Rosslare AC-115 User manual

AC-115
Compact Networked Single Door Controller
Installation and User Manual
December 2007

Table of Contents
AC-115 Hardware Installation and User's Guide
Page ii
Table of Contents
1. Introduction.............................................................................5
1.1 Key Features .............................................................................. 6
1.2 Technical Specifications ............................................................ 7
2. Installation...............................................................................9
2.1 Mounting the Controller .......................................................... 10
2.2 Power Wiring........................................................................... 12
2.3 Typical Lock and Option Wiring ............................................. 12
2.4 Reader Wiring.......................................................................... 13
2.5 Connecting a controller to a PC ............................................... 13
2.6 Connecting a system to a PC ................................................... 14
3. Features and Concepts .........................................................15
3.1 Code Assignment (Lock Strike & Auxiliary) .......................... 15
3.2 Modes of Operation ................................................................. 16
Normal Mode ..................................................................16
Bypass Mode ...................................................................16
Secure Mode...................................................................17
3.3 Changing the Modes of Operation ........................................... 17
Changing from Normal Mode to Secure Mode........17
Changing from Secure Mode to Normal Mode........17
Changing from Normal Mode to Bypass Mode ........18
Changing from Bypass Mode to Normal Mode ........18
3.4 Events and Event Actions ........................................................ 19
Monitor Event ..................................................................19
Door Ajar Event...............................................................19
Forced Door Event .........................................................19
Duress Event ....................................................................20
Tamper Event ..................................................................20
Lock Strike Code Event..................................................20
Auxiliary Code Event......................................................21
Release to Exit (REX) Event............................................21
Valid Employee Code Event ........................................21

Table of Contents
Page iii AC-115 Hardware Installation and User's Guide
4. Programming Instructions ................................................... 22
4.1 Programming Menu Quick Reference Guide........................... 22
4.2 Entering Programming Mode................................................... 23
4.3 Exiting Programming Mode .................................................... 23
4.4 Return to Factory Default Settings........................................... 24
4.5 Deleting all Employee Codes................................................... 25
4.6 Adding an Employee Code ...................................................... 25
4.7 Lock Strike Relay and Auxiliary Relay Code Assignment...... 26
4.8 Deleting an Employee Code .................................................... 27
4.9 Resetting all Special Codes to Factory Default Settings.......... 28
4.10 Changing the Programming Code............................................ 28
4.11 Changing the Normal / Secure Code........................................ 29
4.12 Changing the Duress Code....................................................... 30
4.13 Changing the Lock Strike Code ............................................... 31
4.14 Changing the Auxiliary Code .................................................. 32
4.15 Changing the Normal / Bypass Code ....................................... 32
4.16 Resetting all Timed Events and Output Settings to Factory
Default Settings........................................................................ 33
4.17 Setting up the Lock Strike Release Time and Output Settings 34
4.18 Setting up the Door Ajar Time................................................. 35
4.19 Setting up the Forced Door Time............................................. 35
4.20 Setting up the Siren Time ........................................................ 36
4.21 Setting up the Auxiliary Release Time and Output Settings.... 37
4.22 Resetting all Event Actions to Factory Default Settings.......... 38
4.23 Setting up the Door Ajar Event Actions .................................. 39
4.24 Setting up the Forced Door Event Actions .............................. 39
4.25 Setting up the Tamper Event Actions ...................................... 40
4.26 Setting up the Duress Event Actions........................................ 41
4.27 Setting up the Release to Exit (REX) Event Actions ............... 41
4.28 Setting up the Chime Alert Event Action ................................ 42

Table of Contents
AC-115 Hardware Installation and User's Guide
Page iv
4.29 Setting up the Real Time Clock (RTC) - Year......................... 43
4.30 Setting up the Real Time Clock (RTC) – Date ........................ 44
4.31 Setting up the Real Time Clock (RTC) - Time ........................ 44
4.32 Changing the Door Number..................................................... 45
4.33 Replacing a lost Programming Code ....................................... 45
4.34 Replacing a lost Normal / Secure Code ................................... 46
Appendix A. Replacing the Battery.....................................47
Appendix B. Limited Warranty .......................................... 49
Appendix C. Technical Support .......................................... 51

