Rohde & Schwarz ESW User manual

R&S®ESW
EMI Test Receiver
User Manual
1177629802
Version 13
(;ÛÌð2)

This manual describes the following R&S®ESW models:
●R&S®ESW8 (1328.4100K08)
●R&S®ESW8 (1328.4100K09)
●R&S®ESW26 (1328.4100K26)
●R&S®ESW26 (1328.4100K27)
●R&S®ESW44 (1328.4100K44)
●R&S®ESW44 (1328.4100K45)
The contents of this manual correspond to firmware version 2.10 SP1 and higher.
© 2021 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1177.6298.02 | Version 13 | R&S®ESW
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol , e.g. R&S®ESW is indicated as
R&S ESW.

Contents
R&S®ESW
3User Manual 1177.6298.02 ─ 13
Contents
1 Preface.................................................................................................. 15
1.1 About This Manual...................................................................................................... 15
1.2 Conventions used in the documentation..................................................................16
1.2.1 Typographical conventions............................................................................................16
1.2.2 Conventions for procedure descriptions........................................................................16
1.2.3 Notes on screenshots................................................................................................... 16
2 Safety and regulatory information......................................................18
2.1 Safety Instructions......................................................................................................18
2.2 Warning messages in the documentation................................................................ 21
2.3 Korea certification class B......................................................................................... 21
3 Documentation overview.....................................................................22
3.1 Getting started manual............................................................................................... 22
3.2 User manuals and help...............................................................................................22
3.3 Service manual............................................................................................................22
3.4 Instrument security procedures................................................................................ 23
3.5 Basic safety instructions............................................................................................23
3.6 Data sheets and brochures........................................................................................ 23
3.7 Release notes and open source acknowledgment (OSA).......................................23
3.8 Application notes, application cards, white papers, etc......................................... 23
4 Preparing for use................................................................................. 24
4.1 Lifting and carrying.....................................................................................................24
4.2 Unpacking and checking............................................................................................24
4.3 Choosing the operating site.......................................................................................24
4.4 Setting up the product................................................................................................25
4.4.1 Placing the product on a bench top...............................................................................25
4.4.2 Mounting the R&S ESW in a rack................................................................................. 26
4.5 Connecting the AC power.......................................................................................... 27
4.6 Switching the instrument on and off.........................................................................27
4.7 Connecting to LAN......................................................................................................28
4.8 Connecting a keyboard.............................................................................................. 29

Contents
R&S®ESW
4User Manual 1177.6298.02 ─ 13
4.9 Connecting an external monitor................................................................................ 30
4.10 Windows operating system........................................................................................31
4.11 Logging on...................................................................................................................33
4.12 Checking the supplied options..................................................................................34
4.13 Performing a self-alignment.......................................................................................35
4.14 Considerations for test setup.................................................................................... 35
4.15 Protecting data using the secure user mode........................................................... 36
5 Instrument tour.....................................................................................39
5.1 The front panel............................................................................................................ 39
5.1.1 Display (touchscreen)................................................................................................... 40
5.1.2 Power key..................................................................................................................... 41
5.1.3 System control keys...................................................................................................... 41
5.1.4 USB ports......................................................................................................................41
5.1.5 Probe power connector (3 and 5 pins).......................................................................... 42
5.1.6 Headphone jack and volume control.............................................................................42
5.1.7 Fast access knobs........................................................................................................ 42
5.1.8 RF inputs (50 Ω)............................................................................................................42
5.1.9 Trigger input and output................................................................................................ 43
5.1.10 Navigation controls........................................................................................................43
5.1.11 Keypad.......................................................................................................................... 45
5.1.12 The function keys.......................................................................................................... 45
5.2 The rear panel..............................................................................................................47
5.2.1 Removable hard disk.................................................................................................... 48
5.2.2 AC power supply connection and main power switch................................................... 48
5.2.3 Display port and DVI..................................................................................................... 48
5.2.4 LAN connector.............................................................................................................. 49
5.2.5 USB ports......................................................................................................................49
5.2.6 IF / video / demod output.............................................................................................. 49
5.2.7 Sync trigger input and output........................................................................................ 49
5.2.8 GPIB interface...............................................................................................................49
5.2.9 Aux. port........................................................................................................................50
5.2.10 External generator control option (R&S ESW-B10).......................................................50
5.2.11 OCXO (optional)............................................................................................................50

