Rohm FORTO-H 70 Operational manual

Translation of the Original Operating Manual
Actuating cylinder FORTO-H
Version 1.0 • 15.12.2021
Store for reference
ID: XX.XXX
EN

Table of Contents
FORTO-H EN III
Table of Contents
1 About this operating manual ..................................................................... 6
1.1 Manufacturer Details................................................................................. 6
1.2 Copyright ................................................................................................. 6
1.3 Liability and Warranty ............................................................................... 7
1.4 Conventions of Presentation .....................................................................8
1.4.1 Text Display........................................................................................8
1.4.2 Display of Safety and Warning Instructions .........................................9
1.5 Definitions .............................................................................................. 10
1.5.1 Manufacturer of the machine ............................................................ 10
1.5.2 Manufacturer .................................................................................... 10
1.5.3 Operator ........................................................................................... 10
1.5.4 Assembly information for holding screws .......................................... 10
1.5.5 Dial gage symbol .............................................................................. 11
1.5.6 Piston positions front and back......................................................... 11
2 Safety ....................................................................................................... 12
2.1 Intended Use .......................................................................................... 12
2.2 Improper use .......................................................................................... 12
2.3 Obligations of the operator ..................................................................... 12
2.3.1 General............................................................................................. 12
2.3.2 Rotation............................................................................................ 13
2.3.3 Installation/replacement/conversion/change ..................................... 13
2.4 Qualification of Operating and Specialist Personnel ................................ 15
2.5 Personal protective equipment ............................................................... 15
2.6 General hazards ..................................................................................... 16
2.6.1 Skin irritation due to operating materials...........................................16
2.6.2 Risk of injury due to handling heavy loads ........................................16
2.6.3 Risk of burns due to hot surfaces .....................................................17
2.6.4 Danger of crushing due to moving distributor housing ......................18
2.6.5 Risk of ejection, detachment and falling of components at the actuating
cylinder ............................................................................................ 19
2.6.6 Risk of ejection, detachment and falling of workpieces .....................19
2.7 Miscellaneous......................................................................................... 20
2.7.1 Procedure in the Event of Danger and Accidents ..............................20
2.7.2 Eyebolts for transport of actuating cylinder.......................................20
2.7.3 Modification of the actuating cylinder ...............................................20
2.7.4 Dismantling of the actuating cylinder ................................................ 20
2.7.5 Collision/falling ................................................................................. 20

Table of Contents
IV FORTO-H EN
3 Product description ................................................................................. 21
3.1 About this actuating cylinder .................................................................. 21
3.2 Options .................................................................................................. 24
3.3 Technical data ........................................................................................ 25
3.3.1 Overview of construction sizes .........................................................25
3.3.2 Name plate ....................................................................................... 30
3.3.3 Media-carrying connections.............................................................. 30
3.3.4 Environmental and operating conditions ........................................... 30
3.3.5 Permissible operating materials ........................................................31
3.3.6 Structural operating conditions ......................................................... 31
3.3.7 Technical control requirements .........................................................34
4 Transport.................................................................................................. 36
4.1 Transport actuating cylinder with eyebolt................................................ 36
4.2 Set down actuating cylinder.................................................................... 37
5 Assembly.................................................................................................. 38
5.1 Preparing the machine............................................................................ 38
5.2 Mounting the actuating cylinder at the machine spindle .......................... 39
5.3 Install protection against torsion (at the leakage oil fitting) ...................... 43
5.4 Assembling options on the actuating cylinder ......................................... 44
5.4.1 Assembling draw bar option .............................................................44
5.4.2 Assembling leakage oil fitting option................................................. 45
5.4.3 Assembling the position measuring system/proximity switch option.. 46
5.4.4 Assembling cylinder flange option..................................................... 48
5.4.5 Balancing the actuating cylinder option ............................................50
5.4.6 Assembling (simple) rotary feed-through option (FORTO-H 70/85/100)
......................................................................................................... 52
5.4.7 Assembling (simple) rotary feed-through option (FORTO-H
125/150/175/200) ............................................................................. 54
5.4.8 Assembling rotary feed-through (double) option (FORTO-H
125/150/175/200) ............................................................................. 56
5.5 Connect media-carrying connections...................................................... 59
5.5.1 Connecting hydraulic hoses.............................................................. 59
5.5.2 Connecting the leakage oil hose ....................................................... 60
6 Commissioning ........................................................................................ 61
6.1 Fill the actuating cylinder with hydraulic oil and vent out the air .............. 61
6.2 Carrying out a functional test.................................................................. 63
6.3 Configuring clamping path monitoring .................................................... 64
6.4 Tightening holding screws ...................................................................... 65