Introduction
Page 5 AC-115 Hardware Installation and User's Guide
1. Introduction
The AC-115 is an advanced single door controller, of which up
to 8 units can be connected together along with a PC to form
an 8-door, PC programmable network.
The AC-115 has been designed to be highly flexible, allowing it
to be used in multiple applications. The controller is feature
rich, and provides the user valuable control over the door(s) it
is attached to.
When using the AC-115 as a standalone controller, it can be
programmed using its own built in programming keypad or by
using the AC-115 PC Software.
When using the AC-115 in a multi-controller network, the
network of controllers can only be programmed using the AC-
115 PC software.
Note:
The AC-115 has been tested by UL as a standalone
system only. Connecting the AC-115 in a multi-
controller network application was not verified by UL.
In this manual, you will learn how to easily install and program
the AC-115 using the controller’s built-in programming keypad.
Programming the AC-115 with a PC is even easier and unlocks
features that aren’t accessible from the controller’s
programming keypad. Programming the AC-115 with a PC is
covered in the provided Software Installation and User’s Guide.
It is recommended that the Hardware Manual be read first
before the Software Manual, as key concepts are introduced
in the Hardware Manual that are not covered in the Software
Manual.
The topics in this chapter are:
•Key Features
•Technical Specifications

Introduction
AC-115 Hardware Installation and User's Guide
Page 6
1.1 Key Features
Some of the AC-115 system key features are:
•Networkable up to 8 doors (not tested by UL)
•RS485 PC Programming Interface
•Multi-language PC software
•Programmable PC software access rights
•Supports up to 2400 users
•Real-time System Monitoring (not tested by UL)
•2000 Event History
•Real-time Clock
•8 Programmable Access Time Zones
•24 Programmable Holiday Dates
•Supports two 26-Bit Wiegand compatible Readers
•Three Modes of Operation
oNormal Mode
oBypass Mode
oSecure Mode
•Lock Strike Relay Output
•Auxiliary Relay Output
•Request to Exit (REX) button
•Door Monitor
•Forced Door and Door Ajar detection
•Internal Siren
•Comes with security screw and security tool
•Two Status / Programming Interface LED’s
•Built-in Programming Keypad
•Back-up Real Time Clock Battery
•Battery Charger (not tested by UL)
•Built-in Case Tamper
•Bell, Chime, & Strobe annunciator

Introduction
Page 7 AC-115 Hardware Installation and User's Guide
•Programmable Lock Strike & Auxiliary Relay release time.
•Built-in Lock Strike suppressor diode.
•Comes with mounting template for easier installation.
•Built-in Reader Power Supply
•Built-in Lock Strike Power Supply
1.2 Technical Specifications
Electrical Characteristics
Main Unit
Operating Voltage AC Input - Class 2 transformer
model PTC1640U, 16.5Vac, 40VA
Maximum Input Current (Not including attached devices)
Standby: 65mA
Maximum: 120mA
Battery Charger (not
tested by UL)
12V DC Lead Acid Battery
Up to 7AH recommended
Outputs
Lock Strike Relay Output 5A Relay
Max Load: 1.2A
Lock Strike Power Supply 12V DC constant voltage
1.2 A current limit
Auxiliary Relay Output 1A Relay Closed to Ground
Max Load: 1A (AUX load & Lock
Strike not to exceed 1.2A)
Reader Power Supply Voltage: 11~12V DC
Max Current: 300mA (for a
combination of both In and Out
Readers)
Inputs
Release to Exit (REX) N.O. Dry Contact
Door Monitor N.C. Dry Contact

Introduction
AC-115 Hardware Installation and User's Guide
Page 8
Reader Input 26-Bit Wiegand Compatible
Indicators & Annunciators
Visual Two Tri-Colored LEDs
Audio Built in Sounder (Bell, Chime &
Siren)
Piezoelectric Buzzer
Environmental Characteristics
Operating Temperature -25°F to 145°F (-31°C to 63°C)
0-49°C for C-UL-US Listed
applications
Operating Humidity 0 to 95% (Non-Condensing)
0 to 85% (Non-Condensing) for
C-UL-US Listed applications
Mechanical Characteristics
Dimensions 5.3” (134mm) L x 3.4” (85mm) W
x 1.2” (30mm) D
(Fits US Gang Box)
Weight 0.5 lbs (220g)

