Rohde & Schwarz RTP Series User manual

R&S®RTP
High-Performance
Oscilloscope
Getting Started
Getting Started
Version 05
1337994602
(=Uñ^2)

This manual describes the following R&S®RTP models with firmware version 4.60
and higher:
●R&S®RTP044 (1320.5007K04)
●R&S®RTP064 (1320.5007K06)
●R&S®RTP084 (1320.5007K08)
●R&S®RTP134 (1320.5007K13)
●R&S®RTP164 (1320.5007K16)
© 2019 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Fax: [phone]
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1337.9946.02 | Version 05 | R&S®RTP
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol , e.g.
R&S®RTP is indicated as R&S RTP.

Contents
R&S®RTP
3Getting Started 1337.9946.02 ─ 05
Contents
1 Safety Information................................................................. 5
2 Preface....................................................................................7
2.1 Key Features......................................................................................... 7
2.2 Documentation Overview.....................................................................7
3 Preparing for Use.................................................................11
3.1 Unpacking and Checking the Instrument......................................... 11
3.2 Positioning the Instrument................................................................ 12
3.3 Starting the Instrument...................................................................... 14
3.4 Connecting External Devices............................................................ 16
4 Instrument Tour................................................................... 20
4.1 Front Panel.......................................................................................... 20
4.2 Rear Panel........................................................................................... 23
4.3 Keys and Controls.............................................................................. 26
5 Operating the Instrument....................................................38
5.1 Means of Manual Interaction..............................................................38
5.2 Touchscreen Display.......................................................................... 39
5.3 App Cockpit.........................................................................................45
5.4 Working with Waveforms................................................................... 46
5.5 Rohde & Schwarz SmartGrid............................................................. 49
5.6 Toolbar................................................................................................. 50
5.7 Displaying Results..............................................................................59
5.8 Using Dialog Boxes............................................................................ 61
5.9 Entering Data.......................................................................................63
5.10 Messages.............................................................................................65

Contents
R&S®RTP
4Getting Started 1337.9946.02 ─ 05
5.11 Getting Information and Help............................................................ 66
6 Setting Up the Instrument...................................................69
6.1 Performing a Self-alignment.............................................................. 69
6.2 Setting the Display Language............................................................70
7 Contacting Customer Support........................................... 71
Index..................................................................................... 72

Safety Information
R&S®RTP
5Getting Started 1337.9946.02 ─ 05
1 Safety Information
The R&S RTP oscilloscope is designed for measurements on circuits that are
only indirectly connected to the mains or not connected at all. It is not rated for
any measurement category.
The instrument is rated for pollution degree 2 - for indoor, dry location use where
only non-conductive pollution occurs. Temporary conductivity caused by conden-
sation is possible.
The instrument must be controlled by personnel familiar with the potential risks of
measuring electrical quantities. Observe applicable local or national safety regula-
tions and rules for the prevention of accidents.
Safety information is part of the product documentation. It warns you about the
potential dangers and gives instructions how to prevent personal injury or dam-
age caused by dangerous situations. Safety information is provided as follows:
●The "Basic Safety Instructions" in different languages are delivered as a prin-
ted brochure with the instrument.
●Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.
Risk of injury
Use the instrument in an appropriate manner to prevent electric shock, per-
sonal injury, or fire:
●Do not open the instrument casing.
●Do not use the instrument if you detect or suspect any damage of the
instrument or accessories.
●Do not operate the instrument in wet, damp or explosive atmospheres.
●Make sure that the instrument is properly grounded.
●Do not use the instrument to ascertain volt-free state.
●Do not exceed the voltage limits given in Chapter 4.1, "Front Panel",
on page 20.
The instrument is heavy. Be careful when you lift or carry the instrument.

Safety Information
R&S®RTP
6Getting Started 1337.9946.02 ─ 05
Risk of instrument damage due to inappropriate operating conditions
An unsuitable operating site or test setup can damage the instrument and
connected devices. Before switching on the instrument, observe the infor-
mation on appropriate operating conditions provided in the data sheet. In
particular, ensure the following:
●All fan openings are unobstructed and the airflow perforations are unim-
peded. A minimum distance of 10 cm to other objects is recommended.
●The instrument is dry and shows no sign of condensation.
●The instrument is positioned as described in the following sections.
●The ambient temperature does not exceed the range specified in the
data sheet.
●Signal levels at the input connectors are all within the specified ranges.
●Signal outputs are connected correctly and are not overloaded.