Contents
R&S®ESW
5User Manual 1177.6298.02 ─ 13
5.2.12 REF INPUT / REF OUTPUT......................................................................................... 50
5.2.13 Labels on R&S ESW..................................................................................................... 51
5.2.14 Device ID.......................................................................................................................51
6 Operating the instrument.................................................................... 53
6.1 Understanding the display information.................................................................... 53
6.1.1 Channel bar...................................................................................................................54
6.1.2 Window title bar.............................................................................................................56
6.1.3 Marker information........................................................................................................ 57
6.1.4 Frequency and span information in diagram footer.......................................................58
6.1.5 Instrument and status information.................................................................................58
6.1.6 Error information........................................................................................................... 59
6.2 Accessing functions................................................................................................... 60
6.2.1 Toolbar.......................................................................................................................... 61
6.2.2 Softkeys........................................................................................................................ 62
6.2.3 Context menus.............................................................................................................. 63
6.2.4 On-screen keyboard......................................................................................................63
6.3 Changing the focus.....................................................................................................64
6.4 Entering data............................................................................................................... 64
6.4.1 Entering numeric parameters........................................................................................65
6.4.2 Entering alphanumeric parameters............................................................................... 65
6.5 Touchscreen gestures................................................................................................ 67
6.6 Displaying results....................................................................................................... 70
6.6.1 Activating and deactivating channels............................................................................ 70
6.6.2 Laying out the result display with the smartgrid............................................................ 72
6.6.3 Changing the size of windows.......................................................................................76
6.6.4 Switching between a split and maximized window display........................................... 77
6.6.5 Changing the display.....................................................................................................77
6.7 Getting help................................................................................................................. 77
6.8 Remote control............................................................................................................78
6.8.1 Remote desktop connection..........................................................................................79
6.8.2 Connecting a PC via the GPIB interface....................................................................... 79
7 Applications..........................................................................................80
7.1 R&S multiview............................................................................................................. 80

Contents
R&S®ESW
6User Manual 1177.6298.02 ─ 13
7.2 Available Applications................................................................................................ 81
7.3 Starting an Application...............................................................................................83
7.4 Running a sequence of measurements.................................................................... 84
7.4.1 The sequencer concept.................................................................................................84
7.4.2 Sequencer settings....................................................................................................... 87
7.4.3 How to set up the sequencer........................................................................................ 87
8 Measurements and result displays.................................................... 89
8.1 Performing measurements.........................................................................................89
8.2 Bargraph configuration.............................................................................................. 91
8.3 Test automation...........................................................................................................96
8.3.1 Background information................................................................................................ 96
8.3.2 Selecting a test sequence........................................................................................... 106
8.3.3 Performing a scan....................................................................................................... 109
8.3.4 Performing a peak search........................................................................................... 118
8.3.5 Performing final measurements.................................................................................. 125
8.3.6 Configuring line impedance stabilization networks (LISN).......................................... 131
8.4 CISPR APD Measurements...................................................................................... 134
9 Common measurement settings...................................................... 137
9.1 Using the fast access knobs....................................................................................137
9.2 Using the fast access panel..................................................................................... 140
9.3 Using the user port panel.........................................................................................142
9.4 The Notes Display..................................................................................................... 143
9.5 Configuration overview............................................................................................ 144
9.6 Data input and output............................................................................................... 145
9.6.1 Configuring the input................................................................................................... 146
9.6.2 Configuring the preselector......................................................................................... 147
9.6.3 Optional external mixers............................................................................................. 149
9.6.4 External generator.......................................................................................................171
9.6.5 Configuring outputs (IF / video / demodulation).......................................................... 184
9.6.6 Configuring LISNs....................................................................................................... 188
9.6.7 Configuring additional outputs.....................................................................................188
9.7 Amplitude and vertical axis configuration..............................................................191
9.7.1 Increasing measurement sensitivity (or avoiding an input mixer overload).................191