Installation
Page 9 AC-115 Hardware Installation and User's Guide
2. Installation
The AC-115 has been designed for easy installation. Only a few
steps are required to install the controller.
In this chapter, you will learn how to mount the controller in
your desired location.
You will learn how to wire the controller to its power source,
which includes attaching the controller to a rechargeable
Lead Acid battery (attaching the controller to a rechargeable
Lead Acid battery was not tested by UL).
Caution:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to
the manufacturer's instructions.
Wiring diagrams are also provided for attaching the controller
to the REX button, Door Monitor switch, Auxiliary Output, and
External 26-Bit Wiegand Compatible readers.
Also covered in this chapter is how to wire the AC-115 to a PC
as a single unit and for use in a system of networked AC-115’s
(wiring for use in a network was not tested by UL).
Note:
For C-UL Listed applications, the unit shall be installed in
accordance with Part 1 of the Canadian Electrical Code.
The topics in this chapter are:
•Mounting the Controller
•Power Wiring
•Typical Lock and Option Wiring
•Reader Wiring
•Connecting a controller to a PC
•Connecting a system to a PC

Installation
AC-115 Hardware Installation and User's Guide
Page 10
2.1 Mounting the Controller
1. Before starting, select the location to mount the AC-115
controller. The controller should be installed indoors and
within the premises to be secured. It is recommended that
the controller be installed where it cannot be seen for
increased security, but still close enough to the door so that
the controller’s annunciator (Door Bell, Chime & Siren) can
be heard. When selecting a location, take into
consideration how the controller will be attached to a PC
for easier programming and system maintenance.
2. Find the mounting template label that is provided in your
AC-115 packaging, and place it at the location that you
wish to install the controller. The template is designed to
assist you through the mounting procedure, showing you
where you drill holes in the wall to pass the wiring through
and where the wall must be drilled to insert the controllers
mounting screws.
3. (Skip this step when attaching to a US Gang Box)
Drill a hole for cables as indicated on the wiring template.
Two hole sizes are shown to allow for the amount of cables
needed, depending on installation requirements such as
connecting to a PC or adding a backup battery. Drill two
screw holes for mounting the AC-115 to the wall.
4. Remove the case screw from the controller (see diagram
below to locate the case screw) and remove the front
case from the controller.
5. Mount the controller to the wall using the two screws
provided in the Installation Kit or use the screws provided
with your US Gang Box when mounting to a US Gang Box.

Installation
Page 11 AC-115 Hardware Installation and User's Guide
0
8
5
21
46
3
9
7
#
MODE DOOR
Case Screw
3 x 4 Matrix Keypad
Bell Button
Door LED
Mode LED
Figure 1: Mounting the Controller
6. Wire the controller according to the diagrams on the next
few pages.
7. Return and secure the front case using the security screw
and security tool provided in the Installation Kit.
You have now mechanically installed the controller.

Installation
AC-115 Hardware Installation and User's Guide
Page 12
2.2 Power Wiring
0
8
5
21
46
3
9
7
#
MODE DOOR
POWER SUPPLY
FROM
TRANSFORMER
16.5V AC (1.5A, 40VA)
(+)
(-)
12V DC LEAD ACID
BATTERY
UP TO 7 AH
(Not for UL
Installations)
(+)
(-)
Figure 2: Power Wiring
2.3 Typical Lock and Option Wiring
0
8
5
21
46
3
9
7
#
MODE DOOR
REX
GND
+12VDC
A
UX Out
Monitor
+ BAT
GND
+12VDC
Figure 3: Typical Lock and Option Wiring
Note:
For Fail Secure application, the listed panic hardware shall be
used to allow emergency exit from the protected area.

