Roca Broadway Maxi Instruction Manual

1
User’s Handbook
SPA BROADWAY MAXI

2
Congratulations!
and thank you
for buying
this ROCA
product
In keeping with its creative and innovative spirit, ROCA SANITARIO, S.A. has taken one step further in its commitment to
quality, design and the incorporation of new technologies. Our efforts have been rewarded by the loyalty of our customers
and the National Prize for Design awarded by the Ministry of Science and Technology and Fundación BCD.
This recognition confirms our professional career and enables us to continue working and creating the most advanced,
practical and modern products on the market.
Offering maximum comfort enables Roca to develop healthy and pleasant products for you, products to recover from days
filled with stress.
This manual includes the instructions required for the use of your spa. Before using the hydromassage, please read all the
sections in this manual carefully.
This spa has been designed for private use.

3
INDICE
1. HYDROMASSAGE SYSTEM...................................................................................................... 4
2. CONTROL SYSTEM ................................................................................................................... 7
2.1. Switching on/off the pumps ................................................................................................. 7
2.2. Switching on/off the lighting................................................................................................. 7
2.3. Setting the right time ........................................................................................................... 7
2.4. Economy mode ................................................................................................................... 7
2.5. Filtration............................................................................................................................... 8
2.6. Fast filtration (Boost) ........................................................................................................... 8
2.7. Setting the water temperature ............................................................................................ 8
2.8. Increasing the maximum temperature................................................................................. 8
2.9. “Stand-By” function.............................................................................................................. 8
2.10. Control panel keyboard locking ......................................................................................... 9
2.11. ANTIFROST System / Smart Winter Mode........................................................................ 9
2.12. Water level ........................................................................................................................ 9
3. OZONO ....................................................................................................................................... 9
4. MAINTENANCE .......................................................................................................................... 10
4.1. Water maintenance ............................................................................................................. 10
4.2. Water filter maintenance ..................................................................................................... 10
4.3. Thermal cover (additional option)........................................................................................ 10
4.4. Frost advises ....................................................................................................................... 10
4.5. Acrylic plate ......................................................................................................................... 10
4.6. Wooden panels maintenance.............................................................................................. 10
5. ASSEMBLING AND DISMANTLING OF WOODEN PANEL ....................................................... 11
6. TROUBLESHOOTING ................................................................................................................ 11

4
1. HYDROMASSAGE SYSTEM
Hydromassage is the pressure on defined muscles exerting by stream of water or stream of air and water. Water or
air and water at high pressure bring out from regulated jets and hit on body surface. It tones and relaxes the skin, at
the same time massaging and cleaning it. Hydromassage is not recommended for anybody with spine, arthritic or
muscle pains, respiratory system diseases or gynaecological problems. It is therefore essential that you consult your
doctor before using SPA Broadway Maxi.
Water massage system (hydro-massage) elements:
- a set of 69 water and air jets, supplying water or a water and air mix of high kinetic power to the water section of
the bath,
- 3 hydromassage whirl pump,
- 7hydromassage air regulators, installed at the edge of the bath; to regulate the massage intensity,
- 3hydromassage diverters to change massage zone as well as starting of cascade,
- water suction point.
The system based on 3 pumps and 2 control panels allows for using simultanously all pumps together or each of
them separately.
The water massage intensity regulation is possible by means of aeration regulators located at the perimeter of the
bath top, by adding air to the water stream coming from the jets. The more air, the stronger the stream is.
Hydromassage intensity is increased by turning the regulator knobs anti-clockwise
(towards the "ON" sign)
Hydromassage intensity is decreased by turning the regulator knobs clockwise
(towards the "OFF" sign)
Each regulator is responsible of controlling a different jet section.
SECTION 1
SECTION 2
SECTION 3
SECTION 4
SECTION 5
SECTION 6
SECTION 7
WATERFALL
4
5
3
A
B
K
C
DE
F
G
H
I
JF
J
E
IC
F
F
H
G
C
C
J
J
I
I
B
B
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
DD
D
D
D
D
D
D
D
DD
D
D
D
D
L
6
3
2
1
WATERFALL
7
Aeration regulator control zones

