RIOTEC iCR6307ABQ User manual



Programming Quick Guide
-iCR6307ABQ/ iCR6307ABM

Connecting the Scanner
Be sure that PC is turned OFF, before Connect scanner cable to
the PC USB port on the PC as below described, Ensure that all
connections are ready, and turn on your PC.



1. Please switch ON and charge scanner for 4~ 5 hours at first time
before use. Scanner switch shown on Fig. 2.
2. After switch ON, the Orange LED will flash following with 3
beep-sounds. The RED LED will be OFF while it links to cradle
within 2.4GHz radio range.
3. I f RED LED is continual ON, please re-plug USB cable, then, scan
the 3 barcodes on the bottom of cradle sequentially. (Shown on
Fig. 3 From 1 to 3).
4. Charging issue: Cradle works as charger when putting scanner on
it. Even if the scanner's battery is full, the cradle will continue to
supply power to the scanner. We suggest you to remove scanner
from cradle when scanner is charged fully
*Note: Please install PL-2303 driver for iCR6307ABM
LED I ndicator I nformation
Orange LED ON Full charged
Orange LED Flashing Charging / Low battery
Red LED ON Offline / out of service
Green LED ON Good read
Orange LED ON Good read (Batch mode)
Remark:
*When the battery power is too low, the Orange LED will flash and beep
once. Scanner should be charged immediately.
*If scanner shuts down it is recommended to charge it fully before
turning it back on.
*Under power-saving mode, there will not be LED indication when charging.
Reset Configuration to Defaults
(scan from A1 to A7 for iCR6307ABQ or B1 to B7 for iCR6307ABM)
iCR6307ABQ iCR6307ABM
A1 B1

A2 B2
A3 B3
A4 B4
A5 B5
A6 B6
A7 B7

*Note: Please install PL-2303 driver for iCR6307ABM
There are two operating modes on the scanner

1.Data Transmission mode ( Default) 


I t is a necessary to scan “clean memory data" w hen
sw itching between these t wo modes.
Within 2.4GHz radio range Beyond 2.4GHz radio range
Data
read
Transmit data t o PC/ terminal
directly
Save data into scanner’s memory,
scanner will transmit data to PC/
terminal automatically when back to
2.4GHz radio range.
Enter Data Storage mode
LED Green/ Orange LED flashes
followed by 3 beeps.

2.Data Storage mode ( Batch Mode) 


I t is a necessary to scan “clean memory data" w hen switchin
g
betw een these two modes.
Data
read
Save data directly to scanner’s memory, It will transmit the data to PC
/
terminal after you scan the Transmit memory data code. To delete
data please scan the Clean memory data code.
Enter Data Transmission mode
LED Green/ Oran
g
e LED flashes followed by 3 beeps.

Always Clean memory data before switching to Data Transmission
Mode.
Otherwise Red/ Orange LED will flash with one long beep and will not
switch modes.

Under Data storage Mode
The data can be keep or delete by option after transmit
Keep the data
( Default )
Delete the data
Transmit memory data
Green/ Orange LED Flashes followed by 3 beeps
Clean memory data
Green/ Orange LED flashes followed by 3 beeps
The barcode data which is stored in the memory will be deleted.
1

Trigger Mode
Trigger always
(Trigger available at any time)
Trigger standard
(Trigger available, after data sent to the device)
( Default)
Transmission Speed
Transmission speed is dependent on your device. In order not to lose
data, please choose the correct speed. Middle-speed is the Default.
High-speed Ultra Slow-speed
Tr a n s m i ss i on 1transmission
Middle-speed Ultra Slow-speed
Tr a n s m i ss i on
(Default)
2transmission
Slow-speed Ultra Slow-speed
Tr a n s m i ss i on 3transmission
Wireless Auto-connection
Wireless Auto-connection ON:
When out of range, it will keep trying to connect to
device, scanner will not enter power-saving mode.
Wireless Auto-connection OFF:
When you are out of BT signal range, scanner will stop
sending auto-connection signal to device after 2
minutes. During this time, it will not enter power-saving
mode. Once you are back within range, press trigger to
connect to the device. ( Default )
Keyboard Country( For USB HI D only)
Scan the appropriate country code as below to program the keyboard for
your country or language. As a general rule, the following characters are
not supported by the scanner for countries other than the United States:
@ | $ # { } [ ] = / ‘ \ < > ~
USA
(Original setting)
I t alian
Norway
France
Germ any
Viet nam
Sweden
Spain
Denm ark
Por t ugal
Sw it zer lan d Hungary
Power-saving Mode
Power-saving mode OFF
Power-saving mode ON ( Default) :
Enter power-saving mode after 1-minute inactivity.
This function converses battery power. When you
press " SCAN/ Power ON" butt on, it will wake up and
begin to scan.
*When charging, the scanner will not enter power-saving mode
automatically.
How to append a “prefix” or a “suffix” to the
barcode data
pref ix suff ix
1. scan above configuration code for Prefix or Suffix
2. enter the required values (right, numeric barcode) for Prefix or
Suffix using the hex values for the desired HEX values from “Prefix
& Suffix TABLE (blew page)”
3. then, end by scanning Code X (below, right)
*The max. of special characters is 5.
*When you append 1~ 4 required values for Prefix or Suffix, it must
end with Code X.
*It doesn’t need Code X, if you append 5 values to barcode data.
How to delete Prefix or Suffix
1. scan above configuration code for Prefix or Suffix
2. enter the “0” “0” (above, right)
3. then end by scanning Code X (below, right)
Numeric barcode for settings
0
6
C
1 7
D
2 8
E
3 9
F
4
A
5
B X
2

