ROOMS TO GO 2662-18 User manual

ASSEMBLY INSTRUCTIONS
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts.
Which may have come loose inside the carton during shipment. Identify and count all parts and compare with
the hardware list as below :
No. Picture Description Dimension Qty
Hardware List
Parts List
No. Description Qty
1JCBB M8 2 Pcs
A Back rest
Seat
B
C
1 Pc
PARTS DETAILS
8 Pcs
3
JCBB M8
MODEL : 2662-18 SIDE CHAIR
8 x P1.0 x 40mm [Length]
8 x P1.0 x 80mm [Length]
Page 1 of 2
A
B
C
Front Leg (L & R) 2 Pcs
1 Pc
Allen Wrench 1 Pc
M4
2
D
DSide Stretcher 2 Pcs
4Pan Head Screw M4
M4 x 38mm [Length]
4 Pcs
SKU : 42126626, 42226628, 42326620, 42426622, 42526624, 42626626, 42726628.
Tools required (not included): PHILLIPS HEAD SCREW DRIVER
5

Assemble FRONT LEG to SEAT as illustration shown.
Assembly step
STEP 1
STEP 2
Assemble BACKREST to SEAT as illustration shown.
Page 2 of 2
3
2 -80mm
3
2 -80mm
STEP 1b
3
1 -40mm
STEP 1a
A
B
DO NOT TIGHTEN THE SCREWS UNTIL
FULLY SET UP.
DO NOT TIGHTEN THE SCREWS UNTIL
FULLY SET UP.
Assemble STRETCHER to LEG as illustration shown.(NOTE : USE HARDWARE IN BOX 4)
STEP 3
STEP 3a
4 -38mm
TIGHTEN ALL THE SCREWS !!!
D
NOTE:
To ensure that chair is level, assemble the chair on flat & soft surface. DO NOT tighten all the screw
& bolts until the chair been adjust & level all the legs so that they do not wobble. Once adjusted then
only tighten all the screw using Allen Key while making sure that the unit remain level.
STEP 2a
R
C
5
