Rockwell Automation MPF-A310 User manual

Installation Instructions
MP-Series Food Grade Servo Motor with
100 mm to 165 mm Frame Size
Catalog Numbers MPF-A310, MPF-A320, MPF-A330,
MPF-A430, MPF-A4530, MPF-A4540, MPF-A540,
MPF-B310, MPF-B320, MPF-B330, MPF-B430,
MPF-B4530, MPF-B4540, MPF-B540
Topic Page
Important User Information 2
Catalog Number Explanation 3
Before You Begin 4
Install the Motor 8
Verify Connector O-ring and Backshell Seal 8
Change Connector Orientation 9
Mount the Motor 12
Connector Data 15
Mounting Dimensions 17
Motor Load Force Ratings 20
Accessory Kits 22
Specifications 25
Additional Resources 26

2MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
Important User Information
Solid state equipment has operational characteristics differing from those of electromechanical equipment.
Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls, publication
SGI-1.1, is available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com) describes some important differences between solid state
equipment and hard-wired electromechanical devices. Because of this difference, and also because of the
wide variety of uses for solid state equipment, all persons responsible for applying this equipment must
satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many
variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot
assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING
Identifies information about practices or circumstances that can cause an explosion in
a hazardous environment, which may lead to personal injury or death, property
damage, or economic loss.
IMPORTANT
Identifies information that is critical for successful application and understanding of
the product.
ATTENTION
Identifies information about practices or circumstances that can lead to personal injury
or death, property damage, or economic loss. Attentions help you identify a hazard,
avoid a hazard and recognize the consequences.
SHOCK HAZARD
Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that dangerous voltage may be present.
BURN HAZARD
Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that surfaces may reach dangerous temperatures.

MP-Series Food Grade Servo Motor Installation Instructions 3
Publication MP-IN004D-EN-P — April 2009
Catalog Number Explanation
FACTORY DESIGNATED OPTIONS
A = Standard
MOUNTING FLANGE
B = IEC Metric - Oversized
BRAKE
2 = No Brake
4 = 24V DC Brake
CONNECTORS
7 = Circular DIN, Right Angle, 180° Rotatable
ENCLOSURE/SHAFT KEY/SHAFT SEAL
J = IP66/IP67 Housing/Shaft Key/Shaft Seal
FEEDBACK
M = Multi-turn High Resolution Encoder
S = Single-turn High Resolution Encoder
RATED SPEED
A = 500 rpm
B = 1000 rpm
C = 1500 rpm
D = 2000 rpm
E = 2500 rpm
F = 3000 rpm
G = 3250 rpm
H = 3500 rpm
J = 3750 rpm
K = 4000 rpm
L = 4250 rpm
M = 4500 rpm
N = 4750 rpm
P = 5000 rpm
Q = 5250 rpm
R = 5500 rpm
S = 5750 rpm
T = 6000 rpm
MAGNET STACK LENGTH (80 = 8.0 INCHES)
FRAME SIZE (IEC 72-1 FLANGE NUMBER)
3 = 100 mm
4 = 115 mm
45 = 130 mm
5 = 165 mm
VOLTAGE RATING
A = 230 V AC
B = 460 V AC
SERIES TYPE
F = Food Grade
SERIES
MP = MP-Series
MP F - B 5 40 K - M J 7 2 B A

4MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
About the MP-Series Food Grade Motors
MP-Series food grade (MPF) motors feature single-turn or multi-turn high resolution
encoders, and are available with 24V DC brakes. These compact brushless servo
motors combine the characteristics of the MP-Series low-inertia motors with unique
features designed for food and beverage applications.
Before You Begin
Remove all packing material, wedges, and braces from within and around the item.
After unpacking, verify the nameplate catalog number against the purchase order.
1. Remove the motor carefully from its shipping container.
2. Visually inspect the motor frame, shaft, mounting pilot, and encoder for
damage.
3. Notify the carrier of any shipping damage immediately.
Prolonging Motor Life
Thoughtful design and proper maintenance can increase the life of a servo motor.
Follow these guidelines to maximize the life of a servo motor within a food
processing environment.
• Always provide a drip loop in each cable to carry liquids away from the
connection to the motor.
• Avoid spraying liquids under high pressure directly on the junction of the
motor shaft, housing, connectors, and the enclosure joints. Fluids under high
pressure, when forced around worn seals, can contaminate the motor
bearings and significantly shorten the life of a servo motor.
• If design requirements permit, provide shields that protect the motor
housing, shaft, seals and their junctions from product contamination, caustic
agents, and high pressure fluids.
• Replace the shaft seal at or before its expected lifetime of 12 months.
Refer to Shaft Seals for more information on shaft seals.
ATTENTION
Do not attempt to open or modify this motor beyond changing the connector
orientation as described in Change Connector Orientation.
Only an authorized Allen-Bradley repair center shall service this item. Refer to
Rockwell Automation Support for assistance to locate the nearest repair center.
Failure to observe safety precautions could result in personal injury or damage to
equipment.

