Assembly Instructions for EZ-PRO H1B / H2B / H3B
1. Carefully remove all parts from packaging:
• 1 Stand
• 1, 2 or 3 PRO H Containers
I. PRO H Lid (1)
II. 6WR PRO Silicon Paddle Wheel (2)
III. Regular Nozzle (3)
IV. Container (4)
V. Name Tag (5)
VI. PRO Handle & Pin (6)
VII. Mini 1.5mm Screw for Handle (7)
VIII. PRO Fresh Lid (8)
2. Remove all PRO H Containers (B) from individual
packaging and foam protection
3. Remove all PRO H Lids (1) from cardboard insert
before discarding container packaging
4. Insert back of container into PRO Stand (A), making
sure it locks into place
Tip: insert bottom rectangle into frame first,
and snap top rectangle into frame for easiest
and most secure assembly
5. Repeat Step 4 for the remaining containers
6. Fill containers with desired dry product
7. Place all lids on each corresponding container
8. Dispense as you please!
9. Fasten PRO Fresh Lid (8) onto Nozzle when unit is
not in use to maximize the freshness of your dry
goods
(1)
(2)
(3)
(4)
(8)
(6)
(7)
(5)

Please contact our customer support at [phone] and we’ll be
happy to assist with any assembly questions, comments or concerns.
ROSSETO® Skokie, IL 60077
NEED ASSISTANCE?
1. Gently disassemble all parts of unit as indicated below
CLEANING INSTRUCTIONS
PRO Container Disassembly
2. Wash all parts in warm
soapy water (never use
abrasive sponge or cloth)
3. Reassemble unit only after
all parts are completely dry
( see assembly instructions >> )
PRO Container Assembly
1) Place Regular Nozzle (3) into bottom of PRO
H Container (4), narrow part first so it catches on
bottom of Container and clicks into place
2) Place 6WR PRO Silicon Paddle Wheel (2) into
Container, making sure the holes of the paddle
wheel align with holes on front of container
3) If desired, place Name Tag (5) on front side of
Container aligning with hole on front of Container
4) Insert PRO Handle & Pin (8) through hole on Name
Tag (5) and front of Container, through the Paddle
Wheel (2), and secure pin in back of Container.
Tip: make sure pin goes all the way through
hole on back side of Container
5) Carefully fasten back of Container onto PRO Stand
(A), making sure it locks into place and container is
secure
6) Fill Container with desired dry product and place
PRO H Lid (1) on Container
1) Carefully remove PRO H Container (B) from unit
2) Remove PRO Lid (1) from top of Container plus
any remaining product
3) Gently pull on PRO Handle & Pin (6) to remove
from unit, loosen Name Tag (5), and leave 6WR
PRO Silicon Paddle Wheel (2) free-standing
inside Container
4) Reach into container and remove Name Tag and
6WR PRO Silicon Paddle Wheel from container
5) Again reach into Container and remove Regular
Nozzle (3) from the inside of Container
ROSSETO®3600 W. Pratt Avenue. Lincolnwood, IL 60712

TOPPING KIT
EZP001 -
12 wing paddle wheel ≈ 1 tbs. per servings (1)
EZH002 -
Chrome handle (2)
EZH005 -
S - Shaped handle
* Applicable to EZServ: 01/04 Jumbo models
EZL003 - Metal Lid (1)
EZC003 - 3.5 gal Jumbo Container (2) or
EZC004 - 4.0 gal Jumbo Container
EZP003 - 6 wing Paddle Wheel (3)
EZH003 - Metal Handle (4)
(3)
(1)
(2)
(4)
JUMBO
EZL001 - Plastic Lid (1)
EZC001 - 0.9 gal Container (2)
EZP003 - 6 Wing Paddle Wheel (3)
EZH003 - Metal Handle (4)
*Applicable to EZServ:
301/302/303/304/307 models
(1)
(2)
(4)
(3)
ROUND
(1)
(2)
(4)
(5)
(3)
* Applicable to EZServ:
100M/200M/1800/3600/5400/7200 models
EZL004 - Black Lid (1) or
EZL005 - White Lid
EZH002 - Chrome Handle (2) or
EZH001 - White Handle
EZP002 - 6 wing Paddle Wheel (3)
EZC005 - 2.2 gal Container (4)
EZL008 - Black Fresh Lid (5) or
EZL007 - White Fresh Lid
DIVIDED
EZL002 - Plastic Lid (1)
EZC002 - 1.3 gal Container (2)
EZP003 - 6 Wing Paddle Wheel (3)
EZH003 - Metal Handle (4)
* Applicable to EZServ:
02/03/05 & H30/50 models
(1)
(2)
(3)
(4)
TALL
EZL006 - PRO Lid, Stainless Steel (1)
EZP004 - Pro 6 wing Paddle Wheel (2)
EZM005 - Regular Nozzle(3)
EZC008 - Container (4)
EZM006 - Name Tag (5)
EZH004 - Metal Handle & Pin (6 & 7)
EZM019 - 1.5mm tool (8)
EZM003 - Clicking Mechanism (9)
EZP005 - Pro 12 wing Paddle Wheel (10)
EZM004 - Narrow Nozzle (11)
EZL009 - Plastic lid (12)
EZM025 - Pin only (13)
PRO6-SM -Pro 1 Tbs. wheel (14)
EZM027 - Stand for container - SS
PRO
(6)
(1)
(2)
(4)
(5)
(7)
(13)
(8)
(3)
(9)
(10)
(11)
(12)
(14)
Dispensers
