The camera satisfies our drop test (1.5 m height onto a 5 cm thick plywood
surface) complying with MIL-Standard 810F Method 516.5-Shock testing.
• The camera satisfies our test for the waterproof, dustproof, and shockproof
performance, but this does not guarantee it will remain free of trouble or
damages.
• Waterproof performance is not guaranteed if the camera is exposed
to impact such as being dropped or hit.
• Make sure that there are no cracks or scratches on the rubber seal
of the battery/card and terminal covers.
• Make sure there are no foreign objects (dust, sand, hair, lint or liquid) on
the rubber seals or the surface they contact before closing the battery/card
and terminal covers. Wipe off any foreign objects with a clean lint-free cloth.
Precautions Before Using the Camera in the Water
Check the Following Before Going Near the Water
Packing contact surface Waterproof packing
Packing contact surface Waterproof packing
WG20_OPM_ENG.book Page 9 Wednesday, February 5, 2014 2:20 PM

10
• Close the battery/card and terminal covers properly until they click.
Otherwise water may get in and damage the camera.
• Avoid opening the battery/card and terminal covers when near the
waterside or with wet hands. Wait until the camera is completely dry before
changing the battery or the SD Memory Card. Avoid changing the battery
or card where the camera is likely to get wet or dirty, and make sure that
your hands are dry.
• The camera will sink if dropped in water, so be sure to attach the strap and
slip the strap over your wrist when using the camera in or near water.
• To enhance the waterproof performance of the camera, the front of the lens
is protected by glass. As any dirt or water on the glass will affect the quality
of pictures taken, the glass should be kept clean at all times.
• Do not use the camera deeper than 10 meters underwater. Do not use
the camera underwater for more than 120 minutes consecutively.
• Do not open the battery/card and terminal covers underwater.
• Do not use in hot water or in a hot spring.
• Do not apply excessive force to the camera, for example diving into water
with it. Doing so may compromise the waterproof performance of the
camera or cause the covers to open.
• Leaving the camera on the sand at the beach may cause the camera
to exceed its operating temperature or cause the speaker or microphone
to become blocked with sand.
• Avoid subjecting the camera to substantial vibrations, shocks, or pressure
as this may cause a loss in waterproof performance. If the camera is
subjected to substantial vibrations, shocks or pressure, take your camera
to your nearest service center and have it checked.
• Avoid getting sunscreen or sun oil on the camera as it may cause
discoloration of the surface. If any oil gets on the camera, wash it off
immediately with warm water.
• Sudden and extreme changes in temperature may cause condensation
to form in and on the camera. Keep the camera in a bag or case to reduce
the difference in temperature.
Be Careful Near the Water
Precautions When Using the Camera in the Water
WG20_OPM_ENG.book Page 10 Wednesday, February 5, 2014 2:20 PM

11
• Do not open the battery/card cover or terminal cover if the camera is wet.
Wipe off any water with a clean lint-free cloth.
• The inside surface of the covers may get wet when they are opened.
Wipe off any water that is on the cover.
• Wiping off the camera while there is sand or dust on it may scratch the
surface of the camera. Make sure that the battery/card cover and terminal
cover are firmly closed before washing the camera in tap water.
After washing the camera, dry it with a soft cloth.
• Wipe off any dirt or sand on the waterproof packing or the packing contact
surface. The camera’s waterproof performance may be compromised by
loose packing or cracks or dents in the packing or packing contact surface.
If there is any such damage, contact your nearest service center.
• If the camera is very dirty or after it has been used in the sea, make sure
that it is turned off and the battery/card and terminal covers are firmly
closed before rinsing it under running tap water or leaving it in a bowl
of clean water for a short time (2 or 3 minutes).
• Avoid cleaning with agents such as soapy water, mild detergents,
or alcohol as this may compromise the waterproof performance
of the camera.
• To maintain the waterproof performance of the camera, you are
recommended to change the waterproof packing once a year. Contact your
nearest service center regarding changing the packing. (A charge will be
made.)
• The camera’s accessories are not waterproof.
Precautions After Using the Camera in the Water
WG20_OPM_ENG.book Page 11 Wednesday, February 5, 2014 2:20 PM