MP-Series Food Grade Servo Motor Installation Instructions 5
Publication MP-IN004D-EN-P — April 2009
• Inspect the motor and seals for damage or wear on a regular basis. If
damage or excessive wear is observed, replace the item.
• If desired, you may seal the motor front flange to the driven equipment by
applying a bead of food grade RTV around the periphery of the joint
between the motor and the machine surfaces. Use of a gasket or RTV on the
mating surfaces is not recommended, as this can cause misalignment of the
shaft and result in damage to the motor and/or driven equipment.
• The brake option on this servo motor is a spring-set holding brake that
releases when voltage is applied to the brake coil. A separate power source
is required to disengage the brake. This power source can be applied by a
servo motor controller or manual operator control.
If system main power fails, holding brakes can withstand occasional use as
stopping brakes. However, this creates rotational mechanical backlash that is
potentially damaging to the system, increases brake wear, and reduces brake
life.
Using Shaft Seals
A seal is installed on the motor shaft to protect the front bearing from fluids or fine
dust that could contaminate the motor bearing and reduce its lifetime. An IP66/IP67
rating for the motor requires the use of shaft seals, connectors, and cables that
provide an environmental seal equal to or exceeding the rating.
• Refer to Specifications for a brief description of the IP ratings.
• Refer to Shaft Seals to find the catalog numbers of seal kits for your motor.
• Refer to the Kinetix Motion Control Selection Guide, publication
GMC-SG001, to find environmentally sealed connectors and cables that are
compatible with MP-Series motors.
IMPORTANT
Holding brakes are not designed to stop rotation of the motor shaft, nor are they
intended to be used as a safety device. They are designed to hold a motor shaft
at 0 rpm for up to the rated brake holding torque.
The recommended method of preventing motor shaft rotation is a four step
process: first - command the servo drive to 0 rpm, second - verify the motor is at
0 rpm, third - engage the brake; and fourth - disable the drive.
Disabling the drive removes the potential for brake wear caused by a badly tuned
servo system oscillating the shaft.

6MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
Using Couplings and Pulleys
Mechanical connections to the motor shaft, such as couplings and pulleys, require a
torsionally rigid coupling or a reinforced timing belt. The high dynamic
performance of servo motors can cause couplings, pulleys, or belts to loosen or slip
over time. A loose or slipping connection causes system instability and can damage
the motor shaft. All connections between the system and the servo motor shaft must
be rigid to achieve an acceptable response from the system. Periodically inspect
connections to verify their rigidity.
When mounting couplings or pulleys to the motor shaft, make sure that the
connections are properly aligned and that axial and radial loads are within the
specifications of the motor. Refer to Shaft Seals for guidelines to achieve 20,000
hours of motor bearing life.
A shaft key provides a rigid mechanical connection with the potential for
self-alignment when the key is properly installed. These sections provide additional
information:
• Refer to Mounting Dimensions for information about the key and shaft
keyway.
• Refer to Shaft Key for recommendations on how to remove and install a
shaft key.
ATTENTION
Damage may occur to the motor bearings and the feedback device if sharp impact is applied
to the shaft during installation of couplings and pulleys. Damage to the feedback device
may result from applying leverage to the motor mounting face when removing devices
mounted on the motor shaft.
Do not strike the shaft, couplings, or pulleys with tools during installation or removal. Use a
wheel puller to apply pressure from the user end of the shaft to remove any device from the
motor shaft.
Failure to observe safety precautions could result in damage to the motor and its
components.