Installation
Page 13 AC-115 Hardware Installation and User's Guide
2.4 Reader Wiring
0
8
5
21
46
3
9
7
#
MODE DOOR
IN
READER
OUT
READER
+V
(-)
DO
D1
+V
(-)
DO
D1
+V
(-)
DO
D1
12V DC
12V DC
Max Combined
Current: 300mA
Figure 4: Reader Wiring
2.5 Connecting a controller to a PC
0
8
5
21
46
3
9
7
#
MODE DOOR
+V
(-)
L1
L2
Model No: MD-14
RS485 TO RS232 DATACONVERTER
Rosslare
To PC Serial Port
(COM Port)
MD-14
RS232 to RS485 Converter
Figure 5: Connecting a controller to a PC
* Connecting a controller to a PC was not tested by UL.

Installation
AC-115 Hardware Installation and User's Guide
Page 14
2.6 Connecting a system to a PC
1
0
8
5
21
46
3
97
#
MODE DOOR
0
8
5
21
46
3
97
#
MODE DOOR
0
8
5
21
46
3
9
7
#
MODE DOOR
0
8
5
21
46
3
9
7
#
MODE DOOR
0
8
5
21
46
3
97
#
MODE DOOR
0
8
5
21
46
3
97
#
MODE DOOR
0
8
5
21
46
3
9
7
#
MODE DOOR
0
8
5
21
46
3
9
7
#
MODE DOOR
+V
(-)
L1
L2
DOOR 1
DOOR 2
DOOR 3
DOOR 4
DOOR 5
DOOR 6
DOOR 7
DOOR 8
MD-14
RS232 to RS485 Converter
To PC Serial Port
0
87
L1
L2
* Connecting a system to a PC was not tested by UL.

Features and Concepts
Page 15 AC-115 Hardware Installation and User's Guide
3. Features and Concepts
Now that you have installed your AC-115 controller or
networked system of controllers, it is time to get familiar with its
features and concepts.
In this chapter you will learn about all the features that are
programmable without the use of the PC software. They are
the basic features of the AC-115 and can be programmed
directly from the controller’s programming keypad.
You will learn about the controller’s various modes of
operation, how to switch between the Modes of Operation,
Special Codes, Events and Event Actions.
The topics in this chapter are:
•Code Assignment (Lock Strike & Auxiliary)
•Modes of Operation
•Changing the Modes of Operation
•Events and Event Actions
3.1 Code Assignment (Lock Strike & Auxiliary)
Whenever an employee is added to an AC-115 from the
controller’s programming keypad or from a PC, by default the
employee code is set to activate the Lock Strike Output when
it is presented to a reader.
Each Employee Code can also be programmed to activate
only the Auxiliary Output, as well as both the Lock Strike and
Auxiliary Outputs at the same time.
Setting which Output(s) are activated when a code is
presented to a reader is called Code Assignment. See the
Programming Menu Quick Reference Guide on Page 22 for
more details on Code Assignment.

Features and Concepts
AC-115 Hardware Installation and User's Guide
Page 16
Mode Door
Oran
g
e
3.2 Modes of Operation
The AC-115 has three modes of operation: Normal, Bypass, and
Secure Mode. The three modes provide different levels of
security.
Normal Mode
•The Mode LED is green
In Normal Mode, both the In Reader (the reader that is
installed outside the premises) and the Out Reader (the reader
that is installed inside the premises) are functioning. The
controller’s programming keypad and the REX button are also
functioning.
When a valid code is entered at the In Reader, the controller
will first check if the employee is attempting entry during a
permitted time zone before activating the Lock Strike Output
and/or the Auxiliary Output. When a valid code is entered at
the Out Reader or the programming keypad, the Lock Strike
Output and/or the Auxiliary Output will open without checking
time zones.
If the Employee Code is Code Assigned to the Lock Strike
Output, the Lock Strike Output will activate, and remain active
until the Lock Strike Release Time has passed or the door
monitor detects that the door has been opened.
If the Employee Code is Code Assigned to the Auxiliary Output,
the Auxiliary Output will activate, and remain active until the
Auxiliary Release Time has passed or toggle if the Auxiliary
Release Time is set to zero.
Bypass Mode
In Bypass Mode, if the Lock Strike Output is set to Normally
Closed, the Lock Strike Output will constantly
be active and the Mode LED will be orange
and the Door LED will be green.
•The Mode LED is orange and the Door LED is green
If the Lock Strike Output is set to Normally Open, pressing the
REX or the bell button, entering a Lock Strike, Auxiliary, or Valid
Code can be used to activate the Lock Strike Output and/or
Mode Door
Green

