Rinnai Arriva User manual

Arriva and Evolve gas fireplaces
Flue installation guide

Important
Rinnai gas replace ueing shall be installed in accordance with:
-Manufacturer’s installation instructions
-Current AS/NZS 3000, AS/NZS 3500, AS/NZS 5601.1 and G12/AS1
Must be installed, commissioned and serviced by an authorised person,
being in New Zealand a licensed gastter.
The Arriva and Evolve res must be installed with an approved ue
system, approved components are shown in this guide.
Warning
Improper installation, adjustment, alteration, service and maintenance
can cause property damage, personal injury or loss of life.
For more information about buying, using, and servicing of Rinnai
appliances call: 0800 RINNAI (0800 746 624).
Rinnai New Zealand Limited
105 Pavilion Drive, Mangere, Auckland
PO Box 53177, Auckland Airport, Auckland 2150
Phone: [phone]
Email: [email protected]
Web: rinnai.co.nz
youtube.com/rinnainz
facebook.com/rinnainz

About this guide .......................................................... 4
Flueing options ........................................................... 5
General ueing guidelines .......................................... 6
Flue components ........................................................ 8
Flue component connections...................................... 10
Flue transition (ASPDFK, ASPKIT03, EVOKIT03) ..... 11
Wall penetration .......................................................... 12
Direct ueing - mushroom ue kits ............................. 13
Direct ueing using the ASPDFK ................................ 14
Vertical in-wall ueing ................................................. 15
Sideways ueing......................................................... 16
Through-wall vertical ueing ....................................... 17
Down and out ueing .................................................. 18
Cutting the ASPDFK and ESPIPE900 to length to
connect to another part............................................... 20
Steps to create a wall terminal ................................... 21
Connecting the heater exhaust pipe ........................... 22
Connecting the air supply ........................................... 23
Arriva condensate drain kit connection....................... 24
Evolve condensate drain kit connection ..................... 25
Appendices
Appendix 1: ESBEND 90° .......................................... 26
Appendix 2: ESBEND 45° .......................................... 27
Contents
Every gas re requires a ue system that will draw e󰀨ectively and clear ue products safely
under all wind and climatic conditions. It is up to the installer to ensure the appliance is provided
with an e󰀨ective ue.
Down rating the re
For all ueing EXCEPT direct ueing, the re must be down rated (ensures optimum
performance of the fan) as per the commissioning instructions.
Installer responsibility

4 | Arriva/Evolve ue installation guide: 10726-I 09-21
About this guide
This guide is to outline the most common types of ue installations and to provide an overview
of how to assemble the various ue components. If you have an installation that varies from this
guide, please contact Rinnai.
Flue installation di󰀨erences between the Arriva and Evolve
• Direct ue kits di󰀨er
Due to the size of the Evolve unit and the cavity dimensions, the only direct ue kit available
for the Evolve is the ASPDFK. The direct mushroom ue kits that can be used for the Arriva are
not suitable as the telescopic exhaust section of the Evolve is not long enough to connect to
the ue transition of the mushroom ues.
EVOLVE MODELS ASPDFK direct ue kit Mushroom direct ue kit
• Adaption ue kits di󰀨er
- Arriva uses the ASPKIT03, refer p.8
- Evolve uses the EVOKIT03, refer p.8
• How condensate is handled di󰀨ers
For the Arriva a condensate drain kit needs to be installed, refer p.24. For the Evolve the
condensate drain tube is connected directly to the condensate pipe on the heater, refer
appendix 1 on p.25.

