Rosslare AYC-Q54B Assembly instructions

AYC-Qx4 Series
Vandal Resistant Convertible
Reader/Controllers
Installation and Programming Manual
Models:
AYC-Q54B
AYC-Q64B
AYC-Q54B
AYC-Q64B

Copyright © 2017 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to REL, RSP
Inc. and/or their related companies and/or subsidiaries (hereafter: ”ROSSLARE”).
Only ROSSLARE and its customers have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the express written
permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or
other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN
THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS
AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND
TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION
MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third
party any license to these patents, trademarks, copyrights or other intellectual
property rights, except as expressly provided in any written agreement of
ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time,
without being obliged to announce such revisions or changes beforehand or
after the fact.

Table of Contents
AYC-Qx4 Family Installation and Programming Manual iii
Table of Contents
1. Introduction ................................................................9
1.1 Reader/Controller Types........................................................... 9
1.2 Box Content ......................................................................... 10
1.3 Ancillary Equipment .............................................................. 10
2. Technical Specifications............................................11
3. Installation ................................................................13
3.1 Mounting ............................................................................. 13
3.2 Wiring Instructions ................................................................ 14
3.2.1 Wiring the Unit as a Reader ..........................................................14
3.2.2 Wiring the Unit as a Controller .....................................................15
4. Reader Operation......................................................18
4.1 Standby Mode ...................................................................... 18
4.2 Programming as a Reader...................................................... 18
4.2.1 Entering Programming Mode........................................................20
4.2.2 Exiting Programming Mode ..........................................................20
4.2.3 Selecting Keypad Transmission Format .........................................21
4.2.4 Selecting Proximity Card Transmission Format ..............................26
4.2.5 Changing the Programming Code ................................................28
4.2.6 Changing the Facility Code...........................................................29
4.2.7 Setting the Backlight Behavior ......................................................29
4.2.8 Return to Factory Default Settings ................................................30
4.2.9 Replacing a Lost Programming Code ............................................31
5. Controller Operation.................................................32
5.1 Normal, Secure, and Master Users.......................................... 32

Table of Contents
iv AYC-Qx4 Family Installation and Programming Manual
5.2 Modes of Operation.............................................................. 33
5.2.1 Normal Mode ...............................................................................33
5.2.2 Bypass Mode ................................................................................33
5.2.3 Secure Mode ................................................................................34
5.2.4 Changing the Modes of Operation ...............................................34
5.3 Auxiliary Input and Output..................................................... 35
5.4 Door Alarms ......................................................................... 35
5.5 Internal Case and Back Tamper.............................................. 36
5.6 Lockout Feature (Keypad/Card Tamper).................................. 36
5.7 REX Function ........................................................................ 36
5.8 Secured Intelligent Power Supply ........................................... 37
5.9 Programming as a Controller ................................................. 37
5.9.1 Entering Programming Mode........................................................38
5.9.2 Exiting Programming Mode ..........................................................39
5.9.3 Changing Lock Strike Code ..........................................................39
5.9.4 Changing Auxiliary Code ..............................................................40
5.9.5 Changing the Programming Code ................................................41
5.9.6 Changing the Normal/Secure Code ..............................................41
5.9.7 Changing the Normal/Bypass Code and Door Chime Settings ......42
5.9.8 Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike
Release Time.................................................................................43
5.9.9 Defining the Auxiliary Input and Output .......................................44
5.9.10 Setting the Lockout Feature..........................................................49
5.9.11 Setting the Backlight Behavior ......................................................50
5.9.12 Enrolling Primary and Secondary Codes ........................................51
5.9.13 Deleting Primary and Secondary Codes.........................................55
5.9.14 Relay Codes Assignment...............................................................57
5.9.15 Relay Code Assignment using Standard Method ..........................57

Table of Contents
AYC-Qx4 Family Installation and Programming Manual v
5.9.16 Relay Code Assignment using Search Method ..............................58
5.9.17 PIN Code Length/Factory Default Settings.....................................59
5.9.18 Replacing a Lost Programming Code ............................................60
5.9.19 Exiting Secure Mode if Normal/Secure Code was Lost...................60
A. Declaration of Conformity........................................61
B. Limited Warranty ......................................................62