MP-Series Food Grade Servo Motor Installation Instructions 7
Publication MP-IN004D-EN-P — April 2009
Preventing Electrical Noise
ElectroMagnetic Interference (EMI), commonly called electrical noise, can reduce
motor performance. Effective techniques to counter EMI include filtering the AC
power, use of shielded cables, separating signal cables from power wiring, and
practicing good grounding techniques.
Follow these guidelines to avoid the effects of EMI:
• Isolate the power transformers or install line filters on all AC input power
lines.
• Physically separate signal cables from motor cabling and power wiring. Do
not route signal cables with motor and power wires, or over the vent
openings of servo drives.
• Ground all equipment using a single-point parallel ground system that
employs ground bus bars or large straps. If necessary, use additional
electrical noise reduction techniques to reduce EMI in noisy environments.
Refer to System Design for Control of Electrical Noise Reference Manual,
publication GMC-RM001, for additional information on reducing the effects of EMI.

8MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
Install the Motor
All motors include a mounting pilot for aligning the motor on the machine.
Preferred fasteners are stainless steel. The installation must comply with all local
regulations and use equipment and installation practices that promote safety and
electromagnetic compatibility.
Verify Connector O-ring and Backshell Seal
O-rings on the feedback and motor/brake connectors secure cable plugs, and a
backshell seal on the feedback connector is necessary to achieve the maximum
environmental rating. Verify the seal and O-rings are installed as described.
ATTENTION
Unmounted motors, disconnected mechanical couplings, loose shaft keys, and
disconnected cables are dangerous if power is applied.
Disassembled equipment should be appropriately identified (tagged-out) and access to
electrical power restricted (locked-out).
Before applying power to the motor, remove the shaft key and other mechanical couplings
which could be thrown from the shaft.
Failure to observe safety precautions could result in personal injury.
ATTENTION
Make sure that cables are installed and restrained to prevent uneven tension or flexing at
the cable connections.
Excessive and uneven lateral force on the cable can result in the environmental seal
opening and closing as the cable flexes.
Failure to observe safety precautions could result in damage to the motor and its
components.
Location Verify
•An O-ring is mounted on the external surface of
both the power/brake connector and the
feedback connector.
•The O-ring is undamaged, not twisted, and rests
in the groove as shown in the illustration.
•A backshell seal covers the joint between the
backshell and the connector housing.
•The backshell seal is undamaged, and it is fully
seated against the face of the backshell.
O-ring On Both
Connector
Housings
Groove Reserved For
Quick-lock Plug
Backshell Seal Inside
Feedback Connector
Housing

MP-Series Food Grade Servo Motor Installation Instructions 9
Publication MP-IN004D-EN-P — April 2009
Change Connector Orientation
You may rotate the connector housing up to 180 degrees. This lets you adjust the
connector to a position that best protects the connection from possible
environmental contaminates while providing cable access.
The circular DIN connector housing can be rotated up to 180° in either direction.
Follow these steps to rotate a DIN connector.
1. Mount and fully seat a mating cable on either the feedback or power/brake
connector.
2. Grasp the mated connector and cable plug and slowly rotate them to the
outside of the motor.
3. Repeat these steps for the other connector.
ATTENTION
Connectors are designed to be rotated into a fixed position during motor installation, and
remain in that position without further adjustment. Strictly limit the applied forces and the
number of times the connector is rotated to make sure that connectors meet the
requirements of IP66 and IP67.
Failure to observe safety precautions could result in damage to the motor and its
components.
IMPORTANT
Do not use tools, such as pliers or vise-grips, to assist you in rotating the connector.
Only apply force to the connector. Do not apply force to or pull on the cable.
ATTENTION
Apply force only to the motor connector and cable plug. Do not apply force to
the cable extending from the cable plug. No tools, for example pliers or
vise-grips, should be used to assist with the rotation of the connector.
Failure to observe safety precautions could result in damage to the motor and
its components.

10 MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
Build and Route the Cables
Knowledgeable cable routing and careful cable construction improves system
performance.
Build and install cables as described in these steps.
1. Keep wire lengths as short as physically possible.
2. Route noise sensitive wiring (encoder, serial, I/O) away from input power
and motor power wiring.
3. Separate cables by 0.3 m (1 ft) minimum for every 9 m (30 ft) of parallel run.
4. Ground both ends of the encoder cable shield and twist the signal wire pairs
to prevent electromagnetic interference (EMI) from other equipment.
ATTENTION
If any shield on a power cable is not grounded, high voltage can be present on
that shield.
Make sure there is a connection to ground for all shield wires inside a power
cable, and for the overall power cable shield.
Failure to observe safety precautions could result in personal injury or damage to
equipment.

