Rosslare AC-Q41HB Assembly instructions

AC-Q4x Series
Anti-Vandal Standalone
Controllers
Installation and Programming Manual
Models:
AC-Q41HB
AC-Q41HP
AC-Q41SB
AC-Q42HB
AC-Q42HP
AC-Q42SB

Copyright © 2017 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to ROSSLARE
ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’
(hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to
use the information.
No part of this manual may be re-produced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the express written
permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or
other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN
THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS
AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND
TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION
MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third
party any license to these patents, trademarks, copyrights or other intellectual
property rights, except as expressly provided in any written agreement of
ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time,
without being obliged to announce such revisions or changes beforehand or
after the fact.

Table of Contents
AC-Q4x Series Installation and Programming Manual iii
Table of Contents
1. Introduction ................................................................9
1.1 Controller Types...................................................................... 9
1.2 Box Content ......................................................................... 10
1.3 Ancillary Equipment .............................................................. 10
1.4 Front Panel Description.......................................................... 11
2. Technical Specifications............................................12
3. Installation ................................................................14
3.1 Mounting ............................................................................. 14
3.2 Wiring .................................................................................. 15
3.2.1 Pre-wired Models..........................................................................16
3.2.2 Terminal Block Models..................................................................20
4. Operation ..................................................................24
4.1 Modes of Operation.............................................................. 24
4.1.1 Normal Mode ...............................................................................24
4.1.2 Secure Mode ................................................................................24
4.1.3 Bypass Mode ................................................................................24
4.2 User Levels............................................................................ 25
4.3 Switching Operational Modes ................................................ 26
4.3.1 From Normal to Secure Mode.......................................................26
4.3.2 From Secure to Normal Mode.......................................................26
4.3.3 From Normal to Bypass Mode.......................................................27
4.3.4 From Bypass to Normal Mode.......................................................27
4.4 Auxiliary Input and Output..................................................... 27
4.5 REX Button ........................................................................... 27

Table of Contents
iv AC-Q4x Series Installation and Programming Manual
4.6 Tamper Feature..................................................................... 28
4.7 Lockout Feature (Keypad/Card Tamper).................................. 28
4.8 BL-D40 External Sounder ....................................................... 29
5. Programming ............................................................30
5.1 Entering the Programming Mode........................................... 31
5.2 Exiting the Programming Mode.............................................. 32
5.3 Changing the Open Code...................................................... 32
5.4 Changing the Auxiliary Code ................................................. 33
5.5 Changing the Programming Code.......................................... 34
5.6 Changing the Normal/Secure Code ........................................ 34
5.7 Changing the Normal/Bypass Code ........................................ 35
5.8 Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike
Release Time......................................................................... 36
5.9 Setting Auxiliary Modes......................................................... 37
5.9.1 Auxiliary Mode 0 ..........................................................................39
5.9.2 Auxiliary Mode 1 ..........................................................................39
5.9.3 Auxiliary Mode 2 ..........................................................................39
5.9.4 Auxiliary Mode 3 ..........................................................................40
5.9.5 Auxiliary Mode 4 ..........................................................................40
5.9.6 Auxiliary Mode 5 ..........................................................................40
5.9.7 Auxiliary Mode 6 ..........................................................................41
5.9.8 Auxiliary Mode 7 ..........................................................................41
5.9.9 Auxiliary Mode 8 ..........................................................................42
5.9.10 Auxiliary Mode 9 ..........................................................................42
5.10 Keypad Heater Operation ...................................................... 43
5.11 Setting the Lockout Feature................................................... 43
5.12 Setting the Backlight Behavior ............................................... 45
5.13 Enrolling Primary and Secondary Codes.................................. 45

Table of Contents
AC-Q4x Series Installation and Programming Manual v
5.13.1 Primary Codes Definition ..............................................................45
5.13.2 Secondary Codes Definition ..........................................................46
5.13.3 Enrolling Methods ........................................................................46
5.14 Deleting Primary and Secondary Codes................................... 49
5.14.1 Deleting Primary and Secondary Codes using the Standard Method
.....................................................................................................49
5.14.2 Deleting Primary and Secondary Codes using the Code Search
Method ........................................................................................50
5.15 Relay Codes Assignment........................................................ 51
5.15.1 Relay Code Assignment using Standard Method ..........................51
5.15.2 Relay Code Assignment using Search Method ..............................52
5.16 Changing PIN Code Length/Factory Default Settings ............... 54
5.17 Replacing a Programming Code............................................. 55
5.18 Replacing a Normal/Secure Code ........................................... 55
A. Limited Warranty ......................................................56

