Riverside Oakmont User manual

Oakmont
Queen Storage Bed
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
8 pcs. 8 pcs.
2 pcs. 2 pcs.
1 pc.
4 pcs. 4 pcs.
1 pc.
4 pcs. 4 pcs. 4 pcs.
Page 1 of 7
2 pcs.
20270 --5/0 Sleigh Headboard
20274 --5/0-6/6 Bed Rails
20273 -- 5/0 Storage Footboard, Panels, Slats
4 pcs.
8 pcs. 8 pcs. 8 pcs.
2 pcs.
1 pc.
8 pcs. 1 pc.

Oakmont
Queen Standard Bed
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
8 pcs. 8 pcs.
1 pc. 4 pcs.
Page 2 of 7
2 pcs.
2 pcs.
20270 --5/0 Arch Headboard
20274 --Bed Rails
20271 -- 5/0 Footboard with Slats
4 pcs.
8 pcs. 8 pcs. 8 pcs.
2 pcs.
1 pc.
8 pcs. 1 pc.

Page 3 of 7
Oakmont
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
ASSEMBLY STEPS :
1. Place the Headboard Panel (H-A) face down on a clean and soft surface.
2. Attach the Headboard Bun feet (H-B) to the bottom of the Headboard. (see Detail A).
3. Attach the Left and Right Headboard Posts (H-C) to the back of the Headboard Panel,
using the Flat Washers (H-G), Spring Washers (H-F) and Bolts (H-E). Do not fully
tighten until after next step. (see Detail B).
4. Attach the Back Stretcher (H-D) to the Headboard Posts using the same Washers and
Bolts as previous step. Tighten Bolts connecting Stretcher with the Allen Wrench (H-I).
(see Detail C). Tighten Bolts connecting Headboard Posts to Headboard Panel.
Gently lean the back of the assembled Headboard against the wall where the Bed will be
located in the room.

Page 4 of 7
Oakmont
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
To remove the drawer:
A. Pull the drawer fully open so the black latch is visible in the inside
channel of the guides.
B. Release the latches by simultaneously pushing one lever up and the
other down.
C. At the same time, pulling the drawer forward until the slides release.
Note which opening they are removed from so they can be reinstalled
back into the correct opening.
ASSEMBLY STEPS :
1. Remove both drawers from the Storage Footboard. Refer to the steps above.
2. Place the Storage Footboard Frame (F-A) face down on a clean and soft surface.
3. Attach the Footboard Bun feet (F-B) to the bottom of the Footboard.
4. Attach the Drawer Box Support Legs (F-D) using the Flat Washers (F-I), Spring Washers
(F-H) and Bolts (F-G). Tighten with the Allen Wrench (F-J).
After the Bed has been completely assembled, reinstall the drawers back into the opening from
where they were removed by aligning the channels and gently pushing the drawer back
into the footboard. Open and close a couple times to verify they are working properly.

Page 5 of 7
Oakmont
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
4 pcs.
ASSEMBLY STEPS :
To prevent possible damage to furniture and personal injury, it is recommended that two people are used to
perform the following steps.
5. Install two All-Thread Bolts (R-B) into the metal threaded inserts installed in the Headboard Posts and into the
metal inserts on the Storage Footboard.
6. Carefully position one end of one Bed Rail (R-A) onto the All-thread Bolts on the Headboard and connect using
the Arc Washers (R-F), Flat Washers (R-E), Spring Washers (R-D), and Hex Nut (R-C). Only partially tighten the
Nuts until the Footboard has been connected. Repeat for other Bed Rail.
7. Position and connect the Storage Footboard (F-A) to the other end of the Bed Rails, attaching as in the previous
Steps.
8. Carefully align the Storage Footboard to be 'square' with the Headboard. Using the Open Wrench (R-G) tighten
all Hex Nuts attaching the Side Rails to the Headboard and Storage Footboard. (See Detail E ).
9. Attach the four Support Legs (F-E) to the bottom side of four Wood Slats (F-L). (See Detail F).
10. Using one of the Support Panels (F-F) as a gauge, locate and position the four Slats so there is a Slat underneath,
centered at the edge of each Support Panel. Attach using the Wood Screws (F-K) and your Phillips Screwdriver.
11. Position and attach the Support Panels to the Slats using the Wood Screws and your Phillips Screwdriver.
The levelers located at the bottom of the Support Legs can be adjusted if necessary to support the panels.
12. Reinstall the Drawers into the Footboard by aligning the metal channels of the guides and push back into the
Footboard.
8 pcs.
4 pcs.

Page 6 of 7
Oakmont
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
8 pcs.
4 pcs.
ASSEMBLY STEPS :
To prevent possible damage to furniture and personal injury, it is recommended that two people are used
to perform the following steps.
5. Install two All-Thread Bolts (R-B) into the metal threaded inserts installed in the Headboard Posts and
into the metal inserts on the Standard Footboard.
6. Carefully position one end of one Bed Rail (R-A) onto the All-thread Bolts on the Headboard and
connect using the Arc Washers (R-F), Flat Washers (R-E), Spring Washers (R-D), and Hex Nut (R-C).
Only partially tighten the Nuts until the Footboard has been connected. Repeat for other Bed Rail.
7. Position and connect the Footboard (F-A) to the other end of the Bed Rails, attaching as in the previous
Steps.
8. Carefully align the Footboard to be 'square' with the Headboard. Using the Open Wrench (R-G) tighten
all Hex Nuts attaching the Side Rails to the Headboard and Footboard. (See Detail E ).
9. Attach the four Support Legs (F-D) to the bottom side of four Wood Slats (F-E). (See Detail F).
10. Position and attach the Slats to the Bed Rails using the Wood Screws (F-J) and your Phillips
Screwdriver.
The levelers located at the bottom of the Support Legs can be adjusted if necessary to support the panels.

Riverside
FURNITURE
email [e-mail]
USE THESE HOLES FOR ATTACHING A FULL SIZE (4/6)
METAL BED FRAME
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
CUSTOMER TO PROVIDE 5/16 X 1-1/2" LONG BOLTS, NUTS
& WASHERS TO CONNECT THE METAL BED FRAME
USE THESE HOLES FOR ATTACHING A QUEEN SIZE
(5/0) METAL BED FRAME
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
CUSTOMER TO PROVIDE 5/16 X 1-1/2" LONG BOLTS,
NUTS & WASHERS TO CONNECT THE METAL BED
FRAME
USE THESE HOLES FOR ATTACHING WOOD SIDE RAILS.
ALL HARDWARE IS INCLUDED WITH THE SIDE RAILS
Page 7 of 7
The Headboard may be used alone with
a Full or Queen Size
Metal Bed Frame
Oakmont
Queen / Full Size Headboard
#20274 QUEEN /
EASTERN
KING RAILS
20270 --4/6-5/0 Sleigh Headboard
20274 --5/0-6/6 Bed Rails
20273 -- 5/0 Storage Footboard
20270 --5/0 Sleigh Headboard
20274 --5/0-6/6 Bed Rails
20271 -- 5/0 Footboard with Slats