Table of Contents
FORTO-H EN V
7 Operation ................................................................................................. 67
7.1 Production mode .................................................................................... 67
8 Cleaning ................................................................................................... 68
8.1 Cleaning the actuating cylinder............................................................... 68
8.2 Checking leakage oil hose for backlogs .................................................. 69
9 Maintenance ............................................................................................ 70
9.1 Checking the actuating cylinder.............................................................. 70
9.2 Checking the non-return valves .............................................................. 70
10 Storage..................................................................................................... 73
11 Troubleshooting....................................................................................... 73
12 Decommissioning and disassembly ........................................................ 73
13 Disposal ................................................................................................... 75
14 Appendix .................................................................................................. 75
14.1 Test record ............................................................................................. 75
14.2 Declaration of Incorporation ................................................................... 76
15 Notes ........................................................................................................ 77

1 | About this operating manual
6 / 80 FORTO-H EN
1About this operating manual
This operating manual describes in detail the use, installation, assembly and
maintenance of a actuating cylinder FORTO-H. The efficiency of the actuat-
ing cylinder depends primarily on correct use and careful maintenance. This
operating manual serves as the leading document and is provided on deliv-
ery of the product. The personnel must have carefully read and understood
the operating manual before beginning any work. Observance of all safety
instructions and instructions for use in these operating manual is the basic
prerequisite for safe work with the actuating cylinder. In addition to the reg-
ulations listed here, local and user-related operating instructions and pro-
fessional accident prevention regulations are to be observed.
1.1 Manufacturer Details
RÖHM GmbH
Heinrich-Röhm-Straße 50
89567 Sontheim/Brenz
Germany
Tel.: [phone]
Fax: [phone]
Web: www.roehm.biz
E-mail: [email protected]
1.2 Copyright
This operating manual is protected by copyright and is intended for internal
purposes only.
The forwarding of the operating manual to third parties, reproduction by any
means – even in part – as well as use and/or communication of the content
without the permission of RÖHM are prohibited (except for internal pur-
poses).
Infringements will lead to claims for compensation. We reserve the right to
assert further claims.

About this operating manual | 1
FORTO-H EN 7 / 80
1.3 Liability and Warranty
All information and instructions in this operating manual are given in good
faith on the basis of our experience and knowledge to date. The products of
RÖHM are subject to constant further development. RÖHM therefore re-
serves the right to make any modifications and improvements deemed use-
ful. However, there is no obligation to extend these modifications and ex-
tensions to any previously delivered actuating cylinder. The actuating cylin-
der is constructed exclusively for the purpose specified under “Intended
Use”. Any use beyond this is deemed to be inappropriate. RÖHM is not li-
able for damage resulting from such use. The risk is borne solely by the op-
erator. Product liability for consequential damage of any type is excluded
for damage and operational interruptions resulting from operating errors,
failure to observe this operating manual or incorrect maintenance by unau-
thorised personnel.
RÖHM expressly points out that replacement and wear parts not supplied
by RÖHM must be authorised by RÖHM. RÖHM does not accept liability for
unauthorised replacement and wear parts. This applies to both product liab-
ility for consequential damage of all types and to liability for damage to
property.
All unauthorised conversions, modifications to the actuating cylinder and/or
changes in conditions are not permitted for safety reasons and exclude
RÖHM from any liability for any damage which may result. If modifications
to the actuating cylinder are necessary or the area of use differs from the in-
tended use, this must be agreed with the express permission of RÖHM.
The statutory and contractually agreed terms and conditions apply.
The following damage or defects are excluded from the warranty:
▪caused by the operator due to non-compliance with the written instruc-
tions of RÖHM with regard to
◦commissioning (e.g. incorrect construction and assembly work),
◦operation and
◦maintenance of the equipment (insofar as this maintenance has not been
contractually taken over by RÖHM).
▪caused by technical operating conditions unknown to RÖHM (e.g.
chemical or electrolytic influences) and/or machine specifications.
▪caused by natural wear.
▪caused by force majeure.
▪caused by incorrect operation of all types or by incorrect use or opera-
tion of the actuating cylinder. This also includes loading beyond the
specified load limits (e.g. speed, pressure, force, etc.).
This also includes damage caused