Contents
R&S®ESW
7User Manual 1177.6298.02 ─ 13
9.7.2 Amplitude settings.......................................................................................................194
9.7.3 Diagram scale............................................................................................................. 196
9.7.4 Preselector.................................................................................................................. 197
9.8 Frequency and span configuration......................................................................... 197
9.8.1 Impact of the frequency and span settings................................................................. 197
9.8.2 Frequency and span settings...................................................................................... 200
9.9 Bandwidth and Filter Configuration........................................................................ 204
9.9.1 Impact of Bandwidth and Filter Settings......................................................................205
9.9.2 Bandwidth and Filter Settings..................................................................................... 205
9.10 Trigger configuration................................................................................................ 206
9.10.1 Basics on triggered measurements.............................................................................206
9.10.2 Triggering measurements........................................................................................... 209
10 Common analysis and display functions........................................ 213
10.1 Result display configuration....................................................................................213
10.1.1 Basic evaluation methods........................................................................................... 213
10.1.2 Laying out the result display with the smartgrid.......................................................... 214
10.2 Zoomed displays.......................................................................................................218
10.2.1 Zoom functions............................................................................................................219
10.2.2 How to zoom into the diagram in receiver mode.........................................................221
10.3 Trace configuration...................................................................................................222
10.3.1 Basics on traces..........................................................................................................222
10.3.2 Trace configuration......................................................................................................234
10.3.3 Trace export................................................................................................................ 235
10.3.4 Copying traces............................................................................................................ 237
10.3.5 Trace mathematics......................................................................................................237
10.3.6 Spectrogram settings.................................................................................................. 239
10.3.7 How to configure traces.............................................................................................. 244
10.3.8 References..................................................................................................................248
10.4 Marker usage............................................................................................................. 250
10.4.1 Basics on markers.......................................................................................................251
10.4.2 Marker settings............................................................................................................255
10.4.3 Marker search settings and positioning functions....................................................... 259
10.5 Display and limit lines.............................................................................................. 264

Contents
R&S®ESW
8User Manual 1177.6298.02 ─ 13
10.5.1 Display lines................................................................................................................ 264
10.5.2 Limit lines.................................................................................................................... 266
11 Data management.............................................................................. 283
11.1 Restoring the default instrument configuration (preset).......................................283
11.2 Protecting data using the secure user mode......................................................... 284
11.3 Storing and recalling instrument settings and measurement data......................286
11.3.1 Quick save/quick recall............................................................................................... 287
11.3.2 Configurable storage and recall.................................................................................. 291
11.3.3 How to save and load instrument settings.................................................................. 296
11.4 Import/export functions............................................................................................298
11.5 I/Q data import and export....................................................................................... 299
11.5.1 Import/export functions................................................................................................300
11.5.2 I/Q data file format (iq-tar)...........................................................................................301
11.6 Creating screenshots of current measurement results and settings.................. 310
11.6.1 Print and screenshot settings......................................................................................310
11.6.2 How to store or print screenshots of the display......................................................... 320
11.6.3 Example for storing multiple measurement results to a PDF file................................ 323
11.7 The Notes Display..................................................................................................... 325
11.8 Working with Test Reports....................................................................................... 326
11.8.1 Designing a Test Report Template.............................................................................. 326
11.8.2 Creating a Test Report................................................................................................ 331
12 General instrument setup..................................................................334
12.1 Alignment...................................................................................................................334
12.1.1 Basics on alignment.................................................................................................... 334
12.1.2 Alignment settings.......................................................................................................336
12.1.3 How to perform a self-test........................................................................................... 340
12.1.4 How to align the instrument.........................................................................................340
12.1.5 How to align the touchscreen......................................................................................341
12.2 Display settings.........................................................................................................341
12.2.1 Display settings........................................................................................................... 341
12.2.2 How to configure the colors for display and printing................................................... 352
12.2.3 How to work with the soft front panels........................................................................ 353
12.3 Toolbar configuration............................................................................................... 354