MP-Series Food Grade Servo Motor Installation Instructions 11
Publication MP-IN004D-EN-P — April 2009
Ground Shielded Signal Wires within a Power Cable
Always connect the shield on any signal wire pair routed inside a power cable to
the overall machine ground.
If you are installing a 2090-XXNPMF-xxSxx, or 2090-CPBM4DF-xxAFxx power
cable, loop the signal wire pairs to the overall cable shield as shown in the
diagram, and then clamp all the shields together in the power cable (chassis)
ground connection on the drive.
Grounding of Signal Wire Shields in a Power Cable
The signal wire pairs within the 2090-XXNPMF-xxSxx, or 2090-CPBM4DF-xxAFxx
power cables often carry a 24V DC brake signal, but also can carry logic signals.
Grounding the shield that surrounds the signal wires dissipates any induced voltage
and reduces the effects of EMI.
ATTENTION
If any shield on a power cable is not grounded, high voltage can be present on that shield.
Make sure there is a connection to ground for all shield wires inside a power cable, and
for the overall power cable shield.
Failure to observe safety precautions could result in personal injury or damage to
equipment.
Shielded Signal Wires (two pairs) Within Power Cable
Overall Power Cable Shield
Signal Wire Shield (one of two) Contacts
Overall Power Cable Shield
Factory Supplied
Field Modified
All power and signal wire shields must connect to
machine ground.
The diagram shows one of the two signal wires in
the correct position. Connect both signal wire
shields and the overall power cable shield to
machine ground.
2090-XXNPMF-xxSxx (shown) contains two signal
wire pairs. 2090-CPBM4DF-xxAFxx contains one
signal wire pair.

12 MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
Mount the Motor
Follow these steps to mount the motor on a machine.
1. Provide sufficient clearance, heatsink mass, and air flow for the motor so it
stays within the operating temperature range of 0…40 °C (32…104 °F).
Do not enclose the motor unless cooling air is forced across the motor and
keep other heat producing devices away from the motor. Heatsink
requirements are listed in a footnote to the Specifications table.
2. Verify the axial and radial shaft loads of your application do not exceed
those listed in the Motor Load Force Ratings.
3. Position the motor on the machine with its connectors pointing downward.
4. Insert and hand-tighten stainless steel fasteners in each of the four mounting
holes in the motor faceplate.
The mounting hole diameter is specified in the Mounting Dimensions table.
5. Align the motor on the machine using the mounting pilot hole to verify the
correct alignment.
6. Tighten the stainless steel fasteners within the recommended torque range.
7. Rotate the shaft for electrical phasing and encoder alignment.
The index pulse occurs on a single-turn encoder when the shaft key is
aligned with the connectors. Refer to Mounting Dimensions for a visual
reference of this alignment.
ATTENTION
Outer surfaces of a motor can reach high temperatures, 125 °C (275 °F) during
operation.
Take precautions to prevent accidental contact with hot surfaces. Consider motor
surface temperature when selecting connections and cables to install on a
motor.
Failure to observe safety precautions could result in personal injury or damage to
equipment.
Cat. No. Torque Range
MPF-x310, MPF-x320, MPF-x330 10…13.6 N•m (90…120 lb•in)
MPF-x430, MPF-x4530, MPF-x4540 21.5…28.3 N•m (190…250 lb•in)
MPF-x540 45.2…56.5 N•m (400…500 lb•in)