12
Using Your Camera Safely ...............................................................1
Care to be Taken During Handling ...................................................5
Regarding Waterproof, Dustproof, and Shockproof Design................... 9
Precautions Before Using the Camera in the Water.........................9
Precautions When Using the Camera in the Water........................10
Precautions After Using the Camera in the Water..........................11
Contents .........................................................................................12
Composition of the Operating Manual ............................................19
Checking the Contents of the Package ..........................................20
Names of Parts...............................................................................21
Names of Operating Parts ..............................................................22
Monitor Indications .........................................................................23
Getting Started 32
Attaching the Strap............................................................................... 32
Attaching the Strap .........................................................................32
Powering the Camera .......................................................................... 33
Charging the Battery.......................................................................33
Installing the Battery .......................................................................34
Using the AC Adapter.....................................................................38
Installing the SD Memory Card ............................................................ 40
Number of Images Recordable on an SD Memory Card................42
Turning the Camera On and Off........................................................... 43
Starting-up in the Playback Mode...................................................44
Initial Settings....................................................................................... 45
Setting the Display Language.........................................................45
Setting the Date and Time..............................................................49
Common Operations 52
Understanding the Button Functions.................................................... 52
A Mode .........................................................................................52
Q Mode ........................................................................................54
Switching Between A Mode and Q Mode...................................56
Setting the Camera Functions.............................................................. 57
Operating the Menus ......................................................................57
Menu List ........................................................................................61
Contents
WG20_OPM_ENG.book Page 12 Wednesday, February 5, 2014 2:20 PM

13
Taking Pictures 65
Taking Still Pictures.............................................................................. 65
Taking Pictures...............................................................................65
Setting the Shooting Mode .............................................................69
Using the Face Detection Function ................................................71
Taking Pictures Automatically (Auto Picture Mode) .......................75
Setting the Functions (Program Mode)...........................................76
Taking Pictures in the Basic Mode (Green Mode)..........................77
Using the Zoom ..............................................................................79
Taking Pictures of Dark Scenes (Night Scene,
Night Scene Portrait, Digital SR, Fireworks,
and Candlelight Modes) ...........................................................81
Taking Pictures of People (Portrait Mode)......................................83
Taking Pictures of Children (Kids Mode) ........................................84
Taking Pictures of Your Pet (Pet Mode) .........................................85
Taking Pictures of Sports and Leisure Activities
(Surf & Snow/Sport Mode) .......................................................88
Taking Pictures of Text (Text Mode) ..............................................89
Taking Pictures in Digital Microscope Mode...................................90
Framing Your Pictures (Frame Composite Mode) ..........................92
Using the Self-timer ........................................................................94
Taking a Series of Pictures
(Continuous Shooting/Burst Shooting).....................................95
Taking Pictures Using the Remote Control Unit (Optional) ............97
Taking Pictures at a Set Interval (Interval Shoot) ...........................99
Taking Pictures with Automatic Exposure Adjustment
(Auto Bracketing) ...................................................................101
Using the Digital Wide Function (Digital Wide Mode) ...................102
Taking Panoramic Pictures (Digital Panorama Mode)..................105
Setting the Shooting Functions .......................................................... 108
Selecting the Flash Mode .............................................................108
Selecting the Focus Mode ............................................................110
Setting the Image Tone ................................................................115
Selecting the Number of Recorded Pixels....................................116
Selecting the Quality Level of Still Pictures ..................................118
Adjusting the White Balance.........................................................119
Setting the AE Metering................................................................121
Setting the Sensitivity ...................................................................122
Setting AUTO ISO Range.............................................................123
Setting the Exposure (EV Compensation)....................................124
Correcting the Brightness (D-Range Setting) ...............................125
Setting Pixel Track SR..................................................................126
Setting the Interval Shooting ........................................................127
WG20_OPM_ENG.book Page 13 Wednesday, February 5, 2014 2:20 PM

14
Setting Blink Detection .................................................................129
Setting the Instant Review............................................................130
Setting the Green Button ..............................................................130
Setting the Image Sharpness (Sharpness)...................................134
Setting the Saturation/Tone Adjustment.......................................135
Setting the Image Contrast (Contrast)..........................................136
Setting the Date Imprint Function .................................................136
Setting the IQ Enhancer Processing ............................................137
Setting the Macro Light.................................................................138
Taking Pictures Underwater............................................................... 139
Taking Underwater Pictures
(Underwater Mode/Underwater Movie Mode) ........................139
Recording Movies .............................................................................. 141
Recording Movies.........................................................................141
Selecting the Number of Recorded Pixels and
Frame Rate for Movies...........................................................143
Setting the Movie SR (Movie Shake Reduction) Function............144
Recording a Movie from Pictures Taken at a Set Interval
(Interval Movie) ......................................................................145
Saving the Settings (Memory)............................................................ 149
Playing Back and Deleting Images 151
Playing Back Images.......................................................................... 151
Playing Back Still Pictures ............................................................151
Playing Back a Movie ...................................................................152
Multi-Image Display ......................................................................153
Using the Playback Function ........................................................155
Slideshow .....................................................................................158
Rotating the Image .......................................................................161
Zoom Playback.............................................................................162
Zoom In on the Subject’s Face Automatically
(Face Close-up Playback)......................................................163
Deleting Images and Sound Files ...................................................... 165
Deleting a Single Image/Sound File .............................................165
Deleting Selected Images and Sound Files..................................167
Deleting All Images and Sound Files............................................168
Protecting Images and Sound Files from Deletion (Protect) ........169
Connecting the Camera to AV Equipment ......................................... 172
Connecting the Camera to a Video IN Jack .................................172
Connecting the Camera to an HDMI Terminal .............................174
WG20_OPM_ENG.book Page 14 Wednesday, February 5, 2014 2:20 PM