5
4
5
WATERFALL
3
A
B
K
C
DE
F
G
H
I
JF
J
E
IC
F
F
H
G
C
C
J
J
I
I
B
B
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
DD
D
D
D
D
D
D
D
DD
D
D
D
D
L
6
3
2
1
SECTION 6
SECTION 4 + SECTION 5 + SECTION 6
SECTION 4 + SECTION 5
GEYSER
GEYSER + SECTION3+WATERFALL
SECTION3+WATERFALL
SECTION 2 SECTION 1
SECTION 1 + SECTION 2
Pump 1
Pump 2
Pump 3
7
Jet Quantity Picture
regular mini jets - D 41 pcs.
fixed ozone mini jet - L 1 pcs.
3” adjustable rotating stream - E 2 pcs.
3” adjustable rotating dual stream - F 4 pcs.
3” multi-shower multi-massage - G 2 pcs.
Hydromassage zones

6
Jet Quantity Picture
3” pulsating shower galaxy massage - H 2 pcs.
3” pulsating stream massage - I 4 pcs.
3 3/8” adjustable rotating dual stream - B 3 pcs.
3 3/8” pulsating stream massage - C 4 pcs.
5” rotating alternating splash gyro - J 4 pcs.
5” alternating splash resonator - K 1 pcs.
big jet geyser - A 1 pcs.

7
2. CONTROL SYSTEM
FILTER
LIGHTJETS 2JETS 3 JETS 1
DOWNUP
AIR/AUX
CLOCK ECONO
213
Broadway Maxi SPA control panel
JETS 1 LIGHT
AIR
JETS 2
Auxiliary control panel
2.1. Switching on/off the pumps JETS 1
1JETS 2
2JETS 3
3
The hydromassage pumps can be switched on/off directly
from the electronic control panel. The pumps react
differently depending on whether they are of one-gear or
two-gear type. Press the button one time to switch on the
one-gear pump (pumps 2 and 3), and press it once again
to switch the pump off. After starting the pump, this icon
2
, will appear on the display (pump 3 does not have
such an icon), and after switching it off, the icon
disappears. Two-gear pump switches, pressing the
button for the first time the pump over to a low gear
(filtration; this icon
1
blinks on the display). Pressing
the button once again the pump switches over to a top
gear (massage; this icon
1
appears on the display). By
pressing the same button again switches the pump off
and the icon disappears from the display.
During the filtration or the water heating process in the
SPA bath, the pump automatically switches to a low gear
after connetcting it to the power supply.
The buttons for pumps 1 and 2 are represented on the
display by the pump icons
1
,
2
. Pump 3 does not
have such a representation. All pumps working in
massage mode have automatic time out (20 minutes)
from the last button start.
2.2. Switching on/off the lighting LIGHT
Press this button to switch on the lighting. This icon
appears on the display. Press the same button again to
switch off the lighting, and the icon disappears from the
display. The lighting switches off automatically after 2
hours from the last pressing of the lighting on/off button.
Press and hold this button LIGHT for more than 5 seconds
to view from inside the spa the water temperature and
time display projection, to read these data.
2.3. Setting the right time CLOCK
The controller is fitted with the RTC system (real-time
clock), which works permanently even after disconnecting
the main power. The RTC system makes it easier to use
the SPA, since the controller memorize the clock, filtration
and the economy mode setting even after the main power
is off. It is not necessary to set the filtration start time and
its duration again. RTC settings are available from big
panel only.
To change the RTC system setting:
●Press and hold the clock button for about 5 seconds
until the clock icon starts blinking and appears
permanently on the display.
●Set the hour by using the up/down arrow buttons
UP
DOWN
●Press the clock button once again to set minutes by
using the up/down arrow buttons
UP DOWN
●Press the clock button once again to save the current
setting after the time modification. If no button is pressed
for longer than 5 seconds, the controller returns to its
normal mode without saving the setting.
2.4. Economy mode ECONO
After switching on the economy mode (energy saving
mode), the controller keeps the temperature 10°C (50°F)
lower than that previously set.
When this mode is working, this icon appears on the
display. The economy mode can be activated (the icon is
displayed permanently) or suspended for 40 minutes
from the moment of switching off the last pump, when at
least one pump is switched on during this mode.
Regardless of the temperature previously set, the
controller maintains the water temperature not lower
than 15°C (59°F).
To enter the economy mode:
●Press this button
ECONO
●The display will then show „Edx”, where x stands for
the economy mode duration (from 0 to 24 hours)
Ed0 – the economy mode is switched off,
Ed24 – the economy mode is working continuously.
●To change the hour, use the up/down arrows
UP