MP-Series Food Grade Servo Motor Installation Instructions 13
Publication MP-IN004D-EN-P — April 2009
Attach Motor Cables
Follow these steps to attach the feedback, and power/brake cables after the motor
is mounted.
1. Form a drip loop in the cable before attaching it.
A drip loop creates a low spot in the cable. Gravity causes any liquid to flow
to the low spot and away from the connectors, thereby reducing the
potential for any liquid to enter the connector.
2. If you use a cable with a quick-lock plug, remove the O-ring on the
feedback or power/brake connector.
Only threaded cable plugs require the O-ring on the connector. The O-ring
dampens the effects of vibration at the cable-to-motor connection and
creates a more secure connection for a threaded plug. O-rings interior to the
cable plug provide complete environmental sealing for a cable with a
quick-lock plug or a cable with a threaded plug.
ATTENTION
Make sure that cables are installed and restrained to prevent uneven tension or flexing at
the motor-to-cable connections.
Excessive and uneven lateral force at the motor connectors can result in the connector’s
environmental seal opening and closing as the cable flexes.
Failure to observe safety precautions could result in damage to the motor and its
components.
IMPORTANT
Cables requiring O-rings include power cable 2090-XXNPMF-xxSxx or
2090-CPxM4DF-xxAFxx, and feedback cable 2090-XXNFMF-Sxx or
2090-CFBM4DF-CDAFxx.
O-rings
Align Flat
Surfaces
Feedback Plug
Power/Brake Plug

14 MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
3. Carefully align the flat surface on the feedback or the power/brake cable
plug (shown in the diagram) with the flat surface on the motor connector.
4. Hand tighten the collar on the plug to fully seat it on the connector.
• Threaded plug requires five to six revolutions.
• Quick-lock plug requires approximately one-quarter of a revolution.
Do not apply excessive force when mating the cable plug with the motor
connector. If the plug and connector do not go together with light hand
force, realign the flat surfaces and try again.
IMPORTANT
The motor orientation shown is used to clearly show the alignment marker on
each cable socket.
The recommended motor orientation when installed positions the connectors at
the bottom of the motor.
ATTENTION
Keyed connectors and cable plugs must properly align and be hand-tightened the
recommended number of turns.
Improper alignment is indicated by the need for excessive force, such as the use
of tools, to fully seat a plug.
Failure to observe safety precautions could result in damage to the motor and
cable, and their components.

MP-Series Food Grade Servo Motor Installation Instructions 15
Publication MP-IN004D-EN-P — April 2009
Connector Data
These tables identify pinouts for the feedback and the power with brake
connectors.
M23 Feedback Connector M23 Power with Brake Connector
Pin MPF-A3xx…MPF-A45xx Pin
MPF-A3xx…MPF-A45xx, and
MPF-B3xx…MPF-B45xxx
1 Sin+ A Phase U
(1)
(1) Power pins A, B, C, and D may be labelled U, V, W, and GND respectively. Brake pins F and G may be labelled as + and -
(positive and negative) respectively. Reserved pins E and H may be numbered 1 and 2.
2 Sin- B Phase V
(1)
3 Cos+ C Phase W
(1)
4 Cos- D Ground
(1)
5 Data+ E Reserved
(1)
6 Data- F MBRK+
(1)
7 Reserved G MBRK-
(1)
8HReserved
(1)
9+5VDC L
10 Common
11 Reserved
12
13 TS+
14 TS-
15 Reserved
16
17
M23 Feedback Connector M23 Power/Brake Connector
1
2
3
4
5
6
7
8
9
10
11
12 13
14
17
15
16
Intercontec P/N
AEDC227NN00000012000
B C
AG
L
F
E
H
D
Intercontec P/N
BEDC090NN00000017000

16 MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
M23 Feedback Connector M40 Power with Brake Connector
Pin MPF-Bxxx (460V) and MPF-A5xx Pin MPF-A5xx and MPF-B5xx
1 Sin+ U Phase U
2 Sin- V Phase V
3 Cos+ W Phase W
4 Cos- Ground
5 Data+ + BR+
6 Data- - BR-
7 Reserved 1 Reserved
82
9
10
11 +9V DC
12 Common
13 TS+
14 TS-
15 Reserved
16
17
M23 Feedback Connector M40 Power/Brake Connector
1
2
3
4
5
6
7
8
9
10
11
12 13
14
17
15
16
Intercontec P/N
AEDC227NN00000012000
V
UW
12
+
-
Intercontec P/N
CEDE271NN00000051000

