ROHO AirLITE User manual

ROHO®AirLITE®Cushion
Operation Manual
SUPPLIER: This manual must be given to the user of this product.
CAREGIVER:Before using this product, read the instructions and save for future reference.
shape fitting technology
®

Table of Contents
Intended Use
Important Safety Information 2
Parts Detail
Product Specifications 3
Cushion, Cover, and Convex Insert Placement 4
Care Instructions
Troubleshooting 5
Return Policy
Contact Information 6
Disposal
Limited Warranty 7
Español 8
Français 15
Deutsch 22
Italiano 29
Nederlands 36
Dansk 43
Svenska 50
Norsk 57
Suomi 64
Português 71
ROHO, Inc.
100 N. Florida Avenue, Belleville, IL 62221-5429 U.S.A.
U.S.A.: 800-851-3449, Fax [phone]
Outside the U.S.A.: 618-277-9150, Fax [phone]
permobilus.com • [email protected]
© 2015, 2017 ROHO, Inc.
Products in this manual may be covered by one or more U.S. and foreign patents and trademarks.
The following are trademarks and registered trademarks of ROHO, Inc.: AirLITE®, ROHO®, and shape
fitting technology®.
ROHO, Inc. has a policy of continual product improvement and reserves the right to amend specifications
presented in this manual.

2
ROHO®AirLITE®Cushion Operation Manual (T22305)
Intended Use
The ROHO®AirLITE®Cushion (AirLITE) is a wheelchair support surface with a non-
adjustable, air-filled, segmented-design ROHO AIR FLOTATION insert encased in contoured
foam. The AirLITE is intended to conform to an individual’s seated shape to provide
positioning. The ROHO®Convex Insert (Convex Insert) component is to be used only with
wheelchair sling seats to provide a flat foundation and minimize the hammocking effect.
The Convex Insert is intended to be positioned between the bottom of the cushion and the
bottom of the cover. There is a weight limit of 300 lbs. (136 kg), and the cushion must be
properly sized to the individual. The AirLITE must be used with the supplied cover.
ROHO, Inc. recommends evaluation by a clinician who is experienced in seating,
positioning and mobility: 1) to determine whether the cushion is appropriate for the
individual; and 2) to determine whether a solid seat platform, such as the Convex Insert,
is recommended if using the cushion on a sling-seat wheelchair.
ROHO medical products are intended to be part of an overall care regimen. ROHO,
Inc. recommends that a clinician make product recommendations based upon an
evaluation of the individual’s medical and therapeutic needs and overall condition.
Important Safety Information
Warnings
• DO NOT use if the individual has an existing pressure ulcer. Skin/soft tissue
breakdown can occur due to a number of factors, which vary by individual. Check
skin frequently, at least once a day. Redness, bruising, or darker areas (when
compared to normal skin) may indicate the beginning of soft tissue breakdown.
Consult with a clinician immediately.
• The cushion, the Convex Insert, and the cover MUST be compatible sizes and
MUST be used as directed in this manual. IF THEY ARE NOT, the benefits provided
by the cushion may be reduced or eliminated, increasing the risk to skin or other
soft tissue and increasing the risk of falling.
• DO NOT use the Convex Insert as a seating surface.
• DO NOT use the cushion as a water flotation device (e.g. a Life Preserver). It will
NOT support you in water.
Cautions:
• DO NOT expose the cushion to high heat, open flames, or hot ashes.
• Prolonged exposure to ozone will degrade materials used in the AirLITE cushion and
may affect the performance of your product and invalidate the product warranty.

3
ROHO®AirLITE®Cushion Operation Manual (T22305)
Sizing (all measurements are approximate):
Smallest Width Smallest Depth Largest Width Largest Depth
in. 13.0 13.0 20.0 20.0
cm 33.0 33.0 51.0 51.0
Average Weight (AirLITE without Convex Insert): 2 lbs. (0.9 kg)
Average Weight of Convex Insert: 0.75 lbs. (0.3 kg)
Height ranges from 2 in. (5 cm) to 3¾ in. (9.5 cm)
Product Specifications
Cover: fluid-resistant, two-way stretch top, two-way stretch sides, and non-skid bottom
Cushion: non-adjustable, segmented, polyurethane air insert encased in polyurethane
and polyethylene foam
Convex Insert: polyethylene foam
Back
Front
Parts Detail
Back
Front
Hook and Loop
Fastener Strips
(not shown)
CushionCover
Operation Manual Product
Registration Card
BackFront
Top View
Bottom View
Convex Insert

4
ROHO®AirLITE®Cushion Operation Manual (T22305)
Cushion, Cover and Convex Insert Placement
NOTE: To correctly orient the components:
Refer to the label on the bottom of the
cushion, the label on the Convex Insert,
and the image on the cover.
Cushion Placement:
1. Place the cushion directly on the seat.
NOTE: If a seat insert is used, place it
inside the cover, beneath the cushion.
When possible, use the hook or
loop fasteners to further secure
the cover to the seating surface.
2. Have the individual sit on the cushion, making sure the boniest prominences are
supported by the air cells.
Check to make sure that the cushion is properly sized to the individual and the
wheelchair.
Cover Removal: Unzip the cover. Remove the cover from the cushion.
Cover Placement:
1. Unzip the cover.
2. Insert the cushion into the cover, front
edge first, with the contoured foam
facing up.
3. Close the zipper.
Inspect the cover for damage
and replace if necessary.
Convex Insert Placement:
Place the Convex Insert inside the cover, between the bottom of the cushion and the
bottom of the cover. For correct orientation, refer to the images in this manual and to
the labeling on the cushion and on the Convex Insert. If desired, use the hook and loop
fastener strips to secure the Convex Insert to the cushion by attaching a hook strip to the
top of the Convex Insert and a loop strip to the bottom of the cushion.
DO NOT use the Convex Insert if your wheelchair does not have a sling seat.
Remove the Convex Insert from the cover.
DO NOT use with multiple individuals if this product becomes soiled or
contaminated.
The seated
figure shows
standard
orientation.
Zipper in Back
Front