List of Figures
vi AC-Q4x Series Installation and Programming Manual
List of Figures
Figure 1: Front Panel........................................................................................11
Figure 2: Drilling Holes Identification ...............................................................14
Figure 3: Pre-Wired Connection for Lock Strike Relay & REX............................17
Figure 4: Pre-Wired Connection for Auxiliary Input & Output ..........................18
Figure 5: Pre-Wired Connection for the BL-D40 External Sounder ...................19
Figure 6: Connections to Terminal Blocks ........................................................20
Figure 7: Terminal Block Wiring of the Lock Strike Relay & REX .......................21
Figure 8: Terminal Block Wiring of the Auxiliary Input and Output ..................22
Figure 9: Terminal Block Wiring of the BL-D40 External Sounder .....................23

List of Tables
AC-Q4x Series Installation and Programming Manual vii
List of Tables
Table 1: Wire Color Guide ...............................................................................16
Table 2: Programming Menus..........................................................................30
Table 3: Quick Reference Guide for Auxiliary Mode Setting.............................38

Introduction
8 AC-Q4x Series Installation and Programming Manual
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty and
liability statement provided in an appendix at the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all
functions described in this manual may be available in the specific system
and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
All data contained herein subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital or
injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction
AC-Q4x Series Installation and Programming Manual 9
1. Introduction
The AC-Q4x series are vandal resistant standalone controllers. All the
units are water resistant and suitable for indoor or outdoor mounting.
The unit(s) accepts up to 500 users and allows entry via a personal
identification number (PIN) and/or by presenting a proximity card.
1.1 Controller Types
The different types of control units described in this manual are:
Type 41 – PIN only
Type 42 – PIN and proximity card
Type 44 – PIN and proximity card, with piezoelectric contacts
Heater Relay
Current
Backlight Keypad
Type
Proximity
AC-Q41HB 2 A Standard 
AC-Q41HP 2 A Standard 
AC-Q41SB 2 A Standard 
AC-Q42HB 2 A Standard 
AC-Q42HP 2 A Standard 
AC-Q42SB 2 A Standard 
AC-Q44 2 A Piezoelectric 

Introduction
10 AC-Q4x Series Installation and Programming Manual
1.2 Box Content
Before beginning, verify that all of the following is in the box. If
anything is missing please report the discrepancy to your nearest
Rosslare Office.
One controller unit
Installation kit
1 drilling template (label/sticker)
1 security spline key
1 security hex screw
4 mounting screws and wall plugs
1.3 Ancillary Equipment
The following ancillary equipment may be required to complete your
installation:
Electric Lock Strike Mechanism – Fail safe (power to lock) or fail
secure (power to open)
Power supply with backup battery – 12 to 24 VDC (from a
regulated power supply) or 16 to 24 VAC (from a transformer)
Request-to-Exit (REX) button (optional) – Normally open type;
switch is closed when pressed
BL-D40 external sounder (optional) – Provides siren, bell, and
chime
Magnetic contact (optional) – Installed for door monitor
capabilities

Introduction
AC-Q4x Series Installation and Programming Manual 11
1.4 Front Panel Description
Controls and indicators of all controller versions are identical
(excluding the antenna, which is unique to Q42 and Q44) (Figure 1).
Figure 1: Front Panel

Technical Specifications
12 AC-Q4x Series Installation and Programming Manual
2. Technical Specifications
AC-Q41HB AC-Q42HB AC-
Q41SB
AC-
Q41HP
AC-
Q42SB
AC-
Q42HP AC-Q44
Input
Voltage
VDC 12–24 VDC
VAC 12–24 VAC 16–24 VAC 12–24 VAC 16–24 VAC
Maximum
Input
Current
(12 VDC)
Heater
Off
130 mA 125 mA 145 mA 130 mA 145 mA 125 mA
Heater
On
610 mA 605 mA 625 mA 610 mA 625 mA N/A
Standby
Input
Current
(12 VDC)
Heater
Off
70 mA 65 mA 85 mA 70 mA 85 mA 65 mA
Heater
On
550 mA 545 mA 565 mA 550 mA 565 mA N/A
Maximum Relay
Current
2 A
REX Input Normally Open (dry contact)
Aux. Input Normally Open (dry contact)
Max. Proximity
Read Range*
N/A 65 mm (2.5
in.)
N/A 65 mm (2.5 in.)

