Roger Technology B70/2ML User manual

3
A
3
3
5
2
2
4
3
Quick Start B70/2ML
Rev00 11/11/2020
ROGER TECHNOLOGY
Via S. Botticelli 8 • 31021 Bonisiolo di Mogliano Veneto (TV) • ITALIA
P.IVA 01612340263 • Tel. [phone] • Fax. [phone]
[e-mail] • www.rogertechnology.com
APower supply B70/2ML - Motors 3x2,5 mm2double insulated cable (max.10 m) - 3x4 mm2 (max. 30 m)
1Photocell - Receiver 5x0,5 mm2double insulated cable (max.20 m)
2Photocell - Transmitter 3x0,5 mm2double insulated cable (max.20 m)
3Flashing lamp unit 2x1 mm2double insulated cable (max.10 m)
4Antenna RG58 50 Ohm cable for external use (max.10 m)
5Selector / Keypad 3x0,5 mm2cable (max.20 m)
1. Typical installation
B70/2ML is the range of 24V DC digital controllers installed in the swing gates product.
EN
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

2. Electrical connections
3. Display: functions and settings
F3.15mA
PROG
WIFI
TEST
+
-
M2
Z Y X
F2
M1
X Y Z
MOTORE 2
MOTOR 2
MOTORE 1
MOTOR 1
COR
9 10
+ -
ANT
35
36
23 24 25 26 27
COM
COM COM STFT2 FT1
FT2
FT1
COM
ST
ISEL
ISEL
28
TRANSFORMER
11 12 13 14 15
SC
SC COM PED PP CH AP COM
COMCOMES LAM 24V
COM
PED
PP
CH
17
COM
AP
18
+24V
19
COM
20
LA M
21
COM
22
+ES
16
1
2
F1
RXTX
12 3 12 3 4 5
-COM
+24
-COM
+24
FT1(N.C)
SYNC SYNC
FIFTHY/24
+ -
Accessories illustrated are indicative only
PROG TEST
+
-
Back
Programming Check error alarms
PARAMETER PARAMETER
VALUE
Increase value
Decrease value
Next
PROG TEST
+
-
All manuals and user guides at all-guidesbox.com

4. Before starting ...
d) Move the gate into the completely CLOSE position.
e) Press the TEST button.
Possible alarms and safety device messages:
SEE ACQUISITION PROCEDURE
00 No safety device in alarm state and no limit switch activated.
27 STOP contact (N.C.) open.
Jumper the STOP contact.
28 Sensing edge contact COS
25 Photocell contact FT1 (N.C.) is open. Check connection. If photocell is not
installed, disable with 50 00.
24 Photocell contact FT2 (N.C.) is open. Check connection. If photocell is not
installed, disable with 53 00.
PROG TEST
+
-
PROG
TEST
+
-
PROG TEST
+
-
a) Select the automation system model installed with the parameter A1.
b) Select the position of the motor relative to the gate with the
parameter 70. This parameter is set for two motors by default.
c) Position the mechanical stops in both the open and closed positions by tightening them very tightly.
1 MOTOR 2 MOTORS
AYRON Series
BE20 Series
MONOS4
All manuals and user guides at all-guidesbox.com

6. Setting basic parameters
30 Motor torque
43 Opening and closing approach
distance setting MOTOR1 44 Opening and closing approach
distance setting MOTOR2
31 Obstacle impact force
sensitivity MOTOR1
33 Motor torque MOTOR2
32 Obstacle impact force
sensitivity MOTOR2
34 Start acceleration MOTOR1
during closing
34 Start acceleration MOTOR1
during closing
35 Start acceleration MOTOR2 during closing
11 Deceleration
MOTOR 1 during closing
12 Deceleration MOTOR2 during closing
26 Closing delay of MOTOR1
19 Stop advance of LEAF1
when opening
20 Stop advance of LEAF2
when opening
14 Position control
13 Position control
13 Position control
14 Position control
25 Opening delay of MOTOR2
11 Deceleration MOTOR 1
during opening
12 Deceleration MOTOR 2
during opening
40 Opening speed
41 Closing speed
35 Start acceleration MOTOR2
during closing
MOTOR 1
MOTOR 2
5. Acquisition procedure
1. Press and hold PROG for 4 seconds.
2. APP- appears on the display.
3. Press PROG.
4. AUTO appears on the display.
5. MOTOR 1 starts opening at low speed.
6. After the delay time set with parameter 25, MOTOR 2 starts an opening manoeuvre.
7. Once the gate is open, the message AUTO flashes on the display.
8. The message AUTO stops flashing.
9. MOTOR 2 starts closing.
10. After a delay set with parameter 26, MOTOR 1 closes.
11. When the gate is closed, the safety device symbols are displayed.
Press
PROG
AP P- AU to
x4 s
Press
PROG
1 click OPEN
MOTOR 1
OPENING
MOTOR 2
OPENING
PARAM. 25
ùDELAY
TIME
AU to
x2 s CLOSED
AU
AU
to
to
Yes
MOTOR 1
CLOSING
MOTOR 2
CLOSING
PARAM. 26
DELAY
TIME
CLOSED
All manuals and user guides at all-guidesbox.com

7. Programming a NEW transmitter
8. Copying a transmitter
P1
L1 L2
P2 P1
L1 L2
P2
ON
P1
L1 L2
P2
1 click
This document is a basic quick guide for the initial installation of a BRUSHLESS swing gate motor.
