Rockler 43450 Operating instructions

Blank Preparation
1. Cuttheblankabout1/8"longerthantheBrassTubetoallow
 for“blow-out”orholeelongation.
2. Drilltheblankwitha10mmdrillbitataspeedof900
 to1200RPM.
3. PolishtheBrassTubewith220gritsandpapertoremove
 oxidationandroughentheTubeforbetteradhesion.This
 canbedonebyhandorbychuckingitinadrillpressor
 portablehanddrill.
4. PreparetogluewithmediumCA(cyanoacrylate)glueor
 two-partfastdryingepoxy.
5. ApplythegluetotheoutsideoftheBrassTubewithaliberal
 amountaroundtheendthatisinsertedfirst.Donotapplyglue
 totheinsideoftheblank,asthiswillcausethegluetoget
 insidetheBrassTubeandruinit.
6. InserttheBrassTubewithatwistingmotionintotheblank
 untiltheTubeisequidistantbetweenbothendsoftheblank.
 Wipeoffanyexcessglueontheendsoftheblank.Allowthe
 gluetodry.
7. Usingabarreltrimmer,disk,orbeltsander,trimtheends
 oftheblankuntilyoucanjustseethebrightbrassendsof
 theTube.Thefaceoftheendsmustbeperpendicularto
 theBrassTubeandparallelwitheachother.Itisimperative
 tomatchthelengthofthetrimmedblanktotheoriginallength
 oftheBrassTubeandthattheinsideoftheBrassTubeis
 cleanandfreeofanyglue.
Turning the Blank
1. Assembletheblankonthemandrelwiththebushingsplaced
 oneithersideoftheblank.Eachbushinghasastepthatis
 designedtobeinsertedintotheTubeforstabilitywhile
 turning,astheinnerdiameteroftheTubeislargerthan
 themandrel.Notethatallofthebushingsarethesamesize.
Note:EitherWoodSpacersorextraBushingsmaybeused
 tofilltheextraspaceonthemandrel.
2. Tightenthetailstockandthentightenthemandrelnutthat
 holdstheblank.Donotover-tightenthetailstockormandrel
 nutasthismaycausethemandreltoflex,causingtheblank
 togooutofround.
3.Turntheblanktothedesiredshape,makingsurethat
 thesurfacesnexttothebushingsareturnedtothesame
 diameterasthebushings.
4.Afterturning,sandthesurfacesinprogressivestepsof
 220,400,600,and1000grit.Ifahigherfinishisdesired,
 micromeshsandpapermaybeused.
5.Applythefinishofchoiceandpolish.
6. Removetheblankfromthemandrel.
Gold Bullet Cartridge Pen Preparation and Turning
43450
© Rockler Companies Inc. 2012
Brass Tube Nut
Mandrel “A”
Wood Spacer
Bullet Bushing Set
Mandrel “A” Setup:
Nut
Adjustable Mandrel
Brass Tube
Adjustable Mandrel Setup:
Bullet Bushing Set
Visit Rockler.com for the most current product
information and videos or call 1-800-260-9663.

Assembly
Readtheassemblyinstructionscompletelybeforeassembly.
1. PresstheCenterBandintotheBrassTube.
2. PresstheCapAssemblyintothefarendoftheBrassTube.
3. SlidetheSpringontothewritingtipoftheInkCartridge.
4. InserttheInkCartridgeintotheCartridgeAssembly.
5. SlidetheTwistMechanismovertheendoftheInkCartridge
 andthreadintotheCartridgeAssembly.
6. GentlypushthecompletedTubeassemblyontothe
 TwistMechanismbyhand.
Reordering Information Stock #
GoldBulletCartridgePenKit...............................43450
7mmMandrel“A”with#2MorseTaper...............43537
7mmMandrel“A”with#1MorseTaper...............39389
Adjustable7mmMandrel“A”
with#2MorseTaper............................................25581
BulletBushingSet................................................43451
10mmDrillBit.......................................................37216
PenMillKit...........................................................47526
Gold Bullet Cartridge Pen Assembly
Cap Assembly
Spring
Cartridge Assembly
Ink Cartridge
Brass Tube
Center Band
Twist Mechanism
43450 - Rev 05/12