15
Editing and Printing Images 176
Editing Images ................................................................................... 176
Changing the Image Size (Resize)...............................................176
Cropping Images ..........................................................................177
Processing Images to Make Faces Look Smaller ........................178
Using the Digital Filters.................................................................180
Using the Ink Rubbing Filter .........................................................185
Creating a Collage Image.............................................................186
Red-eye Compensation................................................................191
Adding a Frame (Frame Composite) ............................................192
Overlaying Your Original Frame on an Image ..............................195
Editing Movies ..............................................................................200
Copying Images and Sound Files.................................................203
Setting the Printing Service (DPOF) .................................................. 205
Printing a Single Image ................................................................205
Printing All Images........................................................................207
Recording and Playing Back Sound 208
Recording Sound (Voice Recording Mode)........................................ 208
Setting Voice Recording ...............................................................208
Recording Sounds ........................................................................209
Playing Back Sound .....................................................................210
Adding a Voice Memo to Images ....................................................... 212
Recording a Voice Memo .............................................................212
Playing Back a Voice Memo.........................................................213
Settings 214
Camera Settings ................................................................................ 214
Formatting the Memory ................................................................214
Changing the Sound Settings.......................................................215
Changing the Date and Time........................................................217
Setting the Alarm ..........................................................................219
Setting the World Time .................................................................221
Setting the Text Size on the Menu ...............................................224
Changing the Display Language ..................................................225
Changing the System for Naming Folders....................................226
Changing the Video Output Format..............................................228
Selecting the HDMI Output Format ..............................................229
Setting the Eye-Fi Communication ...............................................231
Adjusting the Brightness of the Display ........................................232
Using the Power Saving Function ................................................233
WG20_OPM_ENG.book Page 15 Wednesday, February 5, 2014 2:20 PM

16
Setting Auto Power Off .................................................................234
Setting the Quick Zoom Function .................................................235
Setting the Guide Display .............................................................236
Perform Pixel Mapping .................................................................237
Changing the Start-up Screen ......................................................238
Resetting to Default Settings (Reset) ...........................................239
Displaying the Clock Mode ...........................................................240
Connecting to a Computer 241
Connecting to a Computer ................................................................. 241
Provided Software ........................................................................241
System Requirements ..................................................................242
Installing the Software ..................................................................244
Setting the USB Connection Mode...............................................247
Connecting to a Windows PC ............................................................ 249
Connecting the Camera and Your Windows PC ..........................249
Using MediaImpression on Windows ...........................................250
Disconnecting the Camera from Your Windows PC .....................251
Connecting to a Macintosh................................................................. 252
Connecting the Camera and Your Macintosh...............................252
Using MediaImpression on Macintosh..........................................253
Disconnecting the Camera from Your Macintosh .........................254
Transferring Images Using an Eye-Fi Card........................................ 255
Appendix 258
Functions Available for Each Shooting Mode .................................... 258
Messages........................................................................................... 261
Troubleshooting ................................................................................. 263
Default Settings.................................................................................. 265
List of World Time Cities .................................................................... 270
Main Specifications ............................................................................ 271
Warranty Policy .................................................................................. 276
Index .................................................................................................. 281
WG20_OPM_ENG.book Page 16 Wednesday, February 5, 2014 2:20 PM

17
In this manual, the method for operating the four-way controller is shown
in illustrations, such as in the one below.
The meanings of the symbols used in this Operating Manual are
explained below.
1Indicates the reference page number for an explanation
of the related operation.
Indicates information that is useful to know.
Indicates precautions to be taken when operating the camera.
A Mode
This is the mode for taking still pictures and recording movies.
In this manual, "Still Picture Capture Mode" is the mode for taking
still pictures.
Q Mode This is the mode for viewing still pictures and playing back movies
and sound files.
5 or
2 or
3 or
or 4
WG20_OPM_ENG.book Page 17 Wednesday, February 5, 2014 2:20 PM

18
Memo
WG20_OPM_ENG.book Page 18 Wednesday, February 5, 2014 2:20 PM