8
DOWN
and use this button
ECONO
on the control panel
to confirm the setting.
●After confirming the settings, the display will show the
time when the economy mode is to start.
●Set the hour and minutes using the arrows
UP DOWN
and confirm the setting with this button
ECONO
.
●Confirming the minutes with this button
ECONO
the econo
my mode is set. The display returns to its normal status.
The setting of the economy mode is remembered even
after the power cut-off.
2.5. Filtration FILTER
In this system, filtration process is based on water
ozonization. Water is sucked by the skimmer filter and
then mixed with ozone by the injector. After that, water
returns to the SPA bath through the ozone jet. Filtration
process consists on two steps. The first step lasts 1
minute, all three water pumps work at the highest speed,
while the heater is on. Second step of filtration procedure
starts with low speed of double speed pump activation
and ozonizing device activation. The duration of filtration
depends on the time setting. Filtration mode is indicated
by this special icon on the display. Filtration process
can be suspended (the filtration icon is blinking on the
display) by switching on any of massage pumps. Filtration
will return to its normal mode after 40 minutes after user
last operations. Switching the lighting on does not
suspend the filtration process.
Setting filtration parameters:
●Press the filtration button
FILTER
●The display will show Fdxx, where xx stands for the
filtration duration from 0 to 12 hours.
●If xx is set on 0, the filtration does not work
●Filtration duration can be changed with these arrows
UP DOWN
and the selected value is confirmed by
pressing the filtration button
FILTER
●The blinking filtration start time will appear on the
display
●Changes are made with these arrows
UP DOWN
and
confirmed by using the filtration button
FILTER
●After confirming the selected minutes by pressing the
filtration button, the controller memorizes the setting and
returns to its normal work. If no button is pressed for
longer than 5 seconds during the setting procedure, the
controller will quit the filtration setting menu and will not
remember any changes.
2.6. Fast filtration (Boost)
The “boo” function enables to make faster water
filtration. During this function, all the pumps work for
1 minute. Additionally, pump 1 works in a fast gear for
45 minutes along with the ozonator. The heater works
normally during the fast filtration process. After switching
this function on, the „boo” sign appears on the display
and is present until this function is finished. Fast filtration
process is triggered by pressing and holding the pump 1
button for 10 seconds. This function can be switched off
earlier by starting any other pumps.
2.7. Setting the water temperature
To set the water temperature, press the arrow buttons
UP DOWN
on the control panel.
The selected temperature does not have to be confirmed,
but only set. The display, after 5 seconds from the last
pressing, will return to the previous status and start
showing the current water temperature. The controller
maintains the set temperature with an accuracy of
± 0,5°C (1°F). If the water temperature is lower than that
previously set, the controller will start the heater and low
gear pump1 (filtration circuit) and keep it on until the
water reaches its required temperature. If the economy
mode is on
ECONO
the controller keeps the water tempera
ture lower by 10 degrees than that previously set.
After the economy mode is off, the controller returns to
maintaining the previous temperature set.
2.8. Increasing the maximum temperature
This function allows the user to increase the water
temperature by two degrees centigrade above 40°C
(104°F). To set the temperature above 40°C, set the
maximum temperature and next press and hold the up
arrow button
UP
for 5 seconds until the Orx.x sign
appears on the display, where x.x signifies how much the
temperature value is to be increased above the maximum
temperature. This value can be increased half a degree,
and the maximum value is two grades, so the maximum
water temperature is 42° C. To return to a normal mode
of setting the water temperature, press the down arrow
button
DOWN
a few times until the normal temperature,
ranging from 15 to 40°C, appears on the display.