Arriva/Evolve ue installation guide: 10726-I 09-21 | 5
C
A
B
Flueing options
For lowest cost, optimal performance, ease of installation and servicing, Rinnai
recommend direct ued installations are considered before all other options.
Maximum ue
length and
number of bends
Maximum ue length = 8.5 m
Maximum number of bends = three
For every 90° bend, the overall length must be reduced by 1 m. For example, if an installation has
three 90° bends, the maximum flue length can be 5.5 m. The elbow component of the adaption flue
kits is counted as a 90° bend.
Adaption ue kits Arriva: use ASPKIT03
Evolve: use EVOKIT03
Direct and direct extended ueing
Direct through the wall ueing for walls up to 385 mm
thick. Flue can be extended if the wall thickness is
greater than 385 mm by using the ASPDFK ue kit and
additional lengths of ESPIPE900.
Arriva
- Direct mushroom A ue (R2731), or
- Direct mushroom B ue (R2732), or
- Direct ue (ASPDFK)
Evolve
- Direct ue (ASPDFK)
Sideways ueing
The sideways ue installation can run along the left or
right hand side of an internal wall behind the re. When
considering the location of the re, ensure the ue path is
free from obstructions such as noggins, wiring, joists etc.
- Adaption ue kit
- Flue pipe (ESPIPE900)
- Wall terminal (ESWTERM)
Vertical in-wall ueing
The in-wall vertical ue is installed against an internal
wall within a false replace or other suitable cavity, and is
run vertically upwards towards a termination point.
Vertical in-wall direct (A)
- Adaption ue kit
- Flue pipe (ESPIPE900)
- Roof cowl (ESROOFCOWL)
Vertical in-wall o󰀨set (B)
Above list + 45° bends (ESBEND)
Vertical in-wall horizontal (C)
- Adaption ue kit
- Flue pipe (ESPIPE900)
- 45° bends (ESBEND)
- Wall terminal (ESWTERM)
Through wall vertical ueing
For the small number of instances where the re cannot
be directly ued or ued via an internal wall. In some
cases a large portion of the ue may be visible from the
outside.
Down and out ueing
This ue option allows for the adaption ue kit to face
downwards and for the ue to run vertically through a
hole in the oor, and then terminate horizontally outside,
ue termination must be 300 mm above ground level.
- Adaption ue kit
- Flue pipe (ESPIPE900)
- Wall plate (ESPLATE)
- 45° bends (ESBEND
- Wall terminal (ESWTERM)
- Direct ue (ASPDFK)
- 45° bends (ESBEND
- Flue pipe (ESPIPE900)
- Condensate trap (ESCONDK)
- Roof cowl (ESROOFCOWL)

6 | Arriva/Evolve ue installation guide: 10726-I 09-21
General ueing guidelines
Flue clearances to
combustibles
Due to the heat from the ue components, maintain a 25 mm
clearance to combustibles for the rst 500 mm of ue.
Flashings Flashings are not included with the ue kits, these must be
specied.
Flue support The weight of the ue system must not be supported by the
appliance, it must be self-supporting. Supporting the ue is usually
completed during the framing stage with ue supports or straps
within the cavity. Wall straps are included with most Rinnai ue
components.
Securing the ue To prevent the ue from moving or coming apart:
• Joints between the ue components MUST BE secured by
short1 screws (max. length 6 mm) through the outer pipes
(easier to undo if necessary).
• Flue components must be secured to the wall using the ue
straps provided in each ue kit, refer image above.
Lubricate o-ring seals
before connecting
The inner pipe joints are sealed with an o-ring seal lubricant. A small
plastic tub of silicone grease is provided with the main ue kits. Use
this silicone grease to lubricate the o-rings on the inner pipes prior
to assembly. This is important as o-rings can dry out and break, and
replacing o-rings is di󰀩cult.
Do not use petroleum based lubricants as these will cause
deterioration of the o-ring seals.
Flue sections located
outside
Sections of the ue located outside require the following:
• Only use PVC cement between the joints of the outer PVC pipes
to secure and seal the joints against ingress of dust and water.
• Only use non-acidic silicone sealant between the joints of the
outer PVC pipe and any mating aluminium components to seal
the joints against ingress of dust and water. Silicone containing
acetic acid or other acids as the curing agent may cause the
aluminium to corrode.
Shared ues Gas appliances must not be connected to a chimney or ue serving
a separate ue burning appliance.
Condensate The Arriva and Evolve will produce ue condensate when running.
The amount will vary depending on climatic conditions and ue
conguration. Condensate is mildly acidic and can damage
decorative nishes, prized petunias, concrete, and other building
materials. Please consider the customer as to how the condensate
will drain and what it may drain into.
1 Screws must not touch the inner pipe—could cause a transfer of heat to the plastic outer and potentially
melt the plastic.