List of Figures
vi AYC-Qx4 Family Installation and Programming Manual
List of Figures
Figure 1: Drilling Mounting Holes ....................................................................13
Figure 2: Controller Application Wiring Diagram .............................................16
Figure 3: Controller Wiring – Using the Internal Power ....................................17
Figure 4: Controller Wiring – Using the External Power ...................................17

List of Tables
AYC-Qx4 Family Installation and Programming Manual vii
List of Tables
Table 1: Wiring the Reader to the Controller ...................................................14
Table 2: Wiring the Unit as a Controller...........................................................15
Table 3: Reader Programming Menus..............................................................19
Table 4: Controller Programming Menu ..........................................................37
Table 5: Quick Reference Guide for Auxiliary Mode Setting.............................44

Introduction
8 AYC-Qx4 Family Installation and Programming Manual
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty and
liability statement provided in an appendix at the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all
functions described in this manual may be available in the specific system
and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
All data contained herein subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital or
injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or graphic
of the PCB(s) are intended for clearer illustration and understanding of the
product and may differ from the actual PCB(s).

Introduction
AYC-Qx4 Family Installation and Programming Manual 9
1. Introduction
The AYC-Qx4 series are vandal-resistant, waterproof, standalone,
convertible integrated readers and controllers. These units
automatically determine whether to function as a reader or as a
controller. If the unit is connected to a standard access control unit,
then it functions as a reader. If the unit is connected to a Rosslare
secured intelligent power supply such as the PS-A25T, PS-C25T or PS-
C25TU, it functions as a secured controller.
All of the units are water resistant and suitable for indoor or outdoor
mounting. As a controller, the units accept up to 500 users, and allow
entry via a personal identification number (PIN) and/or by presenting a
proximity card. The PIN code length for the controller has several
options. The PIN code length can be a set number of 4, 5, or 6 digits
or it can be a 4-8 digits option.
For information on how the unit functions as a reader, see Chapter 4.
For information on how the unit functions as a controller, see Chapter
5.
1.1 Reader/Controller Types
The different types of units described in this manual are:
Backlight Keypad Type PIN Proximity
AYC-Q54 Standard 
AYC-Q64 Standard 

Introduction
10 AYC-Qx4 Family Installation and Programming Manual
1.2 Box Content
Before beginning, verify that all of the following is in the box. If
anything is missing, please report the discrepancy to your nearest
Rosslare office.
One AYC-Qx4 unit
Installation kit
Installation and operating instructions
1.3 Ancillary Equipment
The following equipment is required to complete your installation:
When functioning as a reader:
Compatible host controller (not supplied)– UL listed access
control unit, such as model AC-215U
When functioning as a controller:
Secured intelligent power supply (such as the PS-A25T, PS-C25T
or PS-C25TU)
The controller connects to the following:
Electric lock strike mechanism or a magnetic lock device,
which implements fail safe (power to lock) or fail secure
(power to open) functions.
Request-to-Exit (REX) button – normally open type
Switch is closed when pressed.
Door monitor switch
Rosslare accessories can be found on www.rosslaresecurity.com.

Technical Specifications
AYC-Qx4 Family Installation and Programming Manual 11
2. Technical Specifications
Specifications AYC-Q54B AYC-Q64B
Electrical Characteristics
Power Supply Type Linear (recommended)
Operating Voltage Range 5 to 16 VDC (when used as a controller,
provided by the secured intelligent
power supply)
Input Current Standby (12 VDC) 65 mA 90 mA
Maximum Input Current (16 VDC) 110 mA 130 mA
LED Control Input Dry contact N.O.
Tamper Output Open collector, active low, 30 mA max
sink current
Cable Distance to Host Controller Up to 150 m (500 ft) using an 18 AWG
cable
Max. Proximity Card Read Range*
N/A 45 mm (1.8 in.)
Proximity Card Modulation N/A ASK at 125 KHz
Proximity Card Compatibility N/A EM cards
Card Transmit Format (Reader) N/A Wiegand 26-Bit, or
Clock & Data
Keypad Transmit Format (Reader) Programmable PIN code formats
LED Indicators Two tri-colored LEDs
Communication Data1/C1, Data0/C2 – open collector, 5
V termination
Environmental Characteristics
Operating Temperature Range -35°C to 66°C (-31°F to 151°F)
Operating Humidity Range 0 to 95% (non-condensing)
Outdoor Usage Weather-resistant, meets IP65, epoxy
potted, suitable for outdoor use