9
2.11. ANTIFROST System / Smart Winter Mode
Most important task of SPA electronic system is holding
temperature of water within the range between 15 to
400C. However electronic system has additional feature
- winter operation mode (Antifrost/Smart Winter mode)
which protects piping against frozing.
PCB integrated temperature sensor continously controls
air temperature which surronds electronic system. If air
temperature decrease below 150C electronic system
starts winter mode. In this mode system switches on every
pump for 1 minute (one by one). Frequency of pumps
operations is connected with surrounding temperature
and is presented in the table below. Water heater works
independently of air temperature sensor, it depends only
of water temperature sensor.
Temperature 0 COperating frequency (min)
12 < t ≤15 120
9 < t ≤12 60
6 < t ≤930
t ≤615
• Operation mode ANTIFROST system is marked by ICE
symbol on the LCD screen.
• Stand by mode doesn’t affect on ANTIFROST system
operations.
• All these functions are not available until ICE symbol
disappered. It is possible to take a bath.
• If electronic system detects temperature below 150C
degrees of the surrounding air then ANTIFROSTsystems
starts after 15 minutes from last pump switch off.
• If during filtration mode ANTIFROST system starts,
filtration mode will be switch off.
2.12. Water level
If level sensor doesn’t detect enough water, any pump
can be started.
3. OZONO
The ozonized air has, therapeutic, antiseptic propierties
and also a nice essence. It greatly helps in keeping the
water clean both in the bath and the plant. Ozone definitely
mantains hygiene in the SPA. The heated and ozonized
air is pumped into the air duct system underneath the
bath. Operates only during filtration.
Oxygen (O )
2Ozone (O ) 3
O1O3
O2
Oxygen atoms
Electric
current
or UV light
2.9. “Stand-By” function
This function blocks access to all devices connected to
the controller for 60 minutes. This function stop all
functions without need of disconnecting the power supply.
To switch on this function, press this button
FILTER
5 seconds.
After switching this function on, the “Sby” sign will appear
together with the time left to the end of this function.
There are three methods to stop this function automaticaly:
●Wait 60 minutes until this function stops.
●Press this button
FILTER
for longer than 5 seconds when
the function works.
●Disconnect the controller from the power supply.
The “Stand-By” function blocks the filtration function. If 40
minutes after going out from “Stand-By” mode SPA still
will be in filtration period, filtration mode will start again.
2.10. Control panel keyboard locking
Partial keyboard locking:
●Press and hold this button
ECONO
. During this operation,
the key-shaped icon blinks.
●The LocP sign will appear on the display after pressing
this button on the control panel for 3 seconds. Once this
sign has appeared, the function becomes active and
the key icon is on permanently. The main and optional
control panel are locked.
●Release the button.
●Following keys are blocked now: jets, light air/aux and
all the keys in optional panel.
To unlock the panel, press and hold this button
ECONO
for
not less than 5 seconds.
The LocP sign will appear on the display if any button is
pressed after locking the keyboard. The partial keyboard
locking function is not remembered after a power cut-off.
Total keyboard locking:
●Press and hold this button
ECONO
. The key-shaped icon
blinks during this operation.
●The “LocP” sign will appear on the display after pressing
this button on the control panel for 3 seconds. Once this
sign has appeared, the function becomes active and the
key icon is on permanently. The main and optional control
panel are locked.
●Keep this button pressed.
●After 5 seconds the LocF sign appears, and since that
moment the function is active.
●Release the button.
All the buttons in both panels are locked.
To unlock the panel, press and hold this button
ECONO
for
not less than 5 seconds.
The LocF sign will appear on the display if any of the
locked buttons is pressed after locking the keyboard.
The total keyboard locking function is not remembered
after a power cut-off.