Arriva/Evolve ue installation guide: 10726-I 09-21 | 7
2° fall to the horizontal ue
terminal
There must be a continuous fall of at least 2°
to the horizontal wall termination. This is so
any condensate and rain water exits the ue
naturally.
The Arriva Direct A and B ue kits have an
inbuilt 2° fall.
fall
Flue terminal locations Flue terminals must be compliant with the ue terminal locations
shown in AS/NZS 5601.1.
• The ue terminal must be positioned away from any
ammable materials.
• Keep snow and other items, such as outdoor furniture well
clear of the ue terminal at all times.
DO NOTDO NOT DO NOT DO NOT
Do not ue into
natural draught
ues or replaces.
Do not ue into
other rooms.
Do not ue into
roof spaces.
Do not ue
under oor
spaces.
To ensure products of combustion
are cleared, adequate clearance
from the building is required. The
vertical cowl should have a
500 mm clearance from any part
of the building. This also applies to
steeped and pitched roofs, where
the ue cowl should be 500 mm
clear of the ridge line.
An adequate ow of fresh air must
exist around the ue cowl following
installation.
Minimum clearances are shown in AS/NZS 5601.1.
500 mm to
nearest
part of the
roof
2° fall back to the re A fall back to the re is required when any part
of the ue system goes horizontally and then
vertically.

8 | Arriva/Evolve ue installation guide: 10726-I 09-21
Flue components
Direct A ue kit - R2731
**Arriva only**
Suitable for walls 115-240 mm thick,
typically weatherboard construction.
This is a complete stainless steel
kit with an inbuilt 2° fall to drain
condensate.
115-240 mm wall thickness 115 mm 80 mm
Direct B ue kit - R2732
**Arriva only**
Suitable for walls 240-400 mm
thick, typically block construction.
This is a complete stainless steel
kit with an inbuilt 2° fall to drain
condensate.
240-400 mm wall thickness 115 mm 80 mm
Arriva adaption ue kit - ASPKIT03
**Arriva only**
Elbow section of this component
(circled) requires a 25 mm clearance
from combustibles. Kit includes:
• ue transition (rotates)
• condensate trap
• wall strap
• drain tube (750 mm)
• o-ring silicone grease
• ue slide stopper (4822)
• R1970 sub-kit
R1970 is the condensate drain kit.
This is used for installations that
require draining condensate back
into the re.
Direct ue kit - ASPDFK (aluminium)
Suitable for walls up to 385 mm thick (can be cut to length). Can also
be used with ESPIPE900 for longer ueing. The minimum length when
measured from the back plate of the transition casting MUST NOT be less
than 300 mm when joining to other components.
540 mm
Ø 75 mm
50 mm
140 mm
Flue transition
25 mm clearance
to combustibles
Flue pipe - ESPIPE900
Extension pipe used for horizontal,
vertical, and downwards ueing. Can
be cut to size at the non-socketed
end.
Inner is aluminium, outer white PVC.
Comes with a wall bracket, o-ring
(4350), and spacer (4351).
Roof terminal - ESROOFCOWL
Roof cowl and connecting pipe for
termination of a vertical ue—can
be cut to size. 500 mm clearance
required from any part of the
building, refer previous page.
Galvanised steel, powder coated
black.
975 mm
Not pictured is the internal white wall plate, refer render on
next page.
Spacers are mandatory to
ensure alignment of the flue
and to stop the outer bends
overheating
45° ue bends - ESBEND
Two bends in a kit. Can be used
separately, or together as a 90° bend.
Refer additional images on p.26-27.

Arriva/Evolve ue installation guide: 10726-I 09-21 | 9
Evolve adaption ue kit - EVOKIT03
**Evolve only**
Elbow section of this component
(circled) requires a 25 mm clearance
from combustibles. Kit includes:
• ue transition (rotates)
• condensate trap
• wall strap
• drain tube (750 mm)
• o-ring silicone grease
• ue slide stopper (4822)
Wall terminal kit - ESWTERM
Used to terminate the ESPIPE900
in horizontal ue installations when
used with the adaption ue kit.
Wall plate - ESPLATE
Used in down and out ueing to
cover the oor penetration, and
also as an extra wall cover if
required, to tidy up an installation.
Outer diameter 170 mm.
Condensate trap - ESCONDK (aluminum)
Only ordered as a separate item if doing through wall vertical ueing,
refer p.5. Supplied with a 750 mm drain tube. When installed arrow MUST
ALWAYS point up.
Rubber drain
outlet
Drain tube
300 mm
Renders
Direct A & B ue
Direct ASPDFK ue
45° bend kit
Roof cowl Flue pipe
Condensate trap
Adaption ue
Adaption ue Wall plate