Preface
R&S®RTP
7Getting Started 1337.9946.02 ─ 05
2 Preface
2.1 Key Features
The R&S RTP high-performance oscilloscopes combine superior signal integrity
with fastest acquisition rate. It combines multiple instrument capabilities for time-
correlated debugging in one box. Outstanding key features are:
Real-time signal integrity
●Superior frontend performance
●Real-time de-embedding and advanced triggering
●Hardware accelerated processing for faster results
●Comprehensive analysis tools, for example, powerful protocol analysis, jitter
analysis functions, automatic compliance tests, spectrograms, and precise
and wideband RF analysis
Multiple instrument capability
●Time-correlated analysis of different signal types
●Easy-to-use serial protocol analysis for various protocols used in embedded
design, mobile communications and more
●General purpose mixed signal option
●Multi-channel power consumption analysis with up to 8 additional voltage and
8 additional current measurement channels and very high dynamic range
Compact and configurable
●Most compact high-end instrument platform
●Highest configuration flexibility
●Advanced user interface
For a detailed specification, refer to the data sheet.
2.2 Documentation Overview
This section provides an overview of the R&S RTP user documentation.
Documentation Overview

Preface
R&S®RTP
8Getting Started 1337.9946.02 ─ 05
2.2.1 Manuals and Instrument Help
You find the manuals on the product page at:
www.rohde-schwarz.com/manual/rtp
Getting started manual
Introduces the R&S RTP and describes how to set up and start working with the
instrument, and describes basic operations. A printed English version is included
in the delivery. Editions in other languages are available on the product website.
Instrument help
The help offers quick, context-sensitive access to the complete information for the
firmware basic functionality and applications.
User manual (Instrument)
Describes all instrument functions in detail. It also provides an introduction to
remote control, a complete description of the remote control commands with pro-
gramming examples, and information on maintenance and instrument interfaces.
Includes the contents of the getting started manual.
The online version of the user manual provides the complete contents for immedi-
ate display on the internet.
Manuals for compliance test options
For compliance test options, extra test procedure manual are available. Test fix-
tures are described in printed manuals, which are delivered with the fixture.
●The following test procedure manuals are available:
– USB 2.0 Compliance Test Procedures
– Ethernet Compliance Tests Procedures
– MIPI D-PHY Compliance Tests Procedures
– PCIe Compliance Tests Procedures
– DDR3 Compliance Tests Procedures
– DDR4 Compliance Tests Procedures
– ScopeSuite Automation
●The following test fixture manuals are available:
– R&S RT-ZF1 USB 2.0 Compliance Test Fixture Set
Documentation Overview

Preface
R&S®RTP
9Getting Started 1337.9946.02 ─ 05
– R&S RT-ZF2 Ethernet Compliance Test Fixture Set
– R&S RT-ZF3 Frequency Converter Board (100BASE-T1)
– R&S RT-ZF4 10BASE-Te Test Fixture
– R&S RT-ZF5 Ethernet Probing Fixture
– R&S RT-ZF6 Frequency Converter Board (1000BASE-T1)
– R&S RT-ZF7 Automotive Ethernet T&D Fixture
– R&S RT-ZF7A SMA Adaptor
– R&S RT-ZF8 Automotive Ethernet Compliance Test Fixture
Basic safety instructions
Contains safety instructions, operating conditions and further important informa-
tion. The printed document is delivered with the instrument.
Instrument security procedures manual
Deals with security issues when working with the R&S RTP in secure areas.
Service Manual
Describes the performance test for checking the rated specifications, module
replacement, firmware update, troubleshooting and fault elimination, and contains
mechanical drawings and spare part lists. The service manual is available for reg-
istered users on the global Rohde & Schwarz information system (GLORIS,
https://gloris.rohde-schwarz.com).
2.2.2 Data Sheet and Brochure
The data sheet contains the technical specifications of the R&S RTP. It also lists
the options with their order numbers and optional accessories. The brochure pro-
vides an overview of the instrument and deals with the specific characteristics.
See www.rohde-schwarz.com/brochure-datasheet/rtp
2.2.3 Release Notes, Open Source Acknowledgment
The release notes list new features, improvements and known issues of the cur-
rent firmware version, and describe the firmware installation. The open source
acknowledgment document provides verbatim license texts of the used open
source software. It can also be read directly on the instrument.
Documentation Overview