10
4. MAINTENANCE
4.1. WATER MAINTENANCE
To maintain the water in perfect hygienic and aesthetic
conditions, we recommend the use of products for
disinfecting and treating water specially designed for
spas.
Ideal values:
Chlorine (free chlorine) 0.3-0 .6 mg/l
Ph value of 7.0-7.4 pH
It is not possible to drain the entire water content inside
the bath just through the drain valve (in the right hand
side). The water should be removed manually (e. g. with
a small bucket) or use „sand and residual water remover”
(PI9000071). The bath should be switched off after it
has been drained. For more informations ask ROCA
Technical Service.
4.2. WATER FILTER MAINTENANCE
The skimmer filter used in the Broadway Maxi has
filtration area 9,2 m2.
A
C
D
B
Filter insert replacement (PD5000075 - filter cartrigde 50
sqft):
1. take out cover A
2. put out B element,
3. screw out cartridge C and D
4. clean or replace for new bath cartridges;
5. Install element B;
6. to clean the filter rinse it with warm water.
Recommended: Rinsing every 2 days
replacement not less frequent than once a
year.
4.3. THERMAL COVER (INCLUDED IN THE SPA)
We recommend to use the cover when:
- the bath is going to be used outdoors, i.e. in a garden (the
cover prevents the water from excessive cooling down
and keeps the bath clean as well as preventing excessive
heating of the bath perimeter due to sun rays),
- when the bath is going to be used very frequently
indoors (the cover serves to prevent the water from
excessive evaporation).
Thermal cover cleaning and maintenance:
- Rinse with cool water using garden hose.
- Spray with gentle, non-foaming cleaner and wipe clean
- For stubborn dirt, use a non-abrasive sponge
- Rinse again thoroughly with water and allow to dry
- Repeat monthly, or as needed
Never use laundry detergent, abrasives, bleach, alcohols,
dish soaps or harsh cleaners.
If the bath will be under direct sunlight, it is
recommended to use the thermal cover
after taking a bath, to prevent damaging
resulting from sunlight heat.
4.4. FROST ADVISES
If the spa is installed outdoors and there is a risk of frozen,
the following norms must be taken into consideration:
- Do not pour hot water on the pipes or the spa to melt
the ice as the sudden change temperature could damage
the materials. Let it thaw at ambient temperature.
- Do not turn the valves or threaded caps if they seem to
be frozen.
Do not use anti-freeze liquids unless they carry health
guarantees.
4.5. ACRYLIC PLATE
Special precautions must be taken in the cleaning and
maintenance of the spa.
- To clean the spa, do not use abrasive or aggressive
products, since they could damage the surface.
- If the surface of your spa shines, you can remove any
surface scratches. Use an emery cloth with water (No.
800) and recover the initial shine with a solvent-free polish
of the type used for car paint. For more informations ask
ROCA Technical Service.
- Do not use any alcohol-base chemical product to
clean plastics neither the electronic panel. To remove
scale, use very diluted vinegar (acetic acid). Never use
chemical products.
4.6. WOODEN PANELS MAINTENANCE
The panel is made of wood which is protected by triple
layer of lacquer Sigma Life. Colour : mahogany, base
0701, pigment 0067. Before applying new layer of lacquer
the area has to be polished by abrasive paper 320.

11
5. ASSEMBLING AND DISMANTLING OF
WOODEN PANEL
Both processes consist on slipping under SPA rim all
elements (wooden or artificial) and bringing down to fix
the aluminium support on the wooden floor bar. For more
informations ask ROCA Technical Service.
Panel has 4 corners and 4 flat pieces.
Broadway Maxi built-in has aluminium
frame not available in versions with panels.
6. TROUBLESHOOTING
Alarm Condition Message on display Inhibited
function Alarm output condition
Pressure/Flux gauge which indicates the
presence of flow when it should not be
there (heating pump is off).
FLC Deactivated
heater
Restore of correct
condition.
Pressure/Flux gauge which does not
indicate the lack of flow when it should
be there (heating pump is on).
FLO Deactivated
heater
Restore of correct
condition.
Detected temperature (hi-limit probe) ≥
480 C (1180F)
HOH
Alternated with water
temperature inside
SPA or every hour
Heater is
deactivated
Temperature decreases
below 440C and the control
is started-up again (on/off
power supply)
Water temperature ≤00C (320F)
Water temperature ≥480 C (1180F) rPF Heater all
commands
towards loads
Temperature falls within
the admitted range.
HL temperature ≤00C (320F)
HL temperature ≥480 C (1180F) HPF Heater
Temperature falls within
the admitted range.
Control is started-up again.
Low water level inside SPA H2O All commands
towards loads Correct water level
If any of these messages keep permanently on the display, please, contact Technical Service.

12
20091103
8S0234000
(available in Spain only)
(available in Spain only)