Features and Concepts
Page 17 AC-115 Hardware Installation and User's Guide
the Auxiliary Output, without checking any Time Zones. The
mode LED will be orange.
•The Mode LED is orange
Secure Mode
•The Mode LED is red
In Secure Mode, the OUT Reader (the reader that is installed
inside the premises) is the only functioning reader. The IN
Reader (the reader that is installed outside the premises) will
only accept the Duress Code. The REX button functions
normally.
The controller’s programming keypad is also functioning,
allowing the entry of Employee Codes, Duress Code, Lock
Strike Code, and Auxiliary Code.
While in Secure Mode, the controller cannot be programmed
from the controller’s programming keypad. The controller can
only be programmed using the PC interface.
3.3 Changing the Modes of Operation
Changing from Normal Mode to Secure Mode
1. The controller is in Normal Mode
•The Mode LED is green
2. Present your Normal / Secure Code to one of the external
readers, or enter your Normal / Secure PIN Code at the
controllers programming keypad.
If your Normal / Secure PIN Code is less than 6-digits long,
do not forget to press the “#” key to confirm your entry
after entering your Normal / Secure PIN Code.
•Mode LED will turn red
You are now in Secure Mode
Changing from Secure Mode to Normal Mode
1. The controller is in Secure Mode
•Mode LED is red
Mode Door
Red
Mode Door
Green
Mode Door
Red
Mode Door
Red

Features and Concepts
AC-115 Hardware Installation and User's Guide
Page 18
Mode Door
Green
2. Present your Normal / Secure Code to one of the external
readers, or enter your Normal / Secure PIN Code at the
controllers programming keypad.
If your Normal / Secure PIN Code is less than 6-digits long,
do not forget to press the “#” key to confirm your entry
after entering your Normal / Secure PIN Code.
•Mode LED will turn green
You are now in Normal Mode
Changing from Normal Mode to Bypass Mode
1. The controller is in Normal Mode
•Mode LED is green
2. Present your Normal / Bypass Code to one of the external
readers, or enter your Normal / Bypass PIN Code at the
controllers programming keypad.
If your Normal / Bypass PIN Code is less than 6-digits long,
do not forget to press the “#” key to confirm your entry
after entering your Normal / Bypass PIN Code.
•Mode LED will turn orange
You are now in Bypass Mode
Changing from Bypass Mode to Normal Mode
1. The controller is in Bypass Mode
•Mode LED is orange
2. Present your Normal / Bypass Code to one of the external
readers, or enter your Normal / Bypass PIN Code at the
controllers programming keypad.
If your Normal / Bypass PIN Code is less than 6-digits long,
do not forget to press the “#” key to confirm your entry
after entering your Normal / Bypass PIN Code.
•Mode LED will turn green
You are now in Normal Mode
Mode Door
Green
Mode Door
Green
Mode Door
Oran
g
e
Mode Door
Oran
g
e

Features and Concepts
Page 19 AC-115 Hardware Installation and User's Guide
3.4 Events and Event Actions
All of the AC-115’s key features are triggered by some events.
For instance, placing a valid code at the reader at the right
time is an Event, and the Valid Code Event may trigger the
Lock Strike Output to activate an Event Action.
In this section, you will learn about the AC-115’s Events and the
Event Actions those Events cause.
Monitor Event
The Monitor Event is triggered when the Door Monitor Switch
has been activated, i.e. the door has been opened.
Possible Monitor Event Actions
Chime Alert
Door Ajar Event if door is not closed in time
Forced Door Event if valid code was not entered
Door Ajar Event
A door is considered ajar when the Door Monitor Switch has
been activated with a Valid Code being entered. If the door is
left open longer than the Ajar Delay Time, a Door Ajar Event
will occur.
Possible Ajar Door Event Actions
Siren Event (Programmable Siren Time)
Auxiliary Output Activation (Programmable Auxiliary
Release Time)
Forced Door Event
A door is considered forced open when the Door Monitor
Switch has been activated without a Valid Code being
entered. When this occurs, a Forced Door Delay Time will count
down. When the count is done, the Forced Door Event will
occur.
