Rosewill PRISM S Instruction manual

Quick User Guide
Gaming Case

Table of Contents
Thank you for purchasing a Rosewill Computer Case.
Please read the instruction manual before use and
retain for future reference.
1
• Product Overview
Disassembly ...................................................... 02
Accessory Box ................................................... 03
• Installation Guide
1. Open the Unit ................................................ 04
2. Install the Power Supply ................................ 05
3. Install Motherboard ........................................ 05
4. Install Add-on Card ........................................ 06
5. Install 3.5”/2.5” HDD/SDD ............................. 07
6. Care ............................................................... 08
7. Options .......................................................... 09
• Specications Table ........................................... 12
Front I/O Cable Pinout ....................................... 13
Front I/O ............................................................. 13

2
PRISM S / PRISM S-LITE
Gaming Case
Product Overview
Disassembly (components vary by country)
Cooling Fan
HDD Cage
SSD
Plates Side Panel
Cooling Fan
(PRISM S-LITE provides one cooling fan)
Dust Filter
Front View Right Side View Rear View Left Side View
210 mm
477 mm
475 mm
SSD/HDD
Plate
Glass Panel

3
Gaming Case PRISM S / PRISM S-LITE
Accessory Box
Image Part Name Qty Function/Component
Screw-A (6-32 x 6mm) 5 PSU
Screw-B (6-32 x 5mm) 22 Motherboard
3.5” HDD
Screw-C (M3 x 5mm) 20 2.5” SSD
Standoff 9 Motherboard
(Pre-Installed)
Nut Setter 1
Standoff Installation
(Optional: Standoffs are
Pre-Installed)
Cable Tie 10 Cable Management
Velcro Strap 4 Cable Management
Micro Fiber Towel 1 Tempered Glass Cleaning

4
PRISM S / PRISM S-LITE
Gaming Case
Installation Guide
1. Open the Unit
1-1. Loosen the thumbscrews and take off panel R and L (Figure 1).
1
•Simply loosen screws to
remove side panel

5
Gaming Case PRISM S / PRISM S-LITE
2. Install the Power Supply
2-1. Set the power supply unit (PSU) at the top of the case and secure with Screw-A (Figure 2).
2
3. Install Motherboard
3-1. Secure the motherboard down onto the pre-installed standoff with Screw-B (Figure 3).
3

6
PRISM S / PRISM S-LITE
Gaming Case
4. Install Add-on Card
4-1. Loosen the screws to open the cover panel/slot cover (Figure 4a).
4-2. Install the add-on card and secure with screws (Figure 4b).
4a
4b

7
Gaming Case PRISM S / PRISM S-LITE
5a
5d
5f 5g 5h
5e
5c
5-2. Secure the 3.5" drive onto the tray/plate with Screw-B (Figure 5d/5e).
5-3. Secure the 2.5” drive onto the tray with Screw-C (Figure 5f/5g/5h).
* If drive is installed on 5e or 5g, water cooling radiator cannot be added.
5-4. Put the tray/plate back onto the chassis and secure with screws.
5. Install 3.5”/2.5” HDD/SDD
5-1. Take out the 3.5”/2.5” HDD/SDD trays/plates from the chassis (Figure 5a/5b/5c).
5b

8
PRISM S / PRISM S-LITE
Gaming Case
6a
6-2. Clean the dust lters on the bottom regularly to ensure adequate airow (Figure 6b).
6. Care
To prevent damage, keep all panels closed and secured.
6-1. Put the side panels back in place and secure with thumbscrews (Figure 6a).
6b

9
Gaming Case PRISM S / PRISM S-LITE
7. Options
7-1. LED Light Mode (only on PRISM S)
Press LED light button briefly:
RGB 1 (steady-rainbow) > RGB 2 (owing-rainbow) > RGB 3 > RGB 4 > RGB 5 (seven-
color-breath) > RGB 6 (seven-color-one-way-billboard) > (seven-color-two-way-billboard) >
Red > Green > Blue > White > Yellow > Cyan > Pink
Press LED light button and hold for >1.5 seconds:
LED light turns off.
7-2. Liquid Cooling Radiator Installation
Installing water cooling radiator on the side:
a. Unscrew to remove the drives plate (Figure 7a).
b. Secure the radiator with screws (Figure 7b).
7a
7b

10
PRISM S / PRISM S-LITE
Gaming Case
d. Secure the radiator with screws and put the dust lter back (Figure 7d).
Installing water cooling radiator on the bottom:
c. Remove the bottom dust lter (Figure 7c).
7c
7d

11
Gaming Case PRISM S / PRISM S-LITE
7-3. GPU Card Holder
PRISM S/S-LITE provides GPU card holder to prevent your GPU from bend (gure 7e/7f):
7e
7e
7f

12
PRISM S / PRISM S-LITE
Gaming Case
Specifications Table
Model
Model Name PRISM S / PRISM S-LITE
Specifications
Type ATX Mid Tower
Color White
Case Material Steel / Tempered Glass
With Power Supply No
Power Supply Mounted Top
Motherboard Compatibility E-ATX, ATX, Micro ATX
With Side Panel Window Yes / Tempered Glass Side Panel
Expansion
External 5.25" Drive Bays 0
Internal 3.5" Drive Bays 3 (0)
Internal 2.5" Drive Bays 2 (5)
Expansion Slots 7
Front Ports
Front Ports
2 x USB 3.0
HD Audio In/Out
LED Light Control/ Reset
Cooling System
120 mm Fans
3 x Bottom
2 x Side
1 x Rear
Physical Specifications
Dimensions 8.27” x 18.7” x 18.5” (W x H x D)
Weight 17.6 lbs
Features
• Supports up to 2 x 120mm Fans / 240mm Water-Cooling Radiator on the side, 3 x 120mm Fans
/ 360mm Water-Cooler on the bottom, 1 x 120mm Fan at the rear
• Supports up to 160mm tall CPU Cooler
• Supports up to 440mm Graphics Card
• Easy-Access Bottom Dust Filter

13
Gaming Case PRISM S / PRISM S-LITE
Front I/O Cable Pinout
Front I/O
USB 3.0 CONNECTOR HD Audio CONNECTOR
Mic.
HD Audio
USB 3.0
LED Switch
or Reset
Power
PRISM S / PRISM S-LITE_A

Technical Support Information
[email protected] 1-800-575-9885
----------------------------------------------------------------------------------
Thank you for purchasing a quality Rosewill product.
Please register your product at www.rosewill.com
for complete warranty information and support for your product.
