Rosslare AC-F4 Series Assembly instructions

2013
March
AC-F/G4x Family
Outdoor Backlit
Standalone Controllers
Installation and Programming Manual
Models:
AC-F43
AC-F44
AC-G43
AC-G44
AC-F4x
AC-G4x

Copyright © 2013 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to REL, RSP
Inc. and/or their related companies and/or subsidiaries’ (hereafter:”ROSSLARE”).
Only ROSSLARE and its customers have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the express written
permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or
other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN
THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS
AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND
TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION
MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third
party any license to these patents, trademarks, copyrights or other intellectual
property rights, except as expressly provided in any written agreement of
ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time,
without being obliged to announce such revisions or changes beforehand or
after the fact.

Table of Contents
AC-F/G4x Family Installation and Programming Manual iii
Table of Contents
1. Introduction ................................................................9
1.1 Controller Types...................................................................... 9
1.2 Key Features ........................................................................... 9
1.3 Box Content ......................................................................... 10
1.4 Ancillary Equipment .............................................................. 11
1.5 Front Panel Description.......................................................... 11
2. Technical Specifications............................................13
3. Installation ................................................................14
3.1 Mounting the Controller........................................................ 14
3.2 Wiring the Controller ............................................................ 15
4. Operation ..................................................................19
4.1 Modes of Operation.............................................................. 19
4.1.1 Normal Mode (Default) .................................................................19
4.1.2 Secure Mode ................................................................................19
4.1.3 Bypass Mode ................................................................................19
4.2 User Levels............................................................................ 20
4.3 Switching Operational Modes ................................................ 21
4.3.1 From Normal to Secure Mode.......................................................21
4.3.2 From Secure to Normal Mode.......................................................21
4.3.3 From Normal to Bypass Mode.......................................................22
4.3.4 From Bypass to Normal Mode.......................................................22
4.4 Special Operational Features.................................................. 22
4.4.1 Auxiliary Input & Output...............................................................23
4.4.2 REX Button ...................................................................................23

Table of Contents
iv AC-F/G4x Family Installation and Programming Manual
4.4.3 Tamper Feature ............................................................................23
4.4.4 Lockout Feature (Keypad/Card Tamper) ........................................24
4.4.5 BL-D40 External Sounder ..............................................................24
5. Programming ............................................................25
5.1 Introduction.......................................................................... 25
5.1.1 Entering the Programming Mode..................................................27
5.1.2 Exiting the Programming Mode ....................................................27
5.2 Changing the Open Code...................................................... 28
5.3 Changing the Auxiliary Code ................................................. 29
5.4 Changing the Programming Code.......................................... 30
5.5 Changing the Normal/Secure Code ........................................ 30
5.6 Changing the Normal/Bypass Code ........................................ 31
5.7 Setting Fail Safe/Secure Operation.......................................... 32
5.8 Setting Auxiliary Modes......................................................... 33
5.8.1 General.........................................................................................33
5.8.2 Detailed Reference Guide .............................................................36
5.9 Setting the Lockout Feature................................................... 40
5.10 Backlight and LED Behavior.................................................... 41
5.11 Enrolling Codes..................................................................... 42
5.11.1 Primary Codes Definition ..............................................................42
5.11.2 Secondary Codes Definition..........................................................42
5.11.3 Primary and Secondary Codes Enrolling Methods .........................42
5.11.4 Standard Method for Codes Enrolling...........................................43
5.11.5 Search Method for Codes Enrolling ..............................................44
5.12 Deleting Codes ..................................................................... 45
5.12.1 Standard Method for Deleting Codes ...........................................45
5.12.2 Search Method for Deleting Codes...............................................46
5.13 Relay Codes Assignment........................................................ 46

Table of Contents
AC-F/G4x Family Installation and Programming Manual v
5.13.1 Relay Code Assignment using Standard Method ..........................47
5.13.2 Relay Code Assignment using Search Method ..............................48
5.14 Changing PIN Code Length/Factory Default Settings ............... 49
5.15 Replacing a Programming Code............................................. 50
5.16 Replacing a Normal/Secure Code ........................................... 50
A. Limited Warranty ......................................................51

List of Figures
vi AC-F/G4x Family Installation and Programming Manual
List of Figures
Figure 1: Front Panel of AC-F4x Series .............................................................11
Figure 2: Front Panel of AC-G4x Series ............................................................12
Figure 3: Drilling Holes Identification ...............................................................14
Figure 4: Wiring Diagram for Lock Strike Relay & REX......................................16
Figure 5: Wiring Diagram for Auxiliary Input & Output ....................................17
Figure 6: Wiring Diagram for the BL-D40 External Sounder .............................18