Preface
R&S®RTP
10Getting Started 1337.9946.02 ─ 05
See www.rohde-schwarz.com/firmware/rtp.
2.2.4 Application notes, Application cards, Videos
These documents deal with special applications or background information on
particular topics.
See www.rohde-schwarz.com/application/rtp and Oscilloscopes Application Vid-
eos - Media Center
Documentation Overview

Preparing for Use
R&S®RTP
11Getting Started 1337.9946.02 ─ 05
3 Preparing for Use
This section describes the basic steps to be taken when setting up the R&S RTP
for the first time.
Observe the information on appropriate operating conditions provided in the data
sheet and the general information given in "Risk of instrument damage due to
inappropriate operating conditions" on page 6.
3.1 Unpacking and Checking the Instrument
To remove the instrument from its packaging and check the equipment for com-
pleteness, proceed as follows:
1. Pull off the polyethylene protection pads from the instrument's rear feet.
2. Carefully remove the pads from the instrument handles at the front.
3. Pull off the corrugated cardboard cover that protects the rear of the instru-
ment.
4. Carefully unthread the corrugated cardboard cover at the front that protects
the instrument handles and remove it.
5. Check the equipment for completeness using the delivery note and the acces-
sory lists for the various items.
6. Check the instrument for any damage. If there is damage, immediately contact
the carrier who delivered the instrument. Make sure not to discard the box and
packing material.
Packing material
Retain the original packing material. If the instrument needs to be transpor-
ted or shipped later, you can use the material to protect the control ele-
ments and connectors.
Unpacking and Checking the Instrument

Preparing for Use
R&S®RTP
12Getting Started 1337.9946.02 ─ 05
3.2 Positioning the Instrument
The instrument is designed for use under laboratory conditions. It can be used in
standalone operation on a bench top or can be installed in a rack.
3.2.1 Bench Top Operation
For standalone operation, place the instrument on a horizontal bench with even,
flat surface. The instrument can be used in horizontal position, standing on its
feet, or with the support feet on the bottom extended.
Risk of injury if feet are folded out
The feet can fold in if they are not folded out completely or if the instrument
is shifted. Collapsing feet can cause injury or damage the instrument.
●Fold the feet completely in or out to ensure stability of the instrument.
Never shift the instrument when the feet are folded out.
●When the feet are folded out, do not work under the instrument or place
anything underneath.
●The feet can break if they are overloaded. The overall load on the fol-
ded-out feet must not exceed 500 N.
Positioning the Instrument

Preparing for Use
R&S®RTP
13Getting Started 1337.9946.02 ─ 05
Risk of injury when stacking instruments
A stack of instruments can tilt over and cause injury if not stacked correctly.
Furthermore, the instruments at the bottom of the stack can be damaged
due to the load imposed by the instruments on top.
Observe the following instructions when stacking instruments:
●Never stack more than three instruments. If you need to stack more
than three instruments, install them in a rack.
●The overall load imposed on the lowest instrument must not exceed
500 N.
●It is best if all instruments have the same dimensions (width and length).
If you need to stack smaller instruments on the top, the overall load
imposed on the lowest instrument must not exceed 250 N.
●If the instruments have foldable feet, fold them in completely.
3.2.2 Rackmounting
The instrument can be installed in a rack using a rack adapter kit. The order num-
ber is given in the data sheet. The installation instructions are part of the adapter
kit.
Positioning the Instrument