Technical Specifications
12 AYC-Qx4 Family Installation and Programming Manual
Specifications AYC-Q54B AYC-Q64B
Physical Characteristics
Size
(Height x Width x Depth)
120 x 76 x 21 mm (4.7 x 3.0 x 0.8 in.)
Weight
480 g (1.1 lb)
* Measured using a Rosslare proximity card or equivalent. Range also depends
on electrical environment and proximity to metal.

Installation
AYC-Qx4 Family Installation and Programming Manual 13
3. Installation
Installation of an RFID reader adjacent to metallic surfaces
might alter the reader’s specifications. To diminish this
interference, use a plastic spacer when mounting the reader.
3.1 Mounting
Before starting, select the location to mount the unit. This location
should be at shoulder height.
To mount the unit:
1. Peel off the back of the self-adhesive installation template and
attach the template to the required location.
2. At the bottom of the unit’s case, remove the screw.
3. Carefully remove the snap-off front cover of the unit to reveal the
screw holes.
4. Depending on the type of installation, gang box or panel mount,
drill the respective holes in the rear cover: for gang box
mounting, drill two holes marked “A”; for flat panel mount, drill
four holes marked “B” (Figure 1).
Figure 1: Drilling Mounting Holes
5. Drill a 10-mm (7/16”) hole for the cable. If the surface is metal,
place a grommet or electrical tape around the edge of the hole.
6. Insert the unit’s cable wire into the cable hole and wire the unit
as described in Section 3.2.
7. Screw the back cover to its mounting location.

Installation
14 AYC-Qx4 Family Installation and Programming Manual
8. Carefully re-attach the front cover of the unit.
9. Secure the front cover by using the supplied security Torx screw.
A Torx security screw tool is provided to tighten the security Torx
screw.
3.2 Wiring Instructions
The unit is supplied with a 6-conductor 56-cm (22-in.) pigtail with
exposed wires coated with solder.
3.2.1 Wiring the Unit as a Reader
If you connect the unit to a standard access control unit, it
automatically functions as a reader.
To connect the unit as a reader (to a controller):
1. Select the appropriate connections according to Table 1.
Table 1: Wiring the Reader to the Controller
Wire Color Function
Black/Shield Ground (-)
Red Vin (+)
Green Data 0/Data (D0)
White Data 1/Clock (D1)
Brown LED control
Purple Tamper
2. Prepare the controller cable by cutting the cable jacket back 3.2
cm (1¼”) and strip the wire 1.3 cm (½”).
3. Splice the reader’s pigtail wires to the corresponding controller
wires and cover each joint with insulating tape.
4. If the tamper output is being utilized, connect the purple wire to
the correct input on the controller.
5. Trim and cover all conductors that are not used.

Installation
AYC-Qx4 Family Installation and Programming Manual 15
•The individual wires extending from the reader are color-coded
according to the required Wiegand standard.
•When using a separate power supply for the reader, this supply and
the controller’s power supply must have a common ground. A linear
power supply is recommended.
•Attach the cable shield wire on the reader to an earth ground (best),
or to a signal ground connection at the panel or power supply end of
the cable. This configuration is best for shielding the reader cable
from external interference.
3.2.2 Wiring the Unit as a Controller
If you connect the unit to a Rosslare PS-x25x secured power supply, it
automatically functions as a controller.
To connect the unit as a controller:
1. Select the appropriate connections according to Table 2.
Table 2: Wiring the Unit as a Controller
Controller Wire Color Function Note
+ Red +DC Input Wired to the PS-x25x
- Black Ground Wired to the PS-x25x
C 1 White Communication Wired to the PS-x25x
C 2 Green Communication Wired to the PS-x25x
AUX. IN Brown Auxiliary Input Wired to input
N/A Purple Not in use N/A
Attach the cable shield wire on the unit to an earth ground (best).
You can also attach it to a signal ground connection at the panel or
power supply end of the cable. This configuration is best for
shielding the controller cable from external interference.
2. Prepare the PS-x25x secured power supply’s cable by cutting the
cable jacket back 3.2 cm (1¼”) and strip the wire 1.3 cm (½”).
3. Splice the controller pigtail wires to the corresponding PS-x25x
secured power supply’s wires and cover each joint with insulating
tape.
4. Trim and cover all conductors not used.

