Robern C Series Assembly instructions

INSTALLATION
AND CARE
OF YOUR
ROBERN
SERIES C
MIRRORED
CABINET
THE FINEST
MIRRORED
CASEWORK
IN THE
WORLD...
INSTALLER NOTE:
1. DOOR ALIGNMENT
IS AFFECTED BY OUT
OF SQUARE WALLS-
CHECK PLUMB.
2. DOOR ALIGNMENT
IS AFFECTED BY
MISHANDLING OF
CABINET- CHECK
SQUARE.
Limited Warranty
One Year Term
Robern warrants to the original purchaser that, it will, at its
election repair, replace, or make appropriate adjustment to
products made by this company shown to have significant
defects in material or workmanship which are reported to
Robern in writing within one (1) year from the date of delivery.
Robern is not responsible for installation costs.
The warranty time period for operating components including
door hinges and opening devices to the original owner
extends beyond the one year term.
The warranty is void in the event the product is damaged in
transit, or if damage or failure is caused by abuse, misuse,
abnormal usage, faulty installation, damage in an accident,
improper maintenance, or any repairs other than those
authorized by Robern. At the expiration of the one year
warranty period, Robern shall be under no further obligation
under any warranty, expressed or implied, including the
implied warranty of merchantability.
Robern shall not be liable for any consequential damages
arising out of or in connection with the use or performance of
its products. Some states do not allow limitations on how long
an implied warranty lasts or do not allow the exclusion or
limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
Any liability against Robern under any implied warranty,
including the warranty of merchantability, is expressly limited
to the terms of this warranty.
Permission to return any merchandise under this warranty
must be authorized by Robern and returned prepaid by the
purchaser.
Claims under this warranty should be sent directly to your
dealer.
PLUMB-
"TWIST" IN
PLANE OF
WALL
SQUARE-
RACKING OF
CABINET
FRAME

ROBERN SERIES C BATH CABINETS
UNPACKING THE CABINET:
1. READ THE INSTRUCTIONS FIRST. CHECK PARTS LIST FOR
ANY MISSING ITEMS.
2. REMOVE CABINET FROM BOX AND CHECK BOX
THOROUGHLY FOR ITEMS TAPED INSIDE.
3. DO NOT REMOVE TABS COVERING DOOR EDGES, TRIM
MIRROR OR FOAM BLOCKS HOLDING DOORS IN PLACE
UNTIL READY TO INSTALL.
GENERAL NOTES:
1. A SQUARE AND PLUMB INSTALLATION INSURES
PROPER DOOR OPERATION. PLEASE FOLLOW
LEVELING INSTRUCTIONS CAREFULLY.
2. IMPROPER INSTALLATION VOIDS WARRANTY. INSTALLED
CABINETS CANNOT BE RETURNED.
3. SEE CARE OF YOUR ROBERN CABINET FOR CLEANING AND
ADJUSTMENTS.
SINGLE DOOR CABINETS:
SINGLE DOOR CABINETS CAN BE INSTALLED WITH THE DOOR
SWINGING FROM LEFT OR RIGHT. IN THE HARDWARE BAG YOU
WILL FIND A DOME HEAD PUSH ROD, POSILATCH AND A SNAP
IN HOLE PLUG. INSTALL THE PUSH ROD IN THE HOLE INSIDE
THE BOTTOM TRACK AND THE HOLE PLUG IN THE TOP TRACK
AS SHOWN. FOLLOW POSILATCH INSTRUCTIONS.
PUSH ROD &
POSILATCH
TAP IN
LIGHTLY WITH
PLASTIC
MALLET
HOLE PLUG
INSTALLATION AND CARE
SURFACE MOUNT CABINETS
A SEPARATE SURFACE KIT MARKED SK-28 (38) IS
NECESSARY FOR SURFACE MOUNTING YOUR CABINET. THIS
KIT CONTAINS TWO SIDE MIRRORS WHICH ARE APPLIED TO
THE CABINET AFTER IT IS HUNG ON THE WALL. THE
INSTRUCTIONS IN 2.E. COVER THE SK-28/38 INSTALLATION.
