rosseto EZ-PRO 1B User manual

Assembly Instructions for EZ-PRO H1B / H2B / H3B
1. Carefully remove all parts from packaging:
• 1 Stand
• 1, 2 or 3 PRO H Containers
I. PRO H Lid (1)
II. 6WR PRO Silicon Paddle Wheel (2)
III. Regular Nozzle (3)
IV. Container (4)
V. Name Tag (5)
VI. PRO Handle & Pin (6)
VII. Mini 1.5mm Screw for Handle (7)
VIII. PRO Fresh Lid (8)
2. Remove all PRO H Containers (B) from individual
packaging and foam protection
3. Remove all PRO H Lids (1) from cardboard insert
before discarding container packaging
4. Insert back of container into PRO Stand (A), making
sure it locks into place
Tip: insert bottom rectangle into frame first,
and snap top rectangle into frame for easiest
and most secure assembly
5. Repeat Step 4 for the remaining containers
6. Fill containers with desired dry product
7. Place all lids on each corresponding container
8. Dispense as you please!
9. Fasten PRO Fresh Lid (8) onto Nozzle when unit is
not in use to maximize the freshness of your dry
goods
(1)
(2)
(3)
(4)
(8)
(6)
(7)
(5)
Assembly Instructions for EZ-PRO H1S/H2S/H3S
1. Carefully remove all parts from packaging:
• 1 Stand
• 1, 2 or 3 PRO S Containers
I. PRO S Lid (1)
II. 6WR PRO Silicon Paddle Wheel (2)
III. Regular Nozzle (3)
IV. Container (4)
V. Name Tag (5)
VI. Dispenser Handle & Pin (6)
VII. Mini 1.5mm Screw for Handle (7)
VIII. PRO Fresh Lid (8)
2. Remove all PRO S Containers (B) from individual
packaging and foam protection
3. Remove all PRO S Lids (1) from cardboard
insert before discarding container packaging
4. Insert back of container into Dispenser Stand (A),
making sure it locks into place
Tip: insert bottom rectangle into frame first,
and snap top rectangle into frame for easiest
and most secure assembly
5. Repeat Step 4 for the remaining containers
6. Fill containers with desired dry product
7. Place all lids on each corresponding container
8. Dispense as you please!
9. Fasten Dispenser Fresh Lid (8) onto Nozzle when
unit is not in use to maximize the freshness of
your dry goods
A
B
SERVING SOLUTIONS

Dispenser Container Assembly
Dispenser Container Disassembly
1) Carefully remove PRO S Container (B) from unit
2) Remove Dispenser Lid (1) from top of Containe
plus any remaining product
3) Gently pull on dispenser Handle & Pin (6) to
remove from unit, loosen Name Tag (5), and
leave 6WR Dispenser Silicon Paddle
Wheel (2) free-standing inside Container
4) Reach into container and remove Name Tag
and 6WR dispenser Silicon Paddle Wheel
from container
5) Again reach into container and remove Regular
Nozzle (3) from the inside of Container
1) Place Regular Nozzle (3) into bottom of PRO S
Container (4), narrow part first so it catches on
bottom of Container and clicks into place
2) Place 6WR Dispenser Silicon Paddle Wheel (2) into
container, making sure the holes of the paddle
wheel align with holes on front of container
3) If desired, place Name Tag (5) on front side of
container aligning with hole on front of Container
4) Insert Dispenser Handle & Pin (8) through hole
on Name Tag (5) and front of Container, through
the Paddle Wheel (2), and secure pin in back o
Container.
Tip: make sure pin goes all the way through
hole on back side of Container
5) Carefully fasten back of Container onto
dispenser stand (A), making sure it locks into
place and container is secure
6) Fill Container with desired dry product and place
PRO S Lid (1) on Container
CLEANING INSTRUCTIONS
1. Gently disassemble all parts of unit as indicated below
2. Wash all parts in warm
soapy water (never use
abrasive sponge or cloth)
3. Reassemble unit only after
all parts are completely dry
(see assembly instructions >>)
Please contact our customer support at [phone] and we’ll be
happy to assist with any assembly questions, comments or concerns.
ROSSETO® 8707 Skokie Blvd. Suite 205 Skokie, IL 60077
NEED ASSISTANCE?
1. Gently disassemble all parts of unit as indicated below
CLEANING INSTRUCTIONS
PRO Container Disassembly
2. Wash all parts in warm
soapy water (never use
abrasive sponge or cloth)
3. Reassemble unit only after
all parts are completely dry
( see assembly instructions >> )
PRO Container Assembly
1) Place Nozzle (3) into bottom of PRO Container (4),
narrow part first so it catches on bottom of
Container and clicks into place
2) Place 6WR PRO Silicon Paddle Wheel (2) into
Container, making sure the holes of the paddle
wheel align with the container’s holes
3) Insert Plastic Pin (8) through back of Container,
through the Paddle Wheel, until it securely fits
onto the back of the Container, with the Plastic
Pin coming out on the front side of the Container
(make sure back of Plastic Pin fits properly onto
back of Container)
4) If desired, place Name Tag (5) on front side of
Container through the Plastic Pin until it fits
snuggly to front of Container
5) Next, Insert PRO Handle (6) into Plastic Pin so the
holes from the Handle and Plastic Pin are aligned
6) Tighten mini 1.5 mm screw for handle (7) with
1.55 mm Allen Wrench (D) until Handle is secure,
making sure screw goes into Hinge as well*
7) Fill Container with desired dry product and place
PRO Lid (1) on Container
8) Carefully insert back of Container onto PRO Stand
(A), making sure it locks into place and container is
secure
1) Carefully remove PRO Container (4) from PRO
Stand (A)
2) Remove PRO Lid (1) from top of Container
3) Loosen mini 1.5mm screw for handle (7) found
on side of PRO Handle (6) until handle is free
utilizing 1.5mm Allen Wrench (D) (Do Not
Remove Screw)*
4) Gently remove PRO Handle from the Plastic Pin
(8) along with Name Tag (5) from front of
Container
5) Gently push Plastic Pin from front of Container
with thumb until there is enough space on the
back side to pull Plastic Pin out
6) Remove Plastic Pin from the back of the
Container, leaving 6WR PRO Silicon Paddle
Wheel (2) free-standing inside Container
7) Reach into Container and remove Paddle Wheel
by gently pulling upwards
8) Again reach into Container and remove Nozzle
(3) from the inside of Container
* IMPORTANT NOTE, PLEASE READ:
Make sure to use long side of Allen wrench to tighten screw. When tightening screw, turn handle so screw hole is facing the bottom
of container towards nozzle for easy access.
ROSSETO®3600 W. Pratt Avenue. Lincolnwood, IL 60712