Contents
R&S®ESW
9User Manual 1177.6298.02 ─ 13
12.4 Transducers...............................................................................................................355
12.4.1 Transducer.................................................................................................................. 355
12.4.2 Working with transducers............................................................................................356
12.4.3 Reference: transducer factor file format......................................................................366
12.4.4 How to configure the transducer................................................................................. 366
12.5 Reference frequency settings..................................................................................370
12.6 System configuration settings.................................................................................374
12.6.1 Hardware information..................................................................................................374
12.6.2 Information on versions and options........................................................................... 375
12.6.3 System messages.......................................................................................................376
12.6.4 Firmware updates....................................................................................................... 377
12.6.5 General configuration settings.................................................................................... 379
12.7 Service functions...................................................................................................... 381
12.7.1 R&S support information............................................................................................. 382
12.7.2 Self-test settings and results....................................................................................... 383
12.7.3 Calibration signal display............................................................................................ 384
12.7.4 Service functions.........................................................................................................385
12.7.5 Hardware diagnostics..................................................................................................387
12.8 Synchronizing measurement channel configuration............................................ 387
12.8.1 General parameter coupling........................................................................................388
12.8.2 Using the custom coupling manager...........................................................................390
12.8.3 Example for a user-defined parameter coupling......................................................... 394
13 Network operation and remote control............................................ 396
13.1 Remote control interfaces and protocols............................................................... 396
13.1.1 LAN interface.............................................................................................................. 397
13.1.2 USB interface.............................................................................................................. 400
13.2 Status reporting system........................................................................................... 401
13.2.1 Hierarchy of status registers....................................................................................... 401
13.2.2 Contents of the status registers.................................................................................. 402
13.2.3 Reset values of the status reporting system............................................................... 414
13.3 GPIB languages.........................................................................................................415
13.4 The IECWIN tool........................................................................................................ 416
13.5 Network and remote control settings......................................................................417

Contents
R&S®ESW
10User Manual 1177.6298.02 ─ 13
13.5.1 General network settings............................................................................................ 418
13.5.2 GPIB settings.............................................................................................................. 420
13.5.3 Compatibility settings.................................................................................................. 423
13.5.4 LAN settings................................................................................................................426
13.5.5 Remote errors............................................................................................................. 428
13.5.6 Returning to manual mode ("Local")........................................................................... 429
13.6 How to set up a network and remote control......................................................... 430
13.6.1 How to configure a network.........................................................................................430
13.6.2 How to operate the instrument without a network....................................................... 436
13.6.3 How to log on to the network.......................................................................................437
13.6.4 How to share directories (only with microsoft networks)............................................. 439
13.6.5 How to control the R&S ESW via the web browser interface......................................440
13.6.6 How to deactivate the web browser interface............................................................. 441
13.6.7 How to set up remote desktop.................................................................................... 442
13.6.8 How to start a remote control session from a PC........................................................448
13.6.9 How to return to manual operation..............................................................................449
14 Remote commands in the receiver application...............................450
14.1 Conventions used in SCPI command descriptions............................................... 450
14.2 Common suffixes...................................................................................................... 451
14.3 Common commands.................................................................................................451
14.4 Application selection................................................................................................ 456
14.5 Measurements and result displays......................................................................... 460
14.5.1 Measurement control.................................................................................................. 460
14.5.2 Measurement sequences............................................................................................464
14.5.3 Result retrieval............................................................................................................ 466
14.5.4 Bargraph configuration................................................................................................471
14.5.5 Scan configuration...................................................................................................... 473
14.5.6 Scan table configuration..............................................................................................475
14.5.7 Peak search................................................................................................................ 483
14.5.8 Peak list.......................................................................................................................488
14.5.9 Final measurement (and trace) configuration............................................................. 493
14.5.10 Final results.................................................................................................................497
14.5.11 LISN configuration.......................................................................................................500

