ROOMS TO GO CREEKSIDE 2.0 User manual

WARNING DANGER
Failure to follow these warnings and assembly instructions could result in serious
injury or death. To help prevent serious or fatal injuries from entrapment or falls:
-
Read all instructions before assembling bunk bed and keep these instructions for future reference.
-
Before each usage or assembly, inspect bunk bed for damaged hardware, loose joints, missing
parts, or sharp edges. DO NOT Use bunk bed if any parts are missing or broken.
-
DO NOT Use substitute parts. Contact your local Rooms To Go or visit www.ROOMSTOGO.COM
for replacement parts and instructional literature if needed.
-
Follow the information on the warnings appearing on the upper bunk end structure and on the carton,
DO NOT REMOVE WARNING LABEL FROM BED.
-
Always use the recommended size mattress or mattress supports, or both to help prevent the likelihood
of entrapment or falls.
-Ensure thickness of mattress and foundation combine does not exceed
10 inches (255mm
) and
mattress surface is at least
5 inches (127mm)
below upper edge of guardrails.
-
Do not allow children under 6 years of age to use the upper bunk.
-
Periodically check and ensure that the guardrail, ladder, and other components are in their proper
position, free from damage, and that all connectors are tight.
-
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
-
Limit top bunk use to one person.
-
Always use the ladder for entering and leaving the upper bunk.
-
Use of night light may provide added safety precaution for a child using the upper bunk.
-
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed next to
the wall, the guardrail that runs the full length of the bed should be placed against the wall to
prevent entrapment between the bed and wall.
-
The use of water or sleep flotation mattress is prohibited.
-
This bunk bed meets all the requirements of ASTM 1427-19.
STRANGULATION HAZARD:
Never attach or hang items to any part of the bunk bed that are not designed for
use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
CREEKSIDE 2.0 COLLECTION
THANK YOU FOR YOUR PURCHASE
11/7/2022 Page 1 of 97

11/7/2022 Page 9 of 97
6 x 1 1/4" Phillips screwdriver (not included)
Trundle bed (Add on)
61 Pc
38 Pcs
Drywall screw
1 Pc
22 Pcs 1 pc bunkbed end twin 5 mm Hex key
51 Pc
5 mm Hex key (included)
Twin slats Step storage unit
16 Pcs
TOOLS NEEDED
Guardrails
14 Pcs
41 Pc
24 Pcs
5/16"-18 x 3 3/8" Bolt
Side rails
PARTS LIST QTY PARTS LIST QTY HARDWARE LIST QTY
38000232 100-645 TW. SLAT PACK (4)
35440419 40B-744 TRUNDLE BED ADD ON
36640414 40B-730
6 PC RAILS (2 GUARD & 4 SIDE RAILS)
38000232 100-645 TW. SLAT PACK (4)
35840417 40B-160 STEP STORAGE UNIT
35540411 40B-706 1 PC BUNKBED END TWIN
3784041P TWIN/TWIN STEP BUNK CHESTNUT
RTG SKU # STYLE # ITEM DESCRIPTION
35440407 40G-744 TRUNDLE BED ADD ON
P A R T S L I S T
3784040P TWIN/TWIN STEP BUNK CHARCOAL
RTG SKU # STYLE # ITEM DESCRIPTION
35840405 40G-160 STEP STORAGE UNIT
38000232 100-645 TW. SLAT PACK (4)
38000232 100-645 TW. SLAT PACK (4)
35540409 40G-706 1 PC BUNKBED END TWIN
36640402 40G-730
6 PC RAILS (2 GUARD & 4 SIDE RAILS)
A
B
C

STAIRS ON THE RIGHT STAIRS ON THE LEFT
(Factory setting)
Install slats, one on each end, two equally spaced in the middle,
then fasten with 1 1/4" screws. Repeat step 1 & 2 for top set of side rails.
11/7/2022
Page 10 of
97
and install it on the other side and secure with the screw. Assemble bottom side rails.
ASSEMBLY INSTRUCTIONS
FIRST DETERMINE THE CONFIGURATION THAT FITS YOUR ROOM
For stairs on the left, first remove the screw, then remove the panel
STEP 3
STEP 2
STEP 1
B
A
A
B
A
A
C
C
C
C
A
B
C
A
A
A
C
C
A
B

Twin size mattress- 74" - 75" long and 37-1/2" - 38-1/2" wide
Twin size Bunkie board- 74" long and 37-1/2" wide
Full size mattress- 74" - 75" long and 52-1/2" - 53-1/2" wide
Full size Bunkie board- 74" long and 52-1/2" wide
ASSEMBLY INSTRUCTIONS
Assemble guardrails and tighten all bolts. For Add on Trundle bed follow assembly instructions inside
PLEASE CONTACT YOUR RETAIL STORE WITH SERVICE OR PARTS REPLACEMENT REQUEST
11/7/2022 Page11 of 97
Place Bunkie boards (required, sold separately) on top of the slats
Use only correct mattress dimensions and Bunkie board:
MAKE SURE ALL BOLTS ARE TIGHTENED COMPLETELY Trundle bed box, then slide under the bed as shown.
STEP 6
STEP 4 A
B
A
A
A
STEP 5
