Riverside Mirabelle User manual

Made in Viet Nam
email: [email protected]
FURNITURE
Riverside
1 pc.
4 pcs.
Page 1 of 5
6 pcs.
6 pcs.
2 pcs. 8 pcs. 8 pcs.
8 pcs. 8 pcs. 8 pcs.
1 pc.
6 pcs.
Mirabelle
King Bed
Assembly Instructions
6/6 King Bed
26286 -- 6/0-6/6 Shelter Upholster Headboard
26287 -- 6/0-6/6 Shelter Upholster Footboard & Slats
26278 -- 5/0-6/6 Shelter Bed Rails (for 6/6 Bed)
OR
26288--6/0 Shelter Bed Rails (for 6/0 Bed)

Page 2 of 5
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside Mirabelle
King Bed
Assembly Instructions
ASSEMBLY STEPS :
1. Place the Headboard Panel (H-A) face down on a clean and soft surface.
2. Install three All-Thread Bolts (H-D) into the metal threaded inserts installed in each
Headboard Post.
3. Carefully position one end of the Headboard Panel (H-A) onto the All-thread Bolts on the
correct Headboard Post and connect using the Arc Washers (H-F), Flat Washers (H-G),
Spring Washers (H-I), and Hex Nut (H-J). Tighten all Hex Nuts using the Open Wrench
(H-K). Repeat to connect the other Headboard Post.
4. Attach the Headboard Stretcher (H-C) to the Headboard Posts using the Flat Washers
(H-G) Spring Washers (H-I) and Allen-Head Bolts (H-E).
5. Tighten using the Allen Wrench (H-M) (see Detail A & B).
Gently lean the back of the assembled Headboard against the wall where the Bed will be
located in the room.

Page 3 of 5
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside Mirabelle
King Bed
Assembly Instructions
ASSEMBLY STEPS :
1. Place the Footboard Panel (F-A) face down on a clean and soft surface.
2. Install two All-Thread Bolts (F-F) into the metal threaded inserts installed in each
Footboard Post.
3. Carefully position one end of the Footboard Panel (F-A) onto the All-thread Bolts on the
correct Footboard Post and connect using the Arc Washers (F-G), Flat Washers (F-I),
Spring Washers (F-H), and Hex Nut (F-J).
4. Tighten all Hex Nuts using the Open Wrench (F-K). Repeat to connect the other Footboard
Post.

Page 4 of 5
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
ASSEMBLY STEPS :
To prevent possible damage to furniture and personal injury, it is recommended that two people are used
to perform the following steps.
5. Install two All-Thread Bolts (R-B) into the metal threaded inserts installed in the Headboard Posts and
into the metal inserts on the Footboard.
6. Carefully position one end of one Bed Rail (R-A) onto the All-thread Bolts on the Headboard and
connect using the Arc Washers (R-F), Flat Washers (R-E), Spring Washers (R-D), and Hex Nut (R-C).
Only partially tighten the Nuts until the Footboard has been connected. Repeat for other Bed Rail.
7. Position and connect the Footboard (F-A) to the other end of the Bed Rails, attaching as in the previous
Steps.
8. Carefully align the Footboard to be 'square' with the Headboard. Using the Open Wrench (R-G) tighten
all Hex Nuts attaching the Side Rails to the Headboard and Footboard. (See Detail C ).
9. Attach the eight Support Legs (F-D) to the bottom side of four Wood Slats (F-C). (See Detail D).
10. Position and attach the Slats to the Bed Rails using the Wood Screws (F-E) and your Phillips
Screwdriver. (See Detail E).
The levelers located at the bottom of the Support Legs can be adjusted if necessary to support the Slats.
Mirabelle
King Bed
Assembly Instructions

Riverside
email: [e-mail]
The Headboard must be used with
the Footboard and Rails as shown,
.
Page 5 of 5
#26278 QUEEN /
EASTERN KING RAILS
26286
King Headboard
USE THESE HOLES FOR ATTACHING WOOD SIDE RAILS.
ALL HARDWARE IS INCLUDED WITH THE SIDE RAILS
26286 -- 6/0-6/6 Shelter Upholster Headboard
26287 -- 6/0-6/6 Shelter Upholster Footboard & Slats
26278 -- 5/0-6/6 Shelter Bed Rails (for 6/6 Bed)
26288--6/0 Shelter Bed Rails (for 6/0 Bed)