Contents
R&S®ESW
11User Manual 1177.6298.02 ─ 13
14.5.12 CISPR APD measurement configuration.................................................................... 503
14.5.13 Programming example: performing a sequence of measurements............................ 504
14.6 Configuration.............................................................................................................506
14.6.1 Input configuration.......................................................................................................506
14.6.2 Output configuration....................................................................................................532
14.6.3 Frequency configuration..............................................................................................540
14.6.4 Amplitude configuration...............................................................................................544
14.6.5 Diagram scale............................................................................................................. 547
14.6.6 Bandwidth and filter configuration............................................................................... 548
14.6.7 Trigger configuration................................................................................................... 550
14.7 Analysis..................................................................................................................... 554
14.7.1 Result display configuration........................................................................................ 554
14.7.2 Zoomed displays......................................................................................................... 564
14.7.3 Trace configuration......................................................................................................567
14.7.4 Markers....................................................................................................................... 578
14.7.5 Display and limit line configuration..............................................................................601
14.8 Data management..................................................................................................... 620
14.8.1 File management........................................................................................................ 621
14.8.2 Items to store.............................................................................................................. 627
14.8.3 Instrument setting management..................................................................................630
14.8.4 Screenshots and printouts.......................................................................................... 634
14.8.5 Notes display...............................................................................................................646
14.8.6 Test reports................................................................................................................. 647
14.8.7 Measurement result export......................................................................................... 659
14.8.8 Examples: managing data...........................................................................................660
14.9 General instrument setup.........................................................................................663
14.9.1 Basic instrument setup................................................................................................663
14.9.2 Reference frequency configuration............................................................................. 665
14.9.3 Calibration and temperature check............................................................................. 669
14.9.4 Transducers................................................................................................................ 672
14.9.5 Display layout and elements....................................................................................... 684
14.9.6 Measurement channel synchronization.......................................................................691
14.9.7 Network and remote control configuration.................................................................. 705

Contents
R&S®ESW
12User Manual 1177.6298.02 ─ 13
14.9.8 System configuration check.........................................................................................711
14.9.9 Service functions.........................................................................................................718
14.10 Using the status register.......................................................................................... 720
14.10.1 General status register commands............................................................................. 720
14.10.2 Reading out the CONDition part................................................................................. 721
14.10.3 Reading out the EVENt part........................................................................................722
14.10.4 Controlling the ENABle part........................................................................................ 722
14.10.5 Controlling the negative transition part........................................................................723
14.10.6 Controlling the positive transition part......................................................................... 723
14.11 Service request......................................................................................................... 724
14.11.1 Initiate service request................................................................................................ 724
14.11.2 Waiting for the arrival of a service request..................................................................726
14.11.3 Waiting without blocking the keyboard and mouse..................................................... 728
14.11.4 Service request routine............................................................................................... 728
14.11.5 Reading out the output buffer......................................................................................729
14.11.6 Reading error messages.............................................................................................730
14.11.7 Evaluation of SCPI status registers.............................................................................730
14.11.8 Evaluation of event status register..............................................................................731
14.12 Reference: GPIB commands of emulated HP models........................................... 732
14.12.1 Command set of models 8560E, 8561E, 8562E, 8563E, 8564E, 8565E, 8566A/B,
8568A/B, 8591E, 8594E, 71100C, 71200C, and 71209A........................................... 733
14.12.2 Special features of the syntax parsing algorithms for 8566A and 8568A models....... 756
14.12.3 Special behavior of commands................................................................................... 757
14.12.4 Model-dependent default settings............................................................................... 758
14.12.5 Data output formats.....................................................................................................759
14.12.6 Trace data output formats........................................................................................... 759
14.12.7 Trace data input formats............................................................................................. 759
14.12.8 GPIB status reporting..................................................................................................759
14.13 Reference: command set of emulated PSA models.............................................. 760
14.14 Reference: command set of emulated PXA models.............................................. 764
15 Maintenance, storage, transport and disposal................................767
15.1 Cleaning..................................................................................................................... 767
15.2 Storage.......................................................................................................................767

Contents
R&S®ESW
13User Manual 1177.6298.02 ─ 13
15.3 Transporting.............................................................................................................. 767
15.4 Disposal..................................................................................................................... 768
16 Troubleshooting.................................................................................769
16.1 Error information.......................................................................................................769
16.2 Error messages in remote control mode................................................................ 770
16.3 Troubleshooting remote operation..........................................................................771
16.4 Miscellaneous troubleshooting hints......................................................................773
16.5 System recovery....................................................................................................... 774
16.6 Collecting information for support..........................................................................775
16.7 Contacting customer support..................................................................................777
List of commands.............................................................................. 778
Index....................................................................................................793