MP-Series Food Grade Servo Motor Installation Instructions 17
Publication MP-IN004D-EN-P — April 2009
Mounting Dimensions
The dimensions in the table are for non-brake motors. Footnotes provide tolerances
for the common dimensions, and the additional dimensions specific to brake
motors or features on specific motors.
S
M
AD
HD
L
P
GE
LA
LB
T
L-LB
D
LE
N
LD
AD
HD
F
MPF-x3xx = 5 x 5 x 25 MPF-x4xx = 6 x 6 x 25 MPF-x45xx = 8 x 7 x 32 MPF-x540 = 8 x 7 x 40
MPF-x3xx, MPF-x4xx, and MPF-x45xx motors. MPF-x540 motors.
131.0 (5.16)
(MPF-x540) only.
AB
AB
(Pilot Diameter)
Shaft End Hole Thread and Depth
Shaft Key
MPF-x540
End Cap
M23 Power/Brake Connector is standard on the
Electronic zero (Index pulse or Stegmann ABS= 0) occurs when the shaft key or dimple (not shown) is aligned with the connectors (as shown).
M40 Power/Brake Connector Dimensions
(MPF-x540-xx7xxx motors)
(Diameter of Holes) (Diameter of Bolt Circle)
M40 Power/Brake Connector is standard only on the
Dimension is to the front of the M40 Power/Brake Connector
M23 Feedback Connector is standard on all MPF motors.

18 MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
MP-Series Food Grade motors are designed to metric dimensions. Inch dimensions are mathematical conversions.
Motor
Series
MPF-A
or
MPF-B
AB
mm
(in.)
AD
mm
(in.)
D (2)
mm
(in.)
(2) Tolerance for this dimension is: MPF-x3xx +0.008, -0.003 mm (+0.0011, -0.0008 in.); MPF-x4xx and MPF-x45xx +0.009,
-0.004 mm (+0.0003, -0.0002 in.); MPF-x540 +0.009, -0.004 mm (+0.0003, -0.0002 in.).
F(3)
mm
(in.)
(3) Tolerance for this dimension is MPF-x3xx and -x4xx -0.03 mm (-0.001 in.); MPF-x45xx -0.04 mm (-0.001 in.); MPF-x540
-0.036 mm (-0.0015 in.).
GE (4)
mm
(in.)
(4) Tolerance for this dimension is: MPF-x3xx and MPF-x4xx +0.1 mm (+0.004 in.) MPF-x45xx and MPF-x540 +0.2 mm
(+0.007 in.).
HD
mm
(in.)
L (5)
, (6)
mm
(in.)
(5) If ordering an MPF-xxxx motor with a brake add: 34.5 mm (1.36 in.) to MPF-x310, MPF-x320, or MPF-x330 dimensions L, LB,
LD. and LE;
48.5 mm (1.91 in.) to MPF-x430 dimensions L, LB, LD. and LE; 48.5 mm (1.91 in.) to MPF-x4530 or MPF-x4540 dimensions L,
LB, LD, and 48.6 mm (1.91 in.) to LE; and 51.6 mm (2.03 in.) to MPF-x540 dimensions L, LB, LD, and LE.
(6) Tolerance for this dimension is ±0.7 mm (±.028 in.).
L-LB (6)
mm
(in.)
LA
mm
(in.)
310 67.5
(2.66)
87.25
(3.43)
16.0
(0.629)
5.0
(0.197)
3.0
(0.118)
133.4
(5.25)
168.0
(6.62)
40.0
(1.57)
9.91
(0.39)
320 193.0
(7.62)
330 219.0
(8.62)
430 69.1
(2.72)
90.9
(3.58)
19.0
(0.748)
6.0
(0.236)
3.5
(0.138)
142.8
(5.59)
215.0
(8.48)
40.0
(1.57)
10.16
(0.4)
4530 69.1
(2.72)
98.6
(3.88)
24.0
(0.945)
8.0
(0.315)
4.0
(0.158)
157.6
(6.20)
229.0
(9.0)
50.0
(1.97)
12.19
(0.48)
4540 254.0
(10.0)
540 72.6
(2.86)
136.4 (1)
(5.37)
(1) This measurement is to the top of the M40 power connector. The measurement to the top of the M23 feedback connector is
83.6 mm (4.47 in.).
28.0
(1.102)
8.0
(0.315)
4.0
(0.158)
209.0
(8.23)
226.0
(9.28)
60.0
(2.36)
13.97
(0.55)