Prefix & Suffix TABLE
HEX HID
(SPP) HEX HID
(SPP) HEX HEX HEX HEX
01 CTRL A
(SOH) 19 CTRL Y (EM) 20 SPACE 38 8 50 P 68 h
02 CTRL B
(STX) 1A CTRL Z(SUB) 21 ! 39 9 51 Q69 i
03 CTRL C
(ETX) 1B ESC (ESC) 22 " 3A : 52 R 6A j
04 CTRL D
(EOT) 1C CTRL \ (FS) 23 # 3B ; 53 S6B k
05 CTRL E
(ENQ) 1D CTRL ] (GS) 24 $ 3C < 54 T 6C l
06 CTRL F
(ACK) 1E CTRL ^ (RS) 25 % 3D = 55 U6D m
07 CTRL G
(BEL) 1F CTRL _ (US) 26 & 3E > 56 V 6E n
08 Backspace
(BS) 27 ' 3F ? 57 W6F o
09 Tab
(HT) 28 ( 40 @ 58 X 70 p
0A CTRL J
(LF) 29 ) 41 A 59 Y71 q
0B CTRL K
(VT) 2A * 42 B 5A Z 72 r
0C CTRL L
(FF) 2B + 43 C 5B [73 s
0D Enter
(CR) 2C , 44 D 5C \ 74 t
0E CTRL N
(SO) 2D - 45 E 5D ]75 u
0F CTRL O
(SI ) 2E . 46 F 5E ^ 76 v
10 CTRL P
(DLE) 2F / 47 G 5F _77 w
11 CTRL Q
(DC1) 30 0 48 H 60 ` 78 x
12 CTRL R
(DC2) 31 1 49 I 61 a79 y
13 CTRL S
(DC3) 32 2 4A J 62 b 7A z
14 CTRL T
(DC4) 33 3 4B K 63 c7B {
15 CTRL U
(NAK) 34 4 4C L 64 d 7C |
16 CTRL V
(SYN) 35 5 4D M 65 e7D }
17 CTRL W
(ETB) 36 6 4E N 66 f 7E ~
18 CTRL X
(CAN) 37 7 4F O 67 g
Barcode Configuration Method: (Flow chart for setup procedure :)

Start Conf iguration End Conf iguration




1D Symbologies On/ Off – 1
ENABLE
CODE 39 DI SABLE
ENABLE
GS1-128
UCC/ EAN-128
DI SABLE
ENABLE EAN-8 DI SABLE
ENABLE EAN-13 DI SABLE
ENABLE CODE 128 DI SABLE
ENABLE
CODE 93 DI SABLE
ENABLE CODE 11 DI SABLE
ENABLE CODABAR DI SABLE
1D Symbologies On/ Off – 2
ENABLE I SSN DI SABLE
ENABLE I SBN DI SABLE
ENABLE UPC-E DI SABLE
ENABLE UPC-A
DI SABLE
ENABLE
I nterleaved
25
DI SABLE
ENABLE
Matrix 25 DI SABLE
ENABLE I ndustrial 25 DI SABLE
ENABLE Plessey DI SABLE
ENABLE
MSI -
Plessey DI SABLE
ENABLE
GS1-Databar
( RSS) DI SABLE
ENABLE
GS1-Databar
( RSS- Limited) DI SABLE
ENABLE
GS1-Databar
( RSS- Expand) DI SABLE