Contents
R&S®ESW
14User Manual 1177.6298.02 ─ 13

Preface
R&S®ESW
15User Manual 1177.6298.02 ─ 13
1 Preface
1.1 About This Manual
This user manual describes general instrument functions and settings common to all
applications and operating modes in the R&S ESW. Furthermore, it provides all the
information specific to EMI measurements in the receiver application.
All other operating modes and applications are described in the specific application
manuals.
The main focus in this manual is on the measurement results and the tasks required to
obtain them. The following topics are included:
●Welcome to the R&S ESW
Introduction to and getting familiar with the instrument
●Operating modes and applications
The concept of using multiple operating modes
●Measurements
Descriptions of the individual measurements in the receiver application, including
result types and configuration settings.
●Common measurement settings
Description of the measurement settings common to all measurement types with
their corresponding remote control commands
●Common measurement analysis and display functions
Description of the settings and functions provided to analyze results independently
of the measurement type with their corresponding remote control commands
●Data management
Description of general functions to handle data files (configuration and result data,
not I/Q data)
●General instrument setup
Description of general instrument settings and functions that are independent of
the current operating mode
●Network and remote operation
Information on setting up the instrument in a network and operating it remotely.
●Remote commands
Remote commands required to configure and run measurements in a remote envi-
ronment, sorted by tasks
Remote commands required to set up the environment and to perform common
tasks on the instrument, sorted by tasks
Programming examples demonstrate the use of many commands and can usually
be executed directly for test purposes
●Maintenance
Information on tasks required to maintain operability of the instrument
●Troubleshooting
Hints and tips on how to handle errors
About This Manual

Preface
R&S®ESW
16User Manual 1177.6298.02 ─ 13
●List of commands
Alphabetical list of all remote commands described in the manual
●Index
1.2 Conventions used in the documentation
1.2.1 Typographical conventions
The following text markers are used throughout this documentation:
Convention Description
"Graphical user interface ele-
ments"
All names of graphical user interface elements on the screen, such as
dialog boxes, menus, options, buttons, and softkeys are enclosed by
quotation marks.
[Keys] Key and knob names are enclosed by square brackets.
Filenames, commands,
program code
Filenames, commands, coding samples and screen output are distin-
guished by their font.
Input Input to be entered by the user is displayed in italics.
Links Links that you can click are displayed in blue font.
"References" References to other parts of the documentation are enclosed by quota-
tion marks.
1.2.2 Conventions for procedure descriptions
When operating the instrument, several alternative methods may be available to per-
form the same task. In this case, the procedure using the touchscreen is described.
Any elements that can be activated by touching can also be clicked using an addition-
ally connected mouse. The alternative procedure using the keys on the instrument or
the on-screen keyboard is only described if it deviates from the standard operating pro-
cedures.
The term "select" may refer to any of the described methods, i.e. using a finger on the
touchscreen, a mouse pointer in the display, or a key on the instrument or on a key-
board.
1.2.3 Notes on screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as many as possible of the provided functions and
possible interdependencies between parameters. The shown values may not represent
realistic usage scenarios.
Conventions used in the documentation

Preface
R&S®ESW
17User Manual 1177.6298.02 ─ 13
The screenshots usually show a fully equipped product, that is: with all options instal-
led. Thus, some functions shown in the screenshots may not be available in your par-
ticular product configuration.
Conventions used in the documentation

Safety and regulatory information
R&S®ESW
18User Manual 1177.6298.02 ─ 13
2 Safety and regulatory information
The product documentation helps you use the product safely and efficiently. Follow the
instructions provided here and in the following chapters.
Intended use
The product is intended for the development, production and verification of electronic
components and devices in industrial, administrative, and laboratory environments.
Use the product only for its designated purpose. Observe the operating conditions and
performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential dan-
gers and gives instructions on how to prevent personal injury or damage caused by
dangerous situations. Safety information is provided as follows:
●In Chapter 2.1, "Safety Instructions", on page 18. The same information is provi-
ded in many languages as printed "Safety Instructions". The printed "Safety
Instructions" are delivered with the product.
●Throughout the documentation, safety instructions are provided when you need to
take care during setup or operation.
2.1 Safety Instructions
Products from the Rohde & Schwarz group of companies are manufactured according
to the highest technical standards. To use the products safely, follow the instructions
provided here and in the product documentation. Keep the product documentation
nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Intended
use and limits are described in the product documentation such as the data sheet,
manuals and the printed "Safety Instructions". If you are unsure about the appropriate
use, contact Rohde & Schwarz customer service.
Using the product requires specialists or specially trained personnel. These users also
need sound knowledge of at least one of the languages in which the user interfaces
and the product documentation are available.
Never open the casing of the product. Only service personnel authorized by
Rohde & Schwarz are allowed to repair the product. If any part of the product is dam-
aged or broken, stop using the product. Contact Rohde & Schwarz customer service at
http://www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
The product is heavy. Do not move or carry the product by yourself. A single person
can only carry a maximum of 18 kg safely depending on age, gender and physical con-
dition. Look up the maximum weight in the data sheet. Use the product handles to
Safety Instructions