MP-Series Food Grade Servo Motor Installation Instructions 19
Publication MP-IN004D-EN-P — April 2009
LB (1)
mm
(in.)
(1) Tolerance for this dimension is: MPF-x3xx and MPF-x4xx +0.1 mm (+0.004 in.) MPF-x45xx and MPF-x540 +0.2 mm
(+0.007 in.).
LD (1)
mm
(in.)
LE (1)
mm
(in.)
M(2)
mm
(in.)
(2) Tolerance for this dimension is: MPF-x3xx +0.012, -0.007 mm (+0.0001, -0.0007 in.); MPF-x4xx +0.013, -0.009 mm (+0.0007,
-0.0002 in.); MPF-x45xx +0.013, -0.009 mm (+0.0002, -0.0007 in.); and, MPF-x540 +0.014, -0.009 mm (+0.0007, -0.0002 in.)
N (3)
mm
(in.)
(3) Tolerance for this dimension is: MPF-x3xx +0.012, -0.007 mm (+0.0001, -0.0007 in.); MPF-x4xx +0.013, -0.009 mm (+0.0007,
-0.0002 in.); MPF-x45xx +0.013, -0.009 mm (+0.0002, -0.0007 in.); and, MPF-x540 +0.014, -0.009 mm (+0.0007, -0.0002 in.)
P
mm
(in.)
S (4)
mm
(in.)
(4) Tolerance for this dimension is: MPF-x3xx, MPF-x4xx, or MPF-x45xx +0.36 mm (±0.007 in.), and MPF-x540 +0.43 mm
(±0.008 in.)
T
mm
(in.)
Shaft End
Threaded Hole
mm (in.)
128.0
(5.04)
102.0
(4.03)
62.0
(2.45)
100.0
(3.94)
80.0
(3.15)
92.39
(3.64)
7.0
(0.283)
2.74
(0.11)
M5 x 0.8 - 6H
Thread depth
12.5 (0.49)
153.0
(6.04)
128.0
(5.03)
88.0
(3.45)
179.0
(7.04)
153.0
(6.03)
113.0
(4.45)
175.0
(6.90)
149.0
(5.89)
110.0
(4.31)
115.0
(4.53)
95.0
(3.74)
102.1
(4.02)
10.0
(0.401)
2.74
(0.11)
M6 x 1.0 - 6H
Thread depth
16 (0.63)
179.0
(7.03)
153.0
(6.02)
113.0
(4.44)
130.0
(5.12)
110.0
(4.331)
118.1
(4.65)
10.0
(0.401)
2.74
(0.11)
M8 x 1.25 - 6H
Thread depth
19 (0.75)
204.0
(8.03)
178.3
(7.02)
138.0
(5.44)
176.0
(6.92)
151.0
(5.95)
161.8
(6.37)
165.0
(6.50)
130.0
(5.118)
145.3
(5.72)
12.0
(0.481)
3.12
(0.12)
M10 x 1.5 - 6H
Thread depth
22 (0.87)

20 MP-Series Food Grade Servo Motor Installation Instructions
Publication MP-IN004D-EN-P — April 2009
Motor Load Force Ratings
Motors are capable of operating with a sustained shaft load. The load force
locations are shown in the figure and maximum values are in the tables.
Loads are measured in kilograms, pounds are mathematical conversions.
Load Forces on Shaft
The following tables represent 20,000 hour L10 bearing fatigue life at various loads
and speeds. This 20,000 hour life does not account for possible application-specific
life reduction that can occur due to bearing grease contamination from external
sources.
Radial Load Force Ratings
Motor 500 rpm
kg (lb)
1000 rpm
kg (lb)
2000 rpm
kg (lb)
3000 rpm
kg (lb)
3500 rpm
kg (lb)
4000 rpm
kg (lb)
5000 rpm
kg (lb)
MPF-A/B310 — 62 (137) 49(108) — 40 (88) — 36 (79)
MPF-A/B320 87 (192) 69 (152) 55 (121) — 45 (99) — 40 (88)
MPF-A/B330 — 74 (163) 59 (130) — 49 (108) — 43 (95)
MPF-A/B430 106 (234) 84 (185) 67 (148) — 55 (121) — 49 (108)
MPF-A/B4530 — 105 (231) 84 (185) 73 (161) — 66 (146) —
MPF-A/B4540 140 (309) 111 (245) 89 (196) 77 (170) — — —
MPF-A/B540 — 143 (315) 114 (251) 99 (218) — 90 (198) —
Axial Load Force
Radial load force applied at center of shaft extension.