10 | Arriva/Evolve ue installation guide: 10726-I 09-21
Flue component connections
Connecting the ue pipe (ESPIPE900)
The socket end of the pipe containing the o-ring connects to the non-socketed end of the previous
component. If cutting to connect to another component always cut the non-socketed end, never
discard the socket o-ring end.
Connecting the roof cowl (ESROOFCOWL)
Connect the non-socketed end to the socketed end of the previous component and secure.
Non-socket end
Socket (o-ring) end of
previous component
Socket (o-ring) end
(do not cut)
Non-socket end
(can be cut)
Connecting the 45° bends (ESBEND)
If installed incorrectly there is potential for the outer bend to overheat. The centering spacer is
a mandatory component that is required for the correct alignment of the ue components when
bends are used. When tted correctly the inner and outer pipes of the ESBEND will be self
centering.
If tting to the ESPIPE900, lubricate the socket o-ring end of the pipe, the end
with the black spacer, and t to the non-socket end of the bend. Fit the white
spacer provided in the ESBEND kit, t the outer, and then repeat if adding
additional components.

Arriva/Evolve ue installation guide: 10726-I 09-21 | 11
The ue transition provides a connection between the ue system and the re ue spigot and air
intake. The below images show the ue transition in di󰀨erent ue congurations.
Arriva 380 mm
Front of enclosure
Rear of
enclosure
Flue Outlet Air Inlet
Evolve 570 mm
Flue transition (ASPDFK, ASPKIT03, EVOKIT03)
Horizontal direct ue transition
When installed as a horizontal direct ue, the ue transition is
pushed hard against the internal wall plate, which is pushed hard
against the rear wall of the enclosure.
Front of enclosure
Rear of
enclosure
Flue Outlet
Air Inlet
Arriva 475 mm
Evolve 570 mm
Vertical ue transition
When installed as a vertical ue, the ue transition is fastened
to the rear wall by the wall straps supplied. Elbow component of
the adaption kit requires 25 mm clearance to combustibles.
Appliance needs to be down rated—refer commissioning sheet.
Front of enclosure
Rear of
enclosure
Flue Outlet
Air Inlet
Arriva 475 mm
Evolve 570 mm
O󰀨set ue transition
When installed as a horizontal or vertical o󰀨set ue, the ue
transition is fastened to the rear of the wall by the wall straps
supplied.
Appliance needs to be down rated—refer commissioning sheet.
Front of enclosure
Rear of
enclosure
Flue Outlet
Air Inlet
Evolve 570 mm
Arriva 500 mm
Down and out ue transition
When installed as a down and out ue, the ue transition is
fastened to the rear of the wall by the wall straps supplied.
Appliance needs to be down rated—refer commissioning sheet.

12 | Arriva/Evolve ue installation guide: 10726-I 09-21
Direct ue wall penetration requirements
Use the guide pictured to mark the penetration points for the gas supply and ue transition
locations. Consideration must be given to the position of any studs, noggins or other components
of the wall structure on both sides of the wall. Mark these measurements accurately as this is
critical to a successful installation.
The penetration for the ue transition only needs to be made for direct ue installations, where the
terminal is directly to the rear of the appliance. If no ue pipe penetration is required the markings
are still useful for indicating the correct position of the ue transition within the enclosure for other
ue applications.
For weatherboard walls, drill through the centre of the weatherboard from the outside, then drill
from the inside through the plaster board.
Ø 80~100
400
55
378
580 ± 25
Gas supply penetration
Flue pipe penetration
Centreline of enclosure
Base of enclosure
Ø 80~100
Gas supply penetration
Flue pipe penetration
500 ± 25
580 (right)
Centreline of enclosure
570 (left)
65
Base of enclosure
Wall penetration
Arriva ue penetration guide
Dimensions are in mm.
Ø 80~100
Gas supply penetration
Flue pipe penetration
500 ± 25
430 (right)
Centreline of enclosure
420 (left)
65
Base of enclosure
Evolve 952 ue penetration guide
Dimensions are in mm.
Evolve 1252 ue penetration guide
Dimensions are in mm.

