Robert Juliat Dalis ACCESS 863 User manual

DALIS 863
Firmware V1.XX
Validation : 02/08/19
DN41149300
Robert Juliat S.A.S. 32, rue de Beaumont, F60530 Fresnoy-en-Thelle - phone : [phone] - fax : [phone] - [e-mail]
www.robertjuliat.com
Dalis ACCESS 863
CycLIODE
CYCLIGHT
Cycliode 150W LED 4 couleurs
4 colours LED 150W Cyclight
Model
Length
Power
863
100 cm
150 W
Manuel /
Manual

Robert Juliat reserve the right to change
or alter any of the items detailed on this page,
to increase or improve manufacturing techniques without prior notice.
Table of contents
1 User’s instructions ....................................................................................................................... 1
2 Presentation ................................................................................................................................ 2
2.1 Functions ............................................................................................................................ 2
2.2 Identification plate ............................................................................................................... 2
2.3 Accessories included ........................................................................................................... 3
2.4 Optional accessories ........................................................................................................... 3
3 Set-up.......................................................................................................................................... 4
3.1 Mechanics ........................................................................................................................... 4
3.2 Electrical ............................................................................................................................. 7
3.3 DATA .................................................................................................................................. 8
4 Operation................................................................................................................................... 10
4.1 Light intensity .................................................................................................................... 10
4.2 Colours ............................................................................................................................. 11
4.3 Strobe ............................................................................................................................... 12
4.4 Group ................................................................................................................................ 13
4.5 Response time .................................................................................................................. 13
5 Control and parameters ............................................................................................................. 14
5.1 Local display and Controls ................................................................................................. 14
5.2 DMX512-A remote control ................................................................................................. 16
5.3 RDM remote control .......................................................................................................... 19
5.4 Art-Net remote control ....................................................................................................... 20
5.5 sACN remote control ......................................................................................................... 21
6 Service ...................................................................................................................................... 22
6.1 Preventive maintenance .................................................................................................... 22
6.2 Analysis............................................................................................................................. 22
6.3 Electronic thermal management system ............................................................................ 22
6.4 Firmware update ............................................................................................................... 22
6.5 Factory defaults ................................................................................................................. 22

EN
EN -1-
1 User’s instructions
GENERAL INSTRUCTIONS
1. Not for residential use.
2. These fixtures must only be serviced by a qualified technician.
3. In addition to the instructions indicated on this page, relevant health and safety requirements of the appropriate EU
Directives must be adhered to at all times.
4. This fixture is in compliance with section 17 - Lighting appliance for theatre stages, television, cinema and photograph
studios. Standards NF EN 60598-1 and NF EN 60598-2-17.
5. This fixture is rated as IP20, and is for indoor use only.
FIXTURE
6. Ensure fixture is correctly mounted on an appropriate support.
7. Protection screens must be replaced in the event of any damage, such as cracks or deep scratches, since these might
reduce performance.
8. When hung or flown the fixture must be secured by an additional hanging accessory (such as a safety cable or bond) of
suitable length
9. Safety bonds or cables must be securely attached to the fixture and be as short as possible, or rolled up as necessary, to
minimise travel distance should the fixture be dislodged. .
10. WARNING: LED source become hot during use. Allow fixture to cool before servicing.
11. Do not tamper with design of fixture nor any of its safety features.
12. Tighten electrical mains cable connections regularly and replace with one of identical specification if damaged.
13. Use only with correct power supply.
14. Do not orientate the fixture towards a source of light (sun, fixture), in particular for LED versions.
VENTILATION
15. Keep well away from flammable material.
16. Not for outdoor use. Do not cover. Do not permit fixture to get wet.
17. To avoid overheating, do not obstruct air vents – do not cover the unit.
PLEASE NOTE
These products have been built to conform to European standards relating to professional lighting equipment. Any modification
made to our products will void the manufacturers' warranty.