List of Tables
AC-F/G4x Family Installation and Programming Manual vii
List of Tables
Table 1: Wiring Color Guide ............................................................................15
Table 2: Programming Menus..........................................................................26
Table 3: Quick Reference Guide for Auxiliary Mode Setting.............................35

Notice and Disclaimer
viii AC-F/G4x Family Installation and Programming Manual
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or
subsidiaries’ (hereafter:"ROSSLARE") exclusive warranty and liability is
limited to the warranty and liability statement provided in an appendix at
the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all
functions described in this manual may be available in the specific system
and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital or
injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction
AC-F/G4x Family Installation and Programming Manual 9
1. Introduction
The AC-F4x series and AC-G4x series access control units are
waterproof standalone controllers. All the units are suitable for both
indoor and outdoor mounting. The unit(s) accepts up to 500 users
and allows entry via a personal identification number (PIN) and/or by
presenting a proximity card.
1.1 Controller Types
The different types of control units described in this manual are:
AC-F43 – PIN only
AC-F44 – PIN and proximity card
AC-G43 – Mullion-Box PIN only
AC-G44 – Mullion-Box PIN and proximity card
Relay
Current
Backlight Keypad
Type
Proximity
AC-F43 2 A

3X4 Standard

AC-F44 2 A

3X4 Standard

AC-G43 2 A

2X6 Mullion

AC-G44 2 A

2X6 Mullion

1.2 Key Features
500 users
Water resistant
Programmable Backlight and active LED control
Three user levels: normal; secure; master
Three modes of operation: normal; bypass; secure
Integrated keypad for PIN entry
Integrated proximity card reader (F44 and G44 only)

Introduction
10 AC-F/G4x Family Installation and Programming Manual
Selectable PIN code length up to 8 digits
Auxiliary input and auxiliary output
Ten auxiliary modes including: door ajar; forced door; shunt; door
monitor; normal / secure; LED control
Input for Request to Exit (REX) button
Code search feature for easy maintenance of user codes
Internal buzzer
Vandal proof screw (special tool supplied)
Two tri-color LED indicators for status / programming Interface
Built-in case and back tamper protection
Lockout feature on wrong entries (Keypad / Card Tamper)
Bell, chime, siren and strobe features available with BL-D40
Programmable siren time (with BL-D40)
Programmable lock strike release time.
Supplied with mounting template for easy installation
1.3 Box Content
Before beginning, verify that all of the following is in the box. If
anything is missing please report the discrepancy to your nearest
Rosslare Office.
One unit
One drilling template (label/sticker)
One security spline key
One security hex screw
Four mounting screws and wall plugs

Introduction
AC-F/G4x Family Installation and Programming Manual 11
1.4 Ancillary Equipment
The following ancillary equipment may be required to complete your
installation:
Electric Lock Strike Mechanism – fail safe (power to lock) or fail
secure (power to open).
Power supply with backup battery – 12 to 24 VDC (from a
regulated power supply) or 16 to 24 VAC (from a transformer).
Request to Exit (REX) Button (optional) – normally open type;
switch is closed when pressed.
BL-D40 External Sounder (optional) – provides siren, bell, and
chime.
Magnetic contact (optional) – installed for door monitor
capabilities.
Other Rosslare accessories can be found at Rosslare's Website:
www.rosslaresecurity.com
1.5 10BFront Panel Description
Figure 1 and Figure 2 show the controls and indicators of all controller
versions.
Figure 1: Front Panel of AC-F4x Series

Introduction
12 AC-F/G4x Family Installation and Programming Manual
Figure 2: Front Panel of AC-G4x Series

Technical Specifications
AC-F/G4x Family Installation and Programming Manual 13
2. Technical Specifications
AC-F43 AC-F44 AC-G43 AC-G44
Input
Voltage*
VDC 12 to 24 VDC
VAC 16 to 24 VAC
Maximum Input Current
(12 VDC)
125 mA 160 mA 125 mA 160 mA
Standby Input Current
(12 VDC)
75 mA 95 mA 75 mA 95 mA
Maximum Relay Current 2 A
REX Input Normally Open (dry contact)
Aux. Input Normally Open (dry contact)
Max. Proximity Read
Range
N/A 75 mm
(2.95 in.)
N/A 80 mm
(3.15 in.)
Proximity Modulation N/A ASK at125
KHz
N/A ASK at 125
KHz
Proximity Card
Compatibility
N/A 26 Bits EM
cards
N/A 26 Bits EM
cards
LED Indicators Two 3-colored LED (Mode and Door)
Operating Temperatures -22°F to 150°F (-30°C to 65°C)
Operating Humidity 0 to 95% (non-condensing)
Outdoor Usage Weather resistant, meets IP-65, Epoxy potted
Size (H x W x D) 120.9 x 71.1 x 29.7 mm
(4.72 x 2.80 x 1.17 in.)
135.4 x 44.2 x 28.5 mm
(5.33 x 1.74 x 1.12 in.)
Weight 0.54 lb (244 g) 0.39 lb (178 g)
* All input voltages should be limited to 1 A maximum. For VAC, the
voltage range is peak-to-peak.