Arriva/Evolve ue installation guide: 10726-I 09-21 | 13
For installations where the unit is mounted directly on the inside of an external wall.
This installation requires a 2° fall from the heater connection to the wall terminal to
drain condensate and wind blown rain—the Arriva Direct A and B ue kits have an
inbuilt 2° fall.
Direct ueing using the Direct A and B ue kits - ARRIVA models only
Before starting, create the wall penetration. The minimum diameter required is 80 mm to non-
combustible surfaces such as brick, and 100 mm to combustible surfaces such as plaster.
Connection Sleeve Terminal
Direct ueing - mushroom ue kits
The ue consists of three parts;
sleeve, inside connections and
tube, and outside terminal.
Disassemble by pulling hard on
the outside terminal and inner
connections, then pull the sleeve
o󰀨 the outer terminal.
1. Disassemble manifold
Fixing Screw
2°
"TOP"
5-10mm
Don't remove green plastic covering from sleeve.
Fix the sleeve to the wall using the
three screws provided. The ange
is marked ‘TOP’. The sleeve must
be tted with this mark up. Check
sleeve protrudes 5-10 mm on the
outside.
4. Fix sleeve
Cut (leave 20mm free)
Pull hard
Fixing tie Lug Sleeve
Terminal
Pull hard on the LH and RH ties,
and clip ties over the lugs inside the
sleeve. You should be able to pull
the ties two or three slots past the
starting point. Cut the ties approx.
20 mm past the lugs and bend so
they are parallel with the wall.
7. Attach ties
Do not extend beyond red line
Extension joint under plastic
Extension
(A flue only)
Adjust length by turning sleeve
Measure the wall length through
the drilled hole. Adjust the sleeve
length to the wall thickness
plus 5-10 mm (required sleeve
protrusion from wall).
2. Adjust ue length
Adjust length by turning sleeve.
Extension joint
under plastic
Extension
("A" flue only)
Do not extend
beyond red line
For ‘A’ ues, depending on wall
thickness, the ue extension may
need to be removed. There is no
extension on the ‘B’ ues, they can
be fully adjusted by turning the
threaded section.
3. Remove ue extension
Terminal seal
(add weatherboard
seal here)
Check the rubber seal is in place
on the terminal. For weatherboard
walls, add the spare rubber seal
provided to compensate for the
weatherboard angle.
5. Check and add rubber seal
Label
Fixing tie Terminal
"TOP" mark "A"
From the outside insert the terminal
into the sleeve with the ‘A’ mark at
the top.
The LH xing tie is marked ‘LEFT’
(from the inside)
6. Install terminal
lnner
connections
Screw
Top mark
Push the inner connection
assembly into the terminal tube.
Ensure correct positioning—refer
‘TOP’ mark. Fix with the three
screws provided.
8. Insert inner connection
Outlet
Rubber cap
Inlet
Adjust the manifold as required.
The manifold can still be turned
after attaching.
9. Adjust manifold

14 | Arriva/Evolve ue installation guide: 10726-I 09-21
The ASPDFK is suitable from walls up to 385 mm thick. For the Arriva models it
can be used as an alternative to the Direct A and B ue kits. The ASPDFK can
be cut to length to suit wall thicknesses less than 385 mm. The ASPDFK can
also be used in combination with ESPIPE900 for walls greater than 385 mm,
this is called direct extended ueing.
IMPORTANT
Refer p.20 if cutting to length for important information about cutting the outer and inner pipes.
Direct ueing using the ASPDFK
1. Create the wall penetration. The minimum diameter is 80 mm to non-combustible surfaces
such as brick, and 100 mm to combustible surfaces such as plaster. Allow for a continuous 2°
fall from the re to the wall terminal.
2. Slide the internal wall plate over the terminal end of the ASPDFK pipe until it is nested on the
raised ring of the ue transition.
3. Pass the ASPDFK through the internal wall penetration.
4. Slide the internal wall plate so it is ush with the wall.
5. Create the wall terminal, refer p.21.
6. Move the re into place and connect the re ue pipe to the ue. This is done with the ue slide
stopper provided with the ue kit.
Interior wall
Exterior wall
Direct ueing and direct extended ueing
Max. wall thickness 385 mm
Internal wall plate, outer face