EN
EN -2-
2 Presentation
2.1 Functions
2
Functions :
1. Feet
2. M10 thread for rigging
3. ID plate
4. Power IN
5. DMX IN
6. Network
7. Display and keypad
8. DMX OUT
9. Power OUT
2.2 Identification plate
Description :
1. Model
2. Version (Hardware version)
3. Serial number
4. Serial number in barcode format
1
2
3
2
4
3
2
1
1
1
2
2
2
4
2
5
6
7
8
9

EN
EN -3-
2.3 Accessories included
Reference
Description
1
COU0003305
Neutrik PowerCON© True1 connector (ref. NAC3FX-W)
2
DN41134700
Quick Start manual
2.4 Optional accessories
!
"
#
4
$
%
&
1
"
Reference
Description
1
CAL03
3 meter power cable ( 3G1,5 HO7RNF) with Neutrik PowerCON© True1 and CEE 7/7
(2P+T NF/SCHUKO) connectors
2
CAL04
1,50m power cable UL/CSA with Neutrik PowerCON© connector
3
CAL05
Combined Neutrik PowerCON© True1 / DMX (5 pins) patch cable - length: 1m
4
FC860/S
Flight-case for 6 Dalis
5
AccessRig
Rigging hardware set (872 clamps x2 + screws + PECS x1 + CS2 x1)
6
CS2
Safety cable Ø3 mm L= 600mm - SWL: 75 Kg
7
PECS
Safety cable attachment point + M10 screw + nut indicator

EN
EN -4-
3 Set-up
3.1 Mechanics
3.1.1 Operating positions
3.1.2 Minimum distance between a flammable material and the lighting unit
3.1.3 Instructions for use
Minimum :
5°C
41°F
Maximum :
40°C
104°F
IP20 – Indoor use only
3.1.4 Floor installation
0,2 m
0.7 ft

EN
EN -5-
3.1.5 Installation with clamps
• The fixture can be secured with clamps by using M10 screws on the M10 threads.
• Ensure fixture is correctly mounted on an appropriate support.
• The fixture must be installed with 2 clamps.
• Net weight : model 863 : 9.3 Kg
• Center M10 thread can be equipped with eye bolt to attach safety cable.
• Safety cables or bonds must be securely attached to the back of the fixture and be as short as
possible, or rolled up as necessary, to minimise travel distance should the fixture be dislodged.
3.1.6 Safety cable.
• When hung or flown, the fixture must be secured by an additional hanging accessory
(such as safety bond or cable) of suitable length.
• Safety cables or bonds must be securely attached to the back of the fixture and be as short as
possible, or rolled up as necessary, to minimise travel distance should the fixture be dislodged.

EN
EN -6-
3.1.7 Angular sensor

EN
EN -7-
3.2 Electrical
3.2.1 Power
Model
Voltage
(V)
Frequency
(Hz)
Amps*
(A)
PF
Power
(W)
Connectors
863
230
50
0,7
0,82
133
Neutrik powerCON TRUE1
ref. NAC3FPX (max. 20A)
see appendix 1 for assembly
instructions
120
60
1,2
0,93
137
100
60
1,5
0,93
138
• Class 1 product. This luminaire must be grounded.
• Must be connected directly to AC power. Do not connect to dimmer power.
• Automatic power detection.
• Daisy chain: maximum of 20 units (230V) / 10 units (120V) / 8 units (100V)
Daisy chain (with optional patch cable):
3.2.2 Power cable
Power cable
Power cable
Connector
Mains plug
Cable
type
Cable
length
Wiring
1
Standard version
Neutrik
PowerCON®
NAC3FX
CEE7/7
3G1.5
H07RNF
3 m
9.8 ft.
Live: Brown
Neutral: Blue
Ground:
Yellow/Green
2
North American
version
-
14AWG
SJ TYPE
(UL/CSA)
1.5 m
4.9 ft.
Live: Black
Neutral: White
Ground: Green
In
Out

