Rosewill RSV-SATA-Cage-34 User manual

RSV-SATA-Cage-34
Internal SATA/SAS Hot-Swap Cage
3x 5.25” to 4x 3.5”/2.5”
USER’S Manual

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
Product Overview 2
Introduction 3
Specification 3
Accessory Bag Detail 3
Installation Guide 4
Hard Drive Tray Assembly / Disassembly 4
Hard Drive Installation 4
Installing a 3.5” HDD 4
Installing a 2.5” HDD 5
Hot Swap Cage Cable Installation 5
Hot Swap Cage Installation – Case 6
Hot Swap Cage Installation – Server (RSV -L4000 as example) 7
Contents

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
Product Overview
2

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
Introduction
Specification
Accessory Bag Detail
RSV-SATA-Cage-34 is a Hot Swap HDD Cage which converts space of 3x 5.25”
CD-rom / DVD-rom to 4x 3.5” or 2.5” SATAI, SATAII, SATAIII, or SAS HDD tray.
This cage allows you make better usage of your Server or Case spaces.
To use the Hot-Swap feature, Please set motherboard BIOS to AHCI and
format the HDD using AHCI.
Enclosure Type
Color
Case Material
120mm Fans
Hot-Swap 3.5"/2.5” Drive Bays
Control & Indicator
Dimensions(L x W x H)
Weight
Package Contents
Modular HDD Rack
Black
Steel, ABS
Rear 120 mm Fan included
4x (SATA I, II, III, & SAS supported)
4 x LED (HDD)
5.87" x 5.02" x 8.27" in (149 x 127.5 x 210 mm)
42.33 oz (1.2 kg)
1x RSV-SATA-Cage-34 Internal SATA/SAS Hot-Swap Cage
4x SATA Cables
1x Accessory Bag
Cooling System
Expansion
Physical Specification
Round head with cap screw x8
Socket head cap screw x16
Clinch screw x16
ITEMPIC
3

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
Installation Guide
• Hard Drive Tray Assembly / Disassembly
• Hard Drive Installation
Installing a 3.5” HDD
1.
Each HDD Tray has a press
button for releasing the
hinge. To remove the HDD
Tray; first press the button.
1.
To install a 3.5” HDD, please
make sure that the 3.5” HDD
is align with the screw holes
on the side of the tray. Then
you can fasten all the screws
onto the HDD. (Please make
sure that the connector of
the HDD is facing outward)
4

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
HDD 1
HDD 2
HDD 3
HDD 4
HDD power 12V
Fan power 12V
Fan 12CM
Installing a 2.5” HDD
1.
To install a 2.5” HDD, please
make sure that the 2.5” HDD
is align with the screw holes
on the tray. Then you can
fasten all the screws onto the
HDD. (Please make sure that
the connector of the HDD is
facing outward)
• Hot Swap Cage Cable Installation
5

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
Hot Swap Cage Installation – Case
1.
Remove three 5.25” bay
covers from the case.
2.
Insert the Cage into the slot.
6

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
3.
Secure the Cage with
Screws
1.
Remove the screws from
each side of the Chassis.
(two on each side)
2.
Once the screws removed,
push the top cover to
remove from the chassis.
Hot Swap Cage Installation – Server (RSV-L4000 as example)
7

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
3.
To remove the cage; first
press the two round shape
button using your thumbs,
then use your index finger to
push the 3.5” module to
remove it.
4.
Pull the module out from the
front.
5.
Take down the top and
bottom Cage rails.
8

Internal SATA/SAS Hot-Swap Cage RSV-SATA-Cage-34 User Manual
6.
Place the four rails onto the
SATA/SAS Hot-Swap Cage
7.
Slide the Cage into the
Server Chassis to complete
the installation process.
Thank you for purchasing a quality Rosewill Product.
Please register your product at: www.rosewill.com for complete warranty information and future
support for your product.
Support: [email protected]
Call Center: [phone]
Web: http://www.rosewill.com
9