TOPPING KIT
EZP001 -
12 wing paddle wheel ≈ 1 tbs. per servings (1)
EZH002 -
Chrome handle (2)
EZH005 -
S - Shaped handle
* Applicable to EZServ: 01/04 Jumbo models
EZL003 - Metal Lid (1)
EZC003 - 3.5 gal Jumbo Container (2) or
EZC004 - 4.0 gal Jumbo Container
EZP003 - 6 wing Paddle Wheel (3)
EZH003 - Metal Handle (4)
(3)
(1)
(2)
(4)
JUMBO
EZL001 - Plastic Lid (1)
EZC001 - 0.9 gal Container (2)
EZP003 - 6 Wing Paddle Wheel (3)
EZH003 - Metal Handle (4)
*Applicable to EZServ:
301/302/303/304/307 models
(1)
(2)
(4)
(3)
ROUND
(1)
(2)
(4)
(5)
(3)
* Applicable to EZServ:
100M/200M/1800/3600/5400/7200 models
EZL004 - Black Lid (1) or
EZL005 - White Lid
EZH002 - Chrome Handle (2) or
EZH001 - White Handle
EZP002 - 6 wing Paddle Wheel (3)
EZC005 - 2.2 gal Container (4)
EZL008 - Black Fresh Lid (5) or
EZL007 - White Fresh Lid
DIVIDED
EZL002 - Plastic Lid (1)
EZC002 - 1.3 gal Container (2)
EZP003 - 6 Wing Paddle Wheel (3)
EZH003 - Metal Handle (4)
* Applicable to EZServ:
02/03/05 & H30/50 models
(1)
(2)
(3)
(4)
TALL
EZL006 - PRO Lid, Stainless Steel (1)
EZP004 - Pro 6 wing Paddle Wheel (2)
EZM005 - Regular Nozzle(3)
EZC008 - Container (4)
EZM006 - Name Tag (5)
EZH004 - Metal Handle & Pin (6 & 7)
EZM019 - 1.5mm tool (8)
EZM003 - Clicking Mechanism (9)
EZP005 - Pro 12 wing Paddle Wheel (10)
EZM004 - Narrow Nozzle (11)
EZL009 - Plastic lid (12)
EZM025 - Pin only (13)
PRO6-SM -Pro 1 Tbs. wheel (14)
EZM027 - Stand for container - SS
PRO
(6)
(1)
(2)
(4)
(5)
(7)
(13)
(8)
(3)
(9)
(10)
(11)
(12)
(14)
Dispensers