Installation
14 AC-F/G4x Family Installation and Programming Manual
3. Installation
3.1 Mounting the Controller
Prior to starting, select the location where the controller unit is to be
mounted.
To install the controller:
1. Open the controller by loosening and removing the case security
screw at the bottom using the security spline key.
2. Depending on the type of installation, gang box or panel mount,
drill the respective holes in the rear cover (Figure 3).
Figure 3: Drilling Holes Identification
The central hole is for routing the wiring to the controller.
3. Use the provided drilling template to accurately locate and drill
the required holes in the wall or panel.
4. Use the hardware provided to mount the back plate on the wall
or on a gang box. Be sure to route the wiring via the large center
hole in the back plate. Check for level.
5. Wire the controller's pre-wired cable as described in Section 3.2.
6. Once wired, replace the controller back onto its back plate and
secure using the tamper-proof screw and special tool, supplied
with the hardware.

Installation
AC-F/G4x Family Installation and Programming Manual 15
3.2 Wiring the Controller
The controllers are provided with a one-meter, pre-wired, 10-
conductor 18-AWG cable.
To wire the controller:
1. Cut and strip the conductors to the necessary length.
2. Splice the controller pigtail wires to the corresponding ancillary
devices and insulate each connection, including unused wires.
3. Refer to Table 1 and to the wiring diagrams, depending on the
desired application:
Wiring the Lock Strike Relay & REX (Figure 4)
Wiring for Auxiliary Input & Output (Figure 5)
Wiring for the BL-D40 External Sounder (Figure 6)
Table 1: Wiring Color Guide
Color Description
Red V input
Black Ground
Green REX / BL
White In / Monitor
Purple Lock: Com
Gray Lock: N.O.
Brown Lock: N.C.
Blue Aux: Com
Yellow Aux: N.O.
Orange Aux: N.C.

Installation
16 AC-F/G4x Family Installation and Programming Manual
Figure 4: Wiring Diagram for Lock Strike Relay & REX

Installation
AC-F/G4x Family Installation and Programming Manual 17
Figure 5: Wiring Diagram for Auxiliary Input & Output

Installation
18 AC-F/G4x Family Installation and Programming Manual
Figure 6: Wiring Diagram for the BL-D40 External Sounder

Operation
AC-F/G4x Family Installation and Programming Manual 19
4. Operation
•In the Operation chapter, “code” refers to a PIN code or proximity
card depending on the unit you have.
•Memory slots can be a proximity card or PIN code depending on
the unit you have.
4.1 Modes of Operation
The control units have three modes of operation. These are indicated
by the color of the Mode indicator:
4.1.1 Normal Mode (Default)
The mode indicator is green.
In Normal mode, the door is locked until a valid primary code is
presented to the controller.
The controller can only be programmed in Normal mode.
4.1.2 Secure Mode
The mode indicator is red.
Only secure and master users can access the premises in Secure mode.
A secure user must enter a primary and secondary code to gain entry.
Once the primary code has been entered, the Door indicator flashes
green for 10 seconds. During this time, the secondary code must be
entered. A master user only needs to enter his code to gain entry.
4.1.3 Bypass Mode
The mode indicator is orange.
In Bypass mode, access to the premises is dependent on the Lock
Strike relays; that is, if the relay is programmed for failsafe operation
or fail-secure operation.
When the Lock Strike relay is programmed for fail secure operation,
the door is locked until the star button (*) is pressed.
When the Lock Strike relay is programmed for failsafe operation, the
door is constantly unlocked.

Operation
20 AC-F/G4x Family Installation and Programming Manual
In case of power failure, once the power is restored, the controller
returns to Normal mode for security reasons.
4.2 User Levels
The AC-F4x and AC-G4x series access control units accept up to 500
users and provide entry via the use of codes. Each user is allocated
two memory slots: Memory Slot 1 (primary code) and Memory Slot 2
(secondary code).
The way in which the two memory slots are programmed, determines
a user’s access level and also establishes access is granted for each of
the three modes of operation.
There are three user levels:
Normal User
A normal user only has a primary code and is granted access only
when the controller is in its Normal or Bypass mode.
Secure User
A secure user must have a primary and secondary code assigned,
and the two codes must not be the same. The secure user can
gain access in any mode of operation. In Normal mode, the
secure user must use the primary code to gain entry. In Secure
mode, the secure user must first enter the primary and then the
secondary code, in order to gain entry.
Master User
A master user must have identical primary and secondary codes
assigned. The codes are entered with the same proximity card or
the same PIN. The master user can gain access during any mode
of operation by entering their code only once.