EN
EN -8-
3.3 DATA
3.3.1 DMX 512-A / RDM
Protocol
Input connector
Output connector
USITT DMX 512-A
RDM
XLR 5-pin
XLR 5-pin
3.3.2 Art-Net / sACN
Protocol
Input connector
Output connector
Art-Net
sACN
RJ45
-
DATA connectors
PIN #
DMX
Description
1
Shielding
Foil & Braided Shield
2
DMX (-)
1st conductor of 1st twisted pair
3
DMX (+)
2nd conductor of 1st twisted pair
4
Not used
1st conductor of 2nd twisted pair
5
Not used
2nd conductor of 2nd twisted pair
Daisy chain
DMX Console
Maximum:
32 units
DMX Console
Art-Net
sACN
Network
switch

EN
EN -9-
3.3.3 Ethernet/DMX node
Protocol
Input connector
Output connector
Art-Net
sACN
RJ45
DMX
DMX Console
Art-Net
sACN
DMX

EN
EN -10-
4 Operation
4.1 Light intensity
4.1.1 Range
4.1.2 Control
4.1.3 Parameters
4.1.3.1 Dimming resolution
4.1.3.2 Dimming curve
à selection in SETUP/DIMMER CURVE menu: Linear or Square
0
20
40
60
80
100
020 40 60 80 100
Light output (%)
Control (%)
Linear Square

EN
EN -11-
4.2 Colours
4.2.1 Range
4.2.2 Control
Remotely with
DMX512-A / Art-Net / sACN protocols
Mode 1 – 2 – 3 – 4
4.2.3 Parameters
4.2.3.1 Resolution
Resolution
DMX mode :
8 bits – 255 steps
3
16 bits – 65 535 steps
1 – 2 – 4
Console

EN
EN -12-
4.2.3.2 Intensity curve
4.3 Strobe
4.3.1 Range
4.3.2 Control
0
20
40
60
80
100
020 40 60 80 100
Light output (%)
Control (%)
Linear

EN
EN -13-
4.4 Group
4.4.1 Range
Model :
Group 4
Group 3
Group 2
Group 1
863
4.4.2 Control
4.5 Response time
4.5.1 Range
4.5.2 Control

EN
EN -14-
5 Control and parameters
5.1 Local display and Controls
5.1.1 Display
Function
Exit the current menu option and/or go back
Enter the current menu option and/or valid
Scrolls through menus and/or Increase data value
Scrolls through menus and/or Decrease data value
Scrolls through menus and/or Increase data value
Scrolls through menus and/or Decrease data value
5.1.2 Parameters
5.1.2.1 Display mode
à Selection in SETUP/DISPLAY MODE menu
Display
Mode
Description
Auto-OFF
Main display OFF after 20 seconds
Always on
Main display always ON
DATA check (dot)
Main display OFF – only a “dot” sign is
visible if data detected
5.1.2.2 Display faults
à Selection in SETUP/DISPLAY FAULTS menu
Display
Mode
Description
Warn on faults
Message displayed in case of data error
Don’t warn on faults
No message in case of data error –
display remains the same
Unit information
.
Unit information
DMX error
Unit information

EN
EN -15-
5.1.3 Menus
DATA
MODE
DMX
• ADDRESS
• PERSONALITY
ARTNET
•NET-SUB-UNI
•IP-CONF
• ADDRESS
• PERSONALITY
SACN
•IP-CONF
• ADDRESS
• PERSONALITY
•UNIVERSE
STANDALONE
•INTENSITY
STATUS
SERIAL NR
SOFTWARE VERSION
LED BOARDS IDS
IP
MAC
SETUP
DISPLAY MODE
DISPLAY FAULTS
GROUP FLIP
DIMMER CURVE
RESPONSE TIME
DMX HOLD
UPDATE
FACTORY
DEFAULT