Technical Specifications
AC-Q4x Series Installation and Programming Manual 13
AC-Q41HB AC-Q42HB AC-
Q41SB
AC-
Q41HP
AC-
Q42SB
AC-
Q42HP AC-Q44
Proximity
Modulation
N/A ASK at 125
kHz
N/A ASK at 125 kHz
Proximity Card
Compatibility
N/A 26-Bit EM
cards
N/A 26-Bit EM cards
LED Indicators Two tri-colored LED (Mode and Door)
Operating Temp.
Range
-20ºC to 60ºC (-4ºF to 140ºF)
Outdoor Usage Water resistant, meets IP54 Weather resistant, epoxy-potted, meets IP65
Size (H x W x T) 120 x 76 x 27 mm
(4.7 x 3.0 x 1.1 in.)
120 x 76 x 22 mm (4.7 x 3.0 x 0.9 in.)
Weight 440 g (1.0 lb) 521 g (1.2 lb)
* Measured using a Rosslare proximity card or equivalent. Range also depends on electrical environment and proximity
to metal.

Installation
14 AC-Q4x Series Installation and Programming Manual
3. Installation
Installation of an RFID reader adjacent to metallic surfaces
might alter the reader’s specifications. To diminish this
interference, use a plastic spacer when mounting the reader.
3.1 Mounting
Prior to starting, select the location where the controller unit is to be
mounted.
To mount the controller:
1. Peel off the back of the self-adhesive mounting label template
and place it on the required mounting location.
2. At the bottom of the unit’s case, remove the screw.
3. Carefully remove the snap-off front cover of the unit to reveal the
screw holes.
4. Depending on the type of installation, gang box or panel mount,
drill the respective holes in the rear cover (see Figure 2 for details).
For gang box mounting, drill two holes marked “A”. For flat
panel mount, drill four holes marked “B”.
Figure 2: Drilling Holes Identification

Installation
AC-Q4x Series Installation and Programming Manual 15
The central hole, marked “C” is for routing the wiring to the
controller.
5. Drill an additional 10-mm (7/16”) hole for the cable. When
installing the reader on a metallic surface, cover the inside of the
hole with a grommet or electrical tape.
6. Insert the unit’s cable wire into the cable hole and wire the unit
as described in Section 3.2.
7. Screw the back plate into the surface. Ensure the screws are the
size specified on the installation template.
The unit can also be mounted using strong epoxy glue. After
application, firmly hold the unit in place until the glue dries.
8. Carefully re-attach the front cover of the unit.
9. Secure the front cover by using the supplied security Torx screw.
A Torx security screw tool is provided to tighten the security Torx
screw.
3.2 Wiring
The controllers are provided either with a pre-wired cable or with a
screw-type terminal block:
Pre-wired Cabling Models Terminal Block Models
AC-Q41SB AC-Q41HB/HP
AC-Q42SB AC-Q42HB
AC-Q44

Installation
16 AC-Q4x Series Installation and Programming Manual
3.2.1 Pre-wired Models
These units are supplied with a 10-conductor 60-cm (24-in.) pigtail
(24-AWG cable) with exposed wires coated with solder.
To wire the controller:
1. Select the appropriate connections according to Table 1.
Table 1: Wire Color Guide
Color Description
Red V input
Black Ground
Green REX/BL
White In/Monitor
Purple Lock: Com
Gray Lock: N.O.
Brown Lock: N.C.
Blue Aux: Com
Yellow Aux: N.O.
Orange Aux: N.C.
2. Prepare the secured power supply’s cable by cutting the cable
jacket back 3.2 cm (1¼”) and strip the wire 1.3 cm (½”).
3. Splice the controller pigtail wires to the corresponding ancillary
devices and insulate each connection, including unused wires.
Refer to the wiring diagrams, depending on the desired
application:
Wiring the Lock Strike Relay & REX (Figure 3)
Wiring for Auxiliary Input & Output (Figure 4)
Wiring for the BL-D40 External Sounder (Figure 5)

Installation
AC-Q4x Series Installation and Programming Manual 17
Figure 3: Pre-Wired Connection for Lock Strike Relay & REX

Installation
18 AC-Q4x Series Installation and Programming Manual
Figure 4: Pre-Wired Connection for Auxiliary Input & Output

Installation
AC-Q4x Series Installation and Programming Manual 19
Figure 5: Pre-Wired Connection for the BL-D40 External Sounder

Installation
20 AC-Q4x Series Installation and Programming Manual
3.2.2 Terminal Block Models
These controllers come with removable terminal blocks that are
pushed on pins on the motherboard of the controllers.
To wire the terminal blocks:
1. Route the wires or cable through the large hole in the back cover
See Figure 6. Connect the terminal blocks as shown.
2. Wire the cabling according to the following diagrams.
3. Wiring the Lock Strike Relay & REX (Figure 7)
4. Wiring for Auxiliary Input & Output (Figure 8)
5. Wiring for the BL-D40 External Sounder (Figure 9)
Figure 6: Connections to Terminal Blocks