Arriva/Evolve ue installation guide: 10726-I 09-21 | 15
Air hose from unit
Condensate (arrow points up)
Flue slide stopper
Wall strap
Wall strap
Joining the ue transition and condensate
Flue length
Total ue length can be 7.5 m—the elbow component of the ASPKIT03/EVOKIT03 is counted as
a 90° bend. If bends need to be included to o󰀨set a stud, noggin etc., the ue length can be up to
5.5 m and contain two 90° bends (two ESBEND kits).
Steps for creating vertical in-wall ueing
Lubricate all inner pipe o-rings with the silicone grease provided.
1. Join the ue transition and condensate together ensuring the arrow points upwards.
2. Fit lengths of ESPIPE900 as required.
3. Determine the location of the roof or ceiling penetration point. To avoid obstructions an o󰀨set
can be created using the ESBEND kit.
4. Create a vertical roof terminal.
5. Secure joints between ue components through the outer pipes with screws and secure the
entire ue system using the wall straps supplied.
6. Connect the condensate tube to the heater once it has been installed. Connection points will
di󰀨er between the Arriva and the Evolve. For the Arriva refer to p.24. For the Evolve refer p.25.
DO NOT remove cap
Remember to consider how the wall straps will be secured to the frame—additional packing will be
required depending on where the wall straps are positioned.
IMPORTANT
Vertical in-wall ueing
The vertical in-wall vertical ue installation is installed against an internal wall
within a false replace or other suitable cavity, and is run vertically upwards to a
termination point. When considering the location of the re ensure the ue path in
the roof space is free from obstructions such as studs, wiring, joists etc.
In-wall vertical ueing showing ue components

16 | Arriva/Evolve ue installation guide: 10726-I 09-21
Sideways ueing
The sideways ue installation can be run along the left or right hand side of an
internal wall behind the heater. When considering the location of the heater ensure
that the ue path is free from obstructions such as studs, noggins, wiring, joists etc.
Flue length
Total ue length can be 7.5 m—the elbow component of the ASPKIT03/EVOKIT03 is counted as
a 90° bend. If bends need to be included to o󰀨set a stud, noggin etc., the ue length can be up to
5.5 m and contain two 90° bends (two ESBEND kits).
Steps for creating sideways ueing
1. Lubricate all inner pipe o-rings with the silicone grease provided.
2. Join the ue transition and condensate together ensuring the condensate outlet points
upwards. Even though the condensate is not actually connected in this ue arrangement, the
condensate component serves as a transition piece between the transition casting and the
ESPIPE900. The transition component must not be connected directly to the ESPIPE900,
which is plastic, due to the heat of the ue gases.
3. Fit lengths of ESPIPE900 as required. Allow for a 2° continuous fall from the heater connection
point to the wall terminal to drain condensate.
4. Create the wall penetration. The minimum diameter is 80 mm to non-combustible surfaces
such as brick, and 100 mm to combustible surfaces such as plaster. Allow for a continuous 2°
fall from the re to the wall terminal.
5. Create the wall terminal, refer p. 21.
6. Secure joints between ue components through the outer pipes with screws and secure the
entire ue system using the wall straps supplied.
Remember to consider how the wall straps will be secured to the frame—additional packing will be
required depending on where the wall straps are positioned.
IMPORTANT
2° fall to terminal to
drain condensate
ASPKIT03/EVOKIT03
(DO NOT remove cap)
Additional packing
for wall straps
Condensate (should be
capped or sealed)
Air hose secured
with cable tie
Evolve model showing position of various ue components in a sideways ue installation

Arriva/Evolve ue installation guide: 10726-I 09-21 | 17
Through-wall vertical ueing
These types of installations are rare, but have been used on the odd occasion where
traditional ueing is not possible. As a large portion of the ue will be visible—check
with the homeowner that this is okay. In this example the ue length can be up to
7.5 m long and contain one 90° bend.
Condensate trap
The supplied condensate tube (750 mm) will not be long enough for this type of installation,
a separate tube will need to be used. This needs to be connected back through to the heater
(separate hole required), which needs to be weathertight. Another option is to drain the condensate
to a waste drain / gully trap through a PVC line. For more information please contact Rinnai.
Steps for creating horizontal through-wall ueing
1. Create the wall penetration. The minimum diameter is 80 mm to non-combustible surfaces
such as brick, and 100 mm to combustible surfaces such as plaster. Allow for a 2° fall back to
the heater.
2. Create the 90° bend using the ESBEND kit.
3. Join the condensate trap to the 90° bend.
4. Fit lengths of ESPIPE900 as required.
5. Create a vertical roof terminal.
6. Secure joints between ue components through the outer pipes with screws.
7. Connect the condensate tube to the heater. You will need to drill a separate hole to run the
condensate tube back to the heater. Connection points will di󰀨er between the Arriva and the
Evolve. For the Arriva refer to p.22 in this guide, for the Evolve refer to p.25.
1
2
3
4
5
5
1. Wall plate
2. 2° fall back to the heater
3. ESBEND
4. Condensate trap
5. Wall straps
Flue components:
• Direct ue kit (ASPDFK)
• 45° bends (ESBEND)
• Condensate trap (ESCONDK)
• Flue pipe (ESPIPE900)
• Roof cowl (ESROOFCOWL)
Flue components required for through-wall ueing
As there is a vertical component in the installation, condensate needs to be drained back
towards the re, this requires the ASPDFK component to be angled 2° back to the unit.

