Rockler 51133 User manual

Review full manual instructions prior to use for important safety information.
Always check Rockler.com to conrm that you are using the most recent manual version for your product.
3 Person Track
Cribbage Template
Instructions
Effective March 2018

2BP0118
This product is designed for specific applications as defined in the instructions and should not be modified and/or used for any
other applications. Before using the 3 Person Track Cribbage Templates, read, understand and follow all instructions and safety
information provided. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY WARNINGS
> Always confirm that you are using the most recent
version of the Instructions and safety warnings for
your product. To find the most recent version, find
the product page on Rockler.com and click on the
link to the Instructions.
> For any tool used in conjunction with this product,
always read, understand and follow the instructions
and safety warnings in the owner’s manual for that tool.
If you do not have the owner’s manual, obtain one from
the tool’s manufacturer before using it with this product.
> Before using this product, review and verify that all
tools to be used with it have safety equipment
installed and are in proper working order as
defined by the tools’ owner’s manuals.
> Do not use this product until you have read and
are confident you understand:
• Drilling the Holes (pp. 3-4).
> Do not use this product in any manner other than
what is described in these instructions. Use only
recommended accessories.
> Do not modify the product in any way unless instructed
to by the instructions.
> Remain alert and use good judgment when using
this product. Do not use this product if you are in any way
impaired by medications, alcohol, drugs or fatigue.
> Dress appropriately and remove all jewelry, secure
loose clothing and tie up long hair before using
this product.
> It is the sole responsibility of the purchaser of this
product to ensure that any third party whom you
allow to use this product reads and complies with all the
instructions and safety precautions outlined in this
manual prior to use.
> Maintain these instructions and warnings as long as
you own the product. Keep this booklet in a place where
it will be readily available for reference.
> The user assumes all risk and responsibility for the
proper use of this product and for ensuring product
suitability for intended application.
> Always wear safety glasses in compliance with ANSI
safety standards and hearing protection and follow all
standard shop safety practices, including:
• Keep your work area well lit and clean;
• Unplug all power tools before making any
adjustments or changing accessories;
• Use dust collection tools and dust face masks to
reduce exposure to dust;
• Use accessory safety equipment such as
featherboards, push sticks and push blocks
whenever appropriate;
• Do not use power tools in explosive
environments (e.g., in the presence of
flammable liquids, fumes or dust);
• Keep children and bystanders away from
the tool operating area;
• Maintain proper footing at all times and
do not overreach;
• Do not force woodworking tools.
> These warnings and instructions do not represent the
total of all information available regarding tool safety,
use and technique. Please read the full manual before
using this product and always seek out opportunities to
learn more and improve your skills and knowledge.
Drilling, sawing, sanding or machining wood
products can expose you to wood dust, a substance known
ot the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for
personal protection. For more information go to
www.P65Warnings.ca.gov/wood.
Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury.
Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury.
Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury
or property damage.
Notice indicates important or helpful information and/or user tips.

3
Minimum board dimensions: 51⁄2" x 161⁄4".
If you intend to use the Round Template as a pattern for
routing the curve on the end, the board must be 51⁄2" wide.
1. Hold or clamp the Square Template on your cribbage board
workpiece, making sure that it’s positioned as desired and
properly aligned.
2. Chuck the included Self-Centering Bit in a handheld drill
and drill the four holes outlined in red in Fig. 1.
3. Press the two included Indexing Pins in the holes you just
drilled to hold the Square Template while you drill the holes
outlined in red in Fig. 2.
4. Remove the Indexing Pins and shift the Square Template so
that the two rearmost outside holes in the “Repeat” section
of the template are over the previous indexing holes. Press
the Indexing Pins in these holes and drill the four holes
outlined in red in Fig. 3.
5. Move the Indexing Pins to the new indexing holes and
drill the holes outlined in red in Fig. 4.
6. Repeat Steps 4 and 5 four more times, drilling the holes
outlined in red in Fig. 3 and Fig. 4.
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Indexing Pin
Indexing Pin
Indexing Pin Indexing Pin
Indexing Pin Indexing Pin
Drilling the Holes

4Distributed by Rockler Companies, Inc.
Medina, Mn 55340
51133
Rev 03/18
Fig. 5
Fig. 6 Fig. 7
7. Remove the Square Template and check that your board
looks like the one shown in Fig. 5.
8. Install the Rounded Template so that its two rearmost
outside holes are over the most recently drilled indexing
holes. Press the Indexing Pins in these holes to hold the
template; then drill the holes outlined in red in Fig. 6.
9. Move the Indexing Pins to the holes shown in Fig. 7
and drill the holes outlined in red.
10. Remove the Round Template and sand the board surface.
Check Rockler.com for updates. If you have further questions, please
contact our Technical Support Department at 1-800-260-9663
or [e-mail]
If you want a curve on the end of your
board, you can use the Round Template as a pattern and
trace the outline.
Holes drill in Steps 4-6
Indexing Pin Indexing Pin
Indexing Pin Indexing Pin