1 | About this operating manual
8 / 80 FORTO-H EN
▪if the operator or third parties carry out modifications or repairs to the
services / products without prior permission of RÖHM. Excepted from
this are damage or defects which have occurred and which were
demonstrably not due to these modifications or repairs.
▪which occur due to use of the actuating cylinder under altered operating
conditions (e.g. materials, tools, cutting parameters, programs, etc.), in
particular without consulting and obtaining written authorisation from
the seller or RÖHM.
▪which are due to altered environmental conditions.
1.4 Conventions of Presentation
1.4.1 Text Display
To improve legibility and comprehension of the text, the following conven-
tions were agreed:
Text type Marking Function
Operating instruction 1.
2., etc.
Marks a sequence of actions
Marks an individual operating instruc-
tion
Ø
Marks an intermediate result of an
operating instruction
ü
End result of an operating instruction
List ▪Marks elements of a list
Marks comments within a list
Contains useful information or further information.

About this operating manual | 1
FORTO-H EN 9 / 80
1.4.2 Display of Safety and Warning Instructions
Safety and warning instructions are marked by pictograms. The signal word
and the colouring show the level of danger.
Observe the safety instructions to prevent personal injury and damage to
property.
DANGER
Indicates an imminently dangerous situation
which may lead to death or permanent personal injury if not
avoided.
ØList of all measures which must be taken to prevent con-
sequences.
WARNING
Indicates a possible danger
which may lead to permanent personal injury or death if not
avoided.
ØList of all measures which must be taken to prevent con-
sequences.
CAUTION
Indicates a possible danger
which may lead to minor reversible injuries if not prevented.
ØList of all measures which must be taken to prevent con-
sequences.
NOTICE
Indicates a possible danger
which may lead to damage to property if not avoided.
ØList of all measures which must be taken to prevent con-
sequences.

1 | About this operating manual
10 / 80 FORTO-H EN
1.5 Definitions
1.5.1 Manufacturer of the machine
In this operating manual, the manufacturer of the machine is defined as the
company which builds the machine into which the actuating cylinder is in-
tegrated.
1.5.2 Manufacturer
In this operating manual, the manufacturer is defined as the manufacturer of
other parts, assemblies or products which are contained in or attached to
the actuating cylinder such as rotary feed-throughs, o-rings, operating ma-
terials, etc. and the manufacturer of which is not RÖHM.
1.5.3 Operator
In this operating manual, the operator is defined as the company which
uses the machine with the actuating cylinder to process workpieces.
1.5.4 Assembly information for holding screws
For the correct assembly it is essential to assemble the holding screws ac-
cording to the information. This information is listed as standard in the fol-
lowing way:
Example:
6x
M10x90
12.9
83Nm
Number of holding screws
Screw size
Strength class
Tightening torque
NOTE:
If there is no information for an item, this item is marked by “-”.
NOTE:
Holding screws are not listed in the figure keys. However, special screws
such as screw plugs or venting screws are also listed in the keys.
NOTE:
The tightening torques stated must be adhered to with a tolerance of ±
10%.