Safety and regulatory information
R&S®ESW
19User Manual 1177.6298.02 ─ 13
move or carry the product. Do not lift by the accessories mounted on the product.
Accessories are not designed to carry the weight of the product.
To move the product safely, you can use lifting or transporting equipment such as lift
trucks and forklifts. Follow the instructions provided by the equipment manufacturer.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof. Water that enters
can electrically connect the casing with live parts, which can lead to electric shock,
serious personal injury or death if you touch the casing. If Rohde & Schwarz provides
accessories designed for your product, e.g. a carrying bag, you can use the product
outdoors.
Unless otherwise specified, you can operate the product up to an altitude of 2000 m
above sea level. The product is suitable for pollution degree 2 environments where
nonconductive contamination can occur. For more information on environmental condi-
tions such as ambient temperature and humidity, see the data sheet.
Setting up the product
Always place the product on a stable, flat and level surface with the bottom of the prod-
uct facing down. If the product is designed for different positions, secure the product so
that it cannot fall over.
If the product has foldable feet, always fold the feet completely in or out to ensure sta-
bility. The feet can collapse if they are not folded out completely or if the product is
moved without lifting it. The foldable feet are designed to carry the weight of the prod-
uct, but not an extra load.
If stacking is possible, keep in mind that a stack of products can fall over and cause
injury.
If you mount products in a rack, ensure that the rack has sufficient load capacity and
stability. Observe the specifications of the rack manufacturer. Always install the prod-
ucts from the bottom shelf to the top shelf so that the rack stands securely. Secure the
product so that it cannot fall off the rack.
Connecting to power
The product is an overvoltage category II product. Connect the product to a fixed
installation used to supply energy-consuming equipment such as household applian-
ces and similar loads. Keep in mind that electrically powered products have risks, such
as electric shock, fire, personal injury or even death.
Take the following measures for your safety:
●Before switching on the product, ensure that the voltage and frequency indicated
on the product match the available power source. If the power adapter does not
adjust automatically, set the correct value and check the rating of the fuse.
●Only use the power cable delivered with the product. It complies with country-spe-
cific safety requirements. Only insert the plug into an outlet with protective conduc-
tor terminal.
Safety Instructions

Safety and regulatory information
R&S®ESW
20User Manual 1177.6298.02 ─ 13
●Only use intact cables and route them carefully so that they cannot be damaged.
Check the power cables regularly to ensure that they are undamaged. Also ensure
that nobody can trip over loose cables.
●If the product needs an external power supply, use the power supply that is deliv-
ered with the product or that is recommended in the product documentation or a
power supply that conforms to the country-specific regulations.
●Only connect the product to a power source with a fuse protection of maximum
20 A.
●Ensure that you can disconnect the product from the power source at any time.
Pull the power plug to disconnect the product. The power plug must be easily
accessible. If the product is integrated into a system that does not meet these
requirements, provide an easily accessible circuit breaker at the system level.
Connecting headphones
Take the following measures to prevent hearing damage. Before using headphones,
check the volume and reduce it if necessary. If you monitor varying signal levels, take
off the headphones and wait until the signal has settled. Then adjust the volume.
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that the
casing is not waterproof. Do not use liquid cleaning agents.
Meaning of safety labels
Safety labels on the product warn against potential hazards.
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Heavy product
Be careful when lifting, moving or carrying the product. Carrying the product requires a suffi-
cient number of persons or transport equipment.
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This connec-
tion protects you against electric shock if an electric problem occurs.
Safety Instructions
