Ricoh Pro C9200 User manual

For safe and correct use, be sure to read Safety Information before
using the machine.
Using the Auto Color Diagnosis Function
Auto Color
Diagnosis Guide

TABLE OF CONTENTS
1. Using the Auto Color Diagnosis Function
Introduction......................................................................................................................................................... 3
Disclaimer........................................................................................................................................................3
Notes...............................................................................................................................................................3
About the Auto Color Diagnosis Function.........................................................................................................4
Generating Paper Properties (When Using Fiery)........................................................................................... 6
Using the "ACD Property" Screen................................................................................................................. 6
Generating Paper Properties.........................................................................................................................8
Printing with Auto Color Diagnosis.............................................................................................................11
Printing Diagnostic Marks........................................................................................................................... 11
Generating Paper Properties (When Using TotalFlow).................................................................................14
Using the "Paper" Screen............................................................................................................................ 14
Generating Paper Properties...................................................................................................................... 16
Troubleshooting................................................................................................................................................18
1

2

1. Using the Auto Color Diagnosis
Function
Introduction
Disclaimer
To the maximum extent permitted by applicable laws, in no event will the manufacturer be liable for any
damages whatsoever arising out of failures of this product, losses of documents or data, or the use or
non-use of this product and operation manuals provided with it.
Make sure that you always copy or have backups of important documents or data. Documents or data
might be erased due to your operational errors or malfunctions of the machine. Also, you are
responsible for taking protective measures against computer viruses, worms, and other harmful software.
Notes
Contents of this manual are subject to change without prior notice.
Depending on the release date, some of the specifications (operations) may differ from those given in
this manual. For details, please contact your local dealer.
Some illustrations in this manual might be slightly different from the machine.
In no event will the manufacturer be responsible for any documents created by you using this product or
any results from the data executed by you.
3

About the Auto Color Diagnosis Function
This section explains the Auto Color Diagnosis function, which is one of the functions of the Auto Color
Diagnosis Unit.
This function uses the in-line sensor to scan the printed colors while a continuous print run is in progress,
and suppresses color deviation without stopping the machine.
DWQ651
Master image Scanned image
Extract reference
color information
Check color deviation
Decide the adjustment
method based on the
paper properties
Tone Correction
Monitoring and Adjusting Colors Automatically
To suppress color deviation during a continuous print run, the machine compares the recently
printed colors to the colors initially printed at the beginning of the print run, and adjusts the colors
automatically.
• You cannot enable or disable the Auto Color Diagnosis function individually for each print
job.
• You need a sufficient number of measurement points in the image to be printed for the function
to be effective.
Generating and Registering Paper Properties
To adjust colors correctly, generate paper properties for each paper type. When generated, this
information is stored in the machine's data storage. The machine reads the properties of the paper
used for printing from the storage and adjusts colors according to the information.
Supported Paper
The paper supported by the Auto Color Diagnosis function is as follows:
1. Using the Auto Color Diagnosis Function
4

Paper attributes Requirements
Paper size 210 mm (8.3inches) or more vertically × 279–700 mm (11–27.6inches)
horizontally; or 279 mm (11inches) or more vertically × 210–700 mm (8.3–
27.6inches) horizontally (including custom and banner paper)
Paper weight Paper weight "1" or greater
Paper type Plain paper, recycled paper, high gloss paper, gloss paper, matte paper, or
synthetic paper
Paper color White
• You cannot use the Auto Color Diagnosis function when printing on a sheet of paper that has been
manually selected instead of selected from the media catalog.
About the Auto Color Diagnosis Function
5

Generating Paper Properties (When Using
Fiery)
To use the Auto Color Diagnosis function, print the color chart and generate paper properties for each
paper type. When generated, this information is stored in the machine's data storage and used for
adjusting colors when printing is performed.
To adjust colors properly, perform calibration before generating paper properties.
• Colors are adjusted using the Auto Color Diagnosis function when printing is performed on the
paper for which paper properties are generated.
• Up to 9 sheets of paper are required to generate paper properties.
• Generate this information again after:
• Changing the data registered in the master library (custom paper) via the machine's control
panel
• Changing the printing speed in the paper settings
• Replacing the Line Sensor
• Changing the maximum density (D-MAX) while performing calibration
• Changing the color profile registered in the paper catalog
• For details about the paper catalog, see the "Utilities" manual for the Fiery controller in use.
Using the "ACD Property" Screen
The "ACD Property" screen displays a list of paper types that can be used on the machine. In the screen,
you can generate paper properties, check the generation status, and specify the accuracy setting of the
information.
Viewing the generation status of paper properties
1. Click [Launch ACD] in the "WebTools" screen.
2. Log in with a user name and password.
When a large number of items is registered in the paper catalog, it may take a few minutes to
display the "ACD Property" screen.
The security warning screen may be displayed in your web browser when you access the
"WebTools" or [Launch ACD] screen.
1. Using the Auto Color Diagnosis Function
6

When the warning screen is displayed, ignore it and continue browsing the web page.
3. Check the generation status of paper properties in the "ACD Property" screen.
In the screen, you can view the information below. To check whether the Auto Color Diagnosis
function is enabled, check the [ACD status] field.
Display item Description
Name Registered paper name
Weight (gsm) Paper weight
Paper size Paper size (standard/inch/mm)
Tray Number of the tray where the paper is currently loaded
ACD status Disabled Paper properties are not generated.
Enabled Paper properties are generated.
Not Applicable Because the Auto Color Diagnosis
function does not support paper types,
paper properties cannot be generated.
ACD last updated The last registration time of paper properties
Specifying generation accuracies for paper properties
You can specify generation accuracies for paper properties from High Accuracy or Standard. You
cannot modify this information after it is generated. Specify settings before generating the information.
Generating Paper Properties (When Using Fiery)
7

1. Click [Settings] in the top right corner of the "ACD Property" screen.
EDD651
2. Select the accuracy (High accuracy/Standard) of paper properties, and then click [OK].
The number of color charts to be printed is 5 for "Standard" and 9 for "High accuracy".
Generating Paper Properties
To generate paper properties, select the paper in the "ACD Property" screen.
• Specify the generation accuracy by following the procedure described in page 7 "Specifying
generation accuracies for paper properties" before generating paper properties.
• After changing the color profile registered in the paper catalog, generate the color properties
again. If you use the machine without generating the color properties, Auto Color Diagnosis may
fail or the hue of the printed image may vary excessively.
1. Load sheets of paper in the tray, and select the tray from the media catalog using the
machine's control panel.
When generating paper properties, depending on the precision of the selected paper properties,
the machine prints color charts on 5 sheets of paper (for "Standard") or on 9 sheets (for "High
accuracy"). Load paper for printing charts in the paper tray.
For details about how to select the tray from the media catalog, see "Specifying a Custom Paper"
Preparation.
2. Perform calibration.
1. Using the Auto Color Diagnosis Function
8