5
ROHO®AirLITE®Cushion Operation Manual (T22305)
Care Instructions
Cleaning and disinfecting are separate processes. Cleaning must precede disinfection.
Before use by a different individual: clean, disinfect, and check product for proper
functioning.
NOTE: Before cleaning and disinfecting, remove the cover and the Convex Insert from the
cushion. Remove hook fastener pieces from the bottom of the cover.
To Clean the Cover: Machine wash in cold water (30°C) with mild detergent,
gentle cycle. Tumble dry low.
To Disinfect the Cover: Hand wash in warm water
(40°C) using 1 part household liquid bleach per 9
parts water, then rinse thoroughly. The cover can also
be machine washed in hot water (60°C) to disinfect. Tumble dry low.
Follow safety guidelines on bleach container.
To Clean the Cushion and the Convex Insert: Remove the cover. Wipe gently with
a cloth dampened with water and a household detergent. Rinse cloth and re-wipe.
Allow foam to air dry thoroughly before putting the cover on or replacing the
Convex Insert.
Disinfectants are not effective on porous surfaces such as foam. If the cushion
or the Convex Insert becomes soiled or contaminated, DO NOT use with multiple
individuals. Replace soiled or contaminated foam components.
This symbol means, “Wipe with a damp cloth.”
DO NOT:
- machine wash or dry the cushion or the Convex Insert
- immerse the cushion or the Convex Insert in water
- autoclave, steam clean, or expose cushion or the Convex Insert to temperatures in
excess of 150˚F (65˚C)
- use caustic, automatic dishwasher detergents
- use cleaning products containing petroleum or organic solvents such as acetone,
toluene, Methyl Ethyl Ketone (MEK), naphtha, dry cleaning fluids, or adhesive
removers
- expose the cushion or the Convex Insert to ozone gas or to ultraviolet light cleaning
methods
1:9
40C +or

6
ROHO®AirLITE®Cushion Operation Manual (T22305)
Troubleshooting
The cushion feels uncomfortable or
unstable.
- Confirm the size and orientation of AirLITE
components.
- Confirm that there are no obstructions between
AirLITE and the seating surface.
- Use the hook and loop fastener strips to secure
the Convex Insert to the cushion.
- Consult with a clinician.
The cushion slides on the chair. - Make sure the cover’s non-skid bottom faces
the seating surface.
- If a seat insert is used, make sure it is inside
the cover, beneath the cushion.
- When possible, use the hook or loop fasteners
to further secure the cover to the seating
surface.
The cushion exhibits unusual
stiffness; the cushion and/or
the Convex Insert has been in
temperatures lower than 32ºF (0ºC)
Before use, allow the cushion and the Convex
Insert to warm to room temperature 72ºF (22ºC).
Return Policy
Contact ROHO before returning your product. Returned products require prior authorization
from ROHO, Inc., must be new and unused, and are subject to a restocking charge.

7
ROHO®AirLITE®Cushion Operation Manual (T22305)
Disposal
When properly used and disposed of, the components of the products in this manual
are associated with no known environmental hazards. Dispose of the product and/or
components in accordance with the applicable regulations in your jurisdiction. DO NOT
INCINERATE.
Limited Warranty
What is covered? ROHO, Inc. covers any defects in materials or workmanship of the
product.
For how long? 24 months from the date the product was originally purchased. The
warranty does not apply to punctures, tears or burns, nor does it apply to the removable
cover.
What is not covered? A product that has been misused, damaged by an accident, or
damaged from “an act of Nature”, e.g., flood, tornado, earthquake, fire. Any substitutions
of supplied product accessories or modification to the product will void the warranty.
What the customer must do: Within the U.S.A., the customer must contact the ROHO,
Inc. Warranty Service Department. Note: Any items sent to ROHO, Inc. without prior
authorization will not be returned to the customer. Outside the U.S.A., contact your
country’s ROHO distributor.
Questions? See CONTACT INFORMATION.
Disclaimer: Any implied warranties, including the MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE are limited to the same time period of the product types referenced
above in the “For how long?” section and any action for a breach of such warranties or
any express warranties herein must be commenced within that time. ROHO, Inc. shall not
be responsible for any incidental or consequential damages with respect to economic loss
to property, whether as a result of a breach of express or implied warranties or otherwise.
Your Rights and the Effect of This Warranty Upon Them: This warranty restricts the
duration of all implied warranties as noted above and limits or excludes recovery for
incidental or consequential damages. Some jurisdictions do not allow limitations on how
long implied warranties will last and some jurisdictions do not allow the exclusion or
limitation of consequential or incidental damages, so those provisions may not apply to
you. While this warranty gives you specific legal rights, you may also have other rights
which vary from jurisdiction to jurisdiction.

Item #T22305
Rev. Date: 4/13/17
Print Date: Qty:
