Robinson Willey ATHENA LF LPG Operation instructions

THEGAS CONSUMERS'COUNCIL
(GCC) ISAN INDEPENDENT
ORGANISATION WHICHPROTECTS
THEINTERESTOF GAS USERS.
IFYOU NEED ADVICE,YOU WILL
FIND THETELEPHONE NUMBER IN
YOUR LOCAL TELEPHONE
DIRECTORY UNDER GAS.
' ElIlIlll~
Cat 1
3PG31 at 37mbar in GB and lE
FOR USE ON PROPANE GAS ONLY
UsersOperating Instructions
THIS LEAFLET IS INTENDED TO HELP YOU UNDERSTAND AND USE YOUR NEW FIRE EFFICIENTLY.
PLEASE READ THESE INSTRUCTIONS BEFORE USING THE FIRE AND KEEP FOR FUTURE REFERENCE.
11
5349
US R

IMPORTANT NOTES 11
________ 1
1. The appliance name and serial numberare on the data badge which is located on the left hand side of the fire box.
Remove the outer case for access to read the data badge. (See Fig.1).
3.This fire must be installed and serviced regularly in accordance with the currentGas Safety(Installation andUse) Regulations
and the rules in force by a competent person e.g.British Gas or CORGI member.Where solid fuel has beenused the chimney mu s t
be swept before installation.Thisfire must be installed in accordance with the installationinstructions.
4. It is recommended that at leastonce a year the appliance should be removed to check the catchmentspace and the chimney
for debris.The fire should bechecked annually to ensure continued clearance of combustion products and that there is no
excessive build up of soot.
5.WARNING: This fire has a naked flame.Also certain parts,especially the canopy, will be hot when inuse.A fireguard
conforming to B.S.6539 : 1984 (Fireguards for use with solid fuel appliances)should be used forthe protection of children,
the elderly or the infirm.Such a guard is also recommended for pet animals.
6.After the fire is installed you may wish to fix a shelf above.This is quite acceptable provided that the underside ofthe shelf is at
least 237mm above the fire anddoes notproject more than 150mm forward.For a deeper shelf allow 13mm increasein shelf
height for every 25mm increasein shelf depth.
8.When the fire isfirst used it may give off some slight smoke and smell butthesewill soon clear after a few hours of use atthe
HIGH setting. 1 0 2 4 5 0
9.Do not burn paper or any rubbish in the fire.
10.IMPORTANT: When considering fitting any heating
appliance or wallpapering a room inwhich one is fitted,
if blown vinyl or other heat sensitive wallpapers are
used in the vicinity of the heat source, then they may
become heat damaged or discoloured especially just
above the fire.
11.It is important for safe operation andto maintain
efficiency that the fire is not operated with damaged
or broken coals.
IMPORTANT NOTE: Under nocircumstances should
extra coals be used together with the existing coals.
ONL Y THE CORRECT COALS SHOULD BE USED.
12.If purpose built ventilation is provided for the fire,it
should be checked periodically to ensure that it is
free from obstruction.
13.IMPORTANT NOTE
Plaster Applied Directly to Pre-castFlue Blocks.
Some Pre-castflues built toB.S.1289:1975 may have
plaster applied directly to theflue blocks.
A recommendation was made,in the revision B.S.1289
part 1:1986,NOT to apply plasterdirectlyto the flue
blocks, otherwise cracking ofthe plaster could occur.
It is not recommended to installthis fire into such
installations, unless remedial action istaken.
;TA BADGE POSmON
BEHIND OUTER CASE
If)

TO LIGHT AND OPERATE ••
-------
WARNING: Ifthe flames are found to be extinguished and the control is not in the OFF position,the control knob should be returned to
the OFF position andno attempt should be madeto light the gas until at least 3 minutes have elapsed.
SAFETY
The fire is fitted with a flame supervision device and an atmosphere sensing device which will shut off the gas supply iffor any reason the
pilot goes out.The device will also extinguish the pilot if the oxygen content in the room falls below a prescribed level.If the fire keeps
going out, the faultmust be rectified immediatelybya competent person.
jy
The control knob is illustrated in Fig.2 and has the markings OFF,HIGH,MED,ECON and PILOT.
The control knob is located on the right side of the fire.Depress the control knob to the PILOT IIGN position until the ignition starts.Keep
the control knob pushed in for a further 10 seconds before releasing.The pilot should remain lit andthe control knob will spring back to
the ECON position .. Refer to Fig.3for viewing ofthe pilot when lit.
When the pilot is established,slide the control knob to the HIGH position.Your fire is now operating on full heat input.You may now slide
the control knob to any the position,HIGH,LOWor ECON.
11
5 349

TO LIGHT AND OPERATE 11
--------
Generally the fire will only need dusting.Any painted
surface or metal part should be cleaned with a damp
cloth only.Never use any abrasive materials or metal
polish on painted surfaces or metal parts.
FUEL EFFECT COMPONENTS
From time to time you may need to remove loose
coals for dusting.The appearance of the fire after you
have removed the loose coals is shown in Fig.4.Use
a soft brush to remove any powdery deposits from the
loose coals.Never use a vacuum cleaner to clean the
coals.If you need to remove the coal bed to dust
away larger particles then it is recommended that you
first remove the outer case.As you lift out the coal bed
take care that you do not damage it against the pilot
burner and also take precautions that particles do not
fall on your carpet etc.
As well as loose coals and coal bed there are a rear
coal and side cheeks which you will not need to
remove but can be dusted in situ after removing the
coal bed.Remove any deposits on the burner with a
soft brush
When replacing the coal bed put it in rear end first to
avoid damage against the pilot.The coalbed is a close
fit in the burner tray.Ensure that it is properly located
by sliding it sideways and front to back. Replace the
loose coals.Place five loose coals in the front
recesses with their decorative faces forward. Similarly
place the remaining four loose coals on top of the
recesses formed by the front loose coals and touching
the rear coal (Fig. 5). Ensure that the loose coals are
stable and not likely to fall off.
Periodically vacuum away any loose particles that
have fallen on the hearth or into the base of the fire.
5 349

SPARES AND SERVICE ••
~---_-.l'
For spares and service apply toyour local supplier or installer stating that the appliance is anATHENA LF LPG.The appliance
G.C.number,Product code and Serial number are marked on the data badge on the left hand side of the fire (remove the outer
case).
With the fire set at the HIGH position it will consume approximately 0.46 kg of gas perhour at a cost of approximately 16 pence.
When set to the ECON positionthe fire will consume approximately 0.18 kg of gas perhour ata cost of approximately 6.4 pence.
(based on a domestic bulk price of 18 pence per litre).
If any 'home improvements'are made to the dwelling in which a gas appliance is fitted, i.e.Thefitting of an extractor fan,draught
proofing or double glazing,then the airsupply to the appliance and the f1uing of the appliance mustbe rechecked by a competent
person (e.g.A CORGI registered engineer).
ADVANTAGE SHOULD BE TAKEN OF ANNUAL SERVICE/INSPECTION FOR GASAPPLIANCES TO ENSURE CONTINUED
SAFE OPERATION.
PARTS REPLACEABLE BY USER •
~ I
ERWJ PART NUMBER DESCRIPTION
992234 Coal Bed
992169 Loose Coals (9 off)
989873 Issue 2
ROBINSON WILLEY LIMITED
Mill Lane,Old Swan,Liverpool.L13 4AJ.England.
Telephone:[phone] Fax:[phone]
www.robinson-willey.co.uk
57349