EN
EN -16-
5.2 DMX512-A remote control
5.2.1 Protocol:
E1.11 – 2008, USITT DMX512-A
5.2.2 Configuration:
DMX address of the unit from
1 to 512
Selection of the unit
personality
5.2.3 Parameters
5.2.3.1 DMX Hold
à Selection in SETUP/DMX HOLD menu
Data Mode
DMX
DMX Address
Start address : XXX
Personality
MX :
XXXXXXXXXXXX

EN
EN -17-
5.2.4 DMX chart:
5.2.4.1 DMX chart: model 863
DMX address
Mode 2
Full1groupmode16b
Mode 3
Full1groupmode8b
Mode 4
4groupsindividual16b
1Dimmer Dimmer Dimmer Group 1 - Dimmer 1
2Dimmer fine Dimmer fine Red Group 1 - Dimmer fine 1
3Group 1 - Red Red Green Group 1 - Red
4Group 1 - Red fine Red fine Royal blue Group 1 - Red fine
5Group 1 - Green Green Warm white Group 1 - Green
6Group 1 - Green fine Green fine
Strobe duration
Group 1 - Green fine
7Group 1 - Royal blue Royal blue
Strobe speed
Group 1 - Royal blue
8Group 1 - Royal blue fine Royal blue fine
Response time
Group 1 - Royal blue fine
9Group 1 - Warm white Warm white Control mode Group 1 - Warm white
10 Group 1 - Warm white fine Warm white fine Group 1 - Warm white fine
11 Group 2 - Red
Strobe duration
Group 2 - Dimmer 2
12 Group 2 - Red fine
Strobe speed
Group 2 - Dimmer fine 2
13 Group 2 - Green
Response time
Group 2 - Red
14 Group 2 - Green fine
Control mode
Group 2 - Red fine
15 Group 2 - Royal blue Group 2 - Green
16 Group 2 - Royal blue fine Group 2 - Green fine
17 Group 2 - Warm white Group 2 - Royal blue
18 Group 2 - Warm white fine Group 2 - Royal blue fine
19 Group 3 - Red Group 2 - Warm white
20 Group 3 - Red fine Group 2 - Warm white fine
21 Group 3 - Green Group 3 - Dimmer 3
22 Group 3 - Green fine Group 3 - Dimmer fine 3
23 Group 3 - Royal blue Group 3 - Red
24 Group 3 - Royal blue fine Group 3 - Red fine
25 Group 3 - Warm white Group 3 - Green
26 Group 3 - Warm white fine Group 3 - Green fine
27 Group 4 - Red Group 3 - Royal blue
28 Group 4 - Red fine Group 3 - Royal blue fine
29 Group 4 - Green Group 3 - Warm white
30 Group 4 - Green fine Group 3 - Warm white fine
31 Group 4 - Royal blue Group 4 - Dimmer 4
32 Group 4 - Royal blue fine Group 4 - Dimmer fine 4
33 Group 4 - Warm white Group 4 - Red
34 Group 4 - Warm white fine Group 4 - Red fine
35
Strobe duration
Group 4 - Green
36
Strobe speed
Group 4 - Green fine
37
Response time
Group 4 - Royal blue
38
Control mode
Group 4 - Royal blue fine
39 Group 4 - Warm white
40 Group 4 - Warm white fine
Mode 1
Full4groupsmode16b

EN
EN -18-
5.2.5 DMX ranges:
5.2.5.1 Strobe duration
Range min
Range max
Function
0
0
Strobe OFF
1
255
Strobe ON - 1ms --> 85ms
5.2.5.2 Strobe speed
Range min
Range max
Function
0
255
Frequency: 5,8 Hz --> 11,5 Hz
5.2.5.3 Response time
Range min
Range max
Function
0
250
Dimmer timing: 0,1s --> 4 s
251
255
OFF
5.2.5.4 Control mode
Range min
Range max
Function
0
0
1
255
RDM desactivated
