Rockler JIG IT User manual

Shelf Pin
Routing Jig Instructions

2
This product is designed for specific applications as defined in the instructions and should not be modified and/or used for
any other applications. Before using the JIG IT®Shelf Pin Routing Jig, read, understand and follow all instructions and safety
information provided. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY WARNINGS
>Always confirm that you are using the most recent version
of the Instructions and safety warnings for your product. To
find the most recent version, find the product page on
Rockler.com and click on the link to the Instructions.
>For any tool used in conjunction with this product,
always read, understand and follow the instructions
 andsafetywarningsintheowner’smanualforthattool.
 Ifyoudonothavetheowner’smanual,obtainonefrom
 thetool’smanufacturerbeforeusingitwiththisproduct.
>Before using this product, review and verify that all
tools to be used with it have safety equipment
installed and are in proper working order as
 definedbythetools’owner’smanuals.
>Do not use this product until you have read and
are confident you understand:
• Product Specific Safety Warnings (pp.3);
• Setup and Use (pp. 3-4).
>Do not use this product in any manner other than
what is described in these instructions. Use only
recommended accessories.
>Remain alert and use good judgment when using
this tool. Do not use this tool if you are in any way
impaired by medications, alcohol, drugs or fatigue.
>Dress appropriately and remove all jewelry, secure
loose clothing and tie up long hair before using
this tool.
>It is the sole responsibility of the purchaser of this
product to ensure that any third party whom you
allow to use this product reads and complies with all the
instructions and safety precautions outlined in this
manual prior to use.
>Maintain these instructions and warnings as long as
you own the product. Keep this booklet in a place where
it will be readily available for reference.
>The user assumes all risk and responsibility for the
proper use of this product and for ensuring product
suitability for intended application.
>Always wear safety glasses in compliance with ANSI
safety standards and hearing protection and follow all
standard shop safety practices, including:
•Keep your work area well lit and clean;
• Unplug all power tools before making any
adjustments or changing accessories;
•Use dust collection tools and dust face masks to
reduce exposure to dust;
•Use accessory safety equipment such as
featherboards, push sticks and push blocks
whenever appropriate;
•Do not use power tools in explosive
environments (e.g., in the presence of
flammable liquids, fumes or dust);
•Keep children and bystanders away from
the tool operating area;
•Maintain proper footing at all times and
do not overreach;
•Do not force the tool.
>These warnings and instructions do not represent the
total of all information available regarding tool safety,
use and technique. Please read the full manual before
using this product and always seek out opportunities to
learn more and improve your skills and knowledge.
Drilling, sawing, sanding or machining wood
products can expose you to wood dust, a substance known
ot the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for
personal protection. For more information go to
www.P65Warnings.ca.gov/wood.
BP0617
Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury.
Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury.
Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury
or property damage.
Notice indicates important or helpful information and/or user tips.

3
Setup and Use
>The Shelf Pin Routing Jig should be used only with a
plunge router and only on unassembled case pieces.
Use with a fixed-base router could result in damage to
the template and the workpiece.
WARNING
1. Install the included Router Guide Bushing on the baseplate
of your plunge router, securing it with the knurled lock
nut. (When the jig is not in use, the Guide Bushing can be
stored on the jig by fitting it into the large hole in the clear
plate and threading on the lock nut.)
2. Install the appropriate router bit in your plunge router. For
a snug fit with 1/4" shelf pins, we recommend using a 15/64"
straight bit (90011, sold separately); for 5mm pins, we
recommend a 3/16" straight bit (90000, sold separately).
Note: Because of the clean, straight holes produced with a
plunge router and this jig, no shelf pin sleeves are necessary.
This jig is not recommended for applications in which shelf
pin sleeves are desired.
3. Set the plunge depth of your router as needed to
accommodate the shelf pins you plan to use. Make sure
the bit will not cut all the way through your material.
4. Determine roughly where you want the run of holes to
begin and end on the unassembled case sides. Measuring
from the top to the approximate center of the run, mark a
reference line across the width of the case sides at exactly
the same location on each piece. Accuracy is crucial
because this line will serve as a guide for positioning the
jig. Any discrepancy will lead to uneven shelf pin locations
and wobbly shelves. Fig. 1.
Fig. 1
>The Shelf Pin Routing Jig should be used only with
a plunge router and only on unassembled case
pieces. Use with a fixed-base router could result
in damage to the template and the workpiece.
>Failure to secure the Router Guide Bushing tightly
to the router base could allow it to come off during
routing, possibly damaging the router and bit and
potentially causing serious personal injury.
>The Shelf Pin Routing Jig must be clamped to the
workpiece, and the workpiece must be clamped to
the bench or table. Failure to clamp the jig and the
workpiece could allow shifting that could damage
the workpiece and cause personal injury.
PRODUCT SPECIFIC SAFETY WARNINGS

4
5. Move one of the case sides so that its front edge overhangs
the edge of the work surface by 2".
6. Position the jig so that the fence is tight against the edge
of the case side and the short horizontal line next to the
center hole on the jig aligns with the centerline you marked
on the side. Clamp the jig to the workpiece, and clamp the
workpiece to the table or bench. Fig. 2.
Failure to clamp the jig to the workpiece
and the workpiece to the table could allow shifting that could
damage the workpiece and cause personal injury.
7. Position your plunge router on the jig so that the Router
Guide Bushing fits into the first guide hole.
8. Turn on the router; plunge the bit fully and then allow it to
retract fully into the router base.
9. Lift the router from the jig and move to the next guide
hole. Plunge the bit fully and then allow it to retract fully
into the router base.
10. Repeat Step 9 for each additional guide hole. Switch the
router off once the final hole has been routed.
11. If you need to extend the run of shelf pin holes, unclamp the
jig and slide it in the desired direction. If machining holes
for 1/4" pins, align the 1/4" indexing hole with the second
hole in from the end; if machining holes for 5mm pin, align
the 5mm indexing hole with the third hole in from the end.
12. Insert a shelf pin through the indexing hole and into the
case side to lock in that position. Make sure the jig’s fence is
tight against the edge of the workpiece and clamp the jig in
place. Fig. 3.
13. Repeat Steps 7-11 until the run of holes is complete.
14. Repeat the process for all of the case pieces requiring
shelf pin holes.
Fig. 3
Fig. 2
Distributed by Rockler Companies, Inc.
©2017 Rockler Woodworking and Hardware
50323
Rev 06/17
Check Rockler.com for updates to these instrutions. If you have
further questions, please contact our Technical Support Department
at 1-800-260-9663 or [e-mail]