18 | Arriva/Evolve ue installation guide: 10726-I 09-21
Down-and-out ueing
The down-and-out ue option allows for the adaption ue kit to face downwards
and for the ue to run vertically through a hole in the oor, and then horizontally
to a suitable location outside. When considering the location of the heater
due care must be taken to ensure that the ue path under the oor is free of
obstructions such as studs, noggins, joists, braces, wiring etc.
1
2
3
4
4
4
5
Interiorwall
Interiorwall
Wall plate
Stand off clip
Interiorwall
Floor penetration
1. Flue slide stopper (provided with the
ASPKIT03/EVOKIT03).
2. Air hose from unit.
3. Condensate trap component—acts
as a transition piece (arrow points
down, and it should be capped or
sealed).
4. Wall straps (provided with each ue
kit).
5. 2° fall to wall terminal to drain
condensate.
Flue length
In this example the ue could be up to
6.5 m long and contain one 90 ° bend.
Important
Flue terminal must terminate horizontally
300 mm above ground level. It must not
terminate under the building.
Down and out conguration overview using the Arriva as an example
Down and out conguration overview using the Arriva as an example

Arriva/Evolve ue installation guide: 10726-I 09-21 | 19
Steps for creating down and out ueing
1. Lubricate all inner pipe o-rings with the silicone grease provided.
2. Join the ue transition and condensate together ensuring the condensate arrow points
downwards. Even though the condensate is not actually connected in this ue arrangement,
the condensate component serves as a transition piece between the transition casting and the
ESPIPE900. The transition component must not be connected directly to the ESPIPE900 due
to heat of the ue gases.
3. Fit lengths of ESPIPE900 as required.
4. Create the oor penetration, ensure the hole edges are smooth. The minimum diameter is
80 mm to non-combustible surfaces such as brick, and 100 mm to combustible surfaces such
as plaster.
5. Pass the ESPIPE900 through the wall plate and through the oor penetration and secure wall
plate in place to seal the oor.
6. Prepare the horizontal section of the ue system under the oor by connecting ESPIPE900,
ESBEND and subsequent ESPIPE900 lengths as required. Allow for a 2° continuous fall from
the rst section of horizontal pipe to the wall penetration to drain condensate.
7. Create the wall terminal, refer p.21.
8. Secure joints between ue components through the outer pipes with screws and secure the
entire ue system using the wall straps supplied.

20 | Arriva/Evolve ue installation guide: 10726-I 09-21
Cutting the ASPDFK or ESPIPE900 may be needed to achieve the required ue length to connect
to another component.
IMPORTANT
desired length
12 mm
12 mm
desired length
Min. 300 mm
12 mm
Cutting components to achieve the desired ue length
1. Measure and mark o󰀨 the outer pipe at the desired length.
2. Cut the outer pipe to the required length. Take care not to cut the inner pipe.
3. From the new end of the outer pipe measure and mark o󰀨 an additional 12 mm on the inner
pipe. Cut the inner pipe at this mark. Take care to keep the cut parallel to the outer pipe.
The additional 12 mm shown in the diagram above is required to allow the component to be joined
to another part.
• The minimum length of the ASPDFK when measured from the back plate of the
transition casting MUST NOT be less than 300 mm when joining to other components.
• Ensure all burrs and swarf are removed from any cut ends.
• ESPIPE900 can be cut to size at the non-socketed end
Cutting the ASPDFK and ESPIPE900 to length
to connect to another part