IF A TLS LIGHT STRIP IS TO BE INSTALLED OVER THE CABINET
A SKL-28 (38) IS NECESSARY. THIS SIDE KIT IS 4” LONGER
TO COVER THE LIGHT.
-2-
1. INSTALL THE MOUNTING BRACKET FIRST:
A. DRAW A PENCIL LINE ON THE WALL WHERE YOU
WANT THE BOTTOM EDGE OF THE CABINET. THIS
SHOULD BE 39” TO 46” ABOVE FINISHED FLOOR.
B. DRILL THROUGH THE MOUNTING BRACKET AT
STUD LOCATIONS (IF NO STUDS ARE AVAILABLE USE
MOLLY TYPE ANCHORS) AS SHOWN LEAVING
1 1/2” ON EITHER SIDE. (MOUNTING BRACKET IS 3”
SHORTER THAN CABINET.
2. INSTALLING THE SURFACE MOUNT CABINET:
NOTE: IF THIS CABINET IS PART OF A RE:FLECT
SURFACE MOUNTED SYSTEM WITH A RFS SHELF
REFER TO THE INSTRUCTIONS WITH THE RF AND RFS
PRODUCTS NOW. IF USING CAHC LIGHTS BE SURE
ELECTRICAL ROUGH-IN IS COMPLETED
A. INSERT THE BOTTOM BOARD GREY SIDE DOWN INTO THE
SLOT AT THE BOTTOM OF THE CABINET.
B. LIFT THE CABINET (PUSHROD DOWN) ONTO THE MOUNTING
ANGLE WHILE GUIDING THE BOTTOM BOARD INTO THE
MOUNTING BRACKET. THE CABINET WILL DROP INTO THE
RECESS IN THE BRACKET.
C. USE 2 OR 3 OF THE RETAINING CLIPS, SCREWS, AND
WASHERS TO SECURE THE TOP OF THE CABINET.(SEE
DRAWING ON PAGE 3)
D. BE SURE CABINET IS PLUMB AND SQUARE.
E. TEST FIT THE SK SIDE MIRRORS FIRST. MOUNT EACH
MIRROR IN THE SK KIT BY PEELING THE RELEASE PAPER
FROM THE BACK AND PRESSING FIRMLY ON TO THE SIDE OF
THE CABINET. THE SIDE MUST BE CLEAN,DRY AND OIL-FREE!

NOTE:
IF WALLS ARE OUT OF SQUARE IT MAY BE
NECESSARY TO SHIM OUT THE CABINET AT ONE OR
MORE OF THE RETAINING CLIPS. USE WOOD SHIMS
AND POSITION THEM AT THE POINT WHICH KEEPS
THE DOORS IN PLANE.
RECESS MOUNT CABINETS
1. WALL OPENING CHART:
MODEL WIDTH R.O. MODEL HEIGHT R . O
1 6 14 1/2” 28 24”
2 0 18 1/2” 38 34 3/4”
2 4 22 3/4”
3 2 30 3/4”
3 6 34 3/4”
4 8 46 3/4’
6 0 58 3/4’
RECOMMENDED HEIGHT FROM FLOOR TO
BOTTOM OF ROUGH OPENING:
28” HIGH 48” FROM FINISHED FLOOR
38” HIGH 41” FROM FINISHED FLOOR
BE SURE 38” HIGH CABINET CLEARS FAUCETS
2. DRILL A MINIMUM OF FOUR HOLES WITH A 3/16” DRILL BIT AS
SHOWN. OPENING SHOULD BE FRAMED FOR CABINET, IF NOT
BE SURE TO DRILL A STUD LOCATIONS. DRILL VERY
CAREFULLY TO AVOID DAMAGE TO CABINET. INSTALL WITH
PUSHRODS AT BOTTOM. DO NOT USE WASHERS.