Preparing for Use
R&S®RTP
14Getting Started 1337.9946.02 ─ 05
Risk of instrument damage due to insufficient airflow in a rack
If you mount several instruments in a rack, you need an efficient ventilation
concept to ensure that the instruments do not overheat. Insufficient airflow
for a longer period can disturb the operation and even cause damage.
3.3 Starting the Instrument
Risk of injury
Connect the oscilloscope to an outlet that has a ground contact.
If grounding is not ensured by the mains system, ground the oscilloscope
using the protective earth conductor on the front panel and an appropriate
cable.
Do not use an isolating transformer to connect the oscilloscope to the AC
power supply.
3.3.1 Powering On and Off
The R&S RTP can be used with different AC power voltages and adapts itself
automatically to it.
The instrument has a C20 connector. A list of appropriate power cables is given in
the user manual. Refer to the data sheet for the requirements of voltage and fre-
quency.
To power on
1. Connect the power cable to the AC power connector on the rear panel of the
R&S RTP.
2. Connect the power cable to the socket outlet.
3. Switch the main power switch at the rear of the instrument to position I.
The power key on the front panel lights up.
Starting the Instrument

Preparing for Use
R&S®RTP
15Getting Started 1337.9946.02 ─ 05
Before you start measurements, be sure to comply with the warm-up phase
specified in the data sheet.
If you leave the main power switch on, the instrument is in standby mode. To dis-
connect from power supply, power off the instrument. Powering off is only
required if the instrument must be disconnected from all power supplies.
To power off
1. If the instrument is running and the [Power] key is green, press the [Power]
key on the front panel to shut down the instrument.
2. Switch the main power switch at the rear of the instrument to position 0.
3. Disconnect the AC power cable from the AC power supply.
Risk of losing data
If you switch off the running instrument using the rear panel switch or by
disconnecting the power cord, the instrument loses its current settings. Fur-
thermore, program data can be lost.
Press the Power key first to shut down the application properly.
3.3.2 Starting Up and Shutting Down
The [Power] key is located in the bottom left corner of the front panel.
To start up the instrument
1. Make sure that the R&S RTP is connected to the AC power supply and the
main power switch on the rear panel is in position I.
2. Press the [Power] key on the front panel.
The instrument performs a system check, boots the Windows operating sys-
tem, and then starts the R&S RTP firmware.
The [Power] key turns green and the illuminated keys on the front panel light
up. If the previous session was terminated regularly, the oscilloscope uses the
last settings.
Starting the Instrument

Preparing for Use
R&S®RTP
16Getting Started 1337.9946.02 ─ 05
To shut down the instrument
► Press the [Power] key on the front panel.
All current settings are saved, and the software shuts down. The [Power] key
turns orange. The standby power supplies only the power switch circuits.
Now it is safe to power off the instrument.
The "Exit" function in the "File" menu shuts down only the firmware application. To
shut down the instrument completely, also shut down the operating system in the
"Start" menu, or use the [Power] key.
3.3.3 EMI Suppression
Electromagnetic Interference (EMI) may affect the measurement results.
To suppress generated Electromagnetic Interference:
●Use suitable shielded cables of high quality. For example use double-shielded
RF and LAN cables.
●Always terminate open cable ends.
●Note the EMC classification in the data sheet.
3.4 Connecting External Devices
The following interfaces for external devices are provided:
●USB connectors at the front and rear panel of the instrument
●Monitor connectors DVI-D and DisplayPort at the rear panel of the instrument
●Connecting USB Devices................................................................................16
●Connecting an External Monitor......................................................................18
3.4.1 Connecting USB Devices
The USB interfaces on the front and rear panels allow you to connect USB devi-
ces directly to the instrument. The number of USB connectors can be increased
by using USB hubs. Due to the large number of available USB devices, there is
almost no limit to the expansions that are possible with the R&S RTP.
Connecting External Devices

