Rocket Fish RF-TVMUC01 User manual

Tools you will need:
Thank you for choosing the
Rocketsh RF-TVMUC01.
The RF-TVMUC01 TV mount
is designed to support
a TV weighing up to
35 lbs. (15.9 kg).
QUICK SETUP GUIDE
RF-TVMUC01 1: Install the locking screw
Screw the TV bracket locking screw (E)into the TV bracket (A) using the
hex key (F). Do not screw in more than three or four turns.
3: Install the under cabinet mount
Note: Cabinet thickness must not be less than 7/16 in.
a. Use the ceiling plate of the under cabinet mount (B) as a template to mark the hole locations.
b. Drill holes through the bottom of the cabinet using a 1/4”drill bit.
c. Tap the three 3-prongT-nuts (I) into the holes in the upper surface of the cabinet. Be careful not to
damage cabinet surface.
d. Attach the under cabinet mount (B) to the bottom surface of the cabinet using the
three cabinet mounting screws.
Package contents
ATV bracket (1)
B Under cabinet mount (1)
C Plate cover (1)
D Cable cover (1)
Locking hardware
E TV bracket screw (1)
F 5/32 in. hex key (1)
M4 bag
G M4 x 12 mm screws (4)
Mounting hardware
H Cabinet mount screws (3)
10-24 x 5/8 in. phillips at head screws
I 3 prong T-nuts (3)
Wire ties
J8 in. BlackWire Ties (3)
2: Attach the TV bracket
Attach the TV bracket (A) to the back of the TV using the four screws (G).
F
H I J
G
E
Locking hardware
Mounting hardware Wire ties
M4 bag
• Pencil
• Phillips screwdriver
• Hammer
• ¼ in. wood drill bit
• Power drill
E
F
A
A
G
a
b
c
d
10-24x 5/8 in.
M4 x 12 mm
5/32 in.
B
B
H
I
AB
C
D
RF-TVMUC01_10-0665 QSG _V3_EN_final press.pdf 1 8/4/2010 2:01:50 PM
6907-002012<03> 10-0777
4: Hang the TV on the under cabinet mount
a. Slide the plate cover (C) onto the under cabinet mount (B) until the cover tabs snap into the tab slots in the top plate.
b. Hang the TV/TV bracket assembly onto the hanging plate (1) of the under cabinet mount (B).
c. To secure the TV bracket (A) to the under cabinet mount (B) tighten theTV bracket screw (E) using the hex key (F).
7: Adjust the swivel (if necessary)
Swivel the TV ±45° to provide the best viewing angle.
IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS
Caution: Do not use this product for any purpose not explicitly specied by Rocketsh. Improper installation
may cause property damage or personal injury. If you do not understand these directions, or have doubts
about the safety of the installation, contact Customer Service or call a qualied contractor. Rocketsh is not
responsible for damage or injury caused by incorrect installation or use. The weight of your TV must not
exceed 35 lbs. (15.9 kg). The wall or cabinet bottom must be capable of supporting ve times the weight of
the TV and wall mount combined.
This product contains small items that could be a choking hazard if swallowed. Keep these items away from
young children!
5-year limited warranty
Visit www.rocketshproducts.com for details.
We’re here for you
www.rocketshproducts.com
For customer service, call:
800-620-2790 (U.S./Canada markets)
01 800-926-3010 (Mexico market)
© 2010 BBY Solutions, Inc., All Rights Reserved.
Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richeld, MN USA 55423-3645
Best Buy Imports, S. de R.L. de C.V. Av. Santa Fe 485, Segundo Piso, Colonia Cruz Manca, Programa Parcial de Desarrollo
Santa Fe, Delegación Cuajimalpa, Distrito Federal, México 05349
ROCKETFISH is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are
trademarks of their respective owners.
6: Attach the Cable Cover
You may need assistance
with this step.
F
E
A
1
B
a. Use the cable ties (J) to bundle the TV cables if necessary.
b. Fit the cables through the slot in the top of the cable
cover (D), then slide the cable cover up and into the
under cabinet mount (B).
c. Swing the cable cover in, then t the notches in the
bottom of the cover into the slots on the under
cabinet mount.
5: Adjust the TV height
Caution: Carefully adjust the height of the TV on the under cabinet mount (B).
Carefully loosen the center screw on the back side of the hanging plate, slide the TV to the height you
want, then retighten the center screw.
Caution: Do not attempt to loosen or tighten the top and bottom screws on the
hanging plate.Only loosen the center screw to make adjustments.
a
b
c
a
ab
c
C
B
1
±45°
B
B
J
D
B
D
B
RF-TVMUC01_10-0665 QSG _V3_EN_final press.pdf 2 8/4/2010 2:01:51 PM