NOTE:
DO NOT INSTALL CABINET THRU SHELF PIN HOLES!
THE DOOR FRAME WILL NOT BE PROPERLY
SUPPORTED AND WILL RACK OUT OF SQUARE. THE
CABINET WARRANTY IS VOID WHEN INSTALLED IN
THIS MANNER.
-3-
DOOR INSTALLATION AND ALIGNMENT
1. IF ALIGNMENT OF DOORS IS NECESSARY LOOSEN THE 4
PHILLIPS HEAD SCREWS AT THE HINGES. MOVE
THE DOOR TO THE PROPER LOCATION (BE SURE AT LEAST 1/8”
IS BETWEEN EACH DOOR). RETIGHTEN CAREFULLY TO AVOID
STRIPPING. IF DOORS CANNOT BE ALIGNED PROPERLY THE
CABINET IS OUT OF SQUARE. CHECK FRAME OF CABINET WITH
A FRAMING SQUARE AND ADJUST.
2. IF DOORS DO NOT CLOSE PROPERLY OR IN PLANE, THE
CABINET MAY BE MOUNTED ON A WALL WHICH IS NOT FLAT.
SHIMMING AS SHOWN TOP LEFT WILL BE NECESSARY UNDER
THE SIDE OR CORNER WHICH WILL BRING THE CABINET FACE
IN PLANE.
3. REPLACEMENT DOORS ARE SHIPPED WITHOUT HINGES OR
TAPERED DOOR STOP. REMOVE THESE ITEMS FROM THE OLD
DOOR AND REINSTALL SO THAT PUSHROD ENGAGES TAPERED
DOOR STOP AND OPENS DOOR.
USE AND CARE OF YOUR ROBERN CABINET
1. UNDER NO CIRCUMSTANCES SHOULD AN
AMMONIA BASED GLASS CLEANER BE USED ON
MIRRORS. USE ONLY A LINT FREE POLISHING
CLOTH ON YOUR CABINET. DAMPEN SLIGHTLY WITH
RUBBING ALCOHOL FOR STUBBORN MARKS.
2. USE A MILD LIQUID CLEANER AND WATER ON THE ALUMINUM
SURFACES OF THE CABINET. AVOID ALL CLEANSERS WITH
ABRASIVES AS THESE WILL SCRATCH THE SURFACE OF THE
CABINET.
3. SHELF PINS ARE ADJUSTABLE EVERY 2”. THEY ARE
DESIGNED FOR A TIGHT FIT, TWIST IN PLACE. GREY PLASTIC
PLUGS ARE SUPPLIED IN YOUR HARDWARE BAG TO FILL THE
SHELF PIN HOLES NOT IN USE.

4. A SWING OUT MAGNIFYING MIRROR IS ENCLOSED. BE SURE
THE HOMEOWNER DETERMINES THE DOOR AND HEIGHT OF
THE MIRROR. FOLLOW THE INSTRUCTIONS PROVIDED WITH
THE MIRROR. (MODEL SOMM)
5. REFER TO DOOR INSTALLATION AND ALIGNMENT FOR DOOR
ADJUSTMENTS.
6. IF YOU SHOULD HAVE PROBLEMS WITH YOUR CABINET
PLEASE CONTACT YOUR ROBERN DEALER. BE SURE TO
INDICATE THE MODEL NUMBER AND SERIAL NUMBER OF YOUR
UNIT ( FOUND INSIDE CABINET ON SIDE FRAME).
NOTE THESE NUMBERS BELOW:
MODEL#_________________________________
SERIAL#_________________________________
page 4 SS519 8/99
FOR OTHER QUESTIONS RELATING TO YOUR ROBERN CABINET
THE FACTORY ADDRESS AND PHONE NUMBER IS:
ROBERN, INC.
701 Nth WILSON AVENUE
BRISTOL, PA 19007
[phone]
800 877.2376
FAX [phone]
DATE INSTALLED_________________________
DEALER_________________________________