Preparing for Use
R&S®RTP
17Getting Started 1337.9946.02 ─ 05
The following USB devices can be useful, for example:
●USB flash drives to save screenshots and measurement results, and for easy
installation of firmware applications
●Keyboard and/or mouse to simplify the operation and the entry of data, com-
ments, filenames, etc.
●Printer to print measurement results and screenshots
You can connect or disconnect all USB devices during operation of the instru-
ment.
Installing USB devices on R&S RTP is easy under the Windows operating sys-
tem, because all USB devices are plug&play. After a device is connected to the
USB interface, Windows automatically searches for a suitable device driver.
If the operating system does not find a suitable driver, it prompts you to specify a
directory that contains the driver software. If the driver software is on a storage
media, connect the appropriate drive to the instrument before proceeding. If the
instrument is integrated in a network, you can also install driver data stored in a
network directory.
When a USB device is disconnected from the R&S RTP, Windows immediately
detects the change in hardware configuration and deactivates the corresponding
driver.
The properties of external USB devices are configured in the operating system,
not in the R&S RTP software. It is recommended that you use mouse and key-
board to access and modify the settings of the Windows operating system. To
access Windows, press the Windows key on the external keyboard, or select
"File" > "Minimize Application" on the R&S RTP menu.
Connecting a USB flash drive
If the installation of a USB flash drive is successful, Windows informs you that the
device is ready to use. The device is made available as a new drive ("D:") and is
displayed in Windows Explorer. The name of the drive depends on the manufac-
turer.
Connecting a keyboard
The keyboard is detected automatically when it is connected. The default input
language is English – US.
Connecting External Devices

Preparing for Use
R&S®RTP
18Getting Started 1337.9946.02 ─ 05
To configure the keyboard properties:
1. Tap the "Find" icon (magnifier) on the Windows taskbar.
2. Type keybord.
3. Select "Edit language and keyboard options".
Connecting a mouse
The mouse is detected automatically when it is connected. To configure the
mouse properties:
1. Tap the "Find" icon (magnifier) on the Windows taskbar.
2. Type mouse.
3. Select "Mouse settings".
Connecting a printer
When printing a file, the instrument checks whether a printer is connected and
turned on, and whether the appropriate printer driver is installed. If necessary,
printer driver installation is initiated by the Windows system. To install a printer
driver:
1. Tap the "Find" icon (magnifier) on the Windows taskbar.
2. Type printer.
3. Select "Printers & scanners".
4. Select "Add a printer or scanner".
3.4.2 Connecting an External Monitor
You can connect an external monitor or projector to the R&S RTP. The following
connectors are available:
●"DVI-D" on page 25
●"DisplayPort" on page 25
Before connecting an external monitor, ensure that the monitor and the R&S RTP
are connected to a ground contact. Otherwise the instrument can be damaged.
Connecting External Devices

Preparing for Use
R&S®RTP
19Getting Started 1337.9946.02 ─ 05
After connecting an additional monitor or projector to the instrument, configure it
for usage. The relevant settings are Windows settings but you can configure the
displays directly in the instrument setup.
1. Check the input type of the monitor or projector. Make sure to select the cor-
rect cable. To use a VGA monitor, you need an active DVI-D to VGA adapter.
2. Press the [Setup] key.
3. Select the "System" tab.
4. Tap "Display / Monitors".
5. To show the instrument's display content only on the external monitor, select
"Projector only".
To show the instrument's display content on both the oscilloscope and the
external monitor, select "Duplicate".
The touchscreen of the R&S RTP has a screen resolution of 1280 x 800 pixel.
Most external monitors have a higher screen resolution. If the screen resolution of
the monitor is set higher than the instrument's resolution, the application window
uses a 1280 x 800 area of the monitor display. For full screen display, adjust the
monitor's screen resolution using "Additional display settings".
Connecting External Devices

Instrument Tour
R&S®RTP
20Getting Started 1337.9946.02 ─ 05
4 Instrument Tour
This chapter describes the front and rear panels of the instrument including all
function keys and connectors, and also the touchscreen with its control elements.
4.1 Front Panel
Figure 4-1 shows the front panel of the R&S RTP. The function keys are grouped
in functional blocks to the left and the right of the touchscreen. Below the screen,
various connectors are located.
Figure 4-1: Front panel of R&S RTP
1 = Touchscreen
2 = Setup controls
3 = Horizontal controls
4 = Trigger controls
Front Panel
