Roger Technology CTRL User manual

Quick Start CTRL
Rev01 03/04/2020
ROGER TECHNOLOGY
Via S. Botticelli 8 • 31021 Bonisiolo di Mogliano Veneto (TV) • ITALIA
P.IVA 01612340263 • Tel. [phone] • Fax. [phone]
[e-mail] • www.rogertechnology.com
APower supply
H07RN-F 3x1,5 mm2 double insulated cable
1Photocell - Receiver 5 x 0.5 mm2double insulated cable (max. 20 m)
2Photocell - Transmitter 3 x 0.5 mm2double insulated cable (max. 20 m)
3Selector / Keypad 3 x 0.5 mm2cable
1. Typical installation (purely for information)
CTRL is the range of 36V DC digital controllers installed with the barrier applications.
EN
A
3
2
2
1
1

F4ES-F4S
Series
R85/60
1 2 3 2345
+- +-
TX RX
1
COM
NO
CS/STD
TRASFORMATORE
PRIMARIO
MONOFASE
SECONDARIO
CEI 61558-2-6
0 19 0 26
F1
F2
F3
PROG TEST
+
-
BATTERY (+)
RECEIVER CARD
BATTERY CHARGER
SEC2
ENC2
ENC1
LOCKS
LED LIGHT
SEC1
BATTERY (-)
123456
Y
X
M
Z
78
COM COM +24V +ES +LAM COM COM LNA LNB +SC
10 11 12 13 14 15 16 17 18 19 20
+LUCI
ST
COM
COS
FT
COM
ANT
21 22 23 24 25
COM
PED
PP
CH
AP
28 29 30 31 32
ORO
33
COM
3426 27
9
F4
N
L
POWER SUPPLY
230Vac / 115Vac
BATTERIES
2 x 12V 4,5Ah
AGILIK BIONIK BIONIK 4HP/6KB BIONIK 8
3. Display: functions and settings
Accessories illustrated are indicative only
PROG TEST
+
-
Back
Programming Check error alarms
PARAMETER PARAMETER
VALUE
Increase value
Decrease value
Next
PROG TEST
+
-
2. Electrical connections

00 No safety device in alarm state and no limit switch activated.
21
STOP contact (N.C.) open.
Jumper the STOP contact.
Release handle or lock open.
Barrier inspection hatch open.
23 Sensing edge contact COS (N.C.) is open. Check connection. If sensing edge is
not installed, disable with 73 00.
24 Photocell contact FT (N.C.) is open. Check connection. If photocell is not installed,
disable with 50 00.
rs (rS) STOP contact active for MASTER barrier (message shown on SLAVE controller
displayed).
dATA
Modify automation position selection with parameter 71
• Press and hold PROG until the message ATA disappear and A appear on
the display.
Repeat acquisition procedure.
4. Before starting ...
d) Move the barrier boom into the completely CLOSED position.
c) Check the spring balance setting and the mechanical stop setting.
See the installation manual for the barrier.
e) Press TEST Possible alarms and safety device messages:
PROG TEST
+
-
PROG
TEST
+
-
PROG TEST
+
-
SEE ACQUISITION PROCEDURE
a) IMPORTANT: Select the length of the boom with the parameter A1.
It is very important that this parameter is selected correctly. An incorrect setting may cause severe damage or injury.
b) Select the position of the barrier in relation to the gate, using parameter 71.
The factory setting of the parameter is with the barrier installed on the right
(7101) and the boom opening/closure gate on the left (seen from the inspection
hatch side).
If the installation position is changed from the right to the left, the position of the spring(s)
must also be changed.
IMPORTANT! Lubricate the pivot points with lithium
based grease
AG/004
KB/004
BI/004HP up to 3 m
BI up to 3 m
AG/004
KB/004
BI/004HP from 3 m to 4,5 m BI/004 from 3 m to 4 m
AG/006
KB/006
BI/006 from 4,5 m to 6 m BI/008 up to 8 m
45° >45°
<45°
BARRIER OPENS TO
THE LEFT
BARRIER OPENS TO
THE RIGHT


IMPOSTAZIONE DI FABBRICA
FACTORY SETTING
inspection
hatch side

5. Acquisition procedure
1. Press and hold PROG for 4 s.
2. APP- appears on the display.
3. Open the release cover.
4. The barrier opens 45° degree (when properly balanced).
5. PHAS appears.
6. Wait until the message PHAS flashes.
7. Close the release cover.
8. AUTO appears.
9. The barrier starts to open.
10. Once the barrier is open, the message AUTO flashes on the display after a few seconds and the barrier starts to close.
11. When the barrier is closed, the safety device symbols are displayed.
6. Setting basic parameters
 Obstacle detection time setting
 Acceleration
during opening
 Opening speed
 Closing speed
 Acceleration
during closing
 Deceleration
during opening
 Deceleration
during closing
 Opening approach
distance
 Closing approach
distance
AP P- PH A5
AU to
PROG
x4 s
OPENING OPEN CLOSING CLOSED
Yes
UNLOCK
BIONIK
BIONIK
LOCK
2x360° 2x360°
45°
PH
PH
A5
A5
AU
AU
to
to
CLOSED

7. Programming a NEW transmitter
8. Copying a transmitter
x5 s x3 s x1 s
AAA
A
B
OLD
P1
L1 L2
P2 P1
L1 L2
P2
ON
P1
L1 L2
P2
1 click
1. Press channel P1 (P2) of the receiver.
2. When LED L1 (L2) ashes 3 times (or 4 times
with rolling code function), press any button
on the transmitter.
3. If LED L1 (L2) remains steadily lit the
transmitter has been stored correctly.
1. Press buttons A and B on the NEW
transmitter simultaneously.
2. The LED ashes for 5 s.
3. Hold button (A) only on the NEW transmitter
you want to store.
4. The LED ashes 3 s.
5. Hold the previously stored transmitter as
close as possible to the NEW transmitter.
6. Press button (A) on the OLD transmitter.
7. The LED lights for 1 s to conrm that the copy
procedure was successful.
8.
This document is a basic quick guide for the initial installation of a BRUSHLESS barrier.
For complete information concerning the control unit, the motor and the accessories mentioned in this quick guide, see the technical manuals available in the B2B area of the website
www.rogertechnology.it
9. Photocells grounding connection
Grounding connection negative terminal (COM) photocells series F4ES/F4S or other than Roger Technology
In case of malfunction, or failure to intervene in case of dimming, or continuous detection, or abnormal behaviour of the automation (gate, overhead door,
barrier, etc.), it is advisable to connect the negative terminal (COM) of the photocells to the grounding of the system.
PROG TEST
+
-
RECEIVER CARD
ENC2
ENC1
LOCKS
LED LIGHT
COM +24V +ES +LAM COM COM LNA LNB +SC
10 11 12 13 14 15 16 17 18 19 20
+LUCI
ST
COM
COS
FT
COM
ANT
21 22 23 24 25
COM
PED
PP
CH
AP
28 29 30 31 32
ORO
33
COM
3426 27
RX
TX
12 3 12345
MASTER
F4
COM(-)
COM(-)
COM(-)
COM(-)