Installation
16 AYC-Qx4 Family Installation and Programming Manual
5. To connect the unit to the desired power supply option, refer to
the relevant wiring diagrams that follow.
Figure 2 shows the wiring for the controller application using a dual
relay secured intelligent power supply.
Figure 2: Controller Application Wiring Diagram

Installation
AYC-Qx4 Family Installation and Programming Manual 17
Figure 3 shows the auxiliary output connection using the internal
power.
Figure 3: Controller Wiring – Using the Internal Power
Figure 4 shows the auxiliary output connection using the external
power.
Figure 4: Controller Wiring – Using the External Power

Reader Operation
18 AYC-Qx4 Family Installation and Programming Manual
4. Reader Operation
Upon power-on reset, the unit searches for the presence of a secured
intelligent power supply. If a secured intelligent power supply is not
detected, it is automatically configured as a reader, as indicated by
one short beep.
The use of a proximity card is for the AYC-Q64 model only.
4.1 Standby Mode
The default mode of the reader is Standby mode. In Standby mode,
the unit is ready to receive data from a presented proximity card or an
entered PIN code.
When the reader is in Standby mode, the left LED
is red and the right LED is off.
When a proximity card is presented or a keypad
entry is being transmitted, the left LED flashes
green.
Keyboard data can be sent via one of eight keypad transmission
formats (see Section 4.2.3).
Proximity cards presented to the reader are always sent in either
Wiegand 26-Bit, Clock & Data or, Wiegand Card + PIN format (see
Section 4.2.4).
4.2 Programming as a Reader
Programming is done solely via the unit's keypad driven Programming
Menu System. During the manufacturing process, certain codes and
settings are pre-programmed. These settings are called the default
factory settings.
Green

Reader Operation
AYC-Qx4 Family Installation and Programming Manual 19
Table 3 shows the names of all the reader programming menus.
Default factory settings are marked by a "*" sign.
Table 3: Reader Programming Menus
Menu Description Default
1 Selecting Keypad Transmission Format
Single Key, 6-Bit Wiegand (Rosslare Format)
Single Key, 6-Bit Wiegand with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, Wiegand 26-Bit
1 to 5 Keys + Facility Code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data
Single Key, Wiegand 4-Bit
*
2 Selecting Card Transmission Format
Wiegand 26-Bit
Clock & Data
Wiegand Card + PIN
*
3 Changing the Programming Code 1234
4 Changing the Facility Code 0
6 Backlight Options
Off
On (Default)
Off until key press when on for 10 seconds
Dimmed until key press when on for 10 seconds
*
0 Return to Factory Default Settings

Reader Operation
20 AYC-Qx4 Family Installation and Programming Manual
4.2.1 Entering Programming Mode
To reach the Programming Menu System, the unit must first be
placed into Programming mode.
•The factory 4-digit Programming code is 1234.
•If a Programming code is not entered within 30 seconds, the unit
returns to Standby mode.
To enter Programming mode:
1. Press #four times.
The left LED turns off and the right LED turns
red.
2. Enter your 4-digit Programming code.
If the Programming code is valid, the right LED
turns green.
If the Programming code is invalid, you hear a long beep and the
reader returns to Standby mode.
4.2.2 Exiting Programming Mode
To exit Programming mode:
1. Press #to exit Programming mode at any time.
You hear a beep.
The left LED turns red and the right LED
turns off.
This indicates that the unit has returned to Standby mode.
Wrong entries may reset the reader back to Standby mode. If no
key is pressed for 30 seconds while in Programming mode, the
unit exits Programming mode and returns to Standby mode.
Red
Green
